Marquis Spas Destiny User manual

WELCOME TO THE SPA LIFE!
We sincerely hope your spa life is a pleasant experience. If problems
should arise, contact your authorized Marquis Spas®dealer. Or contact
Marquis Corp. at any of the following:
Email: [email protected]
Web: www.marquisspas.com
Marquis Corp.
596 Hoffman Road
Independence, OR 97351, USA
This manual is provided to enhance your enjoyment of your spa and to
prevent non-warranty situations. It is your sole responsibility to read,
understand and comply with the instructions in the owner’s manual. Please
save your original sales receipt for reference in case of a future warranty
claim. Failure to use, maintain or install the spa in compliance with this
owner’s manual could result in loss of warranty coverage.
SERIAL NUMBER LOCATION
You will find the serial number on the Underwriters Laboratories tag in the
equipment area.
PLEASE FILL OUT AND KEEP FOR FUTURE REFERENCE
Name of Purchaser_________________________________________________________
Date of Purchase ________________________________________________________
Address _________________________________________________________________
City _________________________________State _________Zip Code ____________
Telephone ______________________________________________________________
Spa Model/Color ________________________________________________________
Spa Serial # _____________________________________________________________
Pack Serial # ____________________________________________________________
Dealer’s Name __________________________________________________________
Dealer’s Address ________________________________________________________
City ____________________________________State_______Zip Code_____________
Telephone ________________________________________________________________
Every effort has been made to ensure the accuracy of this manual. How-
ever, Marquis Spas®reserves the right to improve its product without
notice. This could create a minor variation between this manual and the
actual product you receive. We apologize for any inconvenience this may
cause.
1
OWNER’S MANUAL

IMPORTANT SAFETY INSTRUCTIONS
120V, Cord Connected Models .................................................................. 3
240V, Permanently Installed or Converted Models ............................. 4
All Spa Models ..................................................................................................4-5
Personal Safety ................................................................................................6-7
INSTALLATION INSTRUCTIONS
Location ..............................................................................................................8-9
Filter Cartridges ................................................................................................ 10
Electrical Requirements ................................................................................ 11-13
STARTING YOUR SPA ..................................................................................14-16
2008 SPA MODELS ....................................................................................... 17-37
Destiny ................................................................................................................17-18
Envy .................................................................................................................... 19
Epic ...... ............................................................................................................... 20-21
Euphoria ............................................................................................................. 22-23
Mirage ................................................................................................................. 24-25
Promise .............................................................................................................. 26-27
Quest .................................................................................................................. 28-29
Rendezvous .....................................................................................................30
Resort ................................................................................................................. 31-32
Retreat ................................................................................................................ 33
Reward ............................................................................................................... 34-35
Spirit ..................................................................................................................... 36-37
SPA CONTROL OPERATION
All Models .......................................................................................................... 38-42
Destiny and Epic Marquis Signature Collection ..................................... 43-47
Remote Controls..............................................................................................47
Soundsations™................................................................................................ 49-50
AdagioTM ............................................................................................................. 51
EQUIPMENT DIAGRAMS
Envy, Mirage, Promise, Quest, Rendezvous, Retreat, and Spirit ......52
Destiny, Epic, Euphoria, Resort, and Reward ......................................... 53
TROUBLESHOOTING ................................................................................... 54-57
LCD Diagnostic Messages ...........................................................................55-57
MARQUIS CARE AND ENJOYMENT GUIDE .....................................58-65
MAINTENANCE ................................................................................................66-70
SPABOUTIQUE™.............................................................................................. 71
OWNER’S PROTECTION PLAN ............................................................... 72-74
OWNER’S MANUAL
2
OWNER’S MANUAL INDEX

The following instructions are required to be printed by Underwriters
Laboratories (UL) as a condition of the listing of this product. They contain
important safety information. We strongly encourage you to read and
apply them.
IMPORTANT SAFETY
INSTRUCTIONS
WHEN INSTALLING AND USING THIS ELECTRICAL EQUIP-
MENT, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE
FOLLOWED, INCLUDING THE FOLLOWING:
1. READ AND FOLLOW ALL
INSTRUCTIONS
2. WARNING: To reduce the risk of injury, do not permit children to use
this product unless closely supervised at all times.
3. DANGER: RISK OF CHILD DROWNING. Extreme caution must be
exercised to prevent unauthorized access by children. To avoid acci-
dents, ensure that children cannot use the spa or hot tub unless they
are supervised at all times.
120 VOLT, CORD CONNECTED MODELS
4. DANGER: RISK OF INJURY. Connect only to a grounded source.
5. Do not bury the power cord.
6. WARNING: To reduce the risk of electric shock, replace a damaged cord
immediately.
7. A ground terminal (pressure wire connector) is provided on the surface
of the control box inside the equipment compartment. This connector
should be bonded with a minimum No. 8 AWG (8.4mm2) (No. 6 AWG in
Canada) solid copper wire between this unit and any metal ladders, metal
water pipes, metal enclosures of electrical equipment, conduit, or metal
equipment within five feet (1.5m) of the spa. If the spa is located on a
reinforced concrete pad, the reinforcing steel should also be bonded to
the ground terminal.
8. WARNING: Your spa may be equipped with a ground fault circuit
interrupter (GFCI) on the end of the power supply cord. Before each use
of the spa, with the plug connected to the power supply and the unit
operating, press the “test” button. The unit should stop operating and the
GFCI power indicator will go out. Wait thirty seconds and then reset the
GFCI by pressing the “Reset” button. The GFCI power indicator will turn
on, restoring power to the spa. If the interrupter does not perform in this
manner, it is an indication of an electrical malfunction and the possibility
of an electric shock. Disconnect the plug from the receptacle until the
fault has been identified and corrected.
3
SAFETY INSTRUCTIONS

240 VOLT, PERMANENTLY INSTALLED OR CONVERTED MODELS
9. A ground terminal is provided on the terminal block (TB-1, terminal 7)
located inside the control box. To reduce the risk of electric shock,
connect this terminal to the grounding terminal of your electrical service
or supply panel with a continuous green, insulated copper wire. The
wire must be equivalent in size to the circuit conductors supplying the
equipment. In addition, a bonding terminal (pressure wire connector) is
provided on the outside of the control box for bonding to local ground
points. To reduce the risk of electric shock, this connector should be
bonded with a No. 8 AWG (8.42mm2) (No. 6 AWG in Canada) solid
copper wire to any metal ladders, water pipes, or other metal within five
feet (1.5m) of the spa to comply with local requirements.
10. Your spa uses ground fault circuit interrupters in the electrical sub-panel.
Before each use of the spa and with the unit operating press the Test
button on each breaker. The switch should click over to the “Trip”
position. Wait thirty seconds and reset each GFCI breaker by switching
it completely off and then completely on. The switch should then stay
on. If either of the interrupters does not perform in this manner, it is an
indication of an electrical malfunction and the possibility of an electric
shock. Disconnect the power until the fault has been identified and corrected.
ALL SPA MODELS
11. Install the spa so proper drainage is provided.
12.DANGER: RISK OF ELECTRIC SHOCK. Install the spa at least five
feet (1.5m) away from metal surfaces, in accordance with the National
Electric Code ANS/NMFPA70-1993. Each metal surface must be
permanently connected to a minimum No. 8 (8.42mm2) (No. 6 AWG in
Canada) solid copper conductor attached to the wire bonding connector
on the terminal box provided for this purpose.
13. DANGER: RISK OF ELECTRIC SHOCK. Do not permit any appliance,
such as a light, telephone, radio, or television, etc. within five feet (1.5m)
of the spa or hot tub.
14.WARNING: To reduce the risk of injury:
• Water temperatures between 100°F (38°C) and 104°F (40°C) are
considered safe for a healthy adult. Lower water temperatures are
recommended for extended use (exceeding 10 minutes) and for young
children.
• Since excessive water temperatures have a high potential for causing
fetal damage during the early months of pregnancy, pregnant or
possibly pregnant women should limit spa water temperatures to
100°F (38°C).
• Before entering a spa, the user should measure the water temperature
with an accurate, waterproof, fever thermometer since the tolerance of
temperature-regulating devices may vary as much as +/- 5°F (3°C).
• The use of drugs, alcohol, or medication before or during spa use may
lead to unconsciousness with the possibility of drowning.
• Persons suffering from obesity or with a medical history of heart
disease, low or high blood pressure, circulatory system problems, or
diabetes should consult a physician before using the spa.
4
SAFETY INSTRUCTIONS

• Persons using medications should consult a physician before using a
spa since some medication may induce drowsiness while other
medication may affect heart rate, blood pressure, and circulation.
15.DANGER: TO REDUCE THE RISK OF INJURY TO PERSONS. Do
not remove the suction fittings.
16.DANGER: RISK OF INJURY: Never operate a spa if the suction
guard(s) is broken or missing. Never replace a suction guard with one
rated less than the flow rate marked on the original suction guard. The
suction guard(s) in the spa are sized to match the specific water flow
created by the pump. Should the need arise to replace the suction
guard(s) or the pump, be sure that the flow rates are compatible.
17.DANGER: Children are especially sensitive to hot water. At no time
should children have unsupervised access to the spa. Children must not
be allowed to climb onto the spa cover. All Marquis spas are equipped
with a locking cover that meets the ASTM F1346-91 Standard for Safety
Covers. Always lock the child resistant locks after using the spa for your
children’s safety.
18. SAVE THESE INSTRUCTIONS.
WARNING: Do not permit electric appliances (such as a light, telephone,
radio, or televsion) within five feet (1.5m) of ths spa or hot tub.
WARNING: Children should not use spas or hot tubs without adult
supervision.
WARNING: Do not use spas or hot tubs unless all suction guard(s) are
installed to prevent body and hair entrapment.
WARNING: Do not use drugs or alcohol before or during the use of a
spa or hot tub to avoid unconsciousness and possible drowning.
WARNING: People using medications and/or having an adverse
medical history should consult a physician before using a spa.
WARNING: The use of alcohol, drugs, and medication can greatly
increase the risk of fatal hyperthermia.
WARNING: Before entering the spa or hot tub measure the water
temperature with an accurate thermometer.
WARNING: Water temperature in excess of 104°F (40°C) may be
injurious to your health.
WARNING: Prolonged immersion in a spa or hot tub may be injurious to
your health.
WARNING: People with infectious diseases should not use a spa.
WARNING: Pregnant or possibly pregnant women should consult a
physician before using a spa or hot tub.
WARNING: To avoid injury, exercise care when entering and exiting the
spa or hot tub.
WARNING: Do not use a spa or hot tub immediately following
strenuous exercise.
WARNING: Maintain water chemistry in accordance with
manufacturer’s instructions.
5
SAFETY INSTRUCTIONS

SAFETY INSTRUCTIONS FOR FRENCH SPEAKING SPA OWNERS
AVERTISSEMENT: Ne pas placer d’appareil électrique (luminaire,
téléphone,radio, téléviseur, etc.) moins de 1.52 m de cette cuve de
relaxation.
AVERTISSEMENT: Ne pas laisser les enfants utiliser une cuve de relax-
ation sans surveillance.
AVERTISSEMENT: Pour éviter que les cheveux ou une partie du corps
puissent être aspirés, ne pas utiliser une cuve de relaxation si les grilles de
prise d’aspiration ne sont pas toutes en place.
AVERTISSEMENT: Pour éviter l’évanouissement et la noyade éventuelle,
ne prendre ni drogue ni alcool avant d’utiliser une cuve de relaxation ni
quand on s’y trouve.
AVERTISSEMENT: Les personnes qui prennent des médicaments ou ont
des problemès de santé devraient consulter un médecin avant d’utiliser
une cuve de relaxation.
AVERTISSEMENT: La consommation d/alcool ou de drogue augmente
considérablement les risques d’hyperthermie motrelle dans une cuve de
relaxation.
AVERTISSEMENT: Avant d’utiliser une cuve de relaxation mesurer la
température de l’eau l’aide d’un thermométre précis.
AVERTISSEMENT: Il peut être dangereux pour la santé de se plonger
dans de l’eau plus de 40°C.
AVERTISSEMENT: L’utilisation prolongée d’une cuve de relaxation peut
être dangereuse pour la santé.
AVERTISSEMENT: Les personnes atteintes de maladies infectieuses ne
devraient pas utiliser une cuve de relaxation.
AVERTISSEMENT: Les femmes enceintes, que leur grossesse soit
confirmée ou non, devraient consulter un médecin avant d’utiliser une
cuve de relaxation.
AVERTISSEMENT: Pour éviter des blessures, user de prudence en
entrant dans une cuve de relaxation et en sortant.
AVERTISSEMENT: Ne pas utiliser une cuve de relaxation immédiatement
aprés un exercice fatigant.
ATTENTION: La tenteur de l’eau en matières dissoutes doit être
conforme aux directives du fabricant.
PERSONAL SAFETY
Prolonged immersion in hot water can result in HYPERTHERMIA, a danger-
ous condition which occurs when the internal temperature of the body
reaches a level above normal (98.6°F, 37°C). The symptoms of hyperthermia
include dizziness, fainting, drowsiness, lethargy, and a body temperature
above 98.6°F (37°C). The physical effects of hyperthermia include unaware-
ness of impending hazard, failure to perceive heat, failure to recognize the
need to exit the spa, physical inability to exit the spa, fetal damage in preg-
nant women, and unconsciousness resulting in a danger of drowning.
6
SAFETY INSTRUCTIONS

Other booklets about spa safety are: “Children Aren’t Waterproof,” “Pool
and Spa Emergency Procedures For Infants and Children,” “Layers of
Protection” and “The Sensible Way to Enjoy Your Spa” published by APSP.
WARNING: The use of alcohol, drugs, or medication can greatly increase
the risk of fatal hyperthermia in hot tubs and spas.
Persons taking medications which induce drowsiness such as tranquilizers,
antihistamines, or anticoagulants should not use the spa. Pregnant women
and persons with a medical history of heart disease, diabetes, or high blood
pressure should consult a physician before using the spa.
PERSONAL SAFETY DOs:
• Be sure your spa is connected to the power supply correctly – only use
a licensed electrical contractor.
• Shut off power supply (unplug 120V models) before draining the spa or
servicing the electrical components.
• Test the Ground Fault Circuit Interrupter (GFCI) monthly.
• Always test the water temperature with an accurate thermometer
before entering the spa to be sure that it’s a safe temperature.
• Do not use the spa if water temperature is outside of set temperature.
Remember that wet surfaces can be very slippery. Take care when
entering and exiting the spa.
• Lock the DuraCover when the spa is not in use, whether it is empty or
full of water.
• Keep the water clean and sanitized with correct chemical care.
• Turn on the jets when adding ANY chemicals to the spa water.
• Clean the filter cartridge(s) monthly to remove debris and mineral
buildup which affects the performance of the hydrotherapy jets, limits
the flow, or trips the high limit thermostat which will turn off the entire
spa.
PERSONAL SAFETY DO NOTs:
• Don’t use the spa with the equipment compartment door removed.
• Don’t use the spa for more than 10 minutes of time at water tempera-
tures in excess of 102°F (39°C).
• Don’t allow the jet pump(s) to operate for an extended period of time
with the cover in place. Extended pump operation causes a slow heat
buildup due to water friction. The spa equipment controls are equipped
with a built-in safety timer that automatically shuts off the jet pump(s)
after 15 minutes of continuous operation should it have been left on
inadvertently.
• Don’t operate the spa at any time with the filter cartridges removed.
• Don’t lift or drag the cover by using the tie-down straps; always lift and
carry by using the external handles.
• Don’t store chemicals in the spa’s equipment compartment.
• Don’t hesitate to call your authorized dealer with any questions or
maintenance concerns.
7
SAFETY INSTRUCTIONS

LOCATION
For your portable spa to function properly and safely, it must be located on a
hard, flat, level surface. Inground spas require special installation techniques
and should be planned in conjunction with your authorized Marquis Spas®
dealer. Improper installation can result in structural damage to the spa and
the voiding of your spa warranty. Items to discuss with your dealer include:
Local construction codes, electrical service requirements, serviceability of
equipment, present underground obstructions such as gas, water, and
telephone lines, safety measures such as fences and locks, and visibility of
the spa installation from the home, street, and neighbors.
Do not shim your spa. If your pad is not level you must pour a top cap: contact a
professional.
• Allow for sufficient water drainage around the spa to help preserve the
equipment and support structure. This includes indoor installations.
• A filled spa can weigh up to 4,000 pounds and the location should
support the weight of the filled spa.
• Locate the equipment compartment where it will be accessible. Your
spa MUST be installed to permit access for servicing the equipment
above and/or below any decks or floors. Access is essential and must
allow adequate room for service. To facilitate repairs, Marquis Corp. or its
agent may require access to spa equipment. It is your responsibility to provide
unencumbered access. See spa diagrams for location of power supply.
• Leave access to the circuit breakers in the sub panel (240V models) or
to the interrupter switch (GFCI, 120V models) on the end of the power
cord.
• Be sure the spa is level and in the final position BEFORE filling with
water. Check for power cords, tools, and hoses that may be caught
underneath the spa. Do not apply power to the spa before it is completely
filled with water. Damage to the pumps, heater and sensors may result.
•IMPORTANT: DO NOT LET AN EMPTY SPA REMAIN EXPOSED
TO DIRECT SUNLIGHT.
Spa surface temperatures can reach in excess of 150°F (65°C) if left
exposed to the sun. Significant damage can occur if this is allowed to
happen, including warping and blistering of the surface. Damage, that
occurs as a result of this exposure, is not covered under the warranty.
•CAUTION: Never try to move a spa that has not been fully drained. To
do so could result in damage to the spa and physical injury to the
mover. Cracks in the spa surface, exterior siding or DuraBase due to
improper transport or support of the spa are not covered under the warranty.
8
INSTALLATION INSTRUCTIONS

OUTDOOR AND PATIO INSTALLATION
To install the spa outdoors, we recommend a reinforced concrete pad at
least four inches thick. The reinforcing material should be attached to a #8
AWG bonding wire per national and local electrical code.
If you place the spa on the ground, even temporarily, place the spa empty
of water on concrete pavers under the entire bottom of the spa. The
concrete pavers should be a least two inches thick and level across the
entire surface. The spa will inevitably settle and not remain level on this
surface, thus it’s important to get the spa onto a solid foundation as soon
as possible.
DECK INSTALLATION
Be sure the deck can support the weight of your filled spa by checking the
deck’s maximum load capacity. Consult a qualified building contractor or
structural engineer. Minimum requirement is 100 pounds per square foot.
INDOOR INSTALLATION
There are special requirements if you place your spa indoors. Flooring
material must provide adequate traction when wet. Proper drainage is
essential to prevent water puddling. Proper ventilation to the area is re-
quired. The addition of a ventilation system is recommended. Please see
your contractor for details.
INSTALLATION INSTRUCTIONS
9
OUTDOOR & PATIO INSTALLATION

SHUT-OFF VALVES
Your spa is equipped with shut-off valves (see
EQUIPMENT DIAGRAM) that shut off the water flow
to the equipment system for authorized Marquis
Spas®dealer service. At times, a new spa or one that
has recently been serviced, may have the shut-off
valves partially closed which can restrict the water
flow and hinder jet performance. Be sure the valves
are fully open.
FREEZE PROTECTION
When a freeze condition is detected (which occurs
when the temperature in the heater housing drops
to 55°F, (13°C) the jet pump(s) is automatically acti-
vated. In areas with extremely cold winter conditions,
your spa should be fine as long as it is left running at
normal operating temperatures. For extra protection
see your dealer for an optional freeze sensor. If you
plan to turn the spa off, follow the instructions in this
manual (see SUSPENDED USE OR WINTERIZING
YOUR SPA).
OVERHEATING
In the case of extended hot weather, the spa water
temperature may reach and maintain 104°F to 106°F
(40°C to 41°C) or higher. This is due to the ambient
temperature and the full insulation in the spa cabi-
net. You may have the option of shortening the
pump-run time. See SPA CONTROL OPERATION for
available options.
FILTER CARTRIDGES
Your portable spa is equipped with the Constant-
Clean™ Filtration system. It features one or two
Vortex filters.
NOTE: It is very important that the components of
these filtration systems be installed properly in the
proper part of the spa.
1. Hold the Vortex filter cartridge and center it in
the opening of the filter housing.
2. Use the filter handle and turn the filter cartridge
clockwise to screw it in place. (Use caution not
to overtighten as damage may occur to
threads and is not covered under warranty.)
3. Grasp the edge of the Vortex skimmer lid or
Waterfall, center it over the rings and gently snap
in place.
Shut-off valve in
open position
1) Center filter
cartridge over canister
2) Screw filter
cartridge in place
10
INSTALLATION INSTRUCTIONS

SUCTION GUARDS
The suction guard(s) in the footwell of your spa is an
opening through which the jet pump(s) draws water.
Suction fittings are equipped with a safety guard.
Suction through the fittings can be strong. The safety
guard(s) must remain in place and undamaged. A
fitting with a damaged guard(s) can be dangerous,
especially to small children or people with long hair.
Should any part of the body become drawn to a
fitting, turn the jet pump(s) off immediately. Long hair
should be restrained. Never allow long hair to float
freely in the spa. Replace any missing or damaged
suction guard(s).
NOTE: It is normal for the flow rates of the suction
fittings to vary from strong to barely noticeable.
ELECTRICAL REQUIREMENTS
It is the responsibility of the spa owner to ensure that
all electrical connections are made by a qualified
electrician in accordance with all national, state, and
local electrical codes in effect at the time of installation.
The recommended spa operating environment is -
5°C to +45°C, at 20-80 percent of relative humidity.
Fuses are covered to be free of defect at time of
installation only.
240 Volt
All connections must be made in accordance with
the wiring diagram found on the inside of the control
box cover. Connections must be made with copper
conductors only – do NOT use aluminum wire. All
conductors, circuit breakers, and fuses and the GFCI
must be sized in accordance to the total amperage
load as specified below.
Improperly wired spas can cause irreversible damage
resulting in blown fuse and melted terminal block, and
to other electrical components. Also, damage caused
to components or equipment caused by high or low
voltage, brown outs or electric surges is not covered
under warranty.
• Permanently connected (Hard wired).
• Rated 240V, 60Hz, 50A, three wires (#6 copper)
plus ground (#8 copper), [4 wires total].
• Circuit breaker or fuse size: 50A.
• A disconnecting means must be installed within
sight from the equipment and at least 5 feet (1.52m)
from the inside walls of the spa.
• Connect only to a circuit protected by a Class A
ground Fault Circuit Interrupter (GFCI).
Safety guard of
suction fitting must
remain in place.
11
INSTALLATION INSTRUCTIONS

• For units used in other than single-family dwellings, a clearly labeled emer
gency switch shall be provided as part of the installation. The switch shall be
readily accessible to the occupants and shall be installed at least five feet (1.52
m) away, adjacent to, and within sight of the unit.
• A pressure wire connector is provided on the exterior of the control box to
allow connection of a bonding wire to any metal ladder, metal water pipe,
common bonding grid (reinforced concrete slab, ground plate beneath the
spa), or any other metal within 5 feet (1.52 m) of the spa. The bonding wire
shall be copper and at least #8 AWG (8.42mm²), #6 in Canada.
NOTE: Ensure the GFCI is properly installed. Failure to do so may result in spa
malfunction or damage which is not warranted. Ground Fault Circuit Interrupters
are available from your Marquis Spas dealer.
!!
!!
! AA
AA
ATTENTIONTTENTION
TTENTIONTTENTION
TTENTION The Epic and Destiny models are equipped with
a GFCI Trip Test that must be performed to assure safety and allow proper spa
function.
AUTOMATIC TEST: Approximately 24 hours following startup, the spa will trip the
GFCI, testing it to insure it is functioning properly (do not call your dealer; this is a
signal that the spa is wired correctly). After the trip test is complete, reset the GFCI
as per the manufacturer’s instructions and the spa will function normally.
-OR- MANUAL TEST: The installer can manually initiate the GFCI Trip Test at start
up with a button sequence on the control panel.
1. Press TEMP+, then JETS 1, then SPA LIGHT.
2. Press TEMP+ repeatedly until “gFC” is displayed, then press JETS 1.
3.Press TEMP+ until “Gt.n” is displayed, then press JETS 1 to initiate the test.
The GFCI should trip within several seconds and the spa should shut down. After
the trip test is complete, reset the GFCI as per the manufacturer’s instructions and
the spa will function normally. If the test does not trip theGFCI, manually shut
down the power and verify that a GFCI breaker is installed and that the circuit,
GFCI, and spa are wired correctly. Restore power to the spa and verify the
function of the GFCI with its own test button. Reset the GFCI and repeat the GFCI
Trip Test.
After passing the GFCI trip test, subsequent GFCI trips indicate a ground fault or
other unsafe condition, requiring the power to the spa to be shut off. You can
verify a successful test by navigating to the “gFC” item as described above,
pressing JETS 1 and then pressing TEMP+ until you see “gS.P”, a code that
signifies “GFCI Status – Passed”.
WARNING: The GFCI Trip Test does NOT take the place of locating,
testing, and resetting the GFCI on a regular basis to verify its function.
If the spa is to be rewired, moved, or resold, the GFCI Trip Test should be reset so
it will test the new GFCI. The “GFCI status – Passed” must be cleared before the
test can be run.
12
INSTALLATION INSTRUCTIONS

1. Press TEMP+, then JETS 1, then SPA LIGHT.
2. Press TEMP+ repeatedly until “gFC” is displayed, then press JETS 1.
3. Press TEMP+ until “gC.n” is displayed, then press JETS 1 to clear the GFCI
Status; you will see gS.A” displayed verifying that the GFCI Status has been
set to “Armed”. The system will exit this menu in 30 seconds if no buttons are
pressed.
*When you enter the GFCI menu, it always shows you the current status first.
“gS.P” means that it’s Passed (and will do no further automated GFCI Trip Tests),
“gS.A” means that it’s Armed (and will do an automated GFCI Trip Test in 24
hours, unless a manual GFCI Trip Test is done before that). (“gS.t”, which you are
unlikely to see unless you’ve just initiated a Trip manually, means that it’s about to
Trip within the next dozen seconds or so.)
120 Volt
120 Volt spas shall be plugged into a properly grounded, grounding type 15 amp
receptacle on a dedicated circuit. A dedicated circuit is a circuit with no other
components that consume power, such as lights, televisions, radios, computers,
or other electronic devices. These could cause your spa to malfunction by any
of the following: unusual text on the control panel, slow heating, poor jet action,
tripping house breaker, or blown fuses. Failure to follow these instructions could
lead to premature failure of spa components that would not be covered under
the warranty. The dedicated circuit shall meet the following specifications:
• Rated 120V, 60Hz, 15A (2 wires plus ground)
• Circuit breaker or fuse size: 15A
• The receptacle must be at least 5 feet (1.52 m) from
the spa.
• The 15 foot GFCI power cord provided with the
spa must be plugged directly into the receptacle.Do
NOT use an extension cord or any other adaptor.
Actual exposed length of cord will vary by model,
but will never be less than 12 feet.
Convert 120 Volt to 240 Volt
120 Volt spas may be converted to operate on 240V, 50A. All connections must
be made by a licensed electrician.
1. Disconnect the power by unplugging the power cord from the receptacle,
removing the cord from the terminal block on the circuit board, and storing it
with your owner’s manual.
2. Locate the white wire connecting J11 to J32 on the circuit board. Remove the
wire and discard.
3. For 50A operation, move dip switch 10 to the OFF position.
4. Install 240V power as indicated in the 240 Volt section.
5. Rated 240V, 60Hz, 50A, three wires (#6 copper) plus ground (#8 copper), [4
wires total].
GFCIs are available from your authorized dealer.
Improperly wired spas are beyond Marquis Corp. control and are not covered
under the warranty. Other items beyond Marquis Corp. control include, but are
not limited to, damage resulting from: improper connections; accidents; failure to
follow procedures and instructions defined in the Marquis Spas®printed instruc-
tions; cleaning agents; and natural occurrences including but not limited to
rodent or insect infestation, mold, lightning and other acts of nature.
13
INSTALLATION INSTRUCTIONS

START-UP PROCEDURE
Your spa is equipped with solid-state Comfort Controls specific to your spa
model. (See SPA CONTROL OPERATION for your specific spa model.)
To start your spa, you need spa test strips. It is important to follow each of
these steps when starting your spa. Once you have completed the follow-
ing steps, see MARQUIS CARE AND ENJOYMENT GUIDE for proper
water treatment.
NOTE: Your spa has been filled and test-run at the factory. The first time
your spa is filled with water, some discoloration from residual test water
may appear. This will disappear when the spa is completely filled and the
filtration system is functioning.
WARNING: Spa must be completely filled with water before turning on
power.
Test the water for the proper chemical balance and adjust as necessary.
SpaCare products are recommended. (See WATER TREATMENT.)
PROPER CHEMICAL BALANCE IS IMPORTANT for your safety and
the longevity of your spa.
In the case of relocating your spa, it is imperative to follow the instructions in
the owner’s manual. These instructions must remain with the spa. Damage
caused by relocating spa is not covered under warranty.
THERAPY PUMP(S)
Allow the spa to circulate on high-speed (see SPA CONTROL OPERA-
TION) for four to five minutes to discharge air from the plumbing system.
Do not expect hot water immediately from the jets; the heater will take
several hours to heat the water.
Start-up procedure for all models
1. Place spa on a hard, flat, level surface. Make sure the power supply is
off.
2. Make sure the suction guard(s) in the footwell are in place and undam-
aged.
3. Open the equipment door. Tighten all disconnects and open all shut-off
valves.
NOTE: Keep the drain valve closed at all times except when draining the spa (do not
rely on the cap to stop the flow of water). Not doing so could result in damage to the
drain valve due to freezing water.
14
STARTING YOUR SPA

4. Install filter cartridges. (See INSTALLATION
INSTRUCTIONS, Filter Cartridges.)
5. Fill the spa with water to two-thirds of the way up
the Vortex skimmer openings. The use of a Fill Filter
is recommended, especially in areas with high
mineral content in the water.
6. Turn the power on.
7. Allow the spa to circulate on high-speed (see SPA
CONTROL OPERATION) for four to five minutes to
discharge air from the plumbing system. Do not
expect hot water immediately from the jets; the
heater will take several hours to heat the water.
8. Your spa is now in “pump priming” mode and a “Pr”
message displays in the LCD window of the control
panel. While in this mode the spa appears idle, which
lasts approximately four to five minutes if not exited
manually. To exit manually, press the TEMP pad.
9. At this time the spa should have water flowing
from the jets. If the pump has not primed andthe
water is not flowing from the jets after two minutes
TURN OFF POWER TO THE SPA and vent air from
the pumps by slightly opening the pump unions.
After turning the power on again, the spa initiates a
new priming mode. Repeat steps above.
10. The system requires approximately two minutes of
water flow to determine the water temperature.
After two minutes of water flow, the temperature is
displayed as actual water temperature. After you
have manually exited the priming mode (or allowed
the spa to automatically exit) the LCD window
momentarily displays 102°F (39°C) and then the
display switches to - - °F.
11. The factory default setting for water temperature is
102°F (39°C). Use the TEMP pad on the control
panel to set the water temperature to the desired
level. (See SPA CONTROL OPERATION.) Your spa
heats at the rate of approximately five degrees per
hour for 240V systems.
DURACOVER™
When the spa is not in use, the DuraCover should be
kept on the spa to retain the water’s heat and to
keep out dirt, leaves, etc.
For your safety and convenience, the cover is
equipped with adjustable straps, safety locks, and
handles. Use the exterior handles to remove and
replace your cover. Never attempt to open or remove
the cover by grasping or pulling on the cover skirting
or cover lock straps as the skirting will tear.
Vent air by slightly
opening pump unions.
Use TEMP pad to set
water temperature.
15
STARTING YOUR SPA
Fill spa with water to
two-thirds of the way
up the Vortex skimmer
opening.

Marquis suggests you use the safety locks to help keep out unintended
users and prevent covers from being blown off in windy conditions. The
cover and retractable cover system are not recommended for use in wind
conditions reaching above 25 miles per hour. If your spa is located in an
area susceptible to high winds, additional cover lock straps may be neces-
sary to minimize cover damage.
Open the spa cover:
1. Unfasten all cover lock straps.
2. Place one hand under the cover skirting, between the spa and cover,
to break the cover’s vacuum seal. Do not use cover handles to break
vacuum seal.
3. Fold the front half of the cover over onto the back half.
NOTE: Unlock and release all cover locks before attempting to open cover.
Damage caused by attempting to open the cover while locked or by wind is
not covered under warranty. Do not walk, stand, climb, or sit on the vinyl
cover or retractable cover system. Do not use hard, sharp, or metal objects,
such as a windshield scraper, to remove ice. Such objects can cut, mar, or
puncture the cover’s vinyl surface.
Close the spa cover:
1. Place one hand on the upper corner of the cover and gently push
forward in the direction of the spa. The cover will rotate forward to
cover half of the spa.
2. Unfold the cover by lifting the handle located on the top (front) half of
the cover. Allow the unfolded half to fall down onto the spa.
3. Secure the cover lock straps to the spa and lock them.
NOTE: When opening a cover with a cover removal mechanism, use one
of the manufacturer’s recommended methods. Do not attempt to open
the cover in any other way. Damage caused by improper opening or
closing of the cover is not covered under the warranty.
Fading, staining, torn stitching of the spa cover and broken foam cores are
not covered under the warranty if caused by improper use or maintenance.
Spa covers do not qualify for labor coverage under the warranty. These
parts can be purchased or exchanged under warranty at your authorized
Marquis Spas®dealer.
16
STARTING YOUR SPA

17
THE DESTINYTM
# Component Identification Qty.
1 HK™8 Jets 2
3 HK™16 Jets 17
4 HK™40 Jets 19
5 Light (option) 1
6 Air Controls 2
7 Suction Fittings 4
8 Floor Drain 1
9 Tri-Zone Controls 2
10 Neck Jet Valve 1
11 Bather’s Control Panel 1
12 Filter Canisters 2
13 Spa Frog®(option) 1
14 Spa Frog®Return Fitting (option) 1
15 Ozone Injector Fitting 1
16 Waterfall Feature (option) 1
17 Waterfall Valve (option) 1
18 AdagioTM Speakers (option) 2
19 ConstellationsTM (option) 22
20 Cushioned Headrests (option) 2
Physical Specifications Size
Dimensions 84" x 84"
Height 35"
Corner Radius 17"
Seating Capacity/Positions 7/7
Weight Dry/Lbs. 800
Weight Full/Lbs. 3885
Water Capacity/Gallons 370
Total Therapy Jets 38

INSTALLATION INSTRUCTIONS
18
DESTINYTM THERAPY CONTROL
ZONE 4
(pump 1)
Upper- and
mid-body
jets.*
ZONE 5
(pump 1)
Upper-, mid-,
and lower-
body jets.*
ZONE 6
(pump 1)
Lower-body
jets.*
ZONE 1
(pump 2)
Upper-body
jets.*
ZONE 2
(pump 2)
Upper-, mid-,
and lower-
body jets.*
ZONE 3
(pump 2)
Lower-body
jets.*
*HK8 neck
jets operate in
every zone.

19
THE ENVYTM
# Component Identification Qty.
1HK
TM8 Jets 3
2 HK™12 Jets 8
4 HK™40 Jets 3
5 Light (option) 1
7 Suction Fittings 2
8 Floor Drain 1
9 Jet Selector 1
11 Bather’s Control Panel 1
12 Filter Canister 1
13 Spa Frog®(option) 1
14 Spa Frog®Return Fitting (option) 1
15 Ozone-ready Injector Fitting 1
19 ConstellationsTM (option) 12
Physical Specifications Size
Dimensions 76" diameter
Height 35"
Seating Capacity/Positions 4/5
Weight Dry/Lbs. 550
Weight Full/Lbs. 2635
Water Capacity/Gallons 250
Total Therapy Jets 14
ATTENTION: If you have problems priming the pump use the black thumbscrew in the upper corner of the door
area to relieve the air lock to the pump. Use this solution as you are filling the spa or if the pump is running but no
water is coming out of the jets. Please refer to start up instructions in the Owner’s Manual.
1. Make sure the spa power is off.
2. Remove the door.
3. Remove the thumbscrew while filling the spa. (If spa is full remove the thumbscrew and let all air purge.)
4. Once air is purged replace the thumbscrew.
5. Power up the spa.
6. Make sure there are no leaks at the thumbscrew. Replace the door.

20
THE EPICTM
MARQUIS SPAS
# Component Identification Qty.
1 HK™8 Jets 6
3 HK™16 Jets 16
4 HK™40 Jets 35
5 Light (option) 1
6 Air Controls 2
7 Suction Fittings 4
8 Floor Drain 1
9 Tri-Zone Controls 4
10 Neck Jet Valves 3
11 Bather’s Control Panel 1
12 Filter Canisters 2
13 Spa Frog® (option) 1
14 Spa Frog®Return Fitting (option) 1
15 Ozone Injector Fitting 1
16 Waterfall Feature (option) 1
17 Waterfall Valve (option) 1
18 AdagioTM Speakers (option) 2
19 ConstellationsTM (option) 22
20 Cushioned Headrests (option) 3
Physical Specifications Size
Dimensions 90" x 90"
Height 35"
Corner Radius 17"
Seating Capacity/Positions 6/7
Weight Dry/Lbs. 850
Weight Full/Lbs. 4603
Water Capacity/Gallons 450
Total Therapy Jets 57
