Maruyama EH23DSL Owner's manual

The POWER in Outdoor Power
Completely read and understand this manual PRIOR to using this product.
Lea y entienda este manual a fondo, ANTES de usar este producto.
Lisez complètement et comprenez ce manuel AVANT d'utiliser ce produit.
OWNER'S/OPERATOR'S MANUAL
MANUAL DEL PROPIETARIO U OPERADOR
MANUEL DU PROPRIETAIRE/DE
L'UTILISATEUR
Hedge trimmer
Cortasetos
Taille-haie
EH23DSL
®

−US-1 −
— US-1 —
Limited Warranty Statement
All Maruyama commercial/ industrial products are warranted to the original purchaser to be free from defects
in material and workmanship from the date of purchase for the time periods listed as follows:
Lifetime for inner drive shaft on trimmers and brushcutters and all ignition modules.
3 years for residential, non-institutional, non-income producing use.
1 year for industrial, commercial, institutional, rental and income producing use.
Maruyama AE series engines and Kawasaki TEX45/TEX54 are covered exclusively for one additional
year of industrial, commercial, institutional, rental and income producing use (total of 2 years).
All other engines refer to engine manufacturer's warranty statement.
Any part of a Maruyama product found to be defective within the applicable warranty period shall, at
Maruyama's option, be repaired or replaced without charge. Warranty consideration is obtained by delivering
any Maruyama product believed to be defective to an Authorized Maruyama Servicing Dealer within the
applicable warranty period.
The purchaser shall not be charged for diagnostic labor that leads to the determination that a warranted part
is defective, if the diagnostic work is performed at a Maruyama Dealer.
Any warranted part which is not scheduled for replacement as required maintenance, or which is scheduled
only for regular inspection to the effect of "repair or replace as necessary" shall be warranted for the warranty
period. Any warranted part, which is scheduled for replacement as, required maintenance shall be warranted
for the period of time up to the first scheduled replacement point for that part. Maruyama Mfg. Co., Inc. is
liable for damages to other engine components caused by the failure of a warranted part still under warranty.
The purchaser is responsible for the performance of the required maintenance, as defined by Maruyama Mfg.
Co., Inc. in the Owner's/Operator's Manual.
EMISSION-RELATED PARTS WARRANTY: In addition to the above warranty coverage, Maruyama Mfg.
Co., Inc. will repair or replace, free of charge, for the original purchaser and each subsequent purchaser any
emission-related part or parts found to be defective in material and workmanship for two (2) years from origi-
nal retail delivery date. Emission-related parts are the carburetor assembly, the ignition coil assembly,
the ignition rotor, the spark plug, the catalytic converter and the fuel tank. Any replacement part that is
equivalent in performance and durability may be used in non-warranty maintenance or repairs, and shall not
reduce the warranty obligations of Maruyama Mfg. Co., Inc.
232025-04 12.11.30 11:49 AM ページ 2

−US-2 −
— US-2 —
This warranty does not cover the following:
1. Maintenance items (excluding defects in materials and workmanship) including hoses, spark plugs,
starter rope, air and fuel filters, clutch shoes, vibration isolators, throttle cables and all cutting attach-
ments, etc.
2. Extra expenses including shipping and handling, travel, payment for lost time or pay and for any inconve-
nience and storage.
3. Alterations or modifications including aftermarket parts not authorized by Maruyama U.S., Inc.
4. Wear, accident, abuse, neglect, misuse, negligence, improper fuels, lubricants, fuel mixtures (when
applicable), or failure to operate or maintain the product in accordance with instructions approved by
Maruyama.
Repair or replacement as provided under this warranty is the exclusive remedy of the consumer. Maruyama
shall not be liable for any incidental or consequential damages for breach of any express or implied warranty
on these products except to the extent prohibited by applicable law. Any implied warranty of merchantability
or fitness for a particular purpose on these products is limited in duration to the warranty period as defined in
the limited warranty statement. Maruyama reserves the rights to change or improve the design of the product
without notice and does not assume obligation to update previously manufactured products.
This warranty provides you with specific legal rights, which may vary from state to state.
It is the Owner's and Dealer's responsibility to make sure the Warranty Registration Card is properly filled out
and mailed to Maruyama U.S., Inc. Proof of purchase and registration will be required in order to obtain war-
ranty service.
To locate an Authorized Maruyama Servicing Dealer nearest you, contact:
.
Maruyama U.S., Inc.
4770 Mercantile Drive, suite100,
Fort Worth, TX 76137 U.S.A.
[phone]
[email protected]m
www.maruyama-us.com

−US-3 −
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
.
.
EH23DSL
— US-3 —
FEDERAL EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The U.S. Environmental Protection Agency (EPA), and Maruyama Manufacturing Company, Inc.
are pleased to explain the emission control system warrantyon your small off-road engine. New
1997 and later model year small off-road engines must be designed, built and equipped, at the time
of sale, to meet the U.S. EPA regulations for small off-road engines. The equipment engine must be
free from defects in materials and workmanship which cause it to fail to conform with U.S. EPA stan-
dards for the first two years of engine use from the date of sale to the ultimate purchaser. Maruyama
Manufacturing Company, Inc. must warrant the emission control system on your small off-road
engine for the period of time listed above provided there has been no abuse, neglect or improper
maintenance of your small off-road engine.
Emission durability of 300 hours.
Your emission control system may include parts such as the carburetor or fuel injection system, the
ignition system, and catalytic converter. Also included may be hoses, belts, and connectors and
other emission related assemblies.
Where a warrantable condition exists, Maruyama Manufacturing Company, Inc. will repair your
small off-road engine at no cost to you, including diagnosis (if the diagnostic work is performed at
an authorized dealer), parts, and labor.
MANUFACTURER'S WARRANTY COVERAGE:
The 1997 and later model year small off-road engines are warranted for two years. If any emis-
sion-related part on your engine is defective, the part will be repaired or replaced by Maruyama
Manufacturing Company, Inc. free of charge.
OWNER'S WARRANTY RESPONSIBILITIES:
(a)As the small off-road engine owner, you are responsible for the performance of the required
maintenance listed in your owner's/operator's manual.
Maruyama Manufacturing Company, Inc. recommends that you retain all receipts covering
maintenance on your small off-road engine, but Maruyama Manufacturing Company, Inc.
cannot deny warranty solely for the lack of receipts or for your failure to ensure the perfor-
mance of all scheduled maintenance. Any replacement part or service that is equivalent in
performance and durability may be used in non-warranty maintenance or repairs, and shall
not reduce the warranty obligations of the engine manufacturer.
The engine exhaust from this product
contains chemicals known to the State
of California to cause cancer, birth
defects or other reproductive harm.
WARNING:
.
.
B23L/B23
.
.
B27L/B27
B27L TURBO
.
.
B30L/B30L TURBO/B30

−US-4 −
— US-4 —
(b)As the small off-road engine owner, you should be aware, however, that Maruyama
Manufacturing Company may deny you warranty coverage if your small off-road engine or a
part has failed due to abuse, neglect, improper maintenance or unapproved modifications.
(c) You are responsible for presenting your small off-road engine to a Maruyama Manufacturing
Company, Inc. service center as soon as a problem exists. The warranty repairs should be
completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities, you should contact
Maruyama U.S., Inc. at 1-866-783-7400, or [email protected].
COVERAGE
Maruyama Manufacturing Company, Inc. warrants to the ultimate purchaser and each subse-
quent purchaser that your small off-road engine will be designed, built and equipped, at the time
of sale, to meet all applicable regulations. Maruyama Manufacturing Company, Inc. also warrants
to the initial purchaser and each subsequent purchaser that your small off-road engine is free
from defects in materials and workmanship which cause the engine to fail to conform with applic-
able regulations for a period of two years.
The 1997 and later model years, EPA requires manufacturers to small off-road engines for two
years. These warranty periods will begin on the date the small off-road engine is purchased by
the initial purchaser. If any emission-related part on your engine is defective, the part will be
replaced by Maruyama Manufacturing Company, Inc. at no cost to the owner.
Maruyama Manufacturing Company, Inc. shall remedy warranty defects at any authorized
Maruyama Manufacturing Company, Inc. engine dealer or warranty station. Any authorized work
done at an authorized dealer or warranty station shall be free of charge to the owner if such work
determines that a warranted part is defective. Any manufacturer-approved or equivalent replace-
ment part may be used for any warranty maintenance or repairs on emission-related parts, and
must be provided free of charge to the owner if the part is still under warranty, Maruyama
Manufacturing Company, Inc. is liable for damages to other engine components caused by the
failure of a warranted part still under warranty.
EPA considers emission-related warranted parts to include all the parts listed below. These war-
ranted parts are: the carburetor assembly, the ignition coil assembly, the ignition rotor, the
spark plug, the catalytic converter, and the fuel tank.
MAINTENANCE REQUIREMENTS
The owner is responsible for the performance of the required maintenance as defined by the
Maruyama Manufacturing Company, Inc. in the owner's/operator's manual.
LIMITATIONS
This Emission Control System Warranty shall not cover any of the following:
(a)repair or replacement required because of misuse or neglect, lack of required maintenance,
repairs improperly performed or replacements not conforming to Maruyama Manufacturing
Company, Inc. specifications that adversely affect performance and/or durability, and alter-
ations or modifications not recommended or approved in writing by Maruyama Manufacturing
Company, Inc., and
(b)replacement of parts and other services and adjustments necessary for required mainte-
nance at and after the first scheduled replacement point.

−US-5 −
— US-5 —
CALIFORNIA EMISSION CONTROL WARRANTY STATEMENT
YOUR WARRANTY RIGHTS AND OBLIGATIONS
The California Air Resources Board (CARB), and Maruyama Manufacturing Company, Inc. are
pleased to explain the emission control system warranty on your 2013 small off-road engine. In
California, new small off-road engines must be designed, built and equipped to meet the State's
stringent anti-smog standards. Maruyama Manufacturing Company, Inc. must warrant the emission
control system on your small off-road engine for the period of time listed above provided there has
been no abuse, neglect or improper maintenance of your small off-road engine.
Your emission control system may include parts such as the carburetor or fuel injection system, the
ignition system, and catalytic converter. Also included may be hoses, belts, and connectors and
other emission related assemblies.
Where a warrantable condition exists, Maruyama Manufacturing Company, Inc. will repair your
small off-road engine at no cost to you, including diagnosis, parts, and labor.
MANUFACTURER'S WARRANTY COVERAGE:
The 1995 and later small off-road engines are warranted for two years. If any emission-related part
on your engine is defective, the part will be repaired or replaced by Maruyama Manufacturing
Company, Inc.
OWNER'S WARRANTY RESPONSIBILITIES:
(a)As the small off-road engine owner, you are responsible for the performance of the required
maintenance listed in your owner's/operator's manual.
Maruyama Manufacturing Company, Inc. recommends that you retain all receipts covering
maintenance on your small off-road engine, but Maruyama Manufacturing Company, Inc.
cannot deny warranty solely for the lack of receipts or for your failure to ensure the perfor-
mance of all scheduled maintenance
(b) As the small off-road engine owner, you should be aware, however, that Maruyama
Manufacturing Company may deny you warranty coverage if your small off-road engine or a
part has failed due to abuse, neglect, improper maintenance or unapproved modifications.
(c) You are responsible for presenting your small off-road engine to a Maruyama Manufacturing
Company, Inc. distribution center as soon as a problem exists. The warranty repairs should
be completed in a reasonable amount of time, not to exceed 30 days.
If you have any questions regarding your warranty rights and responsibilities, you should contact
Maruyama U.S., Inc. at 1-866-783-7400, or [email protected].
Emission System Parts
Exhaust Emission
Carburetor
Muffler
Catalytic Converter
Ignition Coil / Magneto
Spark Plug
Air Filter
EGR Valve (piston)
Fuel Filter
Evaporative Emission
Fuel Tank

−US-6 −
Page US-
Limited Warranty Statement.........................................1
Federal Emission Control.............................................3
California Emission Control.........................................5
Introduction...................................................................7
Safety ............................................................................8
Operator Safety.....................................................8
Hedge trimmer Safety...........................................8
Fuel Safety............................................................9
Hedge trimmer Operating Safety .........................9
Product Description .................................................... 11
Safety Decals ..............................................................12
Symbol explanation ....................................................12
Assembling Engine and Drive ShaftAssembly .........13
Connecting Stop Switch Wires...........................13
Connecting Throttle Cable .................................13
Before Operation.........................................................15
Oil and Fuel........................................................15
Mixing Gasoline And Oil ...................................16
Starting And Stopping ........................................17
Page US-
Operating Hedge trimmer...........................................18
Operating Position..............................................19
Adjusting the angle of the blades.......................19
Maintenance................................................................20
Idle Speed Adjustment........................................20
Air Filter.............................................................21
Fuel Filter ...........................................................22
Spark Plug ..........................................................22
Cylinder Cooling Fins........................................23
Spark Arrester.....................................................24
Exhaust Muffler..................................................24
Adjusting Cutting Blades ...................................25
Cutting Blades Maintenance ..............................25
Lubrication .........................................................25
General Cleaning and Tightening.......................26
Storage........................................................................26
Troubleshooting..........................................................27
Maintenance Period ....................................................27
Specifications..............................................................28
Contents

−US-7 −
Thank you for purchasing a Maruyama product.
Maruyama, it’s distributors, and dealers want you to be
completely satisfied with your new product. Please
feel free to contact your local Authorized Service
Dealer for help with service, genuine Maruyama parts,
or other information you may require.
Whenever you contact your Authorized Service Dealer
or the factory, always know the serial number of your
product. This number will help the Service Dealer or
Service Representative provide exact information about
your specific product. You will find the model and
serial number located in a unique place on the product
(Product Description on page US-11).
For your convenience, write the product model name
and serial number in the space to the light.
Model Name
Serial No.
Read this manual carefully to learn how to operate and
maintain your product correctly. Reading this manual
will help you and others avoid personal injury and
damage to the product.
Although Maruyama designs, produces and markets
safe, state-of-the-art products, you are responsible for
using the product properly and safely. You are also
responsible for training persons who you allow to use
the product about safe operation.
Introduction

−US-8 −
The Maruyama warning system in this manual
identifies potential hazards and has special safety
messages that help you and others avoid personal
injury, even death. DANGER, WARNING and
CAUTION are signal words used to identify the level
of hazard. However, regardless of the hazard, be
extremely careful.
DANGER signals an extreme hazard that will cause
serious injury or death if the recommended precautions
are not followed.
WARNING signals a hazard that may cause serious
injury or death if the recommended precautions are not
followed.
CAUTION signals a hazard that may cause minor or
moderate injury if the recommended precautions are
not followed. Two other words are also used to
highlight information. “Important” calls attention to
special mechanical information and “Note” emphasizes
general information worthy of special attention.
Safety
Operator Safety
1. Read and understand this owner's/operator's
Manual before using this product. Be thoroughly
familiar with the proper use of this product.
2. Never allow children to operate the Hedge
trimmer. It is not a toy. Never allow adults to
operate the unit without first reading the owner's/
operator's Manual.
3. Always wear eye protection that complies with
ANSI (American National Standards Institute)
Z87-1.
4. Always wear hearing protection.
5. Always wear heavy, long pants, a long sleeved
shirt, boots and gloves. Do not wear loose
clothing, jewelry, short pants, sandals, or go
barefoot. Secure hair so it is above shoulder
length.
6. Never operate this Hedge trimmer when you are
tired, ill, or under the influence of alcohol, drugs
or medication.
7. Never start or run the engine inside a closed room
or building. Breathing exhaust fumes can cause
death.
8. Keep handles clean of oil, fuel and dirt.
Hedge trimmer Safety
1. Make sure the Hedge trimmer is assembled
correctly.
2. Inspect the Hedge trimmer before each use.
Replace damaged parts. Check for fuel leaks.
Make sure all fasteners are in place and tightened
securely. Follow the maintenance instructions
beginning on page US-20.
3. Make sure the blades does not move at engine idle
speed. Refer to Idle Speed Adjustment, page
US-20.
4. Inspect the blades, guide and replace any parts
that are cracked, chipped or damaged before using
the Hedge trimmer.

−US-9 −
5. Where the Hedge Trimmer is provided with
adjustments to the angle of the cutting device
never hold the cutter blades when making
adjustments to the working position of the cutting
device. Always ensure that the cutting device is
correctly located in a designated working position
before starting the engine or plugging in to the
mains.
6. Never use blades or replacement parts that are not
approved by Maruyama.
7. Maintain the Hedge trimmer according to the
recommended maintenance intervals and
procedures in the Maintenance section on page
US-20.
8. Shut off the engine and be certain the blades has
completely stopped moving before inverting the
Hedge trimmer, performing maintenance on or
working on the machine.
9. If running problems or excessive vibration occur,
stop immediately and inspect the unit for the
cause. If the cause cannot be determined or is
beyond your ability to correct, return the Hedge
trimmer to your servicing dealer for repair.
Fuel Safety
1. Gasoline is highly flammable and must be handled
and stored carefully. Use a container approved for
fuel to store gasoline and/or fuel/oil mixture.
2. Mix and pour fuel outdoors, where there are no
sparks or flames.
3. Do not smoke near fuel or Hedge trimmer, or
while using the Hedge trimmer.
4. Do not overfill the fuel tank. Stop filling 1/4-1/2
inch (6 mm-13 mm) from the top of the tank.
5. Wipe up any spilled fuel before starting the
engine.
6. Move the Hedge trimmer at least 10 feet (3 m)
away from the fueling location before starting the
engine.
7. Do not remove the fuel tank cap while the engine
is running, or right after stopping the engine.
8. Allow the engine to cool before refueling.
9. Drain the tank and run the engine dry before
storing the unit.
10. Store fuel and Hedge trimmer away from open
flame, sparks and excessive heat. Make sure fuel
vapors cannot reach sparks or open flames from
water heaters, furnaces, electric motors, etc.
Hedge trimmer Operating Safety
1. THIS HEDGE TRIMMER CAN CAUSE
SERIOUS INJURIES. Read the instructions
carefully. Be familiar with all controls and the
proper use of the Hedge trimmer.
10 feet (3 m) Minimum

−US-10 −
2. Inspect your work area before you begin. Remove
string, rope or similar materials which can become
entangled in the Hedge trimmer blades.
3. Keep children, bystanders and animals outside
operating area.
4. If you are approached while operating the Hedge
trimmer, stop the engine and cutting blades
moving.
5. Never allow children to operate the Hedge
trimmer.
6. Use the Hedge trimmer only in daylight or good
artificial light.
7. Always keep the Hedge trimmer on the right side
of your body.
8. Do not put hands or feet near or under any moving
parts. Keep clear at all times. Keep all parts of
your body away from the moving cutting blades
and hot surfaces such as the muffler.
9. Keep firm footing and balance. Do not overreach.
10. Do not operate the Hedge trimmier while standing
on a ladder or similar temporary support.
11. Use the right tool for the job. Do not use the
Hedge trimmer for any job that is not
recommended by Maruyama.
Safety and Instruction Decals
Safety decals and instructions are easily visible to the
operator and are located near any area of potential
danger. Replace any decal that is damaged or lost.
ON SHAFT
(Part No.221501)
ON SHAFT
(Part No.221502)
Assembly
Loop Handle Installation
The loop handle kit contains a package of four screws
nuts and the bottom clamp for the loop handle.
1. Place the loop handle and the bottom clamp
approximately 9 inches (22.8 cm) from the end of
the stop switch/throttle trigger assembly for an
initial handle position.
2. Install the four screws and nuts. Leave the screws
finger-tight.
3. Reposition the loop handle up or down the drive
shaft to the most comfortable position, but no closer
than 9 inches (22.8 cm) from the end of the stop
switch.
4. Tighten the screws and nuts.
Handlebar Installation
IMPORTANT: Be careful not to damage the throttle
cable and stop switch wires when you remove the
handlebars from the shipping carton.

−US-11 −
Product Description
12
4
4
7
8
9
10 11
13 12
14
15
1. Blade
2. Gearcase
3.Angle Drive
4. Safety Decal
5. ShaftAssembly
6. Model Name
7. Shaft Grip
8. Throttle Trigger and Stop
Switch
9. Clutch Drum Housing
10. Engine
11. Serial Number (on rear of
engine)
12.Air Filter
13. Fuel Tank
14. Throttle Cable and Stop
Switch Wires
15. Blade Cover
3
EH23DSL
4
11
4
5
6

−US-12 −
Symbol explanation
Indicates Warning, Danger, Caution.
Read and understand this Ownerʼs/Operatorʼs Manual.
Always be careful to wear a face protector, ear protector and helmet when using your Hedge
Trimmer.
Keep hands away from cutting blades.
ON ANGLE DRIVE
(Part No. 407349)
ON SHAFT
(Part No. 221501)
ON SHAFT
(Part No. 217879)
Add grease to
gearcase every
10 hours of use.
ON GEARCASE
(Part No. 223925)
Safety Decals
Safety Decals are easily visible to the operator and are located near any area of potential danger.
Replace any decal that is damaged or lost.

−US-13 −
Assembly
Assembling Engine and Drive Shaft Assembly
Attach the clutch drum housing to the engine using the four screws
supplied with the unit.
Connecting Stop Switch Wires
1. Install the plastic tube (packed with the driveshaft assembly) around
the throttle cable and stop switch wires.
2.
Loosen the knob and remove the air filter cover to access the stop
switch wires.
3.
Plug the stop switch wires into the matching connectors from the
engine. Note that wire polarity is not important.
Connecting Throttle Cable
1. With the air filter cover removed, insert the throttle cable through the
cable adjuster sleeve on the carburetor bracket. Make sure the end
of the cable housing is seated positively in the sleeve.
2.
Position the slotted fitting on the carburetor so the recessed hole for
the lug is away from the cable adjuster sleeve.
3.
Rotate the carburetor throttle cam and slip the throttle cable through
the slot in the slotted fitting, making sure the cable lug drops into the
recessed hole.
4.
Operate the throttle trigger a few times to make sure that it works
correctly.
5.
Adjust the cable adjuster sleeve so the stop on the carburetor
throttle cam just contacts the throttle stop and the cable position
keep 1-2mm play between cable lug and slotted fittings when the
throttle trigger is fully depressed.
Engine Screw (4)
Clutch Drum Housing
Stop Switch Wires
Plastic Tube
Throttle Cable
Stop Switch Wires
Knob
Matching Connectors
Matching
Connectors
Shaft Grip
Throttle Cable Housing
Cable Adjuster Sleeve
Lock Nut
Throttle Cable
Slotted Fitting
Cable Lug
Carburetor
Bracket
Air Filter
Cover
Recessed Hole

−US-14 −
6. When the throttle cable is adjusted correctly, tighten the locknut.
Cable Adjuster
Sleeve
Slotted Fitting
Idle Speed Adjustment
Screw
Throttle Stop/Idle Speed
Adjustment Screw Bracket
Carburetor Throttle Cam

−US-15 −
Before Operation
Oil and Fuel
1. Do not smoke near fuel.
2. Mix and pour fuel outdoors and where there are
no sparks or flames.
3. Always shut off the engine before refueling.
Never remove the fuel tank cap while the engine
is running or just right after sopping the engine.
4. Always open the fuel tank cap slowly to release
any possible overpressure inside the tank.
5. Do not overfill the fuel tank. Stop filling 1/4-1/2
inch (6 mm-13 mm) from the top of the tank.
6. Tighten the fuel tank cap carefully but firmly after
refilling.
7. Wipe up any spilled fuel before starting the
engine.
8. Move the Hedge trimmer at least 10 feet (3 m)
away from the fueling location and fuel storage
container before starting the engine.
DANGER
POTENTIAL HAZARD
• In certain conditions gasoline is
extremely flammable and highly
explosive.
WHAT CAN HAPPEN
• A fire or explosion from gasoline can
burn you, others, and cause property
damage.
HOW TO AVOID THE HAZARD
• Use a funnel and fill the fuel tank
outdoors, in an open area, when the
engine is cold. Wipe up any gasoline
that spills.
• Do not fill the fuel tank completely full.
Add gasoline to the fuel tank until the
level is 1/4” to 1/2” (6 mm to 13 mm)
below the bottom of the filler neck. This
empty space in the tank allows gasoline
to expand.
• Never smoke when handling gasoline,
and stay away from an open flame or
where gasoline fumes may be ignited by
a spark.
• Store gasoline in an approved container
and keep it out of the reach of children.
• Never buy more than a 30-day supply of
gasoline.
WARNING
POTENTIAL HAZARD
• Gasoline contains gasses that can build
up pressure inside a gas tank.
WHAT CAN HAPPEN
• Fuel can be sprayed on you when
removing gas cap.
HOW TO AVOID THE HAZARD
• Remove fuel cap slowly to avoid injury
from fuel spray.
10ft.(3m) Minimum

−US-16 −
Recommended Oil Type
Only use a two-cycle engine oil formulated for use in
high-performance, air-cooled two-cycle engines.
Maruyama brand 2-cycle oil is formulated for use in
high-performance, air-cooled two-cycle engines.
IMPORTANT: Do not use National Marine
Manufacturer’s Association (NMMA) or BIA
certified oils. This type of 2-cycle engine oil
does not have the proper additives for air-
cooled, 2-cycle engines and can cause engine
damage.
Do not use automotive motor oil. This type of
oil does not have the proper additives for air-
cooled, 2-cycle engines and can cause engine
damage.
Recommended Fuel Type
Use clean, fresh lead-free gasoline, including
oxygenated or reformulated gasoline, with an octane
rating of 89 or higher. To ensure freshness, purchase
only the quantity of gasoline that can be used in 30
days. Use of lead-free gasoline results in fewer
combustion chamber deposits and longer spark plug
life. Use of premium grade fuel is not necessary or
recommended.
Use of Fuel Additives
IMPORTANT: NEVER USE ALCOHOL,
GASOHOL CONTAINING MORE THAN
10% ALCOHOL BECAUSE ENGINE FUEL
SYSTEM DAMAGE COULD RESULT.
DO NOT USE FUEL ADDITIVES OTHER
THAN THOSE MANUFACTURED FOR
FUEL STABILIZATION DURING STORAGE
SUCH AS MARUYAMA’S STABILIZER/
CONDITIONER OR A SIMILAR PRODUCT.
MARUYAMA’S STABILIZER/
CONDITIONER IS A PETROLEUM
DISTILLATE BASED CONDITIONER/
STABILIZER.
MARUYAMA DOES NOT RECOMMEND
STABILIZERS WITH AN ALCOHOL BASE
SUCH AS ETHANOL, METHANOL OR
ISOPROPYL. ADDITIVES SHOULD NOT
BE USED TO TRY TO ENHANCE THE
POWER OR PERFORMANCE OF
MACHINE.
Mixing Gasoline And Oil
IMPORTANT: The engine used on this Hedge
trimmer is of a 2-cycle design. The internal
moving parts of the engine, i.e., crankshaft
bearings, piston pin bearings and piston to
cylinder wall contact surfaces, require oil mixed
with the gasoline for lubrication.
Failure to add oil to the gasoline or failure to
mix oil with the gasoline at the appropriate
ratio will cause major engine damage which will
void your warranty.
For your fuel premix, use Maruyama Premium
2-cycle Oil Mix, or equivalent ISO-L-EGD &
JASO FD oil with a minimum 89 octane high
quality gasoline. Maruyama 2-cycle oil is
specially formulated to meet the requirements
of high-performance, low-emission air-cooled
2-cycle engines. Use of other oils may lead to
service issues which may not be covered by your
warranty.
Fuel Mixture
The fuel: oil ratio is 50 parts gasoline to 1 part oil or
50:1.
50:1

−US-17 −
Note:.............Never use a mixing ratio less than 50:1
regardless of the oil package mixing instructions.
Ratios less than 50:1, (for example, 60:1, 80:1,
100:1), reduce the amount of lubrication to the
internal moving parts of the engine and can cause
damage.
Fuel Mixture Chart
Gasoline 50:1 2-cycle oil
1 gallon 2.6 oz.
2 gallons 5.1 oz.
5 gallons 12.8 oz.
1 litre 20 ml
5 litre 100 ml
Mixing Instructions
IMPORTANT: Never mix gasoline and oil directly
in the Hedge trimmer fuel tank.
1. Always mix fuel and oil in a clean container
approved for gasoline.
2. Mark the container to identify it as fuel mix for
the Hedge trimmer.
3. Use regular unleaded gasoline and fill the contain-
er with half the required amount of gasoline.
4. Pour the correct amount of oil into the container
then add the remaining amount of gasoline.
5. Close the container tightly and shake it momentar-
ily to evenly mix the oil and the gasoline before
filling the fuel tank on the Hedge trimmer.
6. When refilling the Hedge trimmer fuel tank, clean
around the fuel tank cap to prevent dirt and debris
from entering the tank during cap removal.
7. Always shake the premix fuel container
momentarily before filling the fuel tank.
8. Always use a spout or funnel when fueling to
reduce fuel spillage.
9. Fill the tank only to within 1/4-1/2 inch (6 mm-13
mm) from the top of the tank. Avoid filling to the
top of the tank filler neck.
Starting And Stopping
Before Starting The Engine
1. Fill the fuel tank as instructed in the Operation
section of this manual (US-16).
2. Rest the Hedge trimmer on the ground.
3. Make sure the cutting attachment is clear of any
broken glass, nails, wire, rocks or other debris.
4. Keep all bystanders, children and animals away
from the working area.
Cold Starting Procedure
This Trimmer is equipped with a fuel primer and a
choke system. To start a “cold” engine properly,
perform the following procedure:
1. Pump the primer bulb at the bottom of the
carburetor until fuel can be seen flowing through
the fuel return line to the fuel tank.
(Flowing fuel should be almost clear, not foamy
or full of bubbles.)
Primer Bulb
Fuel
Return
Line

−US-18 −
2. Move the choke lever to the closed ( ) position
and move the stop switch to the “ON” position.
3. Lock the throttle trigger in the fast-idle start
position, then pull the starter grip.
4. After the engine starts, squeeze and release the
throttle trigger to return it to the idle position, then
move the choke lever to the open ( ) position.
If the engine stops running before you move the
choke lever to the open ( ) position:
A. Go ahead and open the choke.
B. Make sure the throttle trigger is set to the idle
position.
C. Pull the starter grip until the engine starts.
Hot Restart
To start an engine that is already warmed up (hot
restart), or if the ambient temperature exceeds 68°F
(20°C):
1. Pump the primer bulb at the bottom of the
carburetor until fuel can be seen flowing through
the fuel return line to the fuel tank.
2. Move the choke lever to the open ( ) position
and move the stop switch to the “ON” position.
3. Leave the throttle trigger in the idle position and
pull the starter grip.
4. If the engine fails to start after three to four pulls,
follow the instruction in the Cold Starting
Procedure section (US-18).
If the engine fails to start after you follow the
above procedures, contact an authorized
Maruyama dealer.
To Stop The Engine:
1. Release the throttle trigger.
2. Slide the stop switch to the “STOP” position.
Operating Hedge trimmer
Starter Grip
Choke Lever
Stop Switch
STOP
START (ON)
Fast-idle lock
Throttle Trigger (In
fast-idle start
position)
Throttle Trigger
(In idle position)
➯
➯
WARNING
POTENTIAL HAZARD
• The components of your recoilstarter
assembly are under high spring tension.
If improperly disassembled these parts
maystrike you with considerable force,
possibly causing personal injuly.
WHAT CAN HAPPEN
• Contact with the parts can cause
severer personal injury.
HOW TO AVOID THE HAZARD
• Never attempt to disassemble your
recoil starter assembly yourself.
Always consult your authorized
Maruyama dealer for repair by qualified
service technicians. CAUTION
• Read the Safety instructions on page
US-8 concerning proper use of the
Hedge Trimmer.

−US-19 −
Operating Position
Before using the Hedge Trimmer, check the following.
1.
The Hedge trimmer should be on the operator’s right
side.
2 The operator’s right hand should be holding the shaft
grip, with his or her fingers on the throttle trigger.
The right arm should be slightly bent.
3. The left hand should be holding the shaft grip with
the fingers.
4. The Hedge Trimmer weight should be evenly
distributed between the arms.Before using the Hedge
tirimmer check the fo
llowing:
5. Make sure the blades are moving (at least half th-
rottle) before actual cutting begins. The HedgeTrim-
mer performs best at full throttle.
6. Always release the throttle trigger and allow the
engine to return to idle speed when not cutting.
7. Stop the engine when moving between work sites.
・If the cutting blades becomes jammed, stop the
engine immediately.
・Make certain all moving parts have stopped and
disconnect the spark plug before inspecting the
equipment for damage.
・Never use a Hedge Trimmer that has chipped,
cracked or broken Blades.
Adjusting the angle of the blades
Note: Never use the unit if the blade angle is not
48 degrees upwards to 84 degrees downward.
1. First stop the engine. Next attach the blade cover.
2. Turn the clamp knob counter clock wise until the
clamp knob stops. Angle adjustments are not
possible without completely loosening the clamp
knob.
3. Always hold the handle when adjusting the
blades. The blades adjust from a 48 degree
upward angle to an 84 degree downward angle.
Never push the lock lever when adjusting the
angle of the blades.
4. After you have adjusted the angle of the blades
tighten the clamp knob firmly and fix the gearcase
in place. When tightening the clamp knob, make
sure both racks engage.
CAUTION
CAUTION
CAUTION
• Do not touch the sharpened edges of the
cutting blades. The cutting blades are
extremely sharp and dangerous at all
times. Always wear gloves to help
protect your hands and fingers from
injury.
• Do not touch the sharpened edges of the
cutting blades. The cutting blades are
extremely sharp and dangerous at all
times. Always wear gloves to help
protect your hands and fingers from
injury.
• Do not hold any part other than the
handle when adjusting the angle of the
blades.
• Stop the engine when adjusting the
angle of the blades.
• The thickness of branches which may be
cut using this trimmer is limited to up
to appro-ximately 3/16”. Never try to
cut branches thicker than this, as doing
so may result in damage to the trimmer.
