User’s Guide
M2200
P02 & M02 Packing Scale
Marel hf.
Austurhraun 9 iIS-210 Gardabaer iICELAND
Tel: [phone] iFax: [phone]
[email protected] iwww.marel.com
Version 1.00

Information in this document is subject to change without further notice, and does not
represent a commitment by Marel hf. No part of this document may be reproduced,
stored in a retrieval system, or transmitted in any form or by any means, electronic,
mechanical, photocopying or otherwise, without the pri
or written permission of Marel hf.
Marelis a registered trademark of Marel hf.
Printed in Iceland, February 2003.
Copyright 2003, Marel hf. All rights reserved.
030219ENG

Marel hf.
STANDARD SAFETY NOTICE FOR MAREL SCALES
All persons involved in the use and/or installation of this product should be aware of the following
instructions.
Failure to follow these instructions or other safety instructions in the manual voids all warranties
and may result in malfunction of the product, property damage, serious personal injury, or death.
WARNING
•The installation and use of this product must comply with all applicable national, state,
and local codes.
•Turn the electrical power off when servicing the scale.
•Electrical installations and repairs must be performed by a licensed electrician, in
accordance with manufacturer's specifications and national and local electrical codes.
•There are no serviceable parts inside the housing. Do not open the housing as there is
hazardous voltage inside.
Do Not
pull at the upper frame inside the platform casing or the load cell may bend.
Do Not
drop the scale, e.g. from a table to the floor. The scale is a high-precision weighing instrument and is sensitive to
shock.
ATTENTION!
Marel scales are Class I equipment and MUST have a protective earthing connection for safe
operation.
ONLY USE A EARTHED MAINS CONNECTION
Power supply cords, color coding:
International North-American
Earth Green/Yellow Green or Green/Yellow
Neutral Light Blue White
Live Brown Black
Both Neutral and Live are fused.

Marel hf.

Contents
Introduction 3
M2200 IN GENERAL ..............................................................................................3
Default Settings........................................................................................................... 3
Communication........................................................................................................... 3
Initial Inspection ......................................................................................................... 4
ABOUT THIS MANUAL ...........................................................................................4
Improvements ............................................................................................................. 4
Warranty Information ................................................................................................. 5
TECHNICAL SPECIFICATIONS ...............................................................................6
Operation 9
BEFORE YOU START..............................................................................................9
THE USER INTERFACE...........................................................................................9
Function Keys ........................................................................................................... 10
The Scale page .......................................................................................................... 10
The System Page....................................................................................................... 11
CREATING PRODUCTS .........................................................................................12
Selecting a Nominal Mode........................................................................................ 13
WORKING WITH TARE ........................................................................................15
Normal Tare .............................................................................................................. 15
Automatic Tare ......................................................................................................... 16
Preset Tare ................................................................................................................ 17
Marine Adjustments.................................................................................................. 18
CLEANING ............................................................................................................19
ERROR CODES .....................................................................................................21
Installation 23
IN GENERAL .........................................................................................................23
SYSTEM SETTINGS ...............................................................................................23
Adjustments 25
IN GENERAL .........................................................................................................25
Weighing Range and Resolution............................................................................... 26
Unit of Weight .......................................................................................................... 27
Setting Response Time ............................................................................................. 27
User’s Guide Contents •i

ADJUSTING THE SCALE .......................................................................................28
The Span Adjust Option............................................................................................ 29
Programming 31
IN GENERAL .........................................................................................................31
MODEL .................................................................................................................31
TCP SERVER PORTS............................................................................................32
REGISTERED LUA FUNCTIONS............................................................................32
Screen Functions....................................................................................................... 32
Miscellaneous Functions........................................................................................... 33
Communication Port Functions ................................................................................ 33
Model Access Functions ........................................................................................... 34
Event Functions ........................................................................................................ 34
Digital Input Functions ............................................................................................. 34
Digital Output Functions........................................................................................... 35
Real-time Clock Functions........................................................................................ 35
Timer* Functions...................................................................................................... 35
SCREEN CONTROL CHARACTERS.......................................................................36
EVENTS.................................................................................................................36
Appendix 39
LAWS AND REGULATIONS ...................................................................................39
MARKING AND SEALING .....................................................................................39
Markings in the EU................................................................................................... 40
SEALING THE M2200 AFTER ADJUSTMENTS .....................................................41
Protected Parameters................................................................................................. 42
ADDITIONAL INFORMATION ...............................................................................43
M2200 P02 & M02 PAGE OVERVIEW................................................................45
Glossary of Terms 47
Index 49
ii •Contents M2200 P02 & M02

Introduction
M2200 in General
The M2200 consists of an M2200 indicator with an LCD display and, if
used as a scale, of a separate load cell weighing platform. Depending on
the platform type, the M2200 scale is available with a dual range
weighing capability.
The M2200 is available in three models:
M2200-P02-xxxx-V1 packing scale, land-based•
•
•
M2200-M02-xxxx-V1 packing scale, marine
M2200-T02-xxxx-V1 registration terminal
The M2200 indicator is designed to run different user applications and a
variety of applications is available for use in various setups. Use of these
applications is described in separate manuals.
Default Settings
On delivery the M2200 scale has the following default settings1:
• Range mode AUTOMATIC
• Automatic tare NO
• Backlight always on NO
Communication
The following communication options are available for the M2200 scale:
• CAN. The M2200 is specially designed to operate in a networked
environment (CANopen). When the scale is connected to this type of
network, the network can supply the power.
The scale is a CAN Master and it can control up to two I/O modules.
1These settings can be changed via System Setup ÆConfiguration ÆOptions.
User’s Guide Introduction •3

• RS-232. The M2200 can communicate with external equipment
using RS-232 (serial connections). Weighing results can be printed
on an external label printer or the data can be transmitted to a PC for
storing and further processing.
• Ethernet. Application programs in the scale can communicate with
a computer network via Ethernet network.
Initial Inspection
Prior to use, inspect the M2200 for damages incurred during shipment. If
the scale/terminal has been damaged, contact your local Marel service
center immediately.
About This Manual
This manual is a collection of information on the M2200. Some of this
information is aimed directly at the M2200 operator, while other sections
are intended for technicians and software programmers.
The manual is divided into six parts:
General Introduction – this section, for all users.•
•
•
•
•
•
Operation – operating instructions for the operator.
Also includes documentation on various M2200 applications.
Installation – instructions for technicians on communication options,
how to set up network connections, etc.
Adjustments – instructions for technicians on how to make
adjustments to the scale’s weighing parameters.
Programmer’s Guide – instructions for software programmers on
how to create Lua scripts for the M2200.
Appendix – information on laws and regulations relating to the use
of scales and instructions in how to seal the scale.
Improvements
You can help improve this manual and the equipment you purchased. If
you find any errors in the manual, please let us know. You can contact us
at: Marel hf., Austurhraun 9, IS-210 Gardabaer, Iceland;
phone [phone], fax [phone], attn. Documentation &
Localization, email: [email protected].
4 •Introduction M2200 P02 & M02

Warranty Information
Warranties given by Marel hf. are revoked if the equipment in question
has not been used according to specifications. The same applies if the
equipment has been modified in any way without Marel’s consent.
User’s Guide Introduction •5

Technical Specifications
Manufacturer: Marel hf.
Indicator Type: M2200-Pxx, Mxx, Txx, x defines the software
application.
Enclosure: Designed for wash down; AISI 316 stainless
steel; degree of protection exceeds IP67.
Approvals: Certificate of EU Type-Approval No. DK 0199.56
Accuracy Class: III
Maximum number of
verification scale intervals: n’max = 7500 (for each range)
Maximum tare effect: -Max
Load Cell Excitation:
Voltage:
Characteristics:
4 or 6-wire systems:
14 Vdc ±5%
Direct Current
6 wire system using excitation voltage sensing
(3 Ωmax cable resistance).
Optional 4 wire system (0.2 Ωmax).
Rated minimum input
impedance of load cells: 85 Ωfor load cell
Maximum input range: 70 mV
Minimum signal voltage for
dead load:
−70 mV
Maximum signal voltage for
dead load in case of “added
dead load”: 60 mV
Minimum input voltage per
scale interval (v.s.i):
0.4 µV/e
Operating temperature
range:
Min –10° C, Max +40° C
Display and indicators: LCD, 128 x 240 pixel graphical display
Power Requirements: 110-230 VAC 0.16-0.1 A internal power supply
Specification of interfaces: RS-232 bi-directional interface, 9600 Baud
(1200-38400 Baud),
8 data bits and no parity.
CAN (Controller Area Network) Bus Interface
(ISO 11898).
6 •Introduction M2200 P02 & M02

Capacity and Resolution: The tables below shows typical values of Max
and e when configuring a M2200 indicator.
Other values can be used, but a 3000 division
weighing range is often the maximum allowed
with regard to load cell specifications.
The indicator can be configured to operate as a
single or dual range scale that changes from a
low to a high range with the load on the platform.
Example:
First weighing range: Max1 = 3 kg, e = 1 g
(low weighing range, high resolution)
Second weighing range: Max2 = 6 kg, e = 2 g
(high weighing range, low resolution)
Dimensions:
M2200 Indicator
Metric Units Avoirdupois Units
Max e =d Max e =d Max e =d
3 kg 1 g 6 lb 0.002 lb 96 oz 0.05 oz
6 kg 2 g 15 lb 0.005 lb 240 oz 0.1 oz
15 kg 5 g 30 lb 0.01 lb 480 oz 0.2 oz
25 kg 10 g 50 lb 0.02 lb 800 oz 0.5 oz
30 kg 10 g 60 lb 0.02 lb 960 oz 0.5 oz
60 kg 20 g 150 lb 0.05 lb 2400 oz 1 oz
150 kg 50 g 300 lb 0.1 lb
300 kg 100 g 600 lb 0.2 lb
600 kg 200 g 1500 lb 0.5 lb
1000 kg 500 g 2000 lb 1 lb
1500 kg 500 g 3000 lb 1 lb
2000 kg 1 kg 4000 lb 2 lb
3000 kg 1 kg 6000 lb 2 lb
4000 kg 2 kg 8000 lb 5 lb
6000 kg 2 kg 15000 lb 5 lb
Single range
User’s Guide Introduction •7

Metric Units Avoirdupois Units
Max1/Max2 e =d Max e =d Max e =d
3 / 6 kg 1 / 2 g 6 / 15 lb 0.002 / 0.005 lb 96 / 240 oz 0.05 / 0.1 oz
6 / 15 kg 2 / 5 g 15 / 30 lb 0.005 / 0.01 lb 240 / 480 oz 0.1 / 0.2 oz
15 / 25 kg 5 / 10 g 30 / 50 lb 0.01 / 0.02 lb 480 / 800 oz 0.2 / 0.5 oz
15 / 30 kg 5 / 10 g 30 / 60 lb 0.01 / 0.02 lb 480 / 960 oz 0.2 / 0.5 oz
30 / 60 kg 10 / 20 g 60 / 150 lb 0.02 / 0.05 lb 960 / 2400 oz 0.5 / 1 oz
60 / 150 kg 20 / 50 g 150 / 300 lb 0. 5 / 0.1 lb
150 / 300 kg 50 / 100 g 300 / 600 lb 0.1 / 0.2 lb
300 /600 kg 0.1 / 0.2 kg 600 / 1500 lb 0.2 / 0.5 lb
600 / 1000 kg 0.2 / 0.5 kg 1500 / 2000 lb 0.5 / 1 lb
600 / 1500 kg 0.2 / 0.5 kg 1500 / 3000 lb 0.5 / 1 lb
1500 / 2000 kg 0.5 / 1 kg 3000 / 4000 lb 1 / 2 lb
1500 / 3000 kg 0.5 / 1 kg 3000 / 6000 lb 1 / 2 lb
3000 / 4000 kg 1 / 2 kg 6000 / 8000 lb 2 / 5 lb
3000 / 6000 kg 1 / 2 kg 6000 / 15000 lb 2 / 5 lb
D
ual range
8 •Introduction M2200 P02 & M02

Operation
Before You Start
Before you apply power to the M2200 scale, check the following:
• Make sure there are no foreign objects that can interfere with the
platform’s movements.
• The platform must be empty when you power-on the scale.
• The scale must be properly mounted on a stable, level and non-
vibrating foundation.
• Use the built-in spirit level to level the scale platform.
The User Interface
Power-on
indicator
Preset Tare indicato
r
Steady, Zero, Tare
indicators
Rating plate
Screen page
Function ke
y
Weighing range
marke
r
Check key
Page key
ID reader
Figure 1 M2200 Indicator, front view.
The user interface consists of an M2200 front panel with a keypad and a
screen with programmable function keys and various screen items.
User’s Guide Operation •9

Function Keys
The keypad has numeric keys and two special keys, Check and
Page .
Check key
Use the Check key to confirm your actions, e.g. your selection of a menu
option.
Page key
Use the Page key to browse through the pages and to exit pages.
The Scale page
The main weighing page, the Scale page, shows weighing results in the
unit of weight selected for the scale (1).
4
5
3
2
1
Figure 2 The Scale page.
Other features on the Scale page:
Weighing range and resolution (2)•
•
•
•
Two arrow keys and a ZERO/TARE key (3)
Steady and Zero indicators (4)
NET (Tare) and PT (Preset Tare) indicators (5 - not displayed).
Zero
The (ZERO/TARE) key is used to take a new operational zero
point provided the operating zero stays within ±2% of max weight from
the initial zero point.2
The operating zero is the reference point for all weighings, and therefore
a correct operating zero is necessary to ensure accurate weighing results.
The indicator illuminates when the scale is at zero.
2If automatic zero tracking is selected (Top Level Menu Æ4- System Setup ÆSystem ÆConfiguration Æ
Weighing Configuration ÆOptions ÆZero Tracking), the scale will automatically track small variations in the
zero point. The maximum tracking rate is 0.5 divisions per second.
10 •Operation M2200 P02 & M02

To take a new operational zero point
1 Remove any weight from the platform.
2 Press
The Zero indicator ( ) appears on the display.
Tip
If zero can no longer be set using the key, you can
use the option Initial Zero Operation on the Scale Ops page
to take a new initial zero. The range of the initial zero can be
±10% of max weight calculated from the calibration zero
point.
The System Page
The System page (Top Level Menu Æ4-System Setup ÆSystem)
provides access to various system options, for example configuration and
diagnostics.
Note: To access the Top Level Menu page press and hold the PAGE
key for ca. three seconds.
The System Setup page
Figure 3 The System page.
Use the up and down arrow keys to scroll through the menu options.
Use the Check key to select an option and display the relevant page.
User’s Guide Operation •11

Creating Products
You can create a number of products, also called programs, that contain
your own packing parameters.
The following example shows how to create a product and specify the
necessary parameters for a stand-alone packing scale.
Note: M2200 applications use the packing parameters in different ways
and some applications do not use them at all.
To create a product
Figure 4 The Settings page
1 From the Top Level Menu select 4-System Setup ÆSystem
ÆSettings ÆProgram identification. Here you can type an
ID, name, and number for your product.
2 Select Programs ÆSave to save your product with the new
name and ID.
Figure 5 The Packing page
3 Select Packing and type the parameter values you need for
your application, for example:
− Nominal mode: Overweight
− Overweight: 0.100 kg
− Nominal weight: 2 kg
− Upper lock limit: 0.200 kg
− Lower lock limit: 0.200 kg
There are five different nominal modes available: Overweight,
Overweight %, Range, Steps, Any weight.
Each mode is explained in more detail in “Selecting a Nominal
Mode” on page 13.
4 Select Programs ÆSave to save your parameter settings.
Figure 6 The Settings page, the
Automatic recording option
5 Select Automatic Recording, if you want the scale to record
weighing results automatically. There are four options available:
− record when the weight on the platform is removed from the
platform. This option is most commonly used for automatic
recording.
− record when the weight on the platform is increased
− record when the weight on the platform is decreased
− record when the weight on the platform changes and has
become steady.
12 •Operation M2200 P02 & M02

Figure 7 The Settings page, the Limit
detection option
6 Select Limit detection, if you need to specify weight limits to
control conveyors, for example for starting or stopping the
conveyors.
7 Select Programs ÆSave to save your parameter settings.
Note: It is possible to overwrite new parameter settings if you
browse from one product to another with the Left and Right arrows
(see Figure 5, for example).
To prevent accidental overwriting, you are instructed to save your
work frequently (steps 2, 4, and 7).
Selecting a Nominal Mode
Your choice of nominal mode determines how the M2200 calculates the
nominal weight and uses the packing parameters. The following terms
and abbreviations are used in the examples:
Term: Abbr: Parameter
name:
Definition:
Nominal
weight
NW The weight of a product as
specified on the packaging label
Target weight TW The weight the scale operator is
trying to achieve for a package
using one of the available
calculating methods
Pack weight W The final (real) weight of the
package
Fixed weight FW Nominal
Weight
A fixed normal weight
Giveaway
weight
GF Overweight A fixed extra weight which is
added to a fixed nominal weight
to obtain the target weight
Giveaway % GP Overweight % Same as GF, except that the
extra weight is given as a
percentage of the nominal
weight
Minimum
weight
MIW Nominal
Weight
Used in the Range and Steps
modes to specify a lower limit
Maximum
weight
MAW Nominal Upper
Limit
Used in the Range and Steps
modes to specify an upper limit
Weight step WS Nominal Step
Size
Lower Lock
Limit
LLL Lower Lock
Limit
The maximun allowed deviation
(downwards) from the target
weight
Upper Lock
Limit
ULL Upper Lock
Limit
The maximun allowed deviation
(upwards) from the target
weight
User’s Guide Operation •13

Overweight
Use this mode to pack to a fixed weight. The nominal weight is fixed. The
target weight is calculated as:
TW = FW + GF
Here you must specify upper and lower lock limits. The pack weight will be
somewhere in the range between the lower and upper limits.
Parameters that need to be specified:
”Nominal weight”, “Overweight”, “Upper lock limit”, “Lower lock limit”.
ULL
LLL
Nominal
FW
GF
TW
Overweight %
Use this mode to pack to a fixed weight using a percentage of the nominal
weight to reach the target weight.
The target weight is calculated as:
TW = FW * (1+GP/100)
Parameters that need to be specified:
”Nominal weight”, “Overweight %”, “Upper lock limit”, “Lower lock limit”.
2
ULL
LLL
FW
1
Nominal weight
TW
P * FW
Range
Use this mode to pack catch weight (packs of variable weight). The
minimum allowed nominal weight is MIW and the maximum allowed
nominal weight is MAW. There is no target weight.
The nominal weight is calculated as:
NW = W / (1+GP/100)
Parameters that need to be specified:
”Nominal weight”, “Overweight %”, “Nominal upper limit”.
Pack W
1
2
Nominal weigh
t
MIW MAW
W / (1+P)
Steps
This mode is normally only used to pack salmon. The nominal weight is the
lowest weight below W calculated by successively adding WS to MIW.
The target weight is calculated as:
TW = NW * (1+GP/100)
You must specify an upper lock limit for each step. This means that products
whose weight exceeds the upper lock limit for step 1, for example, will fall
into the weight class for step 2.
Parameters that need to be specified:
”Nominal weight”, “Overweight %”, “Nominal upper limit”, “Upper lock
limit”, “Nominal step size”.
MIW MAW
WS
NW3
NW2
TW2
TW1
P * NW2
P * NW1
NW1
ULL
14 •Operation M2200 P02 & M02

Any weight
Use this mode to pack catch weight (packs of variable weight). There are no
restrictions on the nominal weight and there is no target weight.
The nominal weight is calculated as:
NW = W / (1+GP/100)
Parameters that need to be specified:
“Overweight”.
1
2
W / (1+P)
0
Pack weightNominal weight
Working with Tare
The scale has three tare functions:
Normal tare•
•
•
Automatic tare
Preset tare
Normal and automatic tare The first two work in a similar way, except that Automatic Tare
automatically compensates for slightly different weight of trays or boxes
which are placed on the platform.
This means that you can place different trays on the scale’s platform
without having to press every time you change trays – the
Automatic Tare function will do that for you.
Preset tare Preset Tare, however, is different in that it is the user himself who enters a
tare value of his own choice, instead of a weight detected by the scale.
This method can be useful in certain situations, for example in packing
systems where the weight of the packing material is known.
Normal Tare
To enter tare
Figure 8 Scale page, tare in use.
1 Place a tray (the tare weight) on the platform, and press
.
2 The NET indicator appears on the Scale page to show that a tare
is in use.
3 Subsequently, the NET weight on the platform is shown on the
Scale page.
To remove tare
1 Empty the platform.
2 Press .
The NET indicator is turned off.
User’s Guide Operation •15

Direct sale to the public
Note: In some market areas the scale’s tare function may be protected with
a software switch.3This changes the way you work with tare:
• You must remove tare (see above) before you can set a new tare value
that is lower than the current tare value.
Automatic Tare
To use Automatic tare
1 Check whether the Automatic Tare option is currently selected
on your scale. By default, this option is not selected.
2 From the Top Level Menu select 4-System Setup ÆSystem Æ
Configuration ÆOptions.
3 On the Options menu select Automatic Tare and press .
4 Enter YES to work with Automatic Tare and press several
times, until you return to the Scale page.
5 Place a tray (the tare weight) on the platform, and press
(normal tare, see above).
6 Remove the tray, and place a new tray on the platform.
7 If the second tray is within ±30% of the first tray, the weight
of this tray will be automatically tared and the weight
indicator on the Scale page will show zero.
When using automatic tare, you should check the tare from time to time:
♦ Place a tray on the platform, and notice if the weight indicator on the
Scale page returns to zero. If not, tare the scale again by pressing
.
Automatic tare is not available if the scale is configured for “direct sale to
the public”.
Note: The Automatic Tare function can compensate for up to 30%
variation in the tare.
The second tray you put on an empty platform will be tared automatically
if it is within ±30% of the weight set by the manual tare operation.
For this function to work it is important that the scale is stable and with
an empty platform before you place the second tray on the scale.
3According to standard regulations on conditions for direct sale to the public.
16 •Operation M2200 P02 & M02
