Martin Ranger U-6800R User manual

Martin Ranger U-6800R
Wireless Microphone
With Plug-in USB Recharging Lithium Battery
USER MANUAL
www.martinroland.com
U. S. A.
U H F
For warranty service must returned in original box.

Important Notice:
In order to better display wireless microphone system performance, please read the manual
carefully before use.
Don’t use the system in above environment
Non-professionals person could not dismantle the system at will.
Vents should not be covered such as newspapers, tablecloths, curtains and so on items
to obstruct ventilation.
Equipment should not be placed on the naked flame sources, such as lighted candles.
Don’t throw waste batteries, please put in the designated recycling bins
System can only work within -10℃-55℃.
Equipment should not be subjected to water or water splash, the equipment should not
be placed on the liquid items such as vase decoration.
Equipment with hazard “S” marked on the terminal is dangerous charged warned that
outside of these terminals connected wires need to be installed by a personnel or use
the thread guide leads or cord.
Characteristics and control functions of receiver
1, Power switch: Power supply on and off. (ON: Power on, the microphone work; OFF: turn
off the power; CHARGE: charging state.)
2, Recharging interface of USB
3, Antenna: Receiving signals from the transmitting microphone. Because customer use
the microphone transmitter in different location, it will cause the receiver antenna 1 and
antenna 2 receives the signal intensity changes, then function with automatic selection
information of the receiver will automatically switch to the reception signal strength channel
connected to the receiving system to ensure the best working condition, effectively
overcome the reception “blind spot” problem.
4, Volume: Output volume control knob, clockwise volume increase, counterclockwise
volume reduced.
5, RF indicated light: When the receiver to receive the signal from wireless transmitter, the
light bright.
Characteristics and control functions of back panel of receiver
1, Refer to below picture, connect with external devices: receiver MIC port connect with
Karaoke power amplifier MIC, MIC A as the left sound channel, MIC B is right channel,
MDING is mixed output.
2, Power supply: 220V/110V, turn on the power switch of receiver, adjust volume.

3, Adjust A, B two channel knob to right position, adjust the appropriate volume for MIC/A or
MIC/B, let you in high enjoy to sing and listen.
4, Pull up the power cord when long time not in use.
5, Receiver should be putted in the top position and pull-out the antennas for best operation.
Handheld microphone operation
1, Turn on the power switch in receiver.
2, Push the power switch in microphone to PWR position, check the power capacity of
batteries.
3, Check the multifunction display of receiver, to make sure the radio signals was receiving.
4, Push the power switch in microphone to “ON” (open) position, push the MUTE switch to
“OFF” position.
5, The MUTE switch should be pushed to “ON” (muting on) when the microphone is not in
use during singing or speech.
6, Power switch must be pushed to “OFF” (close) position to save power when the
microphone is not in use in the end of singing or speech.
Features and control functions for Belt-pack transmitter
Belt-pack transmitter
1, Battery cover: Push forward to open the battery cover
2, Turn on power switch “ON”, reverse is “OFF”
3, Power light
4, Input socket: Insert and tighten in a clockwise.
5, Collar microphone: it can be caught in the collar, tie, or other instrument to use.

Recharging Instruction
C5 rechargeable battery: (500Mah) 4-7 hours continuous working for microphone
C8 rechargeable battery: (800Mah) 7-10 hours continuous working for microphone
Backup battery case: 2*1.5V AA batteries
1, A. Rechargeable battery can be directly plugged into the USB port on the receiver⑥, plug
in the power switch to CHARGE, the battery charging indicator light when the power on;
the indicator light goes out when the battery is full charged.
B. The rechargeable battery can be plugged into the recharging socket (as below picture)
to connect power. The battery charging indicator light when the power on; the indicator
light goes out when the battery is full charged.
C. Rechargeable battery can be charging in computer or mobile socket. The battery
charging indicator light when the power on, the indicator light goes out when the battery is
full charged.
2. Pull out the battery when the battery is full charged. Do not plug the battery in charging
for long time to avoid to affect battery life. Notice: If you don’t pull out the battery, it will
automatically generate electricity when the external power supply stopped.
Specification
Frequency stability: 0.005%
Frequency response: 50Hz-20KHz
S/N ratio: ＞100dB
T.H.D.: ＜0.5%
Working range: ＞40m
Working temperature: -10℃-50℃
Power supply: AC110-240V, 50/60Hz
(The performance of the battery may limit the scope of work)
Frequency range:
The trick of getting best sound effect
Transmitter face to receiver antenna, no barrier in the middle.
Receiver and antenna must be far away from large metal equipment.
To avoid the rotation of receiver near computer or other RF equipment.
To avoid the rotation of receiver under audio equipment, unless antenna is placed over a
long distance.
Use the correct receiver antenna.
