Marantz PS5200 User manual

AV Surround Amplifier
PS5200 / PS7200
341W855010 MIT
First Issue 2002.02
Service
Manual
PS5200 /F1N, F2N
PS7200 /F1N, F2N
R
PS5200 / PS7200
Please use this service manual with referring to the user guide ( D.F.U. ) without fail.
TABLE OF CONTENTS
1. TECHNICAL SPECIFICATIONS .................................................................................. 1
2. WIRING DIAGRAM ...................................................................................................... 5
3. BLOCK DIAGRAM ........................................................................................................ 7
4. SCHEMATIC DIAGRAM ............................................................................................... 9
5. PARTS LOCATION .................................................................................................... 27
6. IC DATA ..................................................................................................................... 40
7. EXPLODED VIEW AND PARTS LIST ........................................................................ 43
8. ELECTRICAL PARTS LIST ........................................................................................ 50
Printed in Japan
PS5200
PS7200
AV SURROUND AMPLIFIER PS5200
UP
SURROUND VOLUME
DOWN
NIGHT
ATT
DISPLAY OFF
SLEEP S-DIRECT DIMMER
MUTE
A/D7CH INPUT
POWER ON/STANDBY PHONES
STANDBY
AUX INPUT
S-VIDEO VIDEO L AUDIO R
A
SLEEP
MUTE
ANALOG
DIGITAL
MLP PCM
RF AUTO LOCK CIRCLE SURROUND EX MPEG DIRECT MEMORY PRESET SW LFE
SRSCSLRTTAPTYAUTOTUNEDDSP SOUNDVIRTUAL
1 2 3 4 5 6 DIGITALDTS
THX RCLCTTPEONRDSSTEREOTAPE 2 MON
PRO LOGIC
VIDEO SET
B
DOLBY
DSS/VCR2 AUX VCR1 DVD TV CD CDR/MD TAPE TUNER
AV SURROUND AMPLIFIER PS7200
UP
SURROUND VOLUME
DOWN
DSS/VCR2 AUX VCR1 DVD TV CD CDR/MD TAPE TUNER
NIGHT
ATT
DISPLAY OFF
SLEEP S-DIRECT DIMMER
MUTE
A/D7CH INPUT
POWER ON/STNDBY PHONES
STANDBY
AUX INPUT
BSPEAKERSA
MULTI ROOM
MULTI ROOM
S-VIDEO VIDEO L AUDIO R
A
SLEEP
MUTE
ANALOG
DIGITAL
MLP PCM
RF AUTO LOCK CIRCLE SURROUND EX MPEG DIRECT MEMORY PRESET SW LFE
SRSCSLRTTAPTYAUTOTUNEDDSP SOUNDVIRTUAL
1 2 3 4 5 6 DIGITALDTS
THX RCLCTTPEONRDSSTEREOTAPE 2 MON
PRO LOGIC
VIDEO SET
B
DOLBY
Printed on 100% Recycled Paper

MARANTZ DESIGN AND SERVICE
Using superior design and selected high grade components, MARANTZ company has created the ultimate in stereo sound.
Only original MARANTZ parts can insure that your MARANTZ product will continue to perform to the specifications for which
it is famous.
Parts for your MARANTZ equipment are generally available to our National Marantz Subsidiary or Agent.
ORDERING PARTS :
Parts can be ordered either by mail or by Fax.. In both cases, the correct part number has to be specified.
The following information must be supplied to eliminate delays in processing your order :
1. Complete address
2. Complete part numbers and quantities required
3. Description of parts
4. Model number for which part is required
5. Way of shipment
6. Signature : any order form or Fax. must be signed, otherwise such part order will be considered as null and void.
SHOCK, FIRE HAZARD SERVICE TEST :
CAUTION : After servicing this appliance and prior to returning to customer, measure the resistance between either primary AC
cord connector pins ( with unit NOT connected to AC mains and its Power switch ON ), and the face or Front Panel of product and
controls and chassis bottom.
Any resistance measurement less than 1 Megohms should cause unit to be repaired or corrected before AC power is applied, and
verified before it is return to the user/customer.
Ref. UL Standard No. 1492.
In case of difficulties, do not hesitate to contact the Technical
Department at above mentioned address.
020110MIT
SUPERSCOPE TECHNOLOGIES, INC.
USA
MARANTZ AMERICA, INC
1100 MAPLEWOOD DRIVE
ITASCA, IL. 60143
USA
PHONE : 630 - 741 - 0300
FAX : 630 - 741 - 0301
BRAZIL
PHILIPS DA AMAZONIA IND. ELET. ITDA
CENTRO DE INFORMACOES AO
CEP 04698-970
SAO PAULO, SP, BRAZIL
PHONE : 0800 - 123123 (Discagem Direta Gratuita)
FAX : [phone]
JAPAN Technical
MARANTZ JAPAN, INC.
35- 1, 7- CHOME, SAGAMIONO
SAGAMIHARA - SHI, KANAGAWA
JAPAN 228-8505
PHONE : [phone]
FAX : [phone]
EUROPE / TRADING
MARANTZ EUROPE B.V.
P. O. BOX 8744, BUILDING SILVERPOINT
BEEMDSTRAAT 11, 5653 MA EINDHOVEN
THE NETHERLANDS
PHONE : +31 - 40 - 2507844
FAX : +31 - 40 - 2507860
TECHNICAL AUDIO GROUP PTY, LTD
558 DARLING STREET,
BALMAIN, NSW 2041,
AUSTRALIA
PHONE : 61 - 2 - 9810 - 5300
FAX : 61 - 2 - 9810 - 5355
CANADA
LENBROOK INDUSTRIES LIMITED
633 GRANITE COURT,
PICKERING, ONTARIO L1W 3K1
CANADA
PHONE : 905 - 831 - 6333
FAX : 905 - 831 - 6936
AUSTRALIA
QualiFi Pty Ltd,
24 LIONEL ROAD,
MT. WAVERLEY VIC 3149
AUSTRALIA
PHONE : +61 - (0)3 - 9543 - 1522
FAX : +61 - (0)3 - 9543 - 3677
NEW ZEALAND
WILDASH AUDIO SYSTEMS NZ
14 MALVERN ROAD MT ALBERT
AUCKLAND NEW ZEALAND
PHONE : +64 - 9 - 8451958
FAX : +64 - 9 - 8463554
THAILAND
MRZ STANDARD CO., LTD
746 - 754 MAHACHAI ROAD.,
WANGBURAPAPIROM, PHRANAKORN,
BANGKOK, 10200 THAILAND
PHONE : +66 - 2 - 222 9181
FAX : +66 - 2 - 224 6795
TAIWAN
PAI- YUING CO., LTD.
6 TH FL NO, 148 SUNG KIANG ROAD,
TAIPEI, 10429, TAIWAN R.O.C.
PHONE : +886 - 2 - 25221304
FAX : +886 - 2 - 25630415
MALAYSIA
WO KEE HONG ELECTRONICS SDN. BHD.
SUITE 8.1, LEVEL 8, MENARA GENESIS,
NO. 33, JALAN SULTAN ISMAIL,
50250 KUALA LUMPUR, MALAYSIA
PHONE : +60 3 - 2457677
FAX : +60 3 - 2458180
AMERICAS
MARANTZ PROFESSIONAL PRODUCTS
2640 WHITE OAK CIRCLE, SUITE A
AURORA, ILLINOIS 60504 USA
PHONE : 630 - 820 - 4800
FAX : 630 - 820 - 8103
AUSTRALIA
KOREA
MK ENTERPRISES LTD.
ROOM 604/605, ELECTRO-OFFICETEL, 16-58,
3GA, HANGANG-RO, YONGSAN-KU, SEOUL
KOREA
PHONE : +822 - 3232 - 155
FAX : +822 - 3232 - 154
SINGAPORE
WO KEE HONG DISTRIBUTION PTE LTD
130 JOO SENG ROAD
#03-02 OLIVINE BUILDING
SINGAPORE 368357
PHONE : [phone]
FAX : [phone]

1
1. TECHNICAL SPECIFICATIONS
AMPLIFIER SECTION
Maximum Power Output (6 ohms / EIAJ)
Front .................................................................................... 135W
Center .................................................................................. 135W
Surround .............................................................................. 135W
Continuous Power Output (8 ohms / 20 Hz - 20 kHz)
Front ......................................................................................90 W
Center ....................................................................................90 W
Surround ................................................................................90 W
THD Front (20 Hz - 20 kHz) .................................. 8 ohms 0.05 %
Input Sensitivity/Impedance
Linear ..............................................................340 mV/ 47 kohms
Signal to Noise Ratio
Linear ................................................................................ 105 dB
DECORDER SECTION
Applicable Signal Format ..............................................................
......................... PCM Audio (fs=32kHz, 44.1kHz, 48kHz, 96kHz),
.................................................... Dolby Digital, DTS, Mpeg2 AAC
Frequency Range
(Analog Input / Sourse Direct) ........... 8 Hz - 100 kHz (±3 dB)
(Digital Input / 96kHz PCM) ................. 8 Hz - 45 kHz (±3 dB)
VIDEO SECTION
Television Format ................................................................ NTSC
Input Level/Impedance ....................................... 1 Vp-p/ 75 ohms
Output Level/Impedance .................................... 1 Vp-p/ 75 ohms
Video Frequency Response ....................... 5 Hz to 8 MHz (-1 dB)
S/N ....................................................................................... 60 dB
GENERAL
Power Requirement ........................................ AC 100 V 50/60 Hz
Power Consumption ............................................................310 W
Dimensions (MAX)
Width ................................................................................ 440 mm
Height ............................................................................... 164 mm
Depth ................................................................................ 425 mm
Weight ............................................................................... 12.9 kg
ACCESSORIES
Remote Control Unit RC5200SR ................................................ 1
AAA-size batteries ....................................................................... 2
AMPLIFIER SECTION
Maximum Power Output (6 ohms / EIAJ)
Front .................................................................................... 160W
Center .................................................................................. 160W
Surround .............................................................................. 160W
Continuous Power Output (8 ohms / 20 Hz - 20 kHz)
Front .................................................................................... 110W
Center .................................................................................. 110W
Surround .............................................................................. 110W
THD Front (20 Hz - 20 kHz) .................................. 8 ohms 0.05 %
Input Sensitivity/Impedance
Linear ............................................................. 340 mV / 47 kohms
Signal to Noise Ratio
Linear ................................................................................ 105 dB
DECORDER SECTION
Applicable Signal Format ..............................................................
......................... PCM Audio (fs=32kHz, 44.1kHz, 48kHz, 96kHz),
.................................................... Dolby Digital, DTS, Mpeg2 AAC
Frequency Range
(Analog Input / Sourse Direct) ........... 8 Hz - 100 kHz (±3 dB)
(Digital Input / 96kHz PCM) ................. 8 Hz - 45 kHz (±3 dB)
VIDEO SECTION
Television Format ................................................................ NTSC
Input Level/Impedance ....................................... 1 Vp-p/ 75 ohms
Output Level/Impedance .................................... 1 Vp-p/ 75 ohms
Video Frequency Response ....................... 5 Hz to 8 MHz (-1 dB)
S/N....................................................................................... 60 dB
GENERAL
Power Requirement ........................................ AC 100 V 50/60 Hz
Power Consumption ............................................................350 W
Dimensions (MAX)
Width ................................................................................ 440 mm
Height ............................................................................... 164 mm
Depth ................................................................................ 425 mm
Weight ............................................................................... 14.9 kg
ACCESSORIES
Remote Control Unit RC7200SR ................................................ 1
AAA-size batteries ...................................................................... 2
PS5200 PS7200

2
The relation between the selected surround mode and the input signal
The surround mode is selected with the surround mode selector knob of the PS5200 / PS7200 or the remote control unit.
However, the sound from thespeakers depend upon the relationship between the selected surround mode and the input
signal. They are as follows;
PS7200
L/R SL/SR CSCSW
Auto Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL, AUTO >AUTO> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O --- O DIGITAL DOLBY, DIGITAL, AUTO >AUTO> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC, AUTO >AUTO> L,R, SC
96kHz PCM O - - - - DIGITAL PCM, STEREO, AUTO >AUTO>96kHz> L,R
PCM(Audio) O --- O DIGITAL PCM, STEREO, AUTO >AUTO> L,R
Analog O --- O ANALOG STEREO, AUTO >AUTO> -
DTS (5.1ch) OO O - O DIGITAL DTS, AUTO >AUTO> L,C,R,SL,SR,LFE
AAC(5.1) OO O - O DIGITAL MPEG, AUTO >AUTO> L,C,R,SL,SR,LFE
AAC(2.0) O --- O DIGITAL MPEG, STEREO, AUTO >AUTO> L,R
Stereo Dolby Digital (5.1ch) O --- O DIGITAL DOLBY, DIGITAL, STEREO >STEREO> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O --- O DIGITAL DOLBY. DIGITAL, STEREO >STEREO> L,R
Dolby Digital (2ch:Lt/Rt) O --- O DIGITAL DOLBY, DIGITAL, STEREO >STEREO> L,R, SC
96kHz PCM O - - - - DIGITAL PCM, STEREO >STEREO>96kHz> L,R
PCM(Audio) O --- O DIGITAL PCM, STEREO >STEREO> L,R
Analog O --- O ANALOG STEREO >STEREO> -
DTS (5.1ch) O --- O DIGITAL DTS, STEREO >STEREO> L,C,R,SL,SR,LFE
AAC(5.1) O --- O DIGITAL MPEG, STEREO >STEREO> L,C,R,SL,SR,LFE
AAC(2.0) O --- O DIGITAL MPEG, STEREO >STEREO> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Movie Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MOVIE> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MOVIE> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PLII MOVIE>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PLII MOVIE> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PLII MOVIE> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PLII MOVIE> -
AAC(5.1) OO O - O DIGITAL MPEG >PLII MOVIE> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PLII MOVIE> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Music Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MUSIC> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MUSIC> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PLII MUSIC>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PLII MUSIC> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PLII MUSIC> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PLII MUSIC> -
AAC(5.1) OO O - O DIGITAL MPEG >PLII MUSIC> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PLII MUSIC> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Pro Logic Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PRO LOGIC> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PRO LOGIC> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PRO LOGIC>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PRO LOGIC> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PRO LOGIC> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PRO LOGIC> -
AAC(5.1) OO O - O DIGITAL MPEG >PRO LOGIC> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PRO LOGIC> L,R
DTS Dolby Digital (5.1ch) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
96kHz PCM - - - - - DIGITAL (PCM), DTS >DTS>96kHz> -
PCM(Audio) - - - - - DIGITAL (PCM), DTS >DTS> -
Analog - - - - - (ANALOG) DTS >DTS> -
DTS (5.1ch) OO O - O DIGITAL DTS >DTS> L,C,R,SL,SR,LFE
AAC(5.1) - - - - - DIGITAL (MPEG), DTS >DTS> -
AAC(2.0) - - - - - DIGITAL (MPEG), DTS >DTS> -
6.1Ch Dolby Digital (5.1ch) OO OOO DIGITAL DOLBY, DIGITAL >6.1 CH SURROUND> L,C,R,SL,SR,LFE
Surround Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL) >6.1 CH SURROUND> -
Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL) >6.1 CH SURROUND> -
96kHz PCM - - - - - DIGITAL (PCM) >6.1 CH SURROUND>96kHz> -
PCM(Audio) - - - - - DIGITAL (PCM) >6.1 CH SURROUND> -
Analog - - - - - (ANALOG) >6.1 CH SURROUND> -
DTS (5.1ch) OO OOO DIGITAL DTS >6.1 CH SURROUND> L,C,R,SL,SR,LFE
AAC(5.1) - - - - - DIGITAL (MPEG) >6.1 CH SURROUND> -
AAC(2.0) - - - - - DIGITAL (MPEG) >6.1 CH SURROUND> -
Movie Dolby Digital (5.1ch) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Hall Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Stadium Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Matrix 96kHz PCM - - - - - DIGITAL (PCM), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
PCM(Audio) OO O - O DIGITAL PCM, DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX > L,R
Analog OO O - O ANALOG DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
DTS (5.1ch) - - - - - DIGITAL (DTS), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
AAC(5.1) - - - - - DIGITAL (MPEG), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
AAC(2.0) - - - - - DIGITAL (MPEG), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Surround Input Signal Output Fluorescent Indicator
Mode Input Indicator Format Status & Surround Mode Temporary Display Status Ch. Status

NOTES:
• Dolby Digital (2 ch: Lt/Rt): signal with Dolby Surround flag Speakers are full set.
• When DOLBY DIGITAL, DTS, PCM or ANALOG is blinking, the selected surround mode is unavailable for input signal.
Select the other appropriate surround mode to playback.
• No sound outputs from the surround speaker, center speaker and subwoofer if the DVD disc has no surround data.
3
L/R SL/SR CSCSW
Virtual Dolby Digital (5.1ch) O - - - - DIGITAL DOLBY, DIGITAL, VIRTUAL >VIRTUAL> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O - - - - DIGITAL DOLBY, DIGITAL, PROLOGIC, VIRTUAL >VIRTUAL> L,R
Dolby Digital (2ch:Lt/Rt) O - - - - DIGITAL DOLBY, DIGITAL, PROLOGIC, VIRTUAL >VIRTUAL> L,R, SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, VIRTUAL >VIRTUAL>96kHz> -
PCM(Audio) O - - - - DIGITAL PCM, DOLBY, PROLOGIC, VIRTUAL >VIRTUAL> L,R
Analog O - - - - ANALOG DOLBY, PROLOGIC, VIRTUAL >VIRTUAL> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, VIRTUAL >VIRTUAL> -
AAC(5.1) - - - - - DIGITAL (MPEG), DOLBY, VIRTUAL >VIRTUAL> -
AAC(2.0) - - - - - DIGITAL (MPEG), DOLBY, VIRTUAL >VIRTUAL> -
CS5.1 Dolby Digital (5.1ch) - - - - - DIGITAL (DOLBY DIGITAL), CIRCLE SURROUND >CS5.1> -
Dolby Digital (2ch) - - - - - DIGITAL (DOLBY DIGITAL), CIRCLE SURROUND >CS5.1> -
Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY DIGITAL), CIRCLE SURROUND >CS5.1> -
96kHz PCM - - - - - DIGITAL (PCM), CIRCLE SURROUND >CS5.1>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, CIRCLE SURROUND >CS5.1> L,R
Analog OO O - O ANALOG >CS5.1> -
DTS (5.1ch) - - - - - DIGITAL (DTS), CIRCLE SURROUND >CS5.1> -
AAC(5.1) - - - - - DIGITAL (MPEG), CIRCLE SURROUND >CS5.1> -
AAC(2.0) - - - - - DIGITAL (MPEG), CIRCLE SURROUND >CS5.1> -
6CH Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >6CH STEREO> L,C,R,SL,SR,LFE
Stereo Dolby Digital (2ch) OO OOO DIGITAL DOLBY, DIGITAL >6CH STEREO> L,R
Dolby Digital (2ch:Lt/Rt) OO OOO DIGITAL DOLBY, DIGITAL >6CH STEREO> L,R, SC
96kHz PCM - - - - - DIGITAL (PCM) >6CH STEREO>96kHz> -
PCM(Audio) OO OOO DIGITAL PCM >6CH STEREO> L,R
Analog OO OOO ANALOG >6CH STEREO> -
DTS (5.1ch) OO O - O DIGITAL DTS >6CH STEREO> L,C,R,SL,SR,LFE
AAC(5.1) OO O - O DIGITAL MPEG >6CH STEREO> L,C,R,SL,SR,LFE
AAC(2.0) OO OOO DIGITAL MPEG >6CH STEREO> L,R
Surround Input Signal Output Fluorescent Indicator
Mode Input Indicator Format Status & Surround Mode Temporary Display Status Ch. Status
L/R : Front speaker
SL/SR : Surround speaker
C : Center speaker
SC : Surround center speaker
SW : Sub woofer speaker
( ): The indicator blinks L : Left
R : Right
C : Center
SL : Surround Left
SR : Surround Right
SC : Mono Surround
LFE : Low Frequency Effect

4
PS5200
L/R SL/SR CSCSW
Auto Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL, AUTO >AUTO> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O --- O DIGITAL DOLBY, DIGITAL, AUTO >AUTO> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC, AUTO >AUTO> L,R, SC
96kHz PCM O - - - - DIGITAL PCM, STEREO, AUTO >AUTO>96kHz> L,R
PCM(Audio) O --- O DIGITAL PCM, STEREO, AUTO >AUTO> L,R
Analog O --- O ANALOG STEREO, AUTO >AUTO> -
DTS (5.1ch) OO O - O DIGITAL DTS, AUTO >AUTO> L,C,R,SL,SR,LFE
AAC(5.1) OO O - O DIGITAL MPEG, AUTO >AUTO> L,C,R,SL,SR,LFE
AAC(2.0) O --- O DIGITAL MPEG, STEREO, AUTO >AUTO> L,R
Stereo Dolby Digital (5.1ch) O --- O DIGITAL DOLBY, DIGITAL, STEREO >STEREO> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O --- O DIGITAL DOLBY. DIGITAL, STEREO >STEREO> L,R
Dolby Digital (2ch:Lt/Rt) O --- O DIGITAL DOLBY, DIGITAL, STEREO >STEREO> L,R, SC
96kHz PCM O - - - - DIGITAL PCM, STEREO >STEREO>96kHz> L,R
PCM(Audio) O --- O DIGITAL PCM, STEREO >STEREO> L,R
Analog O --- O ANALOG STEREO >STEREO> -
DTS (5.1ch) O --- O DIGITAL DTS, STEREO >STEREO> L,C,R,SL,SR,LFE
AAC(5.1) O --- O DIGITAL MPEG, STEREO >STEREO> L,C,R,SL,SR,LFE
AAC(2.0) O --- O DIGITAL MPEG, STEREO >STEREO> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Movie Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MOVIE> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MOVIE> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PLII MOVIE>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PLII MOVIE> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PLII MOVIE> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PLII MOVIE> -
AAC(5.1) OO O - O DIGITAL MPEG >PLII MOVIE> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PLII MOVIE> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Music Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MUSIC> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PLII MUSIC> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PLII MUSIC>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PLII MUSIC> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PLII MUSIC> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PLII MUSIC> -
AAC(5.1) OO O - O DIGITAL MPEG >PLII MUSIC> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PLII MUSIC> L,R
Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >DOLBY D> L,C,R,SL,SR,LFE
Pro Logic Dolby Digital (2ch) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PRO LOGIC> L,R
Dolby Digital (2ch:Lt/Rt) OO O - O DIGITAL DOLBY, DIGITAL, PRO LOGIC >PRO LOGIC> L,R,SC
96kHz PCM - - - - - DIGITAL (PCM), DOLBY, PRO LOGIC >PRO LOGIC>96kHz> -
PCM(Audio) OO O - O DIGITAL PCM, DOLBY, PRO LOGIC >PRO LOGIC> L,R
Analog OO O - O ANALOG DOLBY, PRO LOGIC >PRO LOGIC> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, PRO LOGIC >PRO LOGIC> -
AAC(5.1) OO O - O DIGITAL MPEG >PRO LOGIC> L,C,R,SL,SR,LFE
AAC(2.0) OO O - O DIGITAL MPEG, PRO LOGIC >PRO LOGIC> L,R
DTS Dolby Digital (5.1ch) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL), DTS >DTS> -
96kHz PCM - - - - - DIGITAL (PCM), DTS >DTS>96kHz> -
PCM(Audio) - - - - - DIGITAL (PCM), DTS >DTS> -
Analog - - - - - (ANALOG) DTS >DTS> -
DTS (5.1ch) OO O - O DIGITAL DTS >DTS> L,C,R,SL,SR,LFE
AAC(5.1) - - - - - DIGITAL (MPEG), DTS >DTS> -
AAC(2.0) - - - - - DIGITAL (MPEG), DTS >DTS> -
6.1Ch Dolby Digital (5.1ch) OO OOO DIGITAL DOLBY, DIGITAL >6.1 CH SURROUND> L,C,R,SL,SR,LFE
Surround Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL) >6.1 CH SURROUND> -
Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL) >6.1 CH SURROUND> -
96kHz PCM - - - - - DIGITAL (PCM) >6.1 CH SURROUND>96kHz> -
PCM(Audio) - - - - - DIGITAL (PCM) >6.1 CH SURROUND> -
Analog - - - - - (ANALOG) >6.1 CH SURROUND> -
DTS (5.1ch) OO OOO DIGITAL DTS >6.1 CH SURROUND> L,C,R,SL,SR,LFE
AAC(5.1) - - - - - DIGITAL (MPEG) >6.1 CH SURROUND> -
AAC(2.0) - - - - - DIGITAL (MPEG) >6.1 CH SURROUND> -
Movie Dolby Digital (5.1ch) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Hall Dolby Digital (2ch) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Stadium Dolby Digital (2ch:Lt/Rt) - - - - - DIGITAL (DOLBY, DIGITAL), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Matrix 96kHz PCM - - - - - DIGITAL (PCM), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
PCM(Audio) OO O - O DIGITAL PCM, DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX > L,R
Analog OO O - O ANALOG DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
DTS (5.1ch) - - - - - DIGITAL (DTS), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
AAC(5.1) - - - - - DIGITAL (MPEG), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
AAC(2.0) - - - - - DIGITAL (MPEG), DSP SOUND > MOVIE/HALL/ STADIUM/MATRIX >-
Surround Input Signal Output Fluorescent Indicator
Mode Input Indicator Format Status & Surround Mode Temporary Display Status Ch. Status
Virtual Dolby Digital (5.1ch) O - - - - DIGITAL DOLBY, DIGITAL, VIRTUAL >VIRTUAL> L,C,R,SL,SR,LFE
Dolby Digital (2ch) O - - - - DIGITAL DOLBY, DIGITAL, PROLOGIC, VIRTUAL >VIRTUAL> L,R
Dolby Digital (2ch:Lt/Rt) O - - - - DIGITAL DOLBY, DIGITAL, PROLOGIC, VIRTUAL >VIRTUAL> L,R, SC
96kHz PCM - - - - - DIGITAL (PCM) , DOLBY, VIRTUAL >VIRTUAL>96kHz> -
PCM(Audio) O - - - - DIGITAL PCM, DOLBY, PROLOGIC, VIRTUAL >VIRTUAL> L,R
Analog O - - - - ANALOG DOLBY, PROLOGIC, VIRTUAL >VIRTUAL> -
DTS (5.1ch) - - - - - DIGITAL (DTS), DOLBY, VIRTUAL >VIRTUAL> -
AAC(5.1) - - - - - DIGITAL (MPEG), DOLBY, VIRTUAL >VIRTUAL> -
AAC(2.0) - - - - - DIGITAL (MPEG), DOLBY, VIRTUAL >VIRTUAL> -
6CH Dolby Digital (5.1ch) OO O - O DIGITAL DOLBY, DIGITAL >6CH STEREO> L,C,R,SL,SR,LFE
Stereo Dolby Digital (2ch) OO OOO DIGITAL DOLBY, DIGITAL >6CH STEREO> L,R
Dolby Digital (2ch:Lt/Rt) OO OOO DIGITAL DOLBY, DIGITAL >6CH STEREO> L,R, SC
96kHz PCM - - - - - DIGITAL (PCM) >6CH STEREO>96kHz> -
PCM(Audio) OO OOO DIGITAL PCM >6CH STEREO> L,R
Analog OO OOO ANALOG >6CH STEREO> -
DTS (5.1ch) OO O - O DIGITAL DTS >6CH STEREO> L,C,R,SL,SR,LFE
AAC(5.1) OO O - O DIGITAL MPEG >6CH STEREO> L,C,R,SL,SR,LFE
AAC(2.0) OO OOO DIGITAL MPEG >6CH STEREO> L,R

5 6
2. WIRING DIAGRAM
[SR7200 /
PS7200 only]
[SR7200 /
PS7200 only]
[SR5200 /
SR6200 /
SR7200 only]

3. BLOCK DIAGRAM
7 8
[PS7200 only]
[PS5200 / PS7200 only]
[PS7200 only]
[PS7200 only]
[PS7200 only]
[PS7200 only]

910
4. SCHEMATIC DIAGRAM
7020-06075-000-3

11 12
7020-06140-000-1

13 14
POWER SW. with TACT SW.
7020-06076-000-3
7020-06076-004-0
7020-06076-003-0
7020-06076-002-0

15 16
7020-06080-002-1
7020-06080-003-1
7020-06080-005-1
7020-06080-000-1 7020-06080-001-17020-06080-001-1
L
R
TUNER
7020-06080-002-1
7020-06080-005-1

17 18
CP302I
[PS7200 only]
L
R
7020-06077-000-1
7020-06077-001-1
7020-06077-003-1
7020-06077-002-1
7020-06077-005
7020-06077-004-1

19 20
7020-06076-001-1

21 22
7020-06079-000-2

23 24
7020-06009-000-1 7020-06106-001-0
7020-06088-000-1

25 26
7020-06078-001-2
7020-06078-001-2

27 28
5. PARTS LOCATION
Q112Q119 Q115Q117Q116Q120Q118Q105Q107Q106Q130
Q104IC105IC103IC101IC107 Q136
IC104IC102IC108
Q125
Q103 Q111
Q101 Q102 Q110
Q109
Q108IC106
Q113
Q135
Q134
Q133
Q132
Q131
MAIN
Q122
Q128
Q129
Q121
Q123
Q124
Q137
Q126
Q127

29 30
Q215R
Q208R
Q209RQ209L
Q207RQ206RQ205RQ206LQ205L
Q203RQ202RQ201R
Q204R
Q215SR
Q208SR
Q209SR
Q207SR
Q206SRQ205SR Q203SR
Q202SRQ201SR Q204SR
Q215SC
Q208SC
Q209SC
Q207SC
Q206SCQ205SC Q203SC
Q202SCQ201SC Q204SC
Q215C
Q208C
Q209C
Q207C
Q206CQ205C Q203C
Q202CQ201C Q204C
Q215SL
Q208SL
Q209SL
Q207SL
Q206SLQ205SL Q203SL
Q202SLQ201SL
AMP
Q204SL
Q215L
Q208L
Q207L
Q203LQ202LQ201L
Q204L
Q714
Q712
POWER [/ N, / U, / F ONLY]
Q711
IC710

31 32
Q301
Q306
Q304
Q305
Q303M
FRONT
H / P H / P
POWER SW POWER SW POWER SW
ST / BY LED
MULTICONTROL
Q302
PS7200
SR7200
SR7200 / K
SR7200 / N
SR5200 / K
SR5200 / N
SR6200 / K
SR6200 / N
PS5200 / F
PS7200 / F
SR5200 / U
SR6200 / U
SR7200 / U
PS5200
SR5200
SR6200
Q309
IC301
