Marshall Electronics M-CT5 User manual

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
Owner’s Manual
M-CT5
Camera-Top Monitor

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
2|
Dear users:
Thank you for purchasing Marshall’s M-CT5-CE6 HD DSLR LCD Moni-
tor. This 5” Pro HD LCD Monitor is designed to be used as an external
video display, allowing you to step back from the camera while still being
able to frame and capture the action without having to look through the
camera’s built-in viewfinder. It employs advanced integrated circuits, high
quality TFT LCD modules, and low power consumption.
This monitor is designed to be small, easily operated, and portable, with
HDMI, Composite Video, Audio Input and HDMI Output. This monitor can
be powered by the Canon E6 battery.
Product Advanced Features:
• Zoom mode
• HDMI input and output. Video Input and Audio input
• Viewfinder marked ranges:0%, 85%, 90%, 93%, 96%
• Cross the screen center mark
• 16:9 or 4:3 Aspect Ratio Setting
• Earphone stereo output.
• Brightness, Contrast, Hue, Saturation and Color Temperature Adjust-
ment
• Support Canon LP-E6 or equivalent
• Removable Sunhood

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|3
To ensure the best use of this product, please read this manual carefully
beforehand.
CAUTION
1. Please use the adapter attached in the accessory or another quali-
fied adapter.
2. Please do NOT expose this product to direct sunlight, heat, or humid
conditions.
3. Please keep away from strong light while using this product to en-
sure the image effect and long-term use.
4. Please avoid heavy impact or drop onto the ground.
5. Please do NOT use chemical solutions to clean this product. Please
wipe with a clean, soft cloth to maintain the brightness of the surface.
6. Please do not take apart or repair the unit by yourself to avoid dam-
age the product.
CONTENTS
1. Product description__________________________________4
Panel Instruction ____________________________________4
Back view _________________________________________5
1/4 inch standard screw bracket fixed hole picture _________5
Battery plate________________________________________6
Sunhood installation and removal _______________________6
2. Power input________________________________________7
3. Operating instructions _______________________________7
Panel shortcut button function instruction__________________7
Menu operating instruction ____________________________7
4. Parameters________________________________________11
5. Accessories _______________________________________12
6. Trouble shooting____________________________________12
7. Menu List _________________________________________13

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
4|
Panel Instruction
1. Volume down to adjust the value setting function
2. Volume up or to adjust the value setting function and activate the
volume adjust menu
3. MENU: To activate OSD menu
4. Menu navigation key up
5. Menu navigation key down
6. HDMI/Video selector key
7. Zoom - DSLR mode
8. Indicator light
9. Speaker
1 2 345 6 8
7
Product Description
9

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|5
Back view
10. HDMI input jack
11. HDMI output jack
12. 3.5mm headphone jack
13. Power on/off
14. Battery mount
15. DC12V input jack
16. Video In
17. Audio In
1/4inch Fixed hole
There is a 1/4 standard screw bracket fixed hole on the top and bottom of
the monitor for mounting the monitor and mounting accessories onto the
monitor.
1011
12 13
15
14
16
17

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
6|
Battery plate:
To power the monitor with the Canon LP-E6 (equivalent) battery.
Battery installation
Suggestion: Remove the battery for long periods of inactivity.
Sunhood installation and Removal
Attach the self adhesive side of the Velcro® to the side of the monitor.
battery plate
Side

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|7
2. Power input
The monitor can be powered by the enclosed CE6 or equivalent battery
or by a 12V power adapter (optional). Please note the input polarity is
Positive with respect to --○-+, otherwise will damage the monitor!
3. Operating instruction
3.1 Menu operating instructions
Before setting the menu functions, please make sure the device is
connected correctly. Power switch (lower right corner of the unit) dial
to ON position. The monitor enters into working state. Please dial to
OFF position when closing the unit. After enter into working state,
press the “mode” button on the unit, according to the input video sig-
nal to switch “HDMI,VIDEO” (under NO menu state, using the short-
cut button on the panel to operate). Press “MENU”button on the unit,
then enter into OSD menu operation. Operate “▲”or “▼”on the unit to
select or adjust the needed optionals.
(color); (menu); (function); (sound);
After selecting the optionals, press “►”or “◄” on the unit to confirm,
then using “▲” or “▼” to select or adjust the value of Analog Data. Af-
ter confirm the needed adjust parameters, using “►” or “◄” to adjust.
If you need to exit OSD menu, repress “MENU” button.
Color
Enter into “Color” OSD, press “◄”or “►” button to confirm, then enter to
adjust the color parameters, use “▲” or ”▼” to select adjustment item,
then use “◄” or “►” adjust the parameters.
¤ Brightness: To adjust the image’s brightness.
¤ Contrast: To adjust the brightest and darkest ratio of the image, please
note the sense of picture when adjust, proportion too large or small, will
make the picture lose the color of showy.
¤ Tint: On NTSC Video mode, the image color tint difference is
adjustable by tint.
¤ Saturation: To adjust color concentration.

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
8|
¤ Color temperature: Enter into (color) menu, press “◄” or “►” on the
unit to confirm, press ”▲” or “▲” to select the form of color tempera-
ture, then press “◄” or “►” on the unit to confirm, then use “▲” or ”▼”
to select color temperature such as: 9300 K, 7500K, 6500K or USER.
(the monitor leave the factory defaults 6500K).
When selecting “USER”, use “▲” or ”▼” to select color R.G.B., then use
“◄” or “►” to adjust the value of Analog Data, to make sure the color of
picture meets your needs.
OSD
After select “OSD” function, press “◄” or “►” button to confirm, then
enter into parameters adjust. Using “▲” or ”▼” button to select optional
items, then using “◄” or “►” button to adjust the parameters.
¤ Language: Languages for OSD as below:
English Italian Francois
Deutsch Español Japanese Pycc

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|9
¤ H Position: To adjust the OSD position in horizontal,
¤ V Position: To adjust the OSD position in vertical.
¤ OSD Timeout: To adjust the clock.
¤ Transparent: To adjust the level of transparent.
Function
After selecting “function”, press “◄” or “►” button to confirm, then enter
into parameters adjust. Using “▲” or ”▼” button to select adjustable
items, then using “◄” or “►” button to adjust the parameters.
¤ Reset Back to original setting.
¤ Display Ratio To change the display ratio, 16:9/4:3.
¤ Finder Frame Safety frame setting
¤ Center Mark: Screen center mark (cross mark) display setting

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
10|
Sound
After select “sound”, press “◄” or “►” button to confirm, then enter into
parameters adjust. Using “▲” or ”▼” button to select adjustable items,
then using “◄” or “►” button to adjust the parameters.
¤ Volume: To adjust the volume.

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|11
4. Parameters
Display panel size TFT LCD 5.0inch 1152000 Pixels
Panel type TFT LCD
Resolution 800*480
Max resolution 1920×1440
Horizontal frequency range 30-60kHz
Field frequency range 60Hz ~ 75Hz
Distance 0.045(W) x 0.135 (H)
Display ratio 16:9
Brightness 350 cd/m2
Contrast 500:1
Response time 10ms
Viewing angle 70°/70°(L/R) 50°/70°(U/D)
Backlight LED
Input signal HDMI, VIDEO, AUDIO
Signal output HDMI(optional)
Supported format 480i, 480p, 576i, 576p, 720p, 1080i,
1080p
Video color system PAL-4.43; NTSC-3.58
Input power voltage range DC6-24V
Power consumption <7w
Standby current <50mA
Unit size(LWH)
With sunhood
146mm(L) *100mm(H) *46mm(W)
146mm(L) *100mm(H) *60.5mm(W)
Weight (no battery)
With sunhood
260g
340g
Working temperature -20~55°C
Storage temperature -30~65°C

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
12|
5. Accessories
5.1. Standard
Mini HDMI to HDMI cable
HDMI to HDMI cable
Hot shoe mount
LP-E6 Canon equivalent battery
Battery Charger
User manual
5.2. Optional
BNC to RCA adapter
DC 12V power adapter
BNC cable
Sunhood
6. Trouble shooting
6.1. Only black and white or monochrome picture.
Please check saturation, brightness & contrast adjustment.
6.2. No picture after turning on the power.
Check signal cable connecting, make sure use the standard adapter
is connected the monitor. If power is supplied by battery, please
check if the battery is fully charged.
6.3. The image color distortion or abnormal, e.g. lack some color.
Please check signal cable whether connected correctly or not. If the
cable is damaged or loosened, it will cause poor transfer, causing
this malfunction.
Check “color” function menu “color temperature” adjustment, whether
adjustment misconduct under the “user” state.
If you are still experiencing problems, contact Marshall Electronics
technical support at: [phone] or [phone]

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
|13
Menu Option Chart
Input Mode HDMI Video
Color Brightness X X
Contrast X X
Hue X X
Saturation X X
Color Temperature X NO
OSD Language X X
H Position X X
V Position X X
OSD Timeout X X
Zoom X NO
Transparent X X
Function Reset X X
Display Ratio X X
Screen Marker X X
Center Marker X X
DSLR X NO
Sound Volume X X

Marshall M-CT5 Camera-Top Monitor Owner’s Manual
Marshall Electronics
1910 E. Maple Avenue
El Segundo, CA 90245 USA
Phone: [phone] • 800-800-6608 • Fax: [phone]
marshall-usa.com
Manual contents subject to change without notice.
