Marantz LC4602e User manual

LCD TV
LC4602e
LC4602e LCD Television
A Marantz flat TV takes you into a world where multimedia entertainment is fused with
awe-inspiring elegance. The LC4602e is a high-performance digital Full HD LCD TV with a
stunning 46-inch latest genaration widescreen liquid crystal display (LCD) and the latest digital
image enhancements such as High Performance sharpness control, precise de-interlacing to get
the best artefact free picture and outperforming videoprocessing for superior picture quality.
Measuring just 100 mm (less than 4 inches) deep, it can easily be wall mounted or placed on your
most stylish table or cabinet using the matching swivel stand. Its subtle black acryl frame finish
with silver speaker will complement your meticulously selected décor, while the breathtaking
picture quality turns every film, event or program into a truly memorable experience. Take the
next step in AV excellence.
Downloaded From TV-Manual.com Manuals

Features Benefits
46" Full HD LCD TV with 1920x1080 pixel resolution
>5000:1 contrast ratio
Luminance of 500 cd/m2
6 milliseconde pixel response
Natural colour reproduction technology
Precise de-interlacing
DVB-T and analogue tuner
Electronic Programma Guide via DVB-T
3x HDMI (HDCP conform)
Multilanguage OSD
Detachable speakersystem
High quality picture performance complying to the Full
HD TV standards
Provides a clear picture with rich and deeper black tones
even in very bright enviroments Assure clear, distinct
colors without smearing effect
Ensures a sharp and accurate image
For a high quality, full bandwidth, digital A/V
signal receivement from a DVB-T source.
Easy to setup and operate with direct on screen
feedback Faithful and accurate sound reproduction for
maximum enjoyment
Technological glossary:
The LC4602e provides a complete multimedia home
entertainment experience with built-in analogue and digital
tuner, stereo loudspeakers and advanced display technology.
By using the latest digital image enhancing techniques and
incorporating the features only found on the very best sets.
And being a Marantz, its standard-setting performance is
matched by its stunning good looks. Put it at the heart of your
home theater.
A visionary experience
The LC4602e’s widescreen liquid crystal display (LCD)
produces an extra bright image (500cd/m2) for perfect
viewing enjoyment even in sunlight. This type of display
works by having a liquid crystal solution between two sheets
of polarized glass. An electric current causes the crystal in a
particular pixel to align and block light, switching the current
off allows light to pass through again. With a pixel response
of 6 milliseconds a dynamic TV picture can be built up in
crisp vivid colors that rivals conventional CRT TVs. And of
course, LCD TVs are much thinner and more energy efficient
than CRTs too.
A conventional TV image is interlaced, where each ‘frame’ is
built up from two interlaced image fields that are viewed
simultaneously. However, when viewing interlaced video on
non-interlaced TVs (like LCD) that display the interlaced
images sequentially, an artifacts known as ‘tear’ is visible.
Tearing is due to both fields showing the object moving at
slightly different times. The Marantz LC4602e has a motion
compensated de-interlacer that merges the two fields to
faithfully reproduce the original frame without unpleasant
motion artifacts.
Behind the scenes, advanced digital image processing
algorithms optimize picture quality, leaving you free to enjoy
the ultimate viewing experience. Digital Color Transient
Improvement (DCTI) reduces color smear at the vertical edges
of bright colored areas on the TV image whereas Digital
Luminance Transient Improvement (DLTI) enhances contour
detail in scenes for a sharper, more natural picture.
LCD image excellence
High quality de-interlacing
Digital transient improvements
Black level expansion creates richer, deeper black tones. It
dynamically analyses every image and literally ‘stretches’
dark areas to a realistic black while leaving light areas
untouched. The result is better contrast, without black areas
looking gray if you increase the picture brightness.
The LC4602e uses a high-performance, 10-bit digital gamma
processing circuit to optimize the non-linear imaging
characteristics of LCD panels. It is far superior to conventional
analogue and lesser bit-rate gamma processing; this circuitry
delivers natural colors and smooth image graduation.
Black level expansion
10-Bit digital gamma processing
Unlike the lower quality comb filters, the 4H Comb Filter in
Marantz LCD TV's separates signals for brightness and color
with an advanced technology. The processing of RF and
composite video signals is done far more accurately for a
sharper, cleaner picture. In addition the filter reduces
discoloration in fine detailed area in a picture and provides
good overall color purity. This clearly separates color
boundaries and making images softer and cleaner. Detail
noise is reduced significantly. This noise can normally be
seen as shimmering or flicker, in complex or intricately
detailed scenes.
If you want the best you need a digital video connection.
Whether you're watching a ball game or an action-packed
movie in high definition, without question, the picture quality
is stunning. For high definition all digital video to look its
best, the data must be transferred from your source to your
LC4602e digital. The 3x HDMI input on the LC4202e is a pure
digital high bandwidth video interface and complies with the
HDCP protocol. What you see on your screen is exactly what
was digitally recorded. You´ll enjoy a razor sharp picture
with incredible detail and vibrant, natural colors.
4H digital comb filter
Digital video input
Downloaded From TV-Manual.com Manuals

Bypacked accessories
- User manual
- Remote control
- Antenna cable
- Batteries
RC3701
Downloaded From TV-Manual.com Manuals

FEATURES
DVB-T digtal TV tuner •
MHEG5 support -
Analogue TV tuner •
Colour Transmission
Systems
PAL B/G, D/K, I,
SECAM B/G, D/K, L
Multinorm •
HDTV ready (720p / 1080i) •/•
Supported PC Resolution: (VGA
/ SVGA / XGA / WXGA /
SXGA)
•/•/•/•/•
Channel Presets 99
Speakers System (fix / detachable) -/•
PICTURE PROCESSING
Progressive Scan •
Film mode detection •
Noise Reduction •
Color Temperature (standard /
warm / cool) •/2/2
Control: (Sharpness / Contrast /
Brigthness / Colour / Tint) •/•/•/•/•
Selectable Aspect Ratio Modes •
Picture Modes (Standard /
Natural / Dynamik / User) •/•/•/•
PIP (multiple screen / swap / size
/ position) •/•/•/•
SOUND PROCESSING
Sound System: A2 Sterep / Nicam
Stereo •/•
Digital Signal Processing •
Bass/Treble Control - (via Equalizer)
Sound Equalizer (Standard, Music,
Movie, News, User) •
Language I-II Selection •
Virtual surround •
AVL (Automatic Volume Level) •
OTHERS
Multilanguage On Screen Display (En,
De, Fr, Sp, It) •
PIP/POP/Double window •/-/•
Channel Surf Loop •
Automatic Tuning System •
Manual Channel Sorting (editing /
naming) •
Fine Tune •
Sleep Timer •
Teletext (TT) •
TT Page Memory 252
Still picture •
Auto Power Off •
Key Lock •
INPUTS/OUTPUTS
DVi (HDCP) -
HDMI (HDCP) 3
Scart In/Out (RGB) 2 (1 RGB)
Component In (Y, Cb/Pb, Cr/Pr) 1
S-video In 1
Composite 1
VGA In 1
Audio In VGA (stereo RCA) 1
Antenna In 1
CAM (conditional access module) Slot -
Card Reader -
Subwoofer out -
Headphone out -
Audio Out (Constant level) 1
Digital Audio Out on DVB (opt. /
coax.) •/•
RS232 (control / update) -/•
SPECIFICATIONS
Visible Screen Diagonal 46 inch
Aspect Ratio 16:9
Viewing angle: Hor. / Ver. 178 / 178
Resolution 1920 x 1080
Pixel pitch TBA
Contrast Ratio (Dark Room) >5.000:1
Brightness 500 cd/m2
Response time 6ms
A-Class panel •
Output Power (8 Ohm RMS) 2ch 10W
Power input
voltage AC100V-240V 50/60Hz
GENERAL
Colour black
Remote •
Power Consumption (typical) 230W
Standby Consumption <2W
Tablestand included •
Wallmount included -
Dimensions (excl. table stand)
(W x H x D)
1143 x 115
x 773
Dimensions (incl. table stand)
(W x H x D)
1143 x 350
x 845
Weight (incl. table stand) 36,7 kg
Design and specifications are subject
to change by Marantz without notice.
www.marantz.com
