A/V Pre-amp with State-of-the-Art Audio & Video Playback Technologies
For the ultimate music and home theater surround sound experience, the Marantz AV8801 A/V pre-amplifier is packed with the
latest state-of-the-art audio and video technologies, including the highest resolution audio formats such as Dolby TrueHD and
DTS HD Master Audio. As well, the AV8801 features the ability to expand beyond conventional 5.1 and 7.1 channel configurations,
thanks to the inclusion of DTS Neo:X and Audyssey DSX technology, which provides up to 11.2 channel playback, with additional
front width and front height channels for the most immersive surround sound experience you’ve ever heard. The video section
features a host of video inputs, with a sophisticated video processor that provides upconversion from standard definition (SD) and
high definition (HD) video to the latest Ultra High Definition (4K) format (3840x2160 pixels) for full compatibility with next generation
Ultra High Definition (4K) displays. There are 7 HDMI inputs and 3 HDMI outputs, with dual HDMI outputs for the main zone that
outputs the same signal to two displays, such as a flat panel TV and a front projector. A third HDMI output lets you enjoy another
program in another room. Equipped with Audyssey MultEQ XT32, the AV8801 automatically configures key acoustical param-
eters and optimizes total system response. Full networking functionality includes 4 Ethernet ports along with available iOS and
Android mobile control apps.
AV8801
11.2ch AV Pre-Amplifier
Audio/Video Quality
n11.2 channel dedicated A/V pre-amplifier
n11.2 channel enhanced surround processing with
Audyssey DSX and DTS Neo:X
nCurrent feedback & HDAM pre-amplifier circuitry
with massive power supply by full shielded toroidal
transformer for superior sound
n4K video support (pass through and GUI overlay)
n4K (3840 × 2160) upscaling via HDMI
nNew smoothest diagonal edge video interpolation
nAudyssey MultEQ XT32 and Audyssey Sub EQ
HT Dual subwoofer EQ processing for optimum
room acoustic calibration
nAudyssey LFC solves the problem of low fre-
quency sounds disturbing people in adjacent rooms
nSupports 192 kHz high resolution network audio
(WAV 192 kHz/24-bit, FLAC 192 kHz/24-bit, ALAC
96 kHz/24 bit)
nGapless audio playback
Connectivity, Flexibility
& Expandability
nAirPlay: Stream music from your iPad, iPhone or
iPod touch or from your iTunes music library
nNetworking: Stream internet radio, Pandora,
SiriusXM internet radio, Spotify, as well as music
and photos over the home network
nIncludes an Ethernet hub (4 ports) for easy con-
nection to network devices on your home network
nBluetooth wireless connectivity (M-XPort) via
optional RX-101 adaptor
n11.2ch XLR balanced preoutputs
nFront HDMI port supports MHLTM
(Mobile High Definition Link) for viewing smart-
phone content on your HDTV
n2 ports (front, rear selectable) USB input direct
digital play for iPod, iPhone and USB drives
n7 (front: 1) /3 HDMI In/Out
-Pass through in standby mode
-Dual HDMI outputs allows two connected dis
play devices (e.g. TV and projector) and outputs
the same source simultaneously
-Zone4 HDMI output allows a different source to
be output to another room
nSupports HDMI (3D, ARC, Deep Color, “x.v.Color”,
Auto Lip Sync, 4K, and HDMI control function)
nAudyssey Dynamic EQ & Dynamic Volume
n3/2 (gold plated) Component In/Out
n2/2 Optical/Coaxial (gold plated) Digital In
nHeadphone output
nHD Radio (AM/FM) tuner built-in
n7 Audio inputs (incl. front input) and
an output (gold plated)
nPhono input (gold plated)
nXLR balanced audio input
Ease of Use
nImproved System Setup with menu assist
nRich overlay GUI with English, French, or Spanish
nNew LCD Learning Remote control
nMobile App control with advanced media browsing
(iOS & Android)
Additional Features
nInstaPrevue provides live picture-in-picture of
connected HDMI sources
n4 source 4 zone capability
nRS232C control (AMX/Crestron command)
nControl4 certified (IP control)
nAssignable DC trigger (+12 V, 150 mA x 2)
nAudyssey Installer Ready
Marantz Audio Advantages
nHybrid PLL jitter reducer for accurate audio clock
nM-DAX (Marantz Dynamic Audio eXpander)
n192 kHz/32-bit audio DACs for all channels
nHigh grade build quality with 3 piece top cover
nCopper plated chassis

Video Section
Standard video connectors
Input/output level and impedance: 1 Vp-p, 75 ohm
Frequency response: 5 Hz – 10 MHz 0, –3 dB
Color component video connector
Input/output level and impedance:
Y signal — 1 Vp-p, 75 ohm
PB signal — 0.7 Vp-p, 75 ohm
PR signal — 0.7 Vp-p, 75 ohm
Frequency response: 5 Hz – 60 MHz — 0, –3 dB
Tuner Section
[FM]
(Note: μV at 75 ohm , 0 dBf = 1 x 10–15 W)
Receiving Range: 87.5 MHz – 107.9 MHz
Usable Sensitivity: 1.5 μV (14.8 dBf)
S/N: MONO 78 dB (IHF–A weighted, DIRECT mode)
STEREO 68 dB (IHF–A weighted, DIRECT mode)
HD 85 dB
Total harmonic Distortion (at 1 kHz):
MONO 0.1 %
STEREO 0.2 %
HD 0.02 %
[AM]
Receiving Range:AM: 530 kHz – 1710 kHz
Usable Sensitivity: 20 μV
S/N: HD 85 dB
Total harmonic Distortion (at 1 kHz): HD 0.02 %
General
Power supply: AC 120 V, 60 Hz
Power consumption: 90 W
0.2 W (Standby mode)
0.5 W (CEC standby mode)
5.1 W (network standby mode)
Dimensions (W x H x D):
17 21/64” x 7 9/32” x 15 21/64”
440.0 x 185.0 x 389.3 mm
Weight: 30 lbs 10 oz, 13.9 kg
*Design and specifications are subject to change without notice. *“Dolby”, “Pro Logic” and the double-D symbol are trademarks of Dolby Laboratories. *DTS-HD, the Symbol, & DTS-HD and the Symbol together are registered trademarks & DTS HD Master Audio is a trademark of
DTS, Inc. *Audyssey MultEQ® XT 32, Audyssey Dynamic EQ®, Audyssey Dynamic Volume® and Audyssey DSX® are registered trademarks of Audyssey Laboratories. Audyssey LFC™ is a trademark of Audyssey Laboratories. *HDMI, the HDMI logo and High-Definition Multimedia
Interface are trademarks or registered trademarks of HDMI Licensing LLC. *MHL, the MHL Logo, and Mobile High-Definition Link are trademark or registered trademarks of MHL LLC in the United States and other countries. *Windows Media and the Windows logo are trademarks
or registered trademarks of Microsoft Corporation in the United States and/or other countries. *NSV is a registered trademark of Analog Devices, Inc. *InstaPrevue and the InstaPrevue logo are trademarks or registered trademarks of Silicon Image, Inc. in the United States and other
countries.*”x.v.Color” is a trademark of Sony Corporation. *SIRIUS, XM and all related marks and logos are trademarks of Sirius XM Radio Inc. and its subsidiaries. All rights reserved. Service not available in Alaska and Hawaii. *HD Radio™ and the HD Radio logo are proprietary
trademarks of iBiquity Digital Corp. *“Made for iPod,” “Made for iPhone,” and mean that an electronic accessory has been designed to connect specifically to iPod, or iPhone, respectively, and has been certified by the developer to meet Apple performance standards. Please note that
the use of this accessory with iPod, or iPhone, may affect wireless performance. *Apple is not responsible for the operation of this device or its compliance with safety and regulatory. *AirPlay, the AirPlay logo, iPhone, iPod, iPod classic, iPod nano, iPod shuffle, iPod touch and iTunes
are trademarks of Apple Inc., registered in the U.S. and other countries.
Specifications
20161012A
Audio Section
Analog
Input sensitivity/Input impedance
Unbalanced input: 200 mV/47 k ohm
Balanced input: 400 mV/94 k ohm
Frequency response: 10 Hz – 100 kHz — +1, –3 dB
(DIRECT mode)
S/N: 105 dB (IHF–A weighted, DIRECT mode)
Distortion: 0.005 % (20 Hz - 20 kHz) (DIRECT mode)
Rated output: Unbalanced pre-output: 1.2 V
Balanced pre-output: 2.4 V
Digital
D/A output: Rated output — 2 V (at 0 dB playback)
Total harmonic distortion — 0.008 % (1 kHz, at 0 dB)
S/N ratio — 102 dB
Dynamic range — 100 dB
Digital input: Format — Digital audio interface
Phono equalizer (PHONO input)
Input sensitivity: 2.5 mV
RIAA deviation: ±1 dB (20 Hz to 20 kHz)
S/N: 74 dB (A weighting, with 5 mV input)
Rated output: 150 mV
Distortion factor: 0.03 % (1 kHz, 3 V)
