Maretron Clm100 User manual

Revision 1.0 Page i

CLM100

Current Loop Monitor

User’s Manual

Revision 1.0

Maretron, LLP

9014 N. 23rd Ave #10

Phoenix, AZ 85021

http://www.maretron.com

Maretron Manual Part #: M003071

CLM100 User’s Manual

Page ii Revision 1.0

Revision History

Revision

Description

1.0

Original document

Revision 1.0 Page iii

Table of Contents

1General ................................................................................................................................1

1.1 Introduction....................................................................................................................1

1.2 Firmware Revision.........................................................................................................1

1.3 Features ........................................................................................................................1

1.4 CLM100 Accessories.....................................................................................................2

1.5 Quick Install...................................................................................................................2

1.6 Theory of Operation.......................................................................................................3

1.7 Resolution......................................................................................................................3

1.8 Accuracy........................................................................................................................4

2Parameters...........................................................................................................................4

3Installation............................................................................................................................5

3.1 Unpacking the Box.........................................................................................................5

3.2 Choosing a Mounting Location ......................................................................................5

3.3 Mounting the CLM100 ...................................................................................................5

3.4 Mounting the Transducer...............................................................................................6

3.5 Connecting the CLM100................................................................................................6

3.5.1 NMEA 2000®Connection....................................................................................6

3.5.2 Transducer Connections.....................................................................................7

3.5.3 Extension of Transducer Wires...........................................................................8

4Configuring the CLM100 ......................................................................................................9

4.1 Configuring Channel Mode..........................................................................................10

4.2 Configuring a Channel in DC Voltage Mode................................................................10

4.2.1 Configuring Instance.........................................................................................10

4.2.2 Configuring Label..............................................................................................11

4.2.3 Units, Range, and Resolution ...........................................................................11

4.2.4 Configuring DC Voltage at 4mA........................................................................11

4.2.5 Configuring DC Voltage at 20mA......................................................................11

4.2.6 Configuring Data Damping Period ....................................................................11

4.3 Configuring a Channel in DC Current Mode ................................................................11

4.3.1 Configuring Instance.........................................................................................12

4.3.2 Configuring Label..............................................................................................12

4.3.3 Units, Range, and Resolution ...........................................................................12

4.3.4 Configuring DC Current at 4mA........................................................................12

4.3.5 Configuring DC Current at 20mA ......................................................................12

4.3.6 Configuring Data Damping Period ....................................................................12

4.4 Configuring a Channel in Flow Rate Mode ..................................................................13

4.4.1 Configuring Source ...........................................................................................13

4.4.2 Configuring Instance Number ...........................................................................13

4.4.3 Units, Range, and Resolution ...........................................................................13

4.4.4 Configuring Label..............................................................................................13

4.4.5 Configuring Flow Rate at 4mA ..........................................................................13

4.4.6 Configuring Flow Rate at 20mA ........................................................................14

4.4.7 Configuring Data Damping Period ....................................................................14

4.5 Configuring a Channel in Distance Mode ....................................................................14

4.5.1 Configuring Instance Number ...........................................................................14

CLM100 User’s Manual

Page iv Revision 1.0

4.5.2 Configuring Label..............................................................................................14

4.5.3 Units, Range, and Resolution ...........................................................................14

4.5.4 Configuring Distance at 4mA ............................................................................14

4.5.5 Configuring Distance at 20mA ..........................................................................15

4.5.6 Configuring Data Damping Period ....................................................................15

4.6 Configuring a Channel in Linear Velocity Mode...........................................................15

4.6.1 Configuring Instance Number ...........................................................................15

4.6.2 Configuring Label..............................................................................................15

4.6.3 Units, Range, and Resolution ...........................................................................15

4.6.4 Configuring Linear Velocity at 4mA...................................................................15

4.6.5 Configuring Linear Velocity at 20mA.................................................................16

4.6.6 Configuring Data Damping Period ....................................................................16

4.7 Configuring a Channel in Linear Acceleration Mode....................................................16

4.7.1 Configuring Instance Number ...........................................................................16

4.7.2 Configuring Label..............................................................................................16

4.7.3 Units, Range, and Resolution ...........................................................................16

4.7.4 Configuring Linear Acceleration at 4mA............................................................16

4.7.5 Configuring Linear Acceleration at 20mA..........................................................16

4.7.6 Configuring Data Damping Period ....................................................................17

4.8 Configuring a Channel in Angle Mode.........................................................................17

4.8.1 Configuring Instance Number ...........................................................................17

4.8.2 Configuring Label..............................................................................................17

4.8.3 Units, Range, and Resolution ...........................................................................17

4.8.4 Configuring Angle at 4mA.................................................................................17

4.8.5 Configuring Angle at 20mA...............................................................................17

4.8.6 Configuring Data Damping Period ....................................................................17

4.9 Configuring a Channel in Angular Velocity Mode.........................................................18

4.9.1 Configuring Instance Number ...........................................................................18

4.9.2 Configuring Label..............................................................................................18

4.9.3 Units, Range, and Resolution ...........................................................................18

4.9.4 Configuring Angular Velocity at 4mA.................................................................18

4.9.5 Configuring Angular Velocity at 20mA...............................................................18

4.9.6 Configuring Data Damping Period ....................................................................18

4.10 Configuring a Channel in Angular Acceleration Mode.......................................18

4.10.1 Configuring Instance Number ...........................................................................19

4.10.2 Configuring Label..............................................................................................19

4.10.3 Units, Range, and Resolution ...........................................................................19

4.10.4 Configuring Angular Acceleration at 4mA .........................................................19

4.10.5 Configuring Angular Acceleration at 20mA .......................................................19

4.10.6 Configuring Data Damping Period ....................................................................19

4.11 Configuring a Channel in Temperature Mode...................................................19

4.11.1 Configuring Source ...........................................................................................19

4.11.2 Configuring Instance Number ...........................................................................20

4.11.3 Configuring Label..............................................................................................20

4.11.4 Units, Range, and Resolution ...........................................................................20

4.11.5 Configuring Temperature at 4mA......................................................................20

4.11.6 Configuring Temperature at 20mA....................................................................20

Revision 1.0 Page v

4.11.7 Configuring Data Damping Period ....................................................................21

4.12 Configuring a Channel in Humidity Mode..........................................................21

4.12.1 Configuring Source ...........................................................................................21

4.12.2 Configuring Instance Number ...........................................................................21

4.12.3 Configuring Label..............................................................................................21

4.12.4 Units, Range, and Resolution ...........................................................................21

4.12.5 Configuring Humidity at 4mA ............................................................................21

4.12.6 Configuring Humidity at 20mA ..........................................................................22

4.12.7 Configuring Data Damping Period ....................................................................22

4.13 Configuring a Channel in Resistance Mode......................................................22

4.13.1 Configuring Instance Number ...........................................................................22

4.13.2 Configuring Label..............................................................................................22

4.13.3 Units, Range, and Resolution ...........................................................................22

4.13.4 Configuring Resistance at 4mA.........................................................................22

4.13.5 Configuring Resistance at 20mA.......................................................................22

4.13.6 Configuring Data Damping Period ....................................................................23

4.14 Configuring a Channel in Strain Gauge Mode...................................................23

4.14.1 Configuring Instance Number ...........................................................................23

4.14.2 Configuring Label..............................................................................................23

4.14.3 Units, Range, and Resolution ...........................................................................23

4.14.4 Configuring Strain gauge at 4mA......................................................................23

4.14.5 Configuring Strain gauge at 20mA....................................................................23

4.14.6 Configuring Data Damping Period ....................................................................23

4.15 Configuring a Channel in Force (Load Cell) Mode............................................24

4.15.1 Configuring Instance Number ...........................................................................24

4.15.2 Configuring Label..............................................................................................24

4.15.3 Units, Range, and Resolution ...........................................................................24

4.15.4 Configuring Force (Load Cell) at 4mA...............................................................24

4.15.5 Configuring Force (Load Cell) at 20mA.............................................................24

4.15.6 Configuring Data Damping Period ....................................................................24

4.16 Configuring a Channel in Pressure Mode .........................................................24

4.16.1 Configuring Source ...........................................................................................25

4.16.2 Configuring Instance Number ...........................................................................25

4.16.3 Configuring Label..............................................................................................25

4.16.4 Units, Range, and Resolution ...........................................................................25

4.16.5 Configuring Pressure at 4mA............................................................................25

4.16.6 Configuring Pressure at 20mA..........................................................................26

4.16.7 Configuring Data Damping Period ....................................................................26

4.17 Configuring a Channel in Decibel Mode............................................................26

4.17.1 Configuring Instance Number ...........................................................................26

4.17.2 Configuring Label..............................................................................................26

4.17.3 Units, Range, and Resolution ...........................................................................26

4.17.4 Configuring Decibel at 4mA ..............................................................................26

4.17.5 Configuring Decibel at 20mA ............................................................................26

4.17.6 Configuring Data Damping Period ....................................................................27

4.18 Configuring a Channel in Rotational Rate Mode...............................................27

4.18.1 Configuring Instance Number ...........................................................................27

CLM100 User’s Manual

Page vi Revision 1.0

4.18.2 Configuring Label..............................................................................................27

4.18.3 Units, Range, and Resolution ...........................................................................27

4.18.4 Configuring Rotational Rate at 4mA..................................................................27

4.18.5 Configuring Rotational Rate at 20mA................................................................27

4.18.6 Configuring Data Damping Period ....................................................................27

5Maintenance.......................................................................................................................28

6Troubleshooting .................................................................................................................28

7Technical Specifications.....................................................................................................29

8Technical Support..............................................................................................................30

9Installation Template..........................................................................................................31

10 Maretron (2 Year) Limited Warranty...................................................................................32

Table of Figures

Figure 1 –Mounting the CLM100 .............................................................................................. 6

Figure 2 –NMEA 2000®Connector Face Views ....................................................................... 7

Figure 3 –4-20mA Transducer Connection Diagram ................................................................ 8

Figure 4 –Troubleshooting Guide ........................................................................................... 28

Figure 5 –Mounting Surface Template ................................................................................... 31

Table of Appendices

Appendix A –NMEA 2000®Interfacing....................................................................................A1

Revision 1.0 Page 1

1 General

1.1 Introduction

Congratulations on your purchase of the Maretron Current Loop Monitor (CLM100). Maretron

has designed and built your monitor to the highest standards for years of reliable, dependable,

and accurate service.

Maretron’s CLM100 converts commercially available 4-20mA transducers into digital data so a

wide variety of information can be displayed on compatible NMEA 2000®displays. Numerous

4-20mA transducers are supported by the CLM100 including transducers for monitoring DC

voltage and current, flow rate, distance, linear velocity and acceleration, angle, angular velocity

and acceleration, temperature, humidity, resistance, strain gauges, force (load cell), pressure,

decibels, and rotational rate. Some typical applications where the CLM100 is used together

with a commercial available 4-20mA transducer include machinery monitoring using

accelerometers and vibration sensors. Vibration monitoring of pumps, motors, fans,

compressors, and gear boxes provides an early warning of potential problems resulting fewer

breakdowns and reduced maintenance expenses. Another application example using the

CLM100 is shaft speed monitoring. A commercially available 4-20mA rotational rate sensors is

coupled to the shaft of interest and the CLM100 converts the transducer to an RPM that can

be read on by a compatible NMEA 2000®display. And if you’re concerned about the force

exerted on a mast stay or perhaps a vessel tow attachment point, commercially available

clevis pins with 4-20mA interface can be connected to the CLM100 and the corresponding load

monitored using any of Maretron’s display products.

The Maretron CLM100 is designed to operate within the harsh demands of the marine

environment. However, no piece of marine electronic equipment can function properly unless

installed, calibrated, and maintained in the correct manner. Please read carefully and follow

these instructions for installation, calibration, and usage of the Maretron CLM100 in order to

ensure optimal performance.

1.2 Firmware Revision

This manual corresponds to CLM100 firmware revision 1.0.0.

1.3 Features

The Maretron CLM100 has the following features:

NMEA 2000®interface

Adapts up to six 4-20mA transducers to the NMEA 2000 network

Each channel independently programmable to transmit the following parameters:

oDC Voltage

oDC Current

oFlow Rate

oDistance

oLinear Velocity

oLinear Acceleration

oAngle

CLM100 User’s Manual

Page 2 Revision 1.0

oAngular Velocity

oAngular Acceleration

oTemperature

oHumidity

oResistance

oStrain Gauge

oForce (Load Cell)

oPressure

oDecibels

oRotational Rate –can be used to monitor shaft speed or engine RPM

1.4 CLM100 Accessories

Maretron offers the following pressure transducer accessories for the CLM100:

PT-V-0-1BAR-01 Pressure Transducer Vacuum to 1 Bar (14.5 PSI)

PT-0-3PSI-01 Pressure Transducer 0 to 3 PSI (0.21 bar)

PT-0-5PSI-01 Pressure Transducer 0 to 5 PSI (0.34 bar)

PT-0-10PSI-01 Pressure Transducer 0 to 10 PSI (0.69 bar)

PT-0-50PSI-01 Pressure Transducer 0 to 50 PSI (3.45 bar)

PT-0-100PSI-01 Pressure Transducer 0 to 100 PSI (6.89 bar)

PT-0-300PSI-01 Pressure Transducer 0 to 300 PSI (20.68 bar)

PT-0-500PSI-01 Pressure Transducer 0 to 500 PSI (34.47 bar)

PT-0-1000PSI-01 Pressure Transducer 0 to 1000 PSI (68.95 bar)

PT-0-3000PSI-01 Pressure Transducer 0 to 3000 PSI (206.84 bar)

PT-0-5000PSI-01 Pressure Transducer 0 to 5000 PSI (344.74 bar)

PT-SNUB-01 Pressure Snubber

WARNING

Maretron pressure transducers are not approved for use with gasoline. If

you wish to use the CLM100 to monitor pressures of gasoline, you must

obtain a pressure transducer that is approved for use with gasoline.

For other parameters, Maretron does not offer any accessories for the CLM100; however, the

CLM100 is compatible with any transducer which offers an industry standard 4-20mA current

loop interface and is able to operate with a current loop excitation voltage of 12-15VDC.

1.5 Quick Install

Installing the Maretron CLM100 involves the following steps. Please refer to the individual

sections for additional details.

1. Unpack the Box (Section 3.1)

2. Choose a Mounting Location (Section 3.2)

3. Mount the CLM100 (Section 3.3)

Revision 1.0 Page 3

4. Connect the CLM100 (Section 3.4)

5. Configure or Program Each Channel (Section 4.1)

1.6 Theory of Operation

The CLM100 operates by measuring the current transmitted by 4-20mA current loop

transducers. The current reading is translated to a parameter value according to the channel’s

operating mode as well as the 4mA and 20mA parameter calibration values.

The CLM100 can be used with either 2-wire or 4-wire 4-20mA current loop transducers.

Standard NMEA 2000 messages are used for parameters wherever possible. Proprietary

messages are used for other parameters.

Parameter

PGN

DC Voltage

127751 DC Voltage/Current

DC Current

127751 DC Voltage/Current

Flow Rate

65286 Fluid Flow Rate (Maretron Proprietary)

Distance
