Maple Systems HMI5000P Series Manual

.Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 •www.maplesystems.com
1036-0145 Page 1 of 6 Rev. 02, 08/28/2013
C O N T R O L L E R I N F O R M A T I O N S H E E T
Maple Model(s)
PLC or Controller
HMI5000 Series
HMI5000P Series
GE Intelligent Platforms
90-30
(Ethernet)
Summary
Maple Systems’ HMI5000 Series Human/Machine Interface Terminals (Maple HMIs)
communicate with GE Intelligent Platforms Series 90-30 and the VersaMax PLC using the
SRTP protocol. When configured with EZware-5000, the Maple HMI is the master in a point-
to-point single master, multiple slave format. Please refer to the Installation and Operation
Manual (Maple p/n 1010-1007) for information on connecting multiple Maple HMIs to a single
PLC port.
Compatible PLCs
PLC Family
PLC Model
Series 90-30
374 plus
Communications Cab le
The Maple HMI can be connected directly to the PLC’s Ethernet port. If connecting directly
from the HMI to the PLC, use a crossover cable. A list of communications cables offered by
Maple Systems as well as cable assembly instructions to assist you in assembling your own
communications cable are available on our website at www.maplesystems.com.
WARNING If your communications cable is not wired exactly as shown in our cable
assembly instructions, damage to the HMI or loss of communications can result.

Phone: [phone] • Fax: [phone] • Email: [e-mail] • www.maplesystems.com
1036-0145 Page 2 of 6 Rev. 02, 08/28/2013
PLC Settings
ThePLC’s IP address must be the same as that specified in EasyBuilder’s “IP Address”
setting.
Accessible PLC Mem ory
Register M emory
The following table lists the PLC’s register memory ranges that the Maple HMIs are able to
access. Please note that your PLC’s memory range may be smaller or larger than that
supported by these HMIs. (Note: d=decimal)
PLC Register Type
Address Range
Format
PLC Register Description
I
1-32753
ddddd
Input Bit Status as an 8-bit
word. Each set of bits must
be separated by 8. For
example, use Address 1 to
show the status of bits 1-8;
use Address 9 to show the
status of bits 9-17, etc.
Q
1-32753
ddddd
Output Bit Status as an 8-bit
word. Each set of bits must
be separated by 8. For
example, use Address 1 to
show the status of bits 1-8;
use Address 9 to show the
status of bits 9-17, etc.
M
1-32753
ddddd
Discrete Internal Coil Status
as an 8-bit word. Each set
of coils must be separated
by 8. For example, use
Address 1 to show the status
of coils 1-8; use Address 9
to show the status of coils 9-
17, etc.
G
1-32753
ddddd
Genius Global Bit Status as
an 8-bit word. Each set of
bits must be separated by 8.
For example, use Address 1
to show the status of bits 1-
8; use Address 9 to show the
status of bits 9-17, etc.

.Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 •www.maplesystems.com
1036-0145 Page 3 of 6 Rev. 02, 08/28/2013
PLC Register Type
Address Range
Format
PLC Register Description
T
1-1024
dddd
Temporary Discrete Bit Status as an
8-bit word. Each set of bits must be
separated by 8. For example, use
Address 1 to show the status of bits
1-8; use Address 9 to show the
status of bits 9-17, etc
SA
1-32753
ddddd
SA Discrete Bit Status as an 8-bit
word. Each set of bits must be
separated by 8. For example, use
Address 1 to show the status of bits
1-8; use Address 9 to show the
status of bits 9-17, etc
SB
1-32753
ddddd
SB Discrete Bit Status as an 8-bit
word. Each set of bits must be
separated by 8. For example, use
Address 1 to show the status of bits
1-8; use Address 9 to show the
status of bits 9-17, etc
SC
1-32753
ddddd
SC Discrete Bit Status as an 8-bit
word. Each set of bits must be
separated by 8. For example, use
Address 1 to show the status of bits
1-8; use Address 9 to show the
status of bits 9-17, etc
S
1-32753
ddddd
S Discrete Bit Status as an 8-bit
word. Each set of bits must be
separated by 8. For example, use
Address 1 to show the status of bits
1-8; use Address 9 to show the
status of bits 9-17, etc
R
1-32768
ddddd
Data Memory Registers
AI
1-32768
ddddd
Analog Input Registers
AQ
1-32768
ddddd
Analog Output Registers
W
1-5000000
ddddddd
Word Registers

Phone: [phone] • Fax: [phone] • Email: [e-mail] • www.maplesystems.com
1036-0145 Page 4 of 6 Rev. 02, 08/28/2013
Discrete Memo ry
The following table lists the PLC’s discrete memory ranges that the Maple HMIs are able to
access. Please note that your PLC’s memory range may be smaller or larger than that
supported by these HMIs. The following discrete memory is displayable in single-bit format
on the Maple HMI. (Note: d=decimal)
PLC Register Type
Address Range
Format
PLC Register Description
I_bit
1-32768
ddddd
Input Bits
Q_bit
1-32768
ddddd
Output Bits
M_bit
1-32768
ddddd
Discrete Internal Bits
G_bit
1-32768
ddddd
Genius Global Bits
T_bit
1-32768
ddddd
Temporary Discrete Bits
SA_bit
1-32768
ddddd
SA Status Bits (Read only)
SB_bit
1-32768
ddddd
SB Status Bits (Read only)
SC_bit
1-32768
ddddd
SC Status Bits (Read only)
S_bit
1-32768
ddddd
S Status Bits (Read only)
R_bit
100-3276815
dddddbb
Data Register Bits
W_bit
100-500000015
dddddddbb
Word Register Bits
Important Memory Con sideratio ns
If your PLC’s memory range is smaller than the range supported by the Maple HMIs, it is possible
to configure the HMI to monitor a PLC memory address which does not exist. Since this can
cause unpredictable results, when you configure the HMI please ensure that all selected PLC
memory addresses are valid for your PLC model.
Do not configure the HMI to write to any PLC memory address which should only be written to
by the PLC.

.Maple Systems Inc., 808 134th Street SW, Suite 120, Everett, WA 98204-7333 •www.maplesystems.com
1036-0145 Page 5 of 6 Rev. 02, 08/28/2013
EZwareSettings
The following table lists the communications settings that must be configured in
EZware. These settings can be found in the Edit-System Parameters menu under the
Device tab. Please note:
The Recommended Settings column provides the recommended setting
based upon the default settings most commonly used in the GE
Intelligent Platforms 90-30 Series controllers.
The Options column lists EZware’s options; your PLC may not support
every option
Name
Recommended
Settings
Options
Important Notes
Name:
GE Fanuc
Series 90-30
(Ethernet)
Description label
HMI or PLC:
PLC
Location:
Local
Local, Remote
Select Local if the PLC is
directly connected to the HMI;
Remote if the PLC is
connected thru another HMI.
PLC type:
GE Fanuc
Series 90-30
(Ethernet)
PLC I/F:
Ethernet
Ethernet
PLC default station
no.:
1
1 - 99
Must match the PLC’s node
setting.
Use UDP
Unchecked
Checked or
Unchecked
Must be Unchecked.
Settings: IP Address:
XXX.XXX.XXX.
XXX
0.0.0.0 –
255.255.255.255
Must match the IP Address of the
PLC
Settings: Port No:
18245
0 –65535
Must be 18245
Settings: Timeout
(sec)
1.0
0.1 to 25.5
Adjust if longer timeout is
required
Settings: Turn around
delay (ms)
0
0-1000
Timeout period between HMI
polls.

Phone: [phone] • Fax: [phone] • Email: [e-mail] • www.maplesystems.com
1036-0145 Page 6 of 6 Rev. 02, 08/28/2013
Name
Recommended
Settings
Options
Important Notes
Send ACK delay:
0
Not Applicable
Settings: Parameter 1:
0
0 - 9999
Not Applicable
Settings: Parameter 2:
0
0 - 9999
Not Applicable
Settings: Parameter 3:
0
0 - 9999
Not Applicable
Interval of block pack
(words):
5
0-512
Max. read-command
size (words):
32
Read Only
Max. write command
size (words):
32
Read Only
