MARTIN AUDIO DX0.5
USER GUIDE

DX0.5
LOUDSPEAKER MANAGEMENT SYSTEM 





 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 1

…………
DX0.5
Contents
DX0.5................................................................................................................................................................................................1
ImportantSafetyInstructions...........................................................................................................................................................5
Introduction......................................................................................................................................................................................7
Features............................................................................................................................................................................................7
HowtoUseThisManual...................................................................................................................................................................7
GettingStarted.................................................................................................................................................................................7
ThingstoRemember:...................................................................................................................................................................8
Hook‐upDiagrams............................................................................................................................................................................9
PassiveFull‐RangeLoudspeakers.................................................................................................................................................9
PassiveMainLoudspeakerswithSubwoofersandDelays..........................................................................................................10
Bi‐ampedFull‐RangeLoudspeakerswithSubwoofers................................................................................................................11
PoweredMainLoudspeakersandSubwooferswithSeparateStereoFull‐RangeLoudspeakers...............................................12
PoweredArrayableLoudspeakersandSubwoofers...................................................................................................................13
DX0.52x6LoudspeakerManagementsystemFeatures:RearPanel..............................................................................................14
1.Power..................................................................................................................................................................................14
2.PowerLeadSocketandFuse..............................................................................................................................................14
3.Main:Lift/Gnd...................................................................................................................................................................14
4.XLROutputs........................................................................................................................................................................14
5.XLRInputs...........................................................................................................................................................................14
DX0.52x6LoudspeakerManagementsystemFeatures:FrontPanel............................................................................................14
6.LCDDisplay.........................................................................................................................................................................14
7.Nav/Edit1Control...............................................................................................................................................................14
8.Edit2Control.......................................................................................................................................................................15
9.Edit3Control.......................................................................................................................................................................15
10.EnterButton.....................................................................................................................................................................15
11.ESCButton........................................................................................................................................................................15
12.UtilityButton....................................................................................................................................................................15
13.Mute/EditButtons..........................................................................................................................................................15
14.EditLEDs...........................................................................................................................................................................15
15.MuteLEDs.........................................................................................................................................................................15
16.Meters..............................................................................................................................................................................15
17.USB...................................................................................................................................................................................16
FactoryReset..........................................................................................................................................................................16
Utilities...........................................................................................................................................................................................16
SystemUtilities...........................................................................................................................................................................17
SystemSetup..........................................................................................................................................................................17


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 2

…………
DelayUnits..............................................................................................................................................................................17
Rampsonchanges..................................................................................................................................................................18
SoftwareVersion....................................................................................................................................................................18
PresetUtilities............................................................................................................................................................................18
RecallaPreset........................................................................................................................................................................18
SaveaPreset...........................................................................................................................................................................18
DeleteaPreset.......................................................................................................................................................................19
SecurityUtilities..........................................................................................................................................................................19
ShowParameter.....................................................................................................................................................................19
LockUnit.................................................................................................................................................................................19
UserPassword........................................................................................................................................................................19
EnablePassword.....................................................................................................................................................................20
Editing.............................................................................................................................................................................................21
InputsA/B:................................................................................................................................................................................21
Gain.........................................................................................................................................................................................21
Delay.......................................................................................................................................................................................21
EQBypass...............................................................................................................................................................................22
5‐BandEQ...............................................................................................................................................................................22
Outputs1‐6:................................................................................................................................................................................22
Name......................................................................................................................................................................................23
Source.....................................................................................................................................................................................23
Polarity....................................................................................................................................................................................23
Gain.........................................................................................................................................................................................23
EQBypass...............................................................................................................................................................................23
7‐BandEQ...............................................................................................................................................................................24
Delay.......................................................................................................................................................................................24
HighPassFilter.......................................................................................................................................................................25
LowPassFilter........................................................................................................................................................................25
Limiter.....................................................................................................................................................................................25
VUMeter................................................................................................................................................................................26
LinkingInputsorOutputs...........................................................................................................................................................26
ServiceInformation........................................................................................................................................................................27
Troubleshooting.........................................................................................................................................................................27
NoPower................................................................................................................................................................................27
Noise/Hum............................................................................................................................................................................27
Toremoveandreplacethefuse:............................................................................................................................................27
Onesideislouderthantheother...........................................................................................................................................27
BadSound...............................................................................................................................................................................28
FactoryReset:.........................................................................................................................................................................28


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 3

…………
Repair.............................................................................................................................................................................................29
AudioConnections..........................................................................................................................................................................30
XLRConnectors...........................................................................................................................................................................30
XLR..........................................................................................................................................................................................30
ControlApplication.........................................................................................................................................................................31
ConnectDevice...........................................................................................................................................................................31
Linking.........................................................................................................................................................................................32
ProgramUtility...........................................................................................................................................................................33
OpenPresetfromPC..............................................................................................................................................................33
SavePresettoPC....................................................................................................................................................................33
StorePresettoDevice............................................................................................................................................................34
RecallPresetfromDevice.......................................................................................................................................................35
SystemUtility..............................................................................................................................................................................37
SystemSetup..........................................................................................................................................................................37
RampAudioonchanges.........................................................................................................................................................38
Versioninfo.............................................................................................................................................................................38
SecurityUtility............................................................................................................................................................................39
Showparameterswhenlocked..............................................................................................................................................39
ChangePassword....................................................................................................................................................................39
LockUnit.................................................................................................................................................................................40
LockUnitPassword.................................................................................................................................................................40
OptionsUtility.............................................................................................................................................................................41
CopyInput..............................................................................................................................................................................41
CopyOutput...........................................................................................................................................................................41
EditChannelnames................................................................................................................................................................42
Gain/Mute/Lim...........................................................................................................................................................................43
Gain.........................................................................................................................................................................................43
Metering.................................................................................................................................................................................44
Routing.......................................................................................................................................................................................46
Inputchannel..............................................................................................................................................................................48
Adjustingfilters...........................................................................................................................................................................51
ClickandHold.........................................................................................................................................................................51
KeyboardShortcuts................................................................................................................................................................51
FaderAdjustment...................................................................................................................................................................51
Directvalue.............................................................................................................................................................................51
OutputChannel..........................................................................................................................................................................52
Adjustingfilters...........................................................................................................................................................................55
ClickandHold.........................................................................................................................................................................55
KeyboardShortcuts................................................................................................................................................................55


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 4

…………
FaderAdjustment...................................................................................................................................................................56
Directvalue.............................................................................................................................................................................56
Delay...........................................................................................................................................................................................57
DelayAdjustment...................................................................................................................................................................58
InversePolarity.......................................................................................................................................................................58
TechnicalSpecifications..................................................................................................................................................................59
Warranty.........................................................................................................................................................................................60
TechnicalDrawing..........................................................................................................................................................................61




 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 5

…………
ImportantSafetyInstructions
1.Readtheseinstructions.
2.Keeptheseinstructions.
3.Heedallwarnings.
4.Followallinstructions.
5.Donotusethisapparatusnearwater.
6.Cleanonlywithadrycloth.
7.Donotblockanyventilationopenings.Installinaccordancewiththemanufacturer’sinstructions.
8.Donotinstallnearanyheatsourcessuchasradiators,heatregisters,stoves,orotherapparatus(includingamplifiers)that
produceheat.
9.Donotdefeatthesafetypurposeofthepolarizedorgrounding‐typemainsplug.Apolarizedplughastwobladeswithone
widerthantheother.Agrounding‐typeplughastwobladesandathirdgroundingprong.Thewidebladeorthethirdprongare
providedforyoursafety.Iftheprovidedplugdoesnotfitintoyouroutlet,consultanelectricianforreplacementoftheobsolete
outlet.
10.Protectthepowerleadfrombeingwalkedonorpinchedparticularlyatplugs,conveniencereceptacles,andthepointwhere
theyexitfromtheapparatus.
11.Onlyuseattachments/accessoriesspecifiedbythemanufacturer.
12.Useonlywithacart,stand,tripod,bracket,ortablespecifiedbythemanufacturer,orsoldwiththeapparatus.Whenacart
isused,usecautionwhenmovingthecart/apparatuscombinationtoavoidinjuryfromtip‐over.
13.Unplugthisapparatusduringlightningstormsorwhenunusedforlongperiodsoftime.
14.Referallservicingtoqualifiedservicepersonnel.Servicingisrequiredwhentheapparatushasbeendamagedinanyway,
suchaspowersupplycableorplugisdamaged,liquidhasbeenspilledorobjectshavefallenintotheapparatus,theapparatus
hasbeenexposedtorainormoisture,doesnotoperatenormally,orhasbeendropped.
15.Thisapparatusshallnotbeexposedtodrippingorsplashing,andnoobjectfilledwithliquids,suchasvasesorbeerglasses,
shallbeplacedontheapparatus.
16.Donotoverloadwalloutletsandextensionleadsasthiscanresultinariskoffireorelectricshock.
17.ThisapparatushasbeendesignedwithClass‐Iconstructionandmustbeconnectedtoamainssocketoutletwithaprotective
earthingconnection(thethirdgroundingprong).
18.Thisapparatushasbeenequippedwitharocker‐styleACmainspowerswitch.Thisswitchislocatedontherearpaneland
shouldremainreadilyaccessibletotheuser.

Thelightningflashwitharrowheadsymbolwithinanequilateraltriangleisintendedtoalerttheusertothe
presenceofuninsulated"dangerousvoltage"withintheproduct'senclosurethatmaybeofsufficient
magnitudetoconstituteariskofelectricshocktopersons.




 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 6

…………

Theexclamationpointwithinanequilateraltriangleisintendedtoalerttheuserofthepresenceof
importantoperatingandmaintenance(servicing)instructionsintheliteratureaccompanyingtheappliance.


19.TheMAINSplugoranappliancecouplerisusedasthedisconnectdevice,sothedisconnectdeviceshallremainreadily
operable.
20.NOTE:ThisequipmenthasbeentestedandfoundtocomplywiththelimitsforaClassBdigitaldevice,pursuanttopart15
oftheFCCRules.Theselimitsaredesignedtoprovidereasonableprotectionagainstharmfulinterferenceinaresidential
installation.Thisequipmentgenerates,uses,andcanradiateradiofrequencyenergyand,ifnotinstalledandusedinaccordance
withtheinstructions,maycauseharmfulinterferencetoradiocommunications.However,thereisnoguaranteethat
interferencewillnotoccurinaparticularinstallation.
Ifthisequipmentdoescauseharmfulinterferencetoradioortelevisionreception,whichcanbedeterminedbyturningthe
equipmentoffandon,theuserisencouragedtotrytocorrecttheinterferencebyoneormoreofthefollowingmeasures:
Reorientorrelocatethereceivingantenna.
Increasetheseparationbetweentheequipmentandthereceiver.
Connecttheequipmentintoanoutletonacircuitdifferentfromthattowhichthereceiverisconnected.
Consultthedealeroranexperiencedradio/TVtechnicianforhelp.

CAUTION:ChangesormodificationstothisdevicenotexpresslyapprovedbyMartinAudiocouldvoidtheuser'sauthorityto
operatetheequipmentunderFCCrules.
21.ThisapparatusdoesnotexceedtheClassA/ClassB(whicheverisapplicable)limitsforradionoiseemissionsfromdigital
apparatusassetoutintheradiointerferenceregulationsoftheCanadianDepartmentofCommunications.
ATTENTION—Leprésentappareilnumériquen’émetpasdebruitsradioélectriquesdépassantlaslimitesapplicablesaux
appareilsnumériquesdeclassA/declassB(selonlecas)prescritesdansleréglementsurlebrouillageradioélectriqueédictépar
lesministeredescommunicationsduCanada.
22.Exposuretoextremelyhighnoiselevelsmaycausepermanenthearingloss.Individualsvaryconsiderablyinsusceptibilityto
noise‐inducedhearingloss,butnearlyeveryonewilllosesomehearingifexposedtosufficientlyintensenoiseforaperiodof
time.TheU.S.Government’sOccupationalSafetyandHealthAdministration(OSHA)hasspecifiedthepermissiblenoiselevel
exposuresshowninthefollowingchart.AccordingtoOSHA,anyexposureinexcessofthesepermissiblelimitscouldresultin
somehearingloss.Toensureagainstpotentiallydangerousexposuretohighsoundpressurelevels,itisrecommendedthatall
personsexposedtoequipmentcapableofproducinghighsoundpressurelevelsusehearingprotectorswhiletheequipmentis
inoperation.Earplugsorprotectorsintheearcanalsorovertheearsmustbewornwhenoperatingtheequipmentinorderto
preventpermanenthearinglossifexposureisinexcessofthelimitssetforthhere:







WARNING—Toreducetheriskoffireorelectricshock,donotexposethis
apparatustorainormoisture.
Duration,perdayinhoursSoundLeveldBA,SlowResponseTypicalExample
890Duoinsmallclub
692
495SubwayTrain
397
2100Veryloudclassicalmusic
1.5102
1105Chainsaw
0.5110
0.25orless115Loudestpartsatarockconcert



 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 7

…………
CorrectDisposalofthisproduct:Thissymbolindicatesthatthisproductshouldnotbedisposedofwithyour
householdwaste,(2002/96/EC)andyournationallaw.Thisproductshouldbehandedovertoanauthorized
collectionsiteforrecyclingwasteelectricalandelectronicequipment(EEE).Improperhandlingofthistypeof
wastecouldhaveapossiblenegativeimpactontheenvironmentandhumanhealthduetopotentially
hazardoussubstancesthataregenerallyassociatedwithEEE.Atthesametime,yourcooperationinthecorrect
disposalofthisproductwillcontributetotheeffectiveusageofnaturalresources.Formoreinformationabout
whereyoucandropoffyourwasteequipmentforrecycling,pleasecontactyourlocalcityoffice,waste
authority,oryourhouseholdwastedisposalservice.
Introduction
OfferingsophisticatedEQ,crossover,dynamicsprocessingandsystemprotection,theMartinAudioDX0.5Loudspeaker
ManagementSystemprovidescompletesystemoptimizationforbothpassiveandpoweredsystems.Fivedifferentoperating
modescoverawiderangeofsystems.Eachofthesixoutputsfeaturededicatedlevelcontrol,mute,polarityinvert,high/low‐
passfilters,7‐bandparametric/shelvingEQ,600msdelayandlimiting.Twoinputchannelsprovideindependentlevelcontrol,
mute,600msdelayandaflexible5‐bandparametric/shelvingEQ.Theconvenientfront‐panelcontrolalsoincludes7‐segment
LEDmeteringperchannel.TheDX0.5utilizeshigh‐end24‐bitAKM®AD/DAconverterswith120dBdynamicrangeforclass‐
leadingsoundquality.With24user‐definablepresetsandflexibleI/Oforsimpleroutingandconfiguration,theDX0.5isanultra‐
flexibleprocessor,idealforawiderangeofportableandpermanentapplications.
Features
Professional2‐input,6‐outputsystemprocessorforpassiveandpoweredLoudspeakersystems
Sophisticated,intuitiveEQ,crossover,delayanddynamicsprocessingoptimizesandprotectsyoursystem
High‐end24‐bitAKM®AD/DAwith120dBdynamicrange
TwobalancedXLRinputswithlevelcontrol,mute,600msdelayand5‐bandparametric/shelvingEQ
SixbalancedXLRoutputswithlevelcontrol,mute,polarityinvert,dedicatedhighandlowpassfilters,7‐band
parametric/shelvingEQ,600msdelay,andlimiting
Powerfullimiteroneveryoutputforultimateprotection
Convenientfront‐panelcontrolsforparametereditingandinput/outputmuting
USBportforsimpleprogrammingviaPC
Linkableinputsandoutputsforeasystereoconfiguration
7‐segmentLEDmeteringforinput/outputlevelorlimiteractivity
5operatingmodes:2xstereo+sub,3xstereo,2x2‐way+sub,2x3‐wayand1x6‐way
24presetsforstoringMartinAudioCDDorothersystemparameters
Switchmodepowersupply:100V–240V
Compact,singlerackunitdesign
HowtoUseThisManual
Afterthisintroduction,agettingstartedguidewillhelpyougetthingssetupfast.Thehook‐updiagramsshowsometypical
setups,whiletheremainingsectionsprovidedetailsoftheDX0.5andhowtouseittooptimizeyourloudspeakersystem.
GettingStarted
Thefollowingstepswillhelpyousetupyoursystemquickly.
1. MakeallinitialconnectionswiththepowerswitchesOFFonallequipment.Makesurethemastervolume,level,orgain
controlsareallthewaydown.
2. Connecttheline‐leveloutputsfromyourmixingconsole(orothersignalsource)totheinputsoftheDX0.5Loudspeaker
ManagementSystem
3. Connectoutputs1‐6fromtheDX0.5totheinputsofpoweramplifiersORdirectlytotheinputsofPoweredloudspeakers
and/orsubwooferssuchastheMartinAudioDD12orPSX.
4. Ifusingamplifiers,connecttheoutputsfromthepoweramplifier(s)totheinputsofPassiveloudspeakers.
5. Turnonthemixingconsole(orothersignalsource).
6. TurnontheDX0.5LoudspeakerManagementSystem.



 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 8

…………
7. SelectthesystemsetupthatbestmatchesyourLoudspeakerSystem[moredetailsmaybefoundonpage17]:

2xStereo+Sub[default].Twofull‐rangeloudspeakerpairsandapairof[monobydefault]subwoofers
2x2Way+SubTwobi‐ampfull‐rangeloudspeakersandapairof[monobydefault]subwoofers
2x3WayTwotri‐ampfull‐rangeloudspeakersorstereosubswithtwobi‐ampspeakers
3xStereoThreefull‐rangeloudspeakerpairs
1x6WayMonocontrolofsixfullrangespeakersystems

8. Un‐mutetheappropriateoutputsontheDX0.5.[Seepage15fordetails.]
9. Turnontheamplifier(s)ORpoweredloudspeakers.Turnupthevolumeorgaincontrol(s),inmostcircumstancesgain
controlsshouldbeturneduptomaximumsotheamplifiergainmatchesthelevelatwhichlimiterthresholdsinthe
DX0.5havebeenset.
10. Startthesignalsourceandraisethemixer’smainL/Rfader(s)upuntilaudioisheardthroughtheloudspeakers.
Atthispointthesystemistestedandworkinghoweverwestronglyencouragethatyoureadtherestofthisowner’smanualto
learnbasicnavigation,howtoedittheinputsandoutputs,setsecurityfeaturesandmore.
ThingstoRemember:
Neverlistentoloudmusicforprolongedperiods.PleaseseetheSafetyInstructionsonpage6forinformationon
hearingprotection.
Whenyoushutdowntheequipment,turnofftheamplifiersfirsttopreventthumpsandothernoisesgeneratedby
anyupstreamequipmentfromcomingoutofthespeakers.Whenpoweringup,turnontheamplifierslast.
Savetheshippingboxesandpackingmaterials,intheunlikelyeventofaproblemwiththeDX0.5thesemaybe
requiredtoshipthedevicetoanauthorisedServiceAgent.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 9

…………
Hook‐upDiagrams
PassiveFull‐RangeLoudspeakers

Inthisexample,theDX0.5isconfiguredusingthe‘3xStereo’setuptype.Theleftandrightline‐levelXLRoutputsfromamixer
feedtheAandBXLRinputsofaDX0.5LoudspeakerManagementsystem.XLRoutputs1and2oftheDX0.5systemfeedthe1
and2XLRinputsofaMartinAudioMA3.0PowerAmplifier.TheCH1andCH2NL4speakeroutputsofthepoweramplifierfeed
thePhoenixinputsoftwoMartinAudioCDD12passiveloudspeakerslocatedeithersideofthevenuestage.
XLRoutputs3and4oftheDX0.5feedthe1and2XLRinputsofaMartinAudioMA2.0PowerAmplifier.TheCH1andCH2NL4
speakeroutputsofthispoweramplifierfeedthePhoenixinputsoftwoMartinAudioCDD8passiveloudspeakers.Theseare
positionedhalfwaytowardtherearofthevenueandhavedelayadded,sotheyaretimealignedwiththeCDD12susingthe
outputdelayavailableontheDX0.5.
FinallyXLRoutputs5and6oftheDX0.5feedthe1and2XLRinputsofanotherMartinAudioMA2.0PowerAmplifier.TheCH1
andCH2NL4speakeroutputsofthispoweramplifierfeedthePhoenixinputsoftwoMartinAudioCDD6passiveloudspeakers
whicharelocatedinaseparateareaawayfromthecoverageofthemainsystem.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 10

…………
PassiveMainLoudspeakerswithSubwoofersandDelays

Inthisexample,theDX0.5isconfiguredusingthe‘2xStereo+Subs’setuptype.Theexamplehereishowthesystemforthe
nightclubsectionoftheCDDlauncheventwasconfigured.Theleftandrightline‐levelXLRoutputsfromamixerfeedtheAand
BXLRinputsoftheDX0.5.XLRoutputs1and2oftheDX0.5feedthe1and2XLRinputsofaMartinAudioMA5.2KPower
Amplifier.TheCH1andCH2NL4speakeroutputsofthepoweramplifierfeedthePhoenixinputsoftwoMartinAudioCDD15
passiveloudspeakers.Theseloudspeakersarepositionedtoprovidethemaindancefloorcoverage.
XLRoutputs3and4oftheDX0.5feedthe1and2XLRinputsofaMartinAudioMA12KPowerAmplifier.TheCH1andCH2NL4
speakeroutputsofthispoweramplifierfeedthePhoenixinputsoftwoMartinAudioCSX2182x18"subwoofers.TheDX0.5’s
high‐andlow‐passfiltersonoutputchannels1–4areconfiguredtocreateacrossovertooptimizethesesubwooferswiththe
CDD15sloudspeakers.ThesubsmaybestereoormonobyconfiguringtheinputsourcesforDX0.5outputs3and4.
XLRoutputs5and6oftheDX0.5feedthe1and2XLRinputsofaMartinAudioMA3.0PowerAmplifier.TheCH1andCH2NL4
speakeroutputsofthispoweramplifierfeedthePhoenixinputsoftwoMartinAudioCDD12passiveloudspeakers.Thisfull‐range
pairispositionedatthebackofthedancefloorfacingbacktowardstheDJtoensurecompletecoverageattheSPLlevels
demandedbyclubattendees.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 11

…………
Bi‐ampedFull‐RangeLoudspeakerswithSubwoofers

Inthisexample,theDX0.5isconfiguredusingthe‘2x2Way+Subs’setuptype.Theleftandrightline‐leveloutputsfromamixer
feedtheAandBXLRinputsofaMartinAudioDX0.5LoudspeakerManagementsystem.XLRoutputs1and2oftheDX0.5feed
the1and2XLRinputsofaMartinAudioMA2.0PowerAmplifier.TheCH1andCH2NL4speakeroutputsofthepoweramplifier
feedthehighfrequencyinputsoftwoMartinAudiobi‐ampedBlacklineH3+.XLRoutputs3and4oftheDX0.5feedthe1and2
XLRinputsofanotherMartinAudioMA3.0PowerAmplifier.TheCH1andCH2NL4speakeroutputsofthispoweramplifierfeed
thelowfrequencyinputsoftheH3+.Thisrequiresafour‐corespeakercabletogototheH3+,attheamplifiersthisneedstobe
splitsothelowfrequencyfeedonpins1+/‐isfedfromtheMA3.0andthemid/highfeedonpins2+/‐isfedfromtheMA2.0.
XLRoutputs5and6oftheDX0.5feedthe1and2XLRinputsofaMartinAudioMA9.6KPowerAmplifier.TheCH1andCH2NL4
speakeroutputsofthispoweramplifierfeedtheNL4inputofS18+subwoofers.
TheDX0.5’shigh‐andlow‐passfiltersontheoutputchannelsareconfiguredtocreateacrossoversothatoutputs1and2ofthe
DX0.5deliverthehighfrequenciestotheloudspeakers,outputs3and4deliverthelowfrequenciestothesameloudspeakers
andoutputs5and6deliverthesubfrequenciestothepassivesubwoofers.Thesubsmaybestereoormonobyproperly
configuringtheinputsourcesforDX0.5outputs5and6.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 12

…………
PoweredMainLoudspeakersandSubwooferswithSeparateStereoFull‐Range
Loudspeakers
TheMartinAudioDX0.5LoudspeakerManagementsystemisalsousefulforcontrollingpoweredloudspeakersandsubwoofers.
Here,theDX0.5isconfiguredusingthe‘2xStereo+Subs’setuptype.Theleftandrightline‐levelXLRoutputsfromamixerfeed
theAandBXLRinputsoftheDX0.5.XLRoutputs1and2oftheDX0.5feedtheXLRinputsoftwoMartinAudioDD12powered
loudspeakers.Theseloudspeakersarelocatedonstage.
XLRoutputs3and4oftheDX0.5feedtheXLRinputsofanothertwoMartinAudioDD12s.Thisfull‐rangepairshouldbepositioned
halfwaytowardtherearofthevenuewithdelayaddedsotheyaretime‐alignedwiththemainpair.
Finally,XLRoutputs5and6oftheDX0.5feedtheXLRinputsoftwoMartinAudioPSXpoweredsubwoofersthatarelocatedon
stageandpairedwiththeDD12loudspeakers.Inthissetup,theDX0.5’shigh‐andlow‐passfiltersonoutputs1and2and5and
6maybeusedtoconfigureacrossoverbetweentheDD12andPSXforaddedcontrolfromtheprocessor.Careshouldbetaken
whenconfiguringtheDX0.5’scrossoversothePSXbuilt‐incrossoverdoesnotconflict.Thesubsmaybestereoormonoby
properlyconfiguringtheinputsourcesforDX0.5outputs5and6.
TheDX0.5maybeusedforadditionalroomcorrectiveEQanddelaytoaligntheloudspeakersandsubwoofersandalimiter
addedforextraprotectionagainstoverpoweringfromirresponsibleDJsforexample.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 13

…………
PoweredArrayableLoudspeakersandSubwoofers

Here,theDX0.5isconfiguredusingthe‘2xStereo+Subs’setuptype.Theleftandrightline‐levelXLRoutputsofamixerfeedthe
AandBXLRinputsoftheDX0.5LoudspeakerManagementsystem.
XLRoutputs1,2,3and4oftheDX0.5feedtheXLRinputsofapairofMA3.0amplifiers.TheCH1andCH2NL4speakeroutputs
ofthesepoweramplifiersfeedthePhoenixinputsofthetopandbottomofastereopairof16moduleOmnilinearrays
XLRoutput5oftheDX0.5isconnectedtotheA&BXLRmaininputsofaMartinAudioMA5.2K;itisonlynecessarytoconnecta
cabletoinputAastheamplifierhasalinkswitchtoparallelbothinputs.TheCH1andCH2NL4speakeroutputsofthispower
amplifierfeedthePhoenixinputofapairofCSX212passivesubwoofers
TheDX0.5’shigh‐ andlow‐passfiltersonoutputchannels1–5maybeconfiguredtocreateacrossovertooptimizethe
subwooferswiththeOmniline.ThesubsarerunmonobyproperlyconfiguringtheinputsourcesforDX0.5output5.TheDX0.5
maybeusedforaddingthePEQrecommendedbytheOmnilinesoftwareandanyadditionalroomcorrectiveEQ.Delaytoalign
theloudspeakersandsubwooferscanbeaddedandalimiterforprotectionofthesystem.



 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 14

…………
DX0.52x6LoudspeakerManagementsystemFeatures:Rear
Panel

1.Power
Usethisrocker‐styleswitchtoturntheunitonoroff.Theprocessorisonwhenthetopoftheswitchispressedin.Itisoffwhen
thebottomoftheswitchispressedin.TheLCDDisplay[6]willilluminateandtextwillappearwhenthepowerswitchison.
TheDX0.5remembersitssettings,soyoumaypowercycletheunitanditwillresumeoperationusingthesamesettingsas
before.TheDX0.5employsrelaysontheoutputstopreventunwantedpopsandnoiseinthesystemwhenpowercyclingand
startinguptheprocessor.Afterengagingthepowerswitch,theunitwillinitializeandtherelayswillswitch.Anyliveoutputswill
smoothlyfadefromsilencetotheirconfiguredoutputlevels.Theprocessormaynowbeedited,oritisreadyforuseiftheDX0.5
isalreadyconfiguredfortheloudspeakersystemundercontrol.
2.PowerLeadSocketandFuse
Thisiswheretoconnectthedetachablepowercableincludedwiththeprocessor.Plugtheotherendofthepowerleadintoan
ACoutlet.Theoutletshouldmatchthepowercable.
WARNING:Bypassingtheplug’ssafetygroundpincanbedangerous.Don’tdoit!
Thefuseislocatedbehindthefusecover,atthebottomoftheIECsocket.Seethe“Troubleshooting”sectiononpage22for
informationaboutreplacingthefuse.
3.Main:Lift/Gnd
Thegroundliftseparatesthechassisgroundfromthesignalground.ThedefaultpositionisGND.Youmayattempttoremedy
systemgroundloophumbymovingtheswitchtoLIFT.
4.XLROutputs
ThesesixmaleXLRconnectorsprovideabalancedline‐levelsignalforeachoftheprocessor’soutputchannels.Connecttheseto
theinputsofpoweramplifiersand/orpoweredloudspeakers.
5.XLRInputs
ThesefemaleXLRconnectorsacceptabalancedline‐levelinputfromamixerorothersourcemainL/Routput.
DX0.52x6LoudspeakerManagementsystemFeatures:
FrontPanel
6.LCDDisplay
TheLCDDisplayisoneofthemostvitalfeaturesoftheprocessor.Itdisplaysprocessorinformationincluding(butnotlimitedto)
System,PresetandSecurityUtilities,gain,delay,EQandotherinputandoutputprocessingparameters.
WhentheDX0.5ispoweredup,thelaststateitwasinwillloadupandtheLCDDisplaywillpresentthecurrentsystemsetup
type:
2xStereo+Sub[default]
2x2Way+Sub
2x3Way
3xStereo
1x6Way

7.Nav/Edit1Control


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 15

…………
TheNav/Edit1rotaryencodercontrolallowsyoutonavigatetheuserinterface,editsectionsoftheprocessor,navigatewithin
screenstoselectsub‐menus,pagesandparameters,aswellasselectvaluesduringediting.
8.Edit2Control
TheEdit2rotaryencodercontrolallowsyoutoeditparameters,aswellasselectvaluesduringediting.
9.Edit3Control
TheEdit3rotaryencodercontrolalsoallowsyoutoeditparameters,aswellasselectvaluesduringediting.
Ingeneral,usetheNav/Edit1rotaryencodercontroltoscrollthroughthevariouspagesandconfigurationsettings.Depending
onthepage,individualparametersmaybechangedbyturningone(ormore)oftheencoders.Insomecases,theEdit2andEdit3
controlsprovidefineandcoursecontrolofthesameparameter.
10.EnterButton
TheEnterButtonallowsyoutodigdeeperanddeeperintomenusandparameters,confirmoperationsandchangesettings.
11.ESCButton
TheESCButtonallowsyoutoretreatfromselectedvariables.Insomecases,itconfirmoperationsandchangessettings,aswell.
Thesewillbenoted.
12.UtilityButton
PressthisbuttontoselectandupdatetheDX0.5’sutilities.Therearethreemainutilitiesmenus:
SystemUtilities
PresetUtilities
SecurityUtilities

Withineach,anarrayofsub‐menusareavailable.
13.Mute/EditButtons
Theseeightbuttonsserveadualpurpose:
Mutingselectedinputsandoutputs
Editingselectedinputsandoutputs

Tomuteaninputoroutput,quicklypressandreleasethedesiredbuttononcetoengagemute;quicklypressandreleaseitagain
toun‐mute.Muteasyoumightexpecttogglesbetweenmutedandunmutedonthecorrespondinginputsandoutputs.
Toeditaninputoroutput,pressandholdthedesiredbuttonuntilthatinputoroutput’sblueLED[14]illuminates.Pressand
holdagaintotakeitoutofeditmode.Editallowsyoutoedit–change–variablesonthechoseninputsandoutputs.Whileitis
notpossibletoedittheinputsANDoutputssimultaneously,itispossibletolinkandedittheinputssimultaneouslyORlinkand
editanynumberofoutputssimultaneously.SimplypressandholdanyadditionalinputoroutputMute/Editbuttonstolink.Any
changedparameterswillaffectalllinkedinputsoroutputs.
14.EditLEDs
ThereareatotalofeightEditLEDsontheDX0.5:twoinputandsixoutput.EditLEDsilluminatebluewhenengaged.SeeMute/
EditButtons[13].
15.MuteLEDs
ThereareatotalofeightMuteLEDsontheDX0.5:twoinputandsixoutput.MuteLEDsilluminateredwhenengaged.SeeMute
/EditButtons[13].
16.Meters


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 16

…………
Theseseven‐segmentmetersdisplaytheinputandoutputsignallevelsORthegainreductionamountforeachoutput’slimiter,
dependingontheselectedVUMetermode.Detailedinformationmaybefoundonpage20[VUMetersection].
Thesemetersshouldremaingreenwiththeoccasionalpeakintotheyellowzone.Ifthelevelstaysconstantlyintheyellow
section(oranyredclipping),lowerthelevelofthesourceuntilfeedingtheDX0.5untilthemeteringreturnstooccasional
excursionsintotheyellow.ItmayalsobenecessarytocheckthegainandEQsettingsontheDX0.5inputandoutputchannels.
Inputmeters(startingatthetop)show:
Clip,+15dBu,+9dBu,+3dBu,0dBu,–10dBuand–20dBu.
Outputmeters(startingatthetop)show:
Limit,Clip,+15dBu,+9dBu,+3dBu,0dBuand–15dBuwheninLevelmode.
IftheVUmetermodeisLimit,theoutputmetersshow:
Limit,0dB,–3dB,–6dB,–9dB,–12dBand–15dB.
17.USB
TheDX0.5maybecontrolledandprogrammedusingaWindows‐basedPC.Gotowww.MartinAudio.com/Softwaretodownload
thefreeapplicationanddriver.HereyouwillalsofindpresetsforotherMartinAudioproductranges
SimplyconnectaUSBcablefromtheDX0.5tothePCinordertocontrolallparametersoftheprocessorviatheDX0.5Application.
FactoryReset
ItispossibletoresettheDX0.5LoudspeakerManagementSystemtoitsfactorysettings.Pleasekeepinmindthatthiserasesall
settings,includinganypasswordsandpresetsthatmayhavebeenset.Besuretopowerdownanyamplifiersand/orpowered
speakersbeforeresettingtheDX0.5.
SimplypressandholdtheEnter[10],ESC[11]andUtility[12]buttonswhenpoweringupuntiltheLCD
Display[6]shows:
Please Wait....
Memory Reset
Thenyoumaytakeyourfingersoffthebuttons.YouwillknowitworkedwhenthesixoutputMuteLEDs[15]illuminateafterthe
DX0.5isfullypoweredup.
Thedefaultpasswordissixzeroes:000000
Utilities
Asmentionedearlier,therearethreemainutilitymenustochoosefrom:
SystemUtilities
PresetUtilities
SecurityUtilities

Withineachutilitymenu,anarrayofsub‐menusareavailable.Wewillgothrougheachutility,eachsubmenu,howtogetthere,
howtoeditandchangesettingsandwhateachControlandbuttondoesineachsituation.
Whennavigatingmenus,thecurrentsettingforanyparameterwillbeindicatedwithanasterisk[*]makingiteasytogetback
whereyoustarted.
PresstheUtilityButton[12]toopentheUtilityMenu.
UsetheNav/Edit1Control[7]tonavigatebetweenthethreeutilitymenus:SystemUtilities,PresetUtilitiesandSecurityUtilities.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 17

…………
PresstheESCbutton[11]toreturntothemainscreen.
PresstheEnterButton[10]toenterandedittheselectedUtilitiesmenu.Thisishowwereachthesub‐menusoftheUtilities.
SystemUtilities
TurntheNav/Edit1ControluntilSystemUtilitiesispresentedandpresstheEnterButton[10]toreachtheSystemUtilitiessub‐
menusaslistedbelow:
SystemSetup
DelayUnits
Rampsonchanges
SoftwareVersion

Lookingateachofthesesub‐menusindividually;‐
1. TheNav/Edit1Control[7]isusedtonavigatebetweenthefourSystemUtilities.
2. TheESCbutton[11]isusedtoreturntotheSystemUtilitiesmenu.
3. TheEnterButton[10]isusedtoenterandeditthechosenSystemUtility.
PresstheEnterButton[10]toenterSystemSetup.
SystemSetup
SystemSetupiswheretheprocessorisconfiguredforyourparticularloudspeakersystem.Itconfigureschannelnames,input
routingtooutputsandprovidesstartingpointsforcrossoversetups.
Thefiveoptionsarelistedbelow.Here,turntheEdit2[8]orEdit3[9]ControltoscrollbetweenthedifferentSystemSetup
choices.
2xStereo+Sub[default]
Twofull‐rangeloudspeakerpairsandapairof[monobydefault]subwoofers
2x2Way+Sub
Twobi‐ampfull‐rangeloudspeakersandapairof[monobydefault]subwoofers
2x3Way
Twotri‐ampfull‐rangeloudspeakers
3xStereo
Threefull‐rangeloudspeakerpairs
1x6Way
Mono6‐way
Onceyouhavedecidedonasystem,presstheEnterButton[10]twice:oncetoselectandagaintoconfirm.Theoutputswill
automaticallymuteonceupdatedandtheprocessorreturnstotheSystemSetupsplashscreen.
YoumayconfiguretheDX0.5forotherscenariosbyadjustingtheavailableparameters.Ifyouarecreatingacustomsetup,choose
thesetupthatmostcloselyresemblesyoursystem,theneditfromthere.
PresstheESCbutton[11]toreturntotheSystemUtilitymenuwithoutmakinganychanges.
DelayUnits
Thisiswheretochooseunitsusedwhenadjustingtheinputandoutputdelayvalues.Youwillbepresentedwiththreeoptions
here:
Unit:Time(ms)
Unit:Distance(m)[default]
Unit:Distance(feet)



 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 18

…………
TurntheEdit2[8]orEdit3[9]Controltoscrollbetweenthesethreechoices.PresstheEnterButton[10]onceaunitofdelayhas
beendecided.TheprocessorwillreturntotheDelayUnitssplashscreen.OrpresstheESCbutton[11]toreturntotheSystem
Utilitymenuwithoutmakinganychanges.
Rampsonchanges
Whenengaged,suddenvolumechangesmaybeavoidedwhenchangingparametervalues,particularlywhenusingaWindows‐
basedPCtocontroltheunit.Disengagethisfeatureforliveapplicationssinceinstantresponsetochangeisdesired.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenRamps : OnandRamps : Off[default].Ifchanging,pressthe
EnterButton[10]onlyoncehere.TheprocessorwillreturntotheRampsonchangessplashscreen.OrpresstheESCbutton[11]
toreturntotheSystemUtilitymenuwithoutmakinganychanges.
SoftwareVersion
Nothingmaybeeditedonthispage.PresstheEnterButton[10]toviewwhatversionofsoftwareisinstalledinthisDX0.5.Press
theEnter[10]orESC[11]ButtontoreturntotheSoftwareVersionsplashscreen.
PresetUtilities
Thisiswheretosave,recallanddeletepresetsontheDX0.5.ThisisusefulwhenthePAsystemhasmultiplesetupsfordifferent
environmentsorseveralloudspeakersystemsutilizingvaryingsetups.
Note:Asmentionedearlier,theDX0.5willloadupthelaststateitwasinwhenitwaspowereddown.
Asmentionedearlier,thewaytogetherefromthemainmenuisbypressingtheUtilityButton[12].OnceinsidetheUtilityMenu,
scrolltheNav/Edit1Control[7]clockwisetoPresetUtilities.NowpresstheEnterButton[10]againtoreachthesub‐menusas
listedbelow:
RecallaPreset
SaveaPreset
DeleteaPreset

Lookingateachofthesesub‐menusindividually;‐
1. TheNav/Edit1Control[7]isusedtonavigatebetweenthethreePresetUtilities.
2. TheESCbutton[11]isusedtoreturntothePresetUtilitiesmenu.
3. TheEnterButton[10]isusedtoenterandeditthechosenPresetUtility.
PresstheEnterButton[10]toenterRecallaPreset.
RecallaPreset
Ifapresethasbeensavedearlier,itmayberecalledhere.Ifnopresetsarestoredintheunit,theprocessorwillreturntothe
RecallaPresetsplashscreen.
Ifpresetsareavailable,turntheEdit2[8]orEdit3[9]Controltoselectwhichpresettorecall.PresstheEnterButton[10]toselect
apresetandagaintoconfirmrecall.ThepresetwillloadandtheprocessorwillreturntotheRecallaPresetsplashscreen.
SaveaPreset
Onceyourdesiredsystemsettingshavebeenprogrammedin,saveittotheDX0.5forrecalllater.TurntheEdit2[8]orEdit3[9]
Controltoscrollbetweenpresets1–24.PresstheEnterButton[10]onceyoudecidethelocationinwhichyouwishtosavethe
preset.
Nextyouareabletonamethepreset.TheNav/Edit1Control[7]movesthecursorleftandrightwhiletheEdit2[8]andEdit3[9]
Controlschangethetext.Oncesatisfiedwiththeresults,presstheEnterButton[10]twice:oncetoselectandagaintoconfirm.
TheprocessorwillreturntotheSaveaPresetsplashscreen.
Itispossibletosaveoveranexistingpreset.Ifattempted,youwillneedtoconfirmbypressingtheEnterButton[10]again.Or
presstheESCButton[11]toreturntothePresetUtilitiesmenuwithoutoverwritingthepreset.


 
 

DX0.5 USERGUIDE
HAM09224UserGuideV1.0 19

…………
DeleteaPreset
Ifapresetisnolongerneededforrecall,itmaybedeletedhere.ItwillhelptokeeptheDX0.5’smemoryclutter‐free.Turnthe
Edit2[8]orEdit3[9]Controltoscrollbetweenpresets1–24.PresstheEnterButton[10]onceyouhaveselectedthepresetto
delete.PresstheEnterButton[10]twice:oncetoselectandagaintoconfirm.TheprocessorwillreturntotheDeleteaPreset
splashscreen.
SecurityUtilities
ThisiswheretolocktheDX0.5topreventanyonefromaccidentally(orintentionally)changingthesettings.Youalsohavecontrol
oversomeofthesystembehaviourafterit’sbeenlocked.
Asdiscussedearlier,thewaytogetherefromthemainmenuisbypressingtheUtilityButton[12].OnceinsidetheUtilityMenu,
scrolltheNav/Edit1Control[7]clockwisetoSecurityUtilities.NowpresstheEnterButton[10]againtoreachthesub‐menusas
listedbelow.
ShowParameter
LockUnit
UserPassword
EnablePassword

1. TheNav/Edit1Control[7]isusedtonavigatebetweenthefourSecurityUtilities.
2. TheESCbutton[11]isusedtoreturntotheSecurityUtilitiesmenu.
3. TheEnterButton[10]isusedtoenterandeditthechosenSecurityUtility.
PresstheEnterButton[10]toenterShowParameter.
ShowParameter
OnceaDX0.5hasbeenlocked,youhavetheoptionofallowingthevariousprocessingparametervaluestobeshownornot.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenParameter will be shown[default]andParameter will
not be shown.Ifchanging,presstheEnterButton[10]onlyoncehere.TheprocessorwillreturntotheShowParameter
splashscreen.
LockUnit
LockingaDX0.5preventsaccidentalchangestoitssettings.
TurntheEdit2[8]orEdit3[9]ControltoscrollbetweenLock : Off [default]andLock : On.Ifchanging,presstheEnter
Button[10]onlyoncehere.
Whenlocked,asymbolresemblingakeywillappearinthelower‐righthandareaoftheLCDDisplay[6].PressingtheUtility
Button[12]herereturnsyoudirectlytotheLockUnitsplashscreen.
Whenunlocked,thekeysymboldisappearsandtheprocessorwillreturntotheSecurityUtilitiessplashscreen.
UserPassword
Fortheultimateprotectionfromaccidentalandintentionalparameteradjustments,setupauserpasswordhere.Onlythose
withthepasswordwillbeallowedaccesstoeditprocessorsettings.
TheNav/Edit1Control[7]movesthecursorleftandrightwhiletheEdit2[8]andEdit3[9]Controlschangethetext.
Inordertochangethepassword,thecurrentpasswordneedstobeentered.Thedefault/factorypasswordis:000000
EnterthecurrentpasswordandpresstheEnterButton[10].Itwillnowpromptyouforanewpassword.Useasfewasone(and
uptoamaximumofsix)characters,usinganycombinationofletters,numbersandsymbols.Enteranewpasswordandpress
theEnterButton[10].Itwillnowpromptyoutoconfirmthenewpassword.EnteritandpresstheEnterButtonagaintoconfirm.
TheprocessorwillreturntotheUserPasswordsplashscreen.
