VAT - 650 Lead-acid Battery Analyzer User Manual
Company Profile
Established in 1996 in Madou District, Tainan City, Mashin Electric Corp. begins as a manufacturer
of car chargers. Over the years, Mashin becomes a professional battery charger manufacturer for
Automotive, Motorcycle, Industry, Jump Starter and functional battery chargers. Especially the car
chargers stand the first selling position in domestic market.
Recently, we have committed into more and more product lines for battery chargers.
We specialized in Battery Charger, Adaptor, Transformer, Switching Power, DC to AC Inverter,
LiFePO4 Lithium Battery Pack, Battery Analyzer, Booster Cable, Jump Starter and related electronic
products. With more than 20 years’factory experiences, we received customers’reliance for
automotive market around the world. Mashin can do OEM services and also has the capability for
ODM. Our products are followed by high SOP standards throughout the whole production process.
Besides, we put into the newest equipment and focus on employees training in order to provide
the best service and products to our customers.
Creativity and experiences are our advantages to receive customers’trust.
Besides, our engineers have decades of experiences and contributed in developing our own battery
chargers. Every year, we will have more than 5% R&D developing fees for our new products. What
we want is to provide our customers a more convenient life.
We take the four policies, “Total Quality Assurance, Quality First, Service First, Customer Satisfy”
as our company goals. From R&D, purchasing, production to the sales and delivery, we all have
completely Quality Management System. In addition, most of our products obtained UL, CE, CB,
FCC, PSE, SAA, RoHs, and CEC certifications and safety regulations. Strict company policy and
management obtain the certification of French (ANFOR) ISO-9001 and be the Japan PSE and U.S.
UL certified factory.
Since the factory established, Mashin has actively built up our own brand and strives to develop the
best products on a daily basis. It wasn’t easy to keep the faith after several decades, but we did.
In the future, we will maintain our creativity, keep developing new types of chargers and extend
the international market. It’s our responsibility to feed back to the world.

VAT - 650 Lead-acid Battery Analyzer User Manual
Notes
◆ Please read the user manual carefully before using.
◆ There will be no further notice for the product upgrade or changes.
Please take the device as standard.
◆ Declaration：Any product names mentioned in this manual are used
for explaining the using methods. The trademarks still belong to the
original company.
◆Only available for 12V lead-acid batteries.
Mashin will have no responsibility for the followings:
◆ This manual is designed for Mashin´s Analyzer only. Any
consequence caused by using this manual to other products.
◆ Any damages or problems that casued by using other accessories or
consumables instead of Mashin´s original products.
◆Any fees or expenses from the damages or losses of the analyzer
caused by private accidents or misused and unused without
following Mashin´s standard.

VAT - 650 Lead-acid Battery Analyzer User Manual
Contents
◆ Chapter 1 Product Summary
■ Product Profile
■ Function
■ Technical Parameters
■ Environmental Requirement
◆ Chapter 2 Parts Indicator
◆ Chapter 3 Operation
■ Pre-Test
■ Connect Analyzer
■ Button Indicator
■ Analyzer Startup
■ Battery System Standard and Rating
■ Battery Test
■ Charging Test Result
■ Cranking Test
■ Charging Test
■ Charging Test Result
■ Review Data
■ System Setup
◆ Chapter 4 Troubleshooting
1.
2.
3.
4.
5.
6.
7.
10.
12.
14.
16.
17.
18.
19.

1.
VAT - 650 Lead-acid Battery Analyzer User Manual
Chapter 1 Product Summary
■Product Profile
VAT-650 Lead-acid Battery Analyzer adopts the world's most advanced conductance
testing technology which can easily, quickly and accurately measure the actual cold
cranking amps capability of the vehicle starting battery, state of battery health, and
common faults of the vehicle starting and charging system. This Battery Analyzer helps
maintenance personnel to find out the problem quickly and accurately to increase the
efficiency for repairing the vehicle.
1、 Available for all automotive lead-acid batteries, eg. Ordinery Battery, AGM Flat
Plate, AGM Spiral, GEL and EFB...etc.
2、 Battery condition detection.
3、 Reverse polarity protection which will not cause the damage when connecting
reversely either for analyzer or battery.
4、 Low battery testing.
5、 Multiple rating system selection, eg. CCA, DIN, JIS, EN, IEC, GB, SAE, MCA, BCI
and CA.
6、 Multi-language support which includes Traditional Chinese, English, Japanese...etc,
other language is available according to customer´s requirement.
■ Function
VAT-650 Lead-acid Battery Analyzer includes Battery Test, Cranking Test, Charging
Test and other additional functions.
Battery Test : Analyze the battery status to calculate the actual cold
cranking capability and aging.
Cranking Test : Test and analyze the condition of starting motor.
Charging Test : Check and analyze the condition of charging system.

2.
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Technical Parameters
◎ Cold Cranking Amps Measure Range:
測量標準 測量範圍
CCA 100 - 2000
DIN 100 - 1400
JIS 26A17 - 245H52
EN 100 - 2000
IEC 100 - 1400
GB 30 - 220
SAE 100 - 2000
MCA 100 - 2000
BCI 100 - 2000
CA 100 - 2000
Measure StandardMeasure Rate
■ Environmental Requirement
◎ Temperature：-20°C ~ 60°C（Non-waterproof）
◎ Storage：-30°C ~ 70°C

3.
VAT - 650 Lead-acid Battery Analyzer User Manual
Chapter 2 Parts Indicator
VAT-650 Lead-acid Battery Analyzer consists of a main device, testing wire sets and
the printer.

4.
VAT - 650 Lead-acid Battery Analyzer User Manual
Chapter 3 Operation
■ Pre-Test
● Please clean battery poles before using.
● Please make sure clamps and battery are well-connected.
● Before testing, please make sure the engine stopped and the door closed.
■ Connect Analyzer
● Please connect the clamps with the battery pole, positive to positive and
negative to negative.
Please make sure clamps are well-connected. If they are not connected well,
the test will be unavailable. If screen shows“CHECK CONNECTION ＂,
before getting into the testing program, please clean the poles and re-connect.
CHECK CONNECTION
● This Analyzer has reverse polarity protection. If the clamps are connecting
reversely, the screen will not light on. But it will not cause any damages either on
analyzer or car load.
※ For parallel batteries, must break off the cathode connection first, then do the
individual test to each battery. If you do not break off the cathode connection,
there might come out with an error testing result.
※ For series batteries, if it is 24V, please test by each battery.

5.
ok
ok
12.64V
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Button Indicator
● （UP & DOWN）
● （BACK）
● （OK）
● （MENU）
Press MENU for additional functions.
■ Analyzer Startup
The Battery Tester will startup automatically when the clamps are well-connected.
The battery voltage will show at the bottom of screen which can be used as DC
Voltmeter. The measureing range is 6 - 30VDC, out of this range will cause the
damage of the analyzer.
Press to get into the MAIN MENU or press to SYSTEM SETUP.
ok

6.
CCA：Cold Cranking Amps, specified by SAE & BCI
DIN：German Institute for Standardisation
JIS：Japanese Industrial Standard, displayed on the battery as combination of the
numbers and letters, e.g. 55D23, 80D26
EN：European Standard
IEC：International Electrotechnical Commission
GB：Chinese National Standard
SAE：Society of Automotive Engineers (USA)
MCA：Marine Cranking Amps standard, effective starting current value at 0°C
BCI：Battery Council International (Publishes Automotive Battery Standards)
CA：Cranking Amps standard, effective starting current value at 0°C
SELECT STANDARD
CCA
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Battery System Standard and Rating
Please select the SYSTEM STANDARD and RATING according to the information
showed on the battery, as the arrow indicated below:

7.
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Battery Test
Press to get into the MAIN MENU and select BATTERY TEST（1/5）then press
.
ok
ok
Press to select your BATTERY TYPE then press .
MAIN MENU
BATTERY TEST
1/5
ok
SELECT BAT. TYPE
REGULAR FLOODED
1/5
SELECT BAT. TYPE
AGM FLAT PLATE
2/5
SELECT BAT. TYPE
AGM SPIRAL
3/5
SELECT BAT. TYPE
GEL
4/5
SELECT BAT. TYPE
EFB
5/5

8.
VAT - 650 Lead-acid Battery Analyzer User Manual
Then press to select SYSTEM STANDARD.
SELECT STANDARD
CCA
1/10
SELECT STANDARD
DIN
2/10
SELECT STANDARD
JIS
3/10
SELECT STANDARD
EN
4/10
SELECT STANDARD
IEC
5/10
SELECT STANDARD
GB
6/10
SELECT STANDARD
SAE
7/10
SELECT STANDARD
MCA
8/10
SELECT STANDARD
BCI
9/10
SELECT STANDARD
CA
10/10

9.
*****************
VAT - 650 Lead-acid Battery Analyzer User Manual
After selecting standard, press to confirm then press to set BATTERY
RATING.
After setting, press to begine the test.
SET BAT. RATING
500A CCA
BATTERY TEST
TESTING
*****
It takes around 3-5 seconds for testing and the result will come out.
SOH 100% 210CCA
SOC 93% 12.65V
INT.R= 14.20mΩ
GOOD BATTERY
ok
ok
Then press to print the result.
PRINT？
PRINTING
2017-03-15 13:03
TEST REPORT
GOOD BATTERY
SOC：
VOLTAGE：
SOH：
MEASURED：
SELECT INPUT：
RATED：
INTERNAL R：
93%
12.56V
100%
800A
CCA
600A
3.7mΩ
BATTERY TEST
VAT-650
ok

10.
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Battery Test Result
There will be 5 different situations as follows：
① Good Battery
10.
NOTE：SOH：State Of Healthy
SOC：State Of Charge
② Good, Recharge
③ Replace
SOH 96% 490CCA
SOC 98% 12.64V
INT. R= 5.8mΩ
GOOD BATTERY
SOH 78% 440CCA
SOC 30% 12.20V
INT. R= 5.8mΩ
GOOD-RECHARGE
Battery is good but in low power, please
charge before using.
SOH 46% 340CCA
SOC 80% 12.68V
INT. R= 7.8mΩ
REPLACE
Might be battery deterioration, please
charge it and re-test. If it comes out the
same result, replace the battery.

11.
VAT - 650 Lead-acid Battery Analyzer User Manual
④ Bad Cell, Replace
⑤ Charge, Re-test
SOH 0% 310CCA
SOC 0% 10.04V
INT. R= 25.7mΩ
BAD CELL-REPLACE
SOH 50% 310CCA
SOC 50% 12.08V
INT. R= 18.5mΩ
CHARGE-RETEST
Replace the battery
Unstable battery, please charge and re-test.
If it still comes out the same result, the
battery is damaged, replace it.
※ Normally a good battery should be in low internal resistance unless it is short-circuit,
this can be a determination when testing.

12.
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Cranking Test
Select CRANKING TEST（2/5）in the MAIN MENU and press .
Please follow the instruction and start your engine :
Once detecting the RPM, the testing will begin automatically and comes out the result.
The normal cranking voltage should higher then 9.6V, if it is lower, then the battery is
faulty and will show as follows:
MAIN MENU
CRANKING TEST
2/5
CRANKING TEST
START ENGINE
CRANKING TEST
RPM DETECTED
CRANKING TEST
TESTING
*****
CRANKING TEST
TIME 644ms
CRANKING NORMAL
11.9V
CRANKING TEST
TIME 1020ms
CRANKING LOW
9.12V
ok

VAT - 650 Lead-acid Battery Analyzer User Manual
13.
PRINTING
PRINT？
2017-03-15 13:03
TEST REPORT
*****************
*****************
CRANKING VOLTAGE NORMAL
CRANKING VOLTAGE :
CRANKING TIME :
11.19V
644ms
CRANKING TEST
VAT-650
After testing, press to print the result.
ok

14.
VAT - 650 Lead-acid Battery Analyzer User Manual
ok
■ Charging Test
Select CHARGING TEST（3/5）in the MAIN MENU and press .
MAIN MENU
CHARGING TEST
3/5
ok
RIPPLE TEST
20mV 13.92V
CHARGING TEST
LOADED TESTING
Loaded testing will take around 3 seconds then show as follows:
CHARGING TEST
INCREASE TO 2500
REV. FOR 5 SEC.
PRESS OK TO NEXT
Then increase the rotating speed to 2500rpms or above for 5 seconds, then press
for testing.
CHARGING TEST
TESTING
****
It will begin with a RIPPLE TEST, the ripple and charging voltage will indicate at the
bottom of the screen.
The ripple test will take around 6 seconds then get into LOADED TESTING.
※ Please start the engine and make sure all the electronic devices are turned off.
If there is any electronic device not in OFF position during the test which could
affect the accuracy of the result.
****

15.
VAT - 650 Lead-acid Battery Analyzer User Manual
It will come out the result :
CHARGING
NO-LOADED
LOADED
RIPPLE
NORMAL
14.43V
13.79V
NORMAL
PRINTING
PRINT？
VAT-650
2017-03-15 13:03
TEST REPORT
*****************
CHARGING VOLTAGE NORMAL
NO-LOADED :
LOADED :
RIPPLE :
14.43V
13.79V
25mV
CHARGING TEST
Then press to print the result.
ok
*****************
NO-OUTPUT
※ If there is no engine rev detected, the connection between alternator regulator and
battery might be faulty. If it fails detecting at least three times, it will come out a
result and showed“NO-OUPUT”.

16.
VAT - 650 Lead-acid Battery Analyzer User Manual
■ Charging Test Result
① Charging Voltage：Normal
No problems detected.
② Charging Voltage：Low
Please check if alternator system is well-connected. Otherwise, the alternator
might be faulty.
③ Charging Voltage：High
Normally the highest voltage for stabilizer will not over 14.7±0.5V, otherwise,
please check if the alternator is faulty.
④ No Output：
Please check if alternator system is well-connected.
⑤ Ripple：
Through detecting the charging current wave to check if the ripple is in a
normal condition. If the voltage is too high means the rectifier is damaged,
please check and replace.
