Owner’s Manual
Integrated Amplier
PM6005
You can print more than one page of a PDF onto a single sheet of paper.

2
Appendix
TipsSettingsPlaybackConnections
Front panel Rear panel IndexRemote
Contents
Accessories························································································ 4
Inserting the batteries ······································································ 5
Operating range of the remote control unit ····································· 5
Features······························································································ 6
High quality sound············································································ 6
High performance ············································································ 7
Easy operation·················································································· 7
Part names and functions
Front panel ························································································ 8
Rear panel························································································ 10
Remote control unit······································································ 11
Amplifier and Tuner operation························································ 11
CD player operation········································································ 12
Network audio player operation ····················································· 13
Connections
Speaker connection ······································································ 15
Connecting the speakers cables ···················································· 15
Speaker A/B connection································································· 16
Bi-wiring connection······································································· 17
Contents
Connecting a playback device ··················································· 18
Connecting a recording device·················································· 19
Connecting a TV/Devices with digital audio
connectors······················································································· 20
Connecting devices with remote control connectors ········ 21
Performing operations by RC on this unit without visual
contact ··························································································· 21
Remotely connecting Marantz devices ·········································· 21
Connecting the power cord························································ 22
Playback
Turning the power on····································································· 24
Selecting the speakers for audio output ········································ 25
Selecting the input source ····························································· 25
Adjusting the volume ····································································· 25
Turning o the sound temporarily ·················································· 25
Adjusting the tone·········································································· 25
Playing CDs ···················································································· 26
Recording ······················································································· 27

3
Appendix
TipsSettingsPlaybackConnections
Front panel Rear panel IndexRemote
Contents
Settings
Setting the Auto Standby mode··············································· 29
Turning Auto Standby mode o ····················································· 29
Turning Auto Standby mode on ····················································· 29
Setting the remote signal receiving function of the
remote control unit······································································· 30
Disabling the remote signal receiving function of the
remote control unit········································································· 30
Enabling the remote signal receiving function of the
remote control unit········································································· 30
Setting remote control codes···················································· 31
Setting remote control codes for the remote control ···················· 31
Setting remote control codes for this unit ····································· 32
Tips
Contents··························································································· 33
Tips································································································· 34
Troubleshooting ············································································· 35
Appendix
Playback on devices that have digital audio terminals ············· 40
Explanation terms············································································ 40
Specifications ··················································································· 41
Index ·································································································· 42

4
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Accessories
Check that the following parts are supplied with the product.
qGetting Started wCD-ROM (Owner’s Manual) eSafety Instructions rWarranty
(for USA)
(for CANADA)
tPower cord yRemote control unit
(RC001PMCD)
uR03/AAA batteries
Thank you for purchasing this Marantz product. To ensure proper operation, please read this owner’s manual carefully before using the product.
After reading this manual, be sure to keep it for future reference.

5
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Inserting the batteries
qRemove the rear lid in the direction of
the arrow and remove it.
wLoad the two batteries properly as
indicated by the qand wmarks in the
battery compartment.
R03/AAA
batteries
ePut the rear cover back on.
NOTE
• When inserting the batteries, be sure to do so in the proper direction, following the
qand wmarks in the battery compartment.
• To prevent damage or leakage of battery fluid:
• Do not use a new battery together with an old one.
• Do not use two dierent types of batteries.
• Remove the batteries from the remote control unit if it will not be in use for long
periods.
• If the battery fluid should leak, carefully wipe the fluid o the inside of the battery
compartment and insert new batteries.
Operating range of the remote control unit
Point the remote control unit at the remote sensor when operating it.
30°30°
Approx. 23 ft/7 m

6
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
High quality sound
• All-discrete current feedback amplifier
This unit uses a high-speed current feedback amplifier circuit for its
preamplifier and power amplifier so that signals from the Super Audio
CD player can be amplified with high fidelity. The high-speed current
feedback amplifier reproduces a natural sound space.
• High-power output
This unit features a slimline body, but comes with a large power supply
unit for dynamic music reproduction with high power.
• High quality audio design
This unit has a high quality audio design such as minimized signal path,
use of high sound quality parts, and large power circuit, which is possible
only in discrete audio components.
• Phono input connectors for connecting turntables
This unit is provided with a phono amplifier so that you can directly
connect a turntable and play records (Only the MM cartridge can be used
(vpage18).).
• Two-sets of speaker output terminals
In addition to using two sets of speakers (Speakers A and Speakers B),
you can connect to bi-wiring speakers with separate input terminals
for high range and low range (vpage 17). The unit adopts screw
terminals that can connect thick audio cables.
Features

7
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
High performance
• Digital Input (Coaxial, Optical)
This unit has a digital input terminal that allows input of digital audio from
external devices such as televisions.
The digital-to-analog converter is an important factor in the sound quality
of digital audio input. The Marantz Super Audio CD player uses the Cirrus
Logic CS4398, which has an excellent reputation for high precision.
• Tone control function
This unit has a tone control function for adjustment of bass (low
frequency) and treble (high frequency) sound to produce your preferred
tone (vpage25).
• LOUDNESS function
This unit is provided with a LOUDNESS function that makes it easier to
hear music played back at a low volume level (vpage26).
Easy operation
• Remote control compatible with CD players and network audio
players
The remote control provided with this unit can control Marantz CD
players and network audio players in addition to this unit (vpage12).
This unit can also switch between three remote control codes. When
using three units in the same area, you can set a dierent remote control
code for each unit to control them independently (vpage32).

8
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Front panel
r o Q0y u itw eq
Q3 Q2 Q1Q4
Part names and functions
qPower indicator
This is lit as follows according to the power status :
• Power on : Off
• Standby : Red
• Power off : Off
• When the protection circuit is activated : Red (blinking)
wPower operation button (X)
This turns the power on/o (vpage24).
eHeadphone jack (PHONES)
Used to connect headphones.
Turn o speaker output when using headphones (vpage25).
NOTE
• To prevent hearing loss, do not raise the volume level excessively when using
headphones.

9
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
r o Q0y uit
Q3 Q2 Q1Q4
rBASS control knob
This adjusts the bass (vpage25).
tSOURCE DIRECT button/indicator
This turns SOURCE DIRECT mode on/o (vpage25, 29).
yTREBLE control knob
This adjusts the treble (vpage25).
uSpeaker switching buttons/indicators (SPEAKERS A/B)
These select the speaker for audio output (vpage25).
iLOUDNESS button/indicator
This turns LOUDNESS mode on/o (vpage26).
oBALANCE control knob
This adjusts the balance of the volume output from the left and right
speakers (vpage25).
Q0 Remote control sensor
This receives signals from the remote control unit (vpage5).
Q1 VOLUME control knob
This adjusts the volume level (vpage24, 25).
Q2 MUTE indicator
This lights while the sound is muted (vpage25, 30).
Q3 Input indicator (vpage25)
Q4 Input source select knob (INPUT SELECTOR)
This selects the input source (vpage25).
NOTE
• r, yand ocan be adjusted when tis o (SOURCE DIRECT mode is o).

10
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Rear panel
uyewq oi
Q2 Q1Q3 Q0
r t
qTurntable input connectors (PHONO)
Used to connect a turntable (vpage18).
wTuner input connectors
Used to connect a tuner (vpage18).
eCD input connectors
Used to connect a CD player (vpage18).
rNetwork audio player input connectors (NETWORK)
Used to connect a network audio player (vpage18).
tRecorder input connectors (RECORDER)
Used to connect the output connector of a recorder (vpage19).
yRECORDER output connectors (RECORDER)
Used to connect the input connector of a recorder (vpage19).
uSpeaker system terminals (SPEAKERS)
Used to connect speakers (vpage15).
iFLASHER IN jack
Used when using a control BOX or other such control devices to
control this unit.
oRemote control input/output connectors (REMOTE CONTROL)
Used to connect to a Marantz audio device that is compatible with the
remote control function (vpage21).
Q0 AC inlet (AC IN)
Used to connect the power cord (vpage22).
Q1 AC outlets (AC OUTLETS)
Used to connect the AC outlets of this unit in order to supply power to
other AV equipment (vpage22).
Q2 Digital audio input connectors (COAXIAL/OPTICAL)
Used to connect a device with a TV or digital audio connector
(vpage20).
Q3 SIGNAL GND jacks
Used to connect a turntable (vpage18).

11
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Remote control unit
r
t
y
e
w
q
Amplifier and Tuner operation
qInput source select buttons
These select the input source (vpage25).
wSOURCE DIRECT button
This turns SOURCE DIRECT mode on/o (vpage26, 29).
eMUTE button ( ).
This mutes the audio (vpage25)
rAMP POWER button (X)
This turns the power on/o (standby) (vpage24).
tTUNER PRESET buttons (df)
These select the radio stations registered as preset stations in the
tuner.
yVOLUME buttons (df)
These adjust the volume level (vpage25).
%
• tis operation buttons for Marantz tuners.

12
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Q5
w
q
e
r
y
i
u
o
t
Q0
Q1
Q2
Q6
Q8
Q4
Q9
Q7
W0
W1
Q3
CD player operation
To operate Marantz CD player, press REMOTE MODE CD button to switch
the remote control to the CD operation mode.
• REMOTE MODE CD button lights for approximately two seconds.
qPOWER button (X)
wRemote mode select button
(REMOTE MODE CD)
e Reverse-skip/Forward-skip
buttons (8, 9)
rStop button (2)
tInput source select button
(INPUT)
yInformation button (INFO)
uTIME button
iCursor buttons (uio p)
oProgram button (PROG)
Q0 Number buttons (0 – 9)
Q1 DIMMER button
Q2 RANDOM button ( )
Q3 SOUND MODE button
Q4 Pause button (3)
Q5 Play button (1)
Q6 Playback mode switching
button (MODE)
Q7 ENTER button
Q8 MENU button
Q9 CLEAR button
W0 REPEAT A-B button
W1 REPEAT button ( )
%
• The amp and tuner can be operated with the amp operation buttons even when the
remote control operation mode is set to CD.

13
Appendix
TipsSettingsPlaybackConnections
Contents
Front panel Rear panel IndexRemote
Network audio player operation
To operate Marantz network audio player, press REMOTE MODE NET
button to switch the remote control to the NETWORK operation mode.
• REMOTE MODE NET button lights for approximately two seconds.
qPOWER button (X)
wRemote mode select button
(REMOTE MODE NET)
e Reverse-skip/Forward-skip
buttons (8, 9)
rStop button (2)
tInput source select button
(INPUT)
yInformation button (INFO)
uHOME button
iCursor buttons (uio p)
oFAVORITE button
Q0 Number buttons (0 – 9, +10)
%
• The amp and tuner can be operated with the amp operation buttons even when the
remote control mode is NET.
Q5
w
e
q
r
y
i
u
t
Q0
Q1
Q2
Q6
Q4
Q8
W0
W1
Q9
Q7
o
Q3
Q1 DIMMER button
Q2 RANDOM button ( )
Q3 M-DAX button
Q4 Pause button (3)
Q5 Play button (1)
Q6 Playback mode switching
button (MODE)
Q7 ENTER button
Q8 MENU button
Q9 CLEAR button
W0 SEARCH button
W1 REPEAT button ( )

Connections
14
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Speaker connection (vpage15)
Connecting a playback device (vpage18)
Connecting a recording device (vpage19)
Connecting a TV/Devices with digital audio connectors
(vpage20)
Connecting devices with remote control connectors
(vpage21)
Connecting the power cord (vpage22)
NOTE
• Do not plug in the power cord until all connections have been completed.
• Do not bundle power cords with connection cables. Doing so can result in humming
or noise.
2Cables used for connections
Provide necessary cables according to the devices you want to connect.
Speaker cable
Coaxial digital cable
Optical cable
Audio cable R
L
R
L
Remote connector
cable

15
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Speaker connection
NOTE
• Disconnect this unit’s power plug from the power outlet before connecting the
speakers.
• Connect so that the speaker cable core wires do not protrude from the speaker
terminal. The protection circuit may be activated if the core wires touch the rear
panel or if the + and – sides touch each other (vpage40 “Protection circuit”).
• Never touch the speaker terminals while the power cord is connected.
• Use speakers with impedances within the ranges shown below to suit how they
are used.
Speakers used Impedance
SPEAKERS A
(Standard connection) 4 – 16 Ω/ohms
SPEAKERS B 4 – 16 Ω/ohms
SPEAKERS A and SPEAKERS B 8 – 16 Ω/ohms
SPEAKERS A and SPEAKERS B
(for bi-wiring connections) 4 – 16 Ω/ohms
Connecting the speakers cables
Carefully check the left (L) and right (R) channels and + (red) and – (black)
polarities on the speakers being connected to the unit, and be sure to
connect the channels and polarities correctly.
1Peel o about 3/8 inch (10 mm) of
sheathing from the tip of the speaker
cable, then either twist the core wire
tightly or apply solder to it.
2Turn the speaker terminal
counterclockwise to loosen it.
3Insert the speaker cable’s core wire to all
the way into the speaker terminal.
4Turn the speaker terminal clockwise to
tighten it.

16
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Speaker A/B connection
• The same signal is output from the SPEAKERS A and SPEAKERS B terminals.
• When only one set of speakers is to be connected, use either the SPEAKERS A or SPEAKERS B terminals.
w qw q
(R)(L)
w qw q
(R)(L)
SPEAKERS A SPEAKERS B

17
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Bi-wiring connection
• When bi-wiring with bi-wireable speakers, connect the mid and high range terminals to SPEAKERS A (or SPEAKERS B), the low range terminals to
SPEAKERS B (or SPEAKERS A).
• This connection limits the eect of signal interference between the high range speakers and low range speakers, allowing you to enjoy high quality
playback.
w q
w q
HIGH
LOW
w q
w q
HIGH
LOW
Speaker (R) Speaker (L)
Remove
shorting bar
Remove
shorting bar
Remove
shorting bar
Remove
shorting bar

18
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Connecting a playback device
You can connect turntables, tuners, CD players and network audio players to this unit.
This unit is compatible with turntables equipped with a moving magnet (MM) phono cartridge. When you connect to a turntable with a low output moving
coil (MC) cartridge, use a commercially available MC head amp or a step-up transformer.
If you set this unit’s input source to “PHONO” and you accidentally increase the volume without having a turntable connected, you may hear a hum noise
from the speakers.
GND
AUDIO
OUT
L
R
AUDIO
OUT
RL
AUDIO
OUT
RL
AUDIO
OUT
RL
L
L
R
R
L
L
R
R
L
L
R
R
CD player
Tuner
Turntable
Network
audio
player
NOTE
• The ground line (SIGNAL GND) on this unit is not a safety
ground. Connect it to reduce noise when noise is excessive.
Note that depending on the turntable, connecting the ground line
may have the reverse eect of increasing noise. In this case, it is
not necessary to connect the ground line.

19
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Connecting a recording device
RL RL
AUDIO OUT AUDIO IN
L
L
R
R
L
L
R
R
Recording device
NOTE
• Never insert the short-circuiting pin plug into the recording output connectors (RECORDER). Doing so could result in damage.

20
Appendix
TipsSettingsPlayback
Contents
Front panel Rear panel IndexRemote
Connections
Connecting a TV/Devices with digital audio connectors
OUT
OPTICAL
OUT
COAXIAL
TV/
Devices with digital
audio connectors
