Marvin GX2472 Release note

GX2472
Two Channel 70MS/s
Waveform Digitizer
Driver Manual
Revision 1.2, Ma 2007
GEOTEST
MARVIN TEST SYSTEMS, INC.

Safety and Handling
Each product shipped b Geotest is carefull inspected and tested prior to shipping. The
shipping box provides protection during shipment, and can be used for storage of both the
hardware and the software when the are not in use.
The circuit boards are extremel delicate and require care in handling and installation. Do not
remove the boards from their protective plastic coverings or from the shipping box until ou
are read to install the boards into our computer.
If a board is removed from the computer for an reason, be sure to store it in its original
shipping box. Do not store boards on top of workbenches or other areas where the might be
susceptible to damage or exposure to strong electromagnetic or electrostatic fields. Store
circuit boards in protective anti-electrostatic wrapping and awa from electromagnetic fields.
Be sure to make a single cop of the software diskette for installation. Store the original
diskette in a safe place awa from electromagnetic or electrostatic fields. Return compact
disks (CD) to their protective case or sleeve and store in the original shipping box or other
suitable location.
Warranty
Geotest products are warranted against defects in materials and workmanship for a period of
12 months. Software products and accessories are warranted for 3 months, unless covered
b software support or maintenance agreement. Geotest shall repair or replace (at its
discretion) an defective product during the stated warrant period. The software warrant
includes an revisions or new versions released during the warrant period. Revisions and
new versions ma be covered b a software support agreement. If ou need to return a
board, please contact Geotest Customer Technical Services Department via
http://www.geotestinc.com/magic - the Geotest on-line support s stem.
If You Need Help
Visit our web site at http://www.geotestinc.com for more information about Geotest products,
services and support options. Our web site contains sections describing support options and
application notes, as well as a download area for downloading patches, example, patches
and new or revised instrument drivers. To submit a support issue including suggestion, bug
report or question please use the following link: http://www.geotestinc.com/magic
You can also use Geotest technical support phone line [phone]. This service is
available between 7:30 AM and 5:30 PM Pacific Standard Time.
Disclaimer
In no event shall Geotest or an of its representatives be liable for an consequential
damages whatsoever (including unlimited damages for loss of business profits, business
interruption, loss of business information, or an other losses) arising out of the use of or
inabilit to use this product, even if Geotest has been advised of the possibilit for such
damages.
Copyright
Cop right  2003-2007 b Geotest, Marvin Test S stems, Inc. All rights reserved. No part of
this document can be reproduced, stored in a retrieval s stem, or transmitted, in an form or
b an means, electronic, mechanical, photocop ing, recording, or otherwise, without the
prior written consent of Geotest.
Trademarks
ATEasyGeotest – MTS Inc.
C++ Builder, Borland C++, Pascal and Delphi Borland Corpora
tion
Microsoft Developer Studio, Microsoft Visual C++, Microsoft Visual Ba
sic,, .NET, Windows 95, 98, NT, ME, 2000 and XP
Microsoft Corpora
tion
All other trademarks are the propert of their respective owners.

TAB E OF CONTENTS
Safet and Handling.................................................................................................................1
Warrant ..................................................................................................................................1
If You Need Help......................................................................................................................1
Disclaimer................................................................................................................................1
Cop right..................................................................................................................................1
Trademarks..............................................................................................................................1
Introduction .............................................................................................................................. 4
1 GX2472 driver package ......................................................................................................... 5
1.1 Installation ....................................................................................................................... 5
1.2 Uninstalling the low level driver ....................................................................................... 5
1.3 “Manual” installation of the low level driver ..................................................................... 5
2 GX2472 DLL functions. .......................................................................................................... 7
2.1 gx2472_AutoCalibrate (vi, mode, displa Time) .............................................................. 7
2.2 gx2472_CheckTestStatus (vi, testStatus) ....................................................................... 7
2.3 gx2472_close( vi ) ........................................................................................................... 7
2.4 gx2472_CodeToVoltage (vi, ADCCode, voltage) ............................................................ 8
2.5 gx2472_ConnectCard(vi , positveInputConnection, negativeInputConnection ) ............. 8
2.6 gx2472_error_message( vi, statusCode, errorMessage ) ............................................... 8
2.7 gx2472_FindInstruments( buslist, devicelist, count ) ...................................................... 9
2.8 gx2472_GetActiveChannel( vi , channel ) ....................................................................... 9
2.9 gx2472_GetAddressCounter(vi, addresscounter ) .......................................................... 9
2.10 gx2472_GetCardConnection(vi, positiveInputConnection, negativeInputConnection )
............................................................................................................................................ 10
2.11 gx2472_GetCardId(vi , id ) .......................................................................................... 10
2.12 gx2472_GetClockDivider (vi, clockDivider) ................................................................. 10
2.13 gx2472_GetClockSource (vi, clockSource) ................................................................. 10
2.14 gx2472_GetDCOffsetLimitVoltages (vi, positiveVoltage, negativeVoltage) ................ 11
2.15 gx2472_GetDCOffsetVoltage(vi , voltage ) ................................................................. 11
2.16 gx2472_GetFilter (vi, filterStatus) ............................................................................... 11
2.17 gx2472_GetGainCalCode (vi, gainCalibrationCode) .................................................. 11
2.18 gx2472_GetInputVoltage (vi, voltage, code, averages, timeOut) ................................ 11
2.19 gx2472_GetLoopMode (vi, loopMode) ........................................................................ 12
2.20 gx2472_GetOffsetCalDacCode(ci, code) .................................................................... 12
2.21 gx2472_GetRange (vi, range) ..................................................................................... 12
2.22 gx2472_GetSampleDivider (vi, sampleDivider) .......................................................... 12
2.23 gx2472_GetSoftwareTriggerStatus(vi, triggerstatus ) ................................................. 12
2.24 gx2472_GetTriggerInput (vi, triggerSource, triggerMode) ........................................... 13
2.25 gx2472_init( resourcediscription , IDQuer , reset, vi ) ............................................... 13
2.26 gx2472_Memor Test (vi, level, errorAddress) ............................................................ 14
2.27 gx2472_ReadAdcResults (vi, startPosition, samples, buffer, includeStatusBits) ........ 14
2.28 gx2472_ReadEEPROM(vi , eeaddress , data) ........................................................... 14
2.29 gx2472_ReadInstrumentMemor (vi, data ) ................................................................. 14
2.30 gx2472_ReadInstrumentMemor Arra (vi , length , buf32, dataInterpretation ) ........... 15
2.31 gx2472_ReadRegister(vi, address, data ) ................................................................... 15
2.32 gx2472_reset(vi ) ........................................................................................................ 15
2.33 gx2472_revision_quer ( vi, driverRev, instrRev ) ....................................................... 15
2.34 gx2472_self_test( vi, testResult, errorMessage ) ........................................................ 16
2.35 gx2472_SetActiveChannel(vi , channel ) .................................................................... 16
2.36 gx2472_SetAddressCounter (vi, addressCounterPosition) ......................................... 16
2.37 gx2472_SetClockDivider(vi , clockdivider ) ................................................................. 16
2.38 gx2472_SetClockOutputEnable(vi, enable ) ............................................................... 17
2.39 gx2472_SetClockSource(vi, clocksource ) .................................................................. 17
2.40 gx2472_SetDCOffsetCode(vi , code, connect ) .......................................................... 17
2.41 gx2472_SetDCOffsetVoltage(vi, voltage, connect ) .................................................... 17
2.42 gx2472_SetDCOffsetLimitVoltages(vi , posvolt , negvolt ) .......................................... 18
2.43 gx2472_SetFilter(vi , filter ) ......................................................................................... 18
2.44 gx2472_SetGainCalCode (vi, code) ........................................................................... 18
DUAL 70MSPS WAVEFORM DIGITIZER
2

2.45 gx2472_SetLockMode(vi , lock ) ................................................................................. 19
2.46 gx2472_SetLoopMode (vi, loopMode) ........................................................................ 19
2.47 gx2472_SetOffsetCalCode(vi, code) .......................................................................... 19
2.48 gx2472_SetRange(vi , range ) .................................................................................... 19
2.49 gx2472_SetSampleDivider (vi, sampleDividerValue) .................................................. 20
2.50 gx2472_SetSoftwareTriggerStatus(vi , triggerstatus ) ................................................ 20
2.51 gx2472_SetTriggerInput(vi , triggersource , triggermode ) .......................................... 20
2.52 gx2472_WriteCardId(vi , id ) ....................................................................................... 21
2.53 gx2472_WriteEEPROM(vi , eeaddress , data ) ........................................................... 21
2.54 gx2472_WriteId(vi , id ) ............................................................................................... 21
2.55 gx2472_WriteInstrumentMemor (vi , data ) ................................................................ 21
2.56 gx2472_WriteInstrumentMemor Arra (vi , length , buffer ) ......................................... 22
2.57 gx2472_WriteRegister(vi , addrress, data ) ................................................................. 22
3 Status codes ........................................................................................................................ 23
DUAL 70MSPS WAVEFORM DIGITIZER
3

Introduction
The GX2472 is a 70MHz dual channel Waveform Digitizer. For software development and
integration in a PXI s stem, the card is provided with a software driver, utilit software, a
demo program for LabView and a calibration tool.
The main part of the GX2472 driver consisst of a Windows d namic link librar , the
gx2472.DLL
For Labview users the driver also includes a LabView librar with the gx2472.dll driver
functions.
This manual describes the functions of the gx2472.dll.
DUAL 70MSPS WAVEFORM DIGITIZER
4

1 GX2472 driver package
The driver includes the following items:
1) A low level driver for direct communication;
2) The user mode driver, gx2472.dll;
3) A Labview librar , gx2472.llb
4) A LabWindows driver (function tree) gx2472.fp including the source file gx2472.c and
the header file gx2472.h. For basic programmers a GX2472.bas file is included.
The following low level drivers can be installed:
1) A kernel mode pxi driver, gx2472.s s;
2) VISA based driver which requires the installation of VISA which is available from
National Instruments.
1.1 Installation
Install the GX2472 Driver Software before the hardware is placed in the s stem.
Place the installation CD in the CD-ROM. If the installation program does not start
automaticall , run the program setup.exe (placed in the root of the CD-ROM).
If the software is installed on a Windows NT based operating s stem (Win2000, WinNT,
WinXP), ou should have Administrator rights.
The PXI Kernel Driver cannot be installed on Windows95 or Windows NT. This selection will
be disabled if one of these operating s stems is detected.
After installation shutdown the computer and place the GX2472 in the s stem. After turning
on the computer the operation s stem should automaticall detect the new hardware and
install the low level driver.
1.2 Uninstalling the low level driver
Before switching from the low-level driver to the VISA based driver, uninstall the current low-
level driver
For uninstalling the low level driver, perform the following steps:
1. Start the Device Manager
2. Select the “GX2472 PXI driver” and uninstall the driver;
3. Go to the Windows inf-director (e.g. Windows\inf, hidden director ).
4. Delete the gx2472_xxxx.inf file. The addition of xxxx indicates the Windows Operation
S stem version.
5. If installed with the pxi kernel mode driver, go the Windows sub-director
S stem\Drivers (e.g. C:\Windows\S stem\Drivers).
6. Delete the gx2472.s s file.
1.3 “Manual” installation of the low level driver
1. Cop the corresponding inf-file to the Windows Inf-subdirector (e.g. C:\Windows\inf).
The inf-files can be found in the following directories of the CD-ROM:
For Visa installation:
Director : \Driver\Visa
Windows9x “gx2472_9x.inf”
WindowsNT4 “gx2472_nt4.inf”
Windows2000 “gx2472_nt5.inf”
WindowsXP “gx2472_nt5.inf”
DUAL 70MSPS WAVEFORM DIGITIZER
5

For the PXI kernel mode driver installation:
Director : \Driver\Kernel
Windows98 “gx2472.inf”
Windows2000 “gx2472.inf”
WindowsXP “gx2472.inf”
The inf-subdirector is a hidden director .
2. If the pxi kernel mode driver is installed, cop also the gx2472.s s file. This file can be
found in the director \Drivers\Kernel\Winxx, where xx indicates the operating s stem.
Cop this file to the Windows sub-director \S stem\Drivers (e.g.
C:\Windows\S stem\Drivers);
3. Turn the s stem off and place the GX2472 in the s stem;
4. Turn the s stem on and reboot the host computer;
5. The operation s stem should detect new hardware;
Be sure driver signing is set to Ignore or Warn, when installing the GX2472 pxi kernel driver
on a Win2000 or WinXP s stem.
If the “Add new hardware” wizard doesn't start or something went wrong during installation,
start the Device Manager. Select the device (normall marked with a question mark, if the
driver could not be loaded) and select properties. Then install/reinstall the driver.
DUAL 70MSPS WAVEFORM DIGITIZER
6

2 GX2472 DLL functions.
This chapter describes the functions of the dll. Each function and its parameters are
described in a table. The following parameter t pes are used:
Type Details
unsigned long 4-b te (32 bit) unsigned long
double 8-b te floating point
unsigned long* reference variable (pointer) to a 4-b te (32 bit) unsigned long
double* reference variable (pointer) to a 8-b te floating point
All functions use the standard calling conventions (stdcall or WINAPI). Ever function returns
the ViStatus (t pe: 32-bit integer). A negative value corresponds to an error. After a
successful completion the return status is VI_SUCCESS, which corresponds to a 0. Possible
status codes can be found in Chapter 3.
2.1 gx2472_AutoCalibrate (vi, mode, displayTime)
Description:
This function performs an auto calibration procedure. The input DC-offset should alread be
calibrated. The calibration voltages can be monitored on the negative input of the module’s
two channels.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
mode unsigned long in mode 0 no monitoring
1 monitor at neg. input
displa Time double in displa time time to displa voltage at
negative input
2.2 gx2472_CheckTestStatus (vi, testStatus)
Description:
This function returns the test status. It will return a 1 if the memor address counter passes
the maximum address counter value (read ). Bit 0 represents channel A, bit 1 channel B.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
testStatus unsigned long* out Test Status 0 A & B not read
1 Channel A read
2 Channel B read
3 A & B read
2.3 gx2472_close( vi )
Description:
Close the card session. All resources belonging to the card will be released.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
DUAL 70MSPS WAVEFORM DIGITIZER
7

2.4 gx2472_CodeToVoltage (vi, ADCCode, voltage)
Description:
This function converts an ADC Code to the corresponding voltage.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
ADCCode unsigned long in mode 0 to 2^32
voltage double* out voltage corresponding voltage
2.5 gx2472_ConnectCard(vi , positveInputConnection,
negativeInputConnection )
Description:
This function connects/disconnects the input rela s. There are 4 rela s for each input. Each
rela can be controlled with a bit:
•Bit 1 (value 1 Hex) : Input rela ;
•Bit 2 (value 2 Hex) : 50 Ohm rela ;
•Bit 3 (value 4 Hex) : 50 Ohm DC rela , this bit controls the positive and negative
channel simultaneousl ;
•Bit 4 (value 8 Hex) : Ground rela , connect input to ground.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
positiveInputConnection unsigned long in positive input see description
negativeInputConnection unsigned long in negative input see description
2.6 gx2472_error_message( vi, statusCode, errorMessage )
Description:
Get the text string corresponding the statusCode. ErrorMessag should be at least have a size
of 255.
Parameters:
Name Type Direction Description Value
vi unsigned
long
in Instrument Handle 0 to 2^32
statusCode unsigned
long
in The status code returned b a
gx2472 driver function
0 to 2^32
errorMessage char* out The error message string
gx2472_error_query( vi, errorCode, Message )
Description:
Error Quer is not supported b this instrument. This function onl exists for compliance with
the VXI Plug and Pla specifications.
It returns a defined value VI_WARN_NSUP_ERROR_QUERY.
DUAL 70MSPS WAVEFORM DIGITIZER
8

Parameters:
Name Type Direction Description Value
vi unsigned
long
in Instrument Handle 0 to 2^32
errorCode unsigned
long
in 0 to 2^32
Message char* out string
2.7 gx2472_FindInstruments( buslist, devicelist, count )
Description:
Returns the number of available instruments and a list with the bus and device number for
each instrument.
Buslist and devicelist should be arra s of at least 100 places.
Parameters:
Name Type Direction Description Value
buslist unsigned
long*
out List with the bus location of
the device(s)
devicelist unsigned
long*
out List with the device location of
the device(s)
count unsigned
long
out Number of available
instruments
0 to 100
2.8 gx2472_GetActiveChannel( vi , channel )
Description:
This function returns the active channel. The active channel is the channel, which can be
configured with the corresponding driver functions. The channel can be set active with the
function SetActiveChannel().
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
channel unsigned long* out channel 1 = Channel A
2 = Channel B
2.9 gx2472_GetAddressCounter(vi, addresscounter )
Description:
This function reads the current position of the memor address counter from the active
channel. If the loopmode is active and card is stopped capturing data, use this function to get
the last captured data position.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
addresscounter unsigned long* out Position of the
address-counter
0 to 2^19
DUAL 70MSPS WAVEFORM DIGITIZER
9

2.10 gx2472_GetCardConnection(vi, positiveInputConnection,
negativeInputConnection )
Description:
Get the status of the input rela s. This routine returns the connection status from the active
channel. There are 4 rela s for each input. Each rela can be controlled with a bit:
•Bit 1 (value 1 Hex) : Input rela ;
•Bit 2 (value 2 Hex) : 50 Ohm rela ;
•Bit 3 (value 4 Hex) : 50 Ohm DC rela , this bit controls the positive and negative
channel simultaneousl ;
•Bit 4 (value 8 Hex) : Ground rela , connect input to ground.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
positiveInputConnection unsigned long* out positive input see description
negativeInputConnection unsigned long* out negative input see description
2.11 gx2472_GetCardId(vi , id )
Description:
This function reads the card ID. A card ID can be set with the function WriteCardId(). The card
ID is placed in the on board serial EEPROM.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
id unsigned long* out card id 0 to 2^32
2.12 gx2472_GetClockDivider (vi, clockDivider)
Description:
This function returns the clock divider value.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
clockDivider unsigned long * out clock divider 1 to 256
2.13 gx2472_GetClockSource (vi, clockSource)
Description:
This function returns the clock source.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
clockSource unsigned long * out clock source 0: Extern clock front
1: Intern clock 70 MHz
2: Intern clock 50 MHz
DUAL 70MSPS WAVEFORM DIGITIZER
10

2.14 gx2472_GetDCOffset imitVoltages (vi, positiveVoltage,
negativeVoltage)
Description:
Returns the DC Offset Limit Voltages. See function SetDCOffsetLimitVoltages(..).
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
positiveVoltage double* out positive limit voltage 5 to 6
negativeVoltage double* out negative limit voltage -5 to - 6
2.15 gx2472_GetDCOffsetVoltage(vi , voltage )
Description:
This function will returns the current voltage of the DC-offset DAC (of the active channel). This
voltage is previousl set with the function SetDCOffsetVoltage().
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
voltage double* out voltage of offset DAC -5 to +5 volt
2.16 gx2472_GetFilter (vi, filterStatus)
Description:
This function returns the filter position.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
filterStatus unsigned long* out filter status 0: Disconnect
1: B pass filter
2: 6 MHz filter
3: 15 MHz filter
4: 30 MHz filter
2.17 gx2472_GetGainCalCode (vi, gainCalibrationCode)
Description:
This function returns the calibration code for gain calibration DAC.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
gainCalibrationCode unsigned long* out gain cal. code 0 to 2^10
2.18 gx2472_GetInputVoltage (vi, voltage, code, averages, timeOut)
Description:
The function measures the input voltage Averages times and averages the voltage. It returns
the voltage and the corresponding ADC code.
DUAL 70MSPS WAVEFORM DIGITIZER
11

Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
voltage double* out measured voltage depends on range
code unsigned long* out adc code 0 to 2^14
average unsigned long in averages 1 to 2^19
timeOut unsigned long in time out 0 to 2^32
no timeout it time out is 0
2.19 gx2472_Get oopMode (vi, loopMode)
Description:
This function returns the Loop Mode status.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
loopMode unsigned long* out loop mode status 0 or 1
2.20 gx2472_GetOffsetCalDacCode(ci, code)
Description:
This function returns the offset calibration dac code.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
code unsigned long* out code 0 to 2^10
2.21 gx2472_GetRange (vi, range)
Description:
This function returns the range setting.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
range unsigned long* out code 1 to 6
2.22 gx2472_GetSampleDivider (vi, sampleDivider)
Description:
The function returns the sample divider value. THIS FUNCTIION IS OBSOLETE.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
sampleDivider unsigned long* out sample dividider 1 to 65536
2.23 gx2472_GetSoftwareTriggerStatus(vi, triggerstatus )
Description:
This function returns the trigger status.
DUAL 70MSPS WAVEFORM DIGITIZER
12

Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
triggerstatus unsigned long * out current trigger status 0 = no channels triggered
1 = channel A triggered
2 = channel B triggered
3 = both channels triggered
2.24 gx2472_GetTriggerInput (vi, triggerSource, triggerMode)
Description:
This function returns the trigger source and trigger mode settings.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
triggerSource unsigned long* out trigger source 0 Front
1 PXI 0
2 PXI 1
3 PXI 2
4 PXI 3
5 PXI 4
6 PXI 5
7 PXI Star
8 Software
9 Level
triggerMode unsigned long* out trigger mode 0 positive level
1 negative level
2 positive edge retrigger
3 negative edge retrigger
4 positive edge continuous
5 negative edge continuous
2.25 gx2472_init( resourcediscription , IDQuery , reset, vi )
Description:
This function performs the following initialization actions:
- Opens a session to the specified device using the bus and device ou specif .
- Returns a ViSession handle that ou use to identif the instrument in all subsequent
instrument driver function calls.
Note:
This function does not create new session if it is called repeatedl without closing it.
Call FindInstruments to get the available instruments in the s stem.
Parameters:
Name Type Direction Description Value
resourcediscription char* in PXI[bus]::
[device]::INSTR
e.g. PXI1::2::INSTR
IDQuer boolean in Set to true 0 or 1
reset boolean in Set to false (not
supported)
0 or 1
vi Unsigned
long*
out Return instrument
handle
DUAL 70MSPS WAVEFORM DIGITIZER
13

2.26 gx2472_MemoryTest (vi, level, errorAddress)
Description:
This function performs a memor test.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
level unsigned long in level 0 = 1/10 of memor is tested
1 = total memor tested
errorAddress unsigned long* out error address if error, this parameter will
contain the address which
contains invalid data
2.27 gx2472_ReadAdcResults (vi, startPosition, samples, buffer,
includeStatusBits)
Description:
This function reads the latest test results from the pd172. The results are a 14 bit
hexadecimal code. If the status bits are included the results are 16 bit words, where the two
upper bits contain the status bits. Bit 14 represents the overflow bit and bit 15 (MSB) an extra
capture bit.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
startPosition unsigned long in start position 0 to 2^19
samples unsigned long in nr. of samples 1 to 2^19
buffer unsigned long* out buffer for adc codes
includeStatusBits unsigned long in include the status bits 0 not included
1 included
2.28 gx2472_ReadEEPROM(vi , eeaddress , data)
Description:
This function reads a 16-bit word from the serial EEPROM at a serial EEPROM address
determined b eeaddress. If the EEPROM address is previousl written with the function
WriteEEPROM(), the lower b te will correspond to the b te written with the function
WriteEEPROM(). The upper b te will be the complement of the lower b te. This b te can be
used for verif ing purposes.
One on board EEPROM is used for both channels.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
eeadress unsigned long in EEPROM address 0 to 255
data unsigned long* out read data 0 to 2^16
2.29 gx2472_ReadInstrumentMemory(vi, data )
Description:
Read from the (capture) ram of the active channel. The ram address is determined b the
address-counter. The address-counter can be initialized with the function
DUAL 70MSPS WAVEFORM DIGITIZER
14

SetAddressCounter(). After this function call the address-counter is incremented with one
step.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
data unsigned long* out read data 0 to 2^16
2.30 gx2472_ReadInstrumentMemoryArray(vi , length , buf32,
dataInterpretation )
Description:
Read length ram-places from the capture ram (of the active channel), starting from the current
address-counter value. The ram address-counter can be initialized with the function
SetAddressCounter(). After this function call the address-counter is incremented with “length”
steps. Ram data can be interpret as test (adc) results. In this case the ram data will be shifted
2 places (right shift) and the upper bit will be inverted (adc digital data is 2's complement).
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
length unsigned long in number of data
elements to be read
0 to 2^18
buf32 unsigned long* out reference to a buffer for
read data
0 to 2^32
dataInterpretation unsigned long in data interpretation 0 raw data from ram
1 adc codes onl
2.31 gx2472_ReadRegister(vi, address, data )
Description:
Read data from specified module register. Onl for debug purposes.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
address Unsigned long in Address 0 to 2^32
data unsigned long* out read data 0 to 2^32
2.32 gx2472_reset(vi )
Description:
A reset is not supported b this instrument.
It returns a defined value VI_WARN_NSUP_RESET.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
2.33 gx2472_revision_query( vi, driverRev, instrRev )
Description:
This function returns the revision number of the instrument driver.
This instrument does not contain firmware so the instr_rev parameter is not valid. It onl
exists for compliance with the VXI Plug and Pla specification.
DUAL 70MSPS WAVEFORM DIGITIZER
15

This function alwa s returns the defined value VI_WARN_NSUP_REV_QUERY.
Parameters:
Name Type Direction Description Value
vi unsigned
long
in Instrument Handle 0 to 2^32
driverRev char* in Driver revision
instrRev char* in Instrument revision
2.34 gx2472_self_test( vi, testResult, errorMessage )
Description:
Self Test is not supported b this instrument.
It returns a defined value VI_WARN_NSUP_SELF_TEST.
Parameters:
Name Type Direction Description Value
vi unsigned
long
in Instrument Handle 0 to 2^32
testResult unsigned
long
in 0 to 2^32
errorMessage char* out
2.35 gx2472_SetActiveChannel(vi , channel )
Description:
Select the active channel. This function selects the channel to be updated.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
channel unsigned long in active channel 1 Channel-A
2 Channel-B
2.36 gx2472_SetAddressCounter (vi, addressCounterPosition)
Description:
This function programs the address counter. Use this function to read from or write to a
specified address.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
addressCounterPosition unsigned long in address counter
position
0 to 2^19
2.37 gx2472_SetClockDivider(vi , clockdivider )
Description:
Set the clock-divider. Programs the divider for the sample clock of the active channel. The
clock divider divides the clock selected with SetClockSource() and determines the sample
rate.
Parameters:
DUAL 70MSPS WAVEFORM DIGITIZER
16

Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
clockdivider unsigned long in clock divider value 1 to 256
2.38 gx2472_SetClockOutputEnable(vi, enable )
Description:
Enable the sample clock output. If annternal clock is selected and the clock output is enabled,
the sample clock (clock/clockdivider) is available on the front clock connection.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
enable unsigned long in enable clock output 0 = Disable clock output
1 = Enable clock output
2.39 gx2472_SetClockSource(vi, clocksource )
Description:
Select the desired clock source (for the selected channel). The clock source and the clock
divider determine the update rate of the output signal. See also SetClockDivider().
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
clocksource unsigned long in select clock source 0 = FRONT PANEL CLK
1 = INT CLK 1 (70MHz)
2 = INT CLK 2 (50MHz)
2.40 gx2472_SetDCOffsetCode(vi , code, connect )
Description:
Write a code to the DC offset DAC (of the selected channel). This functions programs the 16-
bit offset DAC with the desired code. This function can be used for calibration purposes. In
normal operation the function SetDCOffsetVoltage() will program the DC offset voltage to a
desired level. If connect is 1 offset voltage is connected to the negative input.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
code unsigned long in code for DC offset
DAC
0 to 2^16
connection unsigned long in connect 0 disconnect from negative input
1 connect to negative input
2.41 gx2472_SetDCOffsetVoltage(vi, voltage, connect )
Description:
Program the DC offset voltage DAC (of the selected channel) with the desired voltage. The
DC offset voltage can be a voltage between the -5V and +5V.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
voltage double in voltage for offset
DAC
-5 to +5V
connect unsigned long in connect 0 disconnect
1 connect dc offset,
DUAL 70MSPS WAVEFORM DIGITIZER
17

disconnect negative input
2 connect dc offset &
negative input
2.42 gx2472_SetDCOffset imitVoltages(vi , posvolt , negvolt )
Description:
Set limit voltages of dc offset DAC (of the selected channel). These voltages are necessar
for a calibrated offset voltage.
Procedure to determine limit voltages:
•Disconnect card: ConnectCard(ci, 0, 0)
•Filter b pass: SetFilter(ci, 0)
•Program DC offset dac at maximal voltage and connect offset voltage with input:
SetDCOffsetCode(ci,0xFFFF,1)
•Measure DC offset voltage with accurate voltage meter
•Program DC offset dac at minimal voltage and connect offset voltage with input:
SetDCOffsetCode(ci,0x0,1)
•Measure DC offset voltage with accurate voltage meter
•Disconnect offset voltage: SetDCOffsetCode(ci,0x8000,0)
•Call this routine with measured voltages
•Call StoreCalibration for storing data in EEPROM
This routine can be called to store just one of the limit voltages Fill in a voltage < 5V for the
PostiveVoltage or a voltage > -5V for the Negative Voltage and the corresponding voltage will
not be stored.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
posvolt double in measured positive
voltage
> 5V
negvolt double in measured negative
voltage
< -5V
2.43 gx2472_SetFilter(vi , filter )
Description:
Select a desired filter path for the active channel.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
filter unsigned long in filter select 0 = Disconnect
1 = B pass
2 = 6 MHz filter
3 = 15 MHz filter
4 = 30 MHz filter
2.44 gx2472_SetGainCalCode (vi, code)
Description:
Write a code to the gain calibration dac.
Parameters:
Name Type Direction Description Value
vi unsigned long in Instrument Handle 0 to 2^32
DUAL 70MSPS WAVEFORM DIGITIZER
18
