Masport ORIGIN DELUXE User manual

OUTDOOR BBQ
ORIGIN DELUXE
Month and Year of Manufacture: July 2021
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
Part Number
553225 (Aus)
553226 (N-Z)
BBQ Dimensions:
Width 1600mm
Depth 670mm
Height 1200mm

When ordering spares: PLEASE QUOTE PART NUMBER & DESCRIPTION, NOT illustrated number. Item Qty = 1 per part unless stated differently.
BOLD TEXT = Assemblies. Descriptions starting with * = items included in the assemblies & may not be available as a spares item.
Determine the left or right hand sides by standing in the operating position (standing at the handle).
553225 & 553226
BBQ - ORIGIN DELUXE
Page 2
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
Item Part No Description Qty
1 546914 Hood Assy Full-Wndow, 2021 SS/SS 1
1a 546925 *Temperature Gauge, 2021 1
1b 546924 *Glass- Window, Hood 2021 1
1c 549767 *Badge- MASPORT BBQ 17 Large 1
1d 547664 *Rubber Stopper, 15dia x 6mm 2
8 559638 Pin- Hinge & “R” Clip 2
20 548879 Table-Side, RH Assy MK2 Wok SS 1
21 559238 *Lid- S/B, 280x346 SS 1
22 548869 *Trivet- WOK Burner 1
23 559360 *Insert- Side Burner 1
24 547233 *Table- Side, RH (S/B+RBM)HN SS 1
25 559290 *Electrode- Ignition, S/B 1
26 559237 *Burner-Side 1
27 9152765 *Valve-Side, WOK, 0.92 8mm I/IGN 1
27a 547099 *Wire- Ignition, Side Burner 1
28 559791 *Hose-Side Burner, 500mm 1
29 559332 *Regulator & Hose POL (Aus) 1
29 9154655 *Regulator & Hose QCC (N-Z) 1
30 559339 *Bezel- Control Knob 1
31 548703 *Knob-BBQ, 8.0 S/Grip Zinc 1
31a 548705 **Insert- Knob, 8.0mm 1
33 547115 *Jet- Side Burner 0.92 1
34 547105 Module- Ignition, RB 1
38 548000 Wire- Ignition, R/B, 1255mm 1
40 548724 Table- Side, LH (Timer) USB SS 1
41 559342 Timer- Unit Only 1
30 559339 Bezel- Control Knob 1
31 559341 Knob- BBQ, 6.3mm S/Grip Zinc 1
31a 559778 *Insert- Knob, 6.3mm 1
LH Table- USB is shown on page 4
Item Part No Description Qty
31a 559778 Insert- Knob, 6.3mm 1
31b 548705 Insert- Knob, 8.0mm 1
Spares Note
Insert 548705 can be used in knobs 548701
Correct rotation is important prior to the assembly.
Not Illustrated
558782 BBQ Cookery Book 1
559496 Bolt Pack- S/S 1
559745 BBQ Cover- Home Design UV 1
546948 Owner Manual 1
559779 Seal- Valve, Silicon 1
Spares Note 2
547650 Bush- Aligning,S/Table is only required
when a RH Table that has an Ele’ Module option and
when that Ele’ Module is only for the Rear Burner, is
being replaced. (Reduces the hole dia by 2mm)

When ordering spares: PLEASE QUOTE PART NUMBER & DESCRIPTION, NOT illustrated number. Item Qty = 1 per part unless stated differently.
BOLD TEXT = Assemblies. Descriptions starting with * = items included in the assemblies & may not be available as a spares item.
Determine the left or right hand sides by standing in the operating position (standing at the handle).
553225 & 553226
BBQ - ORIGIN DELUXE
Page 3
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
2 559564 Rack- Warming, RB 1
3 559581 Panel- Rear Cover, RB SS 1
4 559573 Pipe- Flexible, RB 1
5 549761 Jet, RB 0.98mm 1
6 559575 Nut- Jet Retainer, RB 1
7 546922 Panel- Side, RH G/Bdy SS 1
8 549835 Ignitor- RB 1
10 547140 Plate- P/E Gloss FAD 395x485 1
11 759345 Burner- Tube (two pack) 3
11a 559289 Electrode- Ignition, Main Burner 6
11b 559015 Pin & Clip (Burner), 4.8dia x 10 6
12 559582 Panel- Rear, Vented SS 1
13 548787 Grill-Body, Smkr 6B+RB PE 1
13a 558826 Rubber Stopper- 9 dia x 3 2
14 548865 Manifold- Assy(INT) MK2 6+ RB 1
14a 548611 *Valve- Main,LPG 0.92 8mm I/IGN 6
14b 549763 *Jet, 6B Main 0.92 8mm dia LPG 6
15 548612 Valve- Rear, LPG 0.98 8mm E/IGN 1
16 559579 Pipe- Flexible, Front R/B 1
17 559566 Bezel- Control Knob, Small 1
18 548704 Knob- BBQ, 8.0 RB S/Grip Zinc 1
19 547239 Tray- Drip, 795 x 435 SS FAD 210 1
20 559242 Cup- Grease 1
21 559336 Panel- Front, Grill SS 1
22 548703 Knob- BBQ, 8.0 S/Grip Zinc 6
23 559339 Bezel- Control Knob 6
24 546928 Dashboard- BBQ Origin Deluxe 1
25 548783 Panel- H/Shield, Frnt(Smoke)6B+RB 1
26 559353 Panel- Heatshield, Side ZP 1
26a 559583 Cross Light - 6 Burner SS 5
27 548641 Flame Tamer, 100 x 410 6B SS 4
28 547137 Interchangeable Cooking System 1
(Refer to page 7 for contents)
29 559570 Deflector- Front, R/B SS 1
30 546921 Panel- Side, LH (25mm) G/Bdy SS 1
33 546923 Panel- Rear, RB+Light SS-G/BDY 1
34 559508 Burner- Rear 1
35 548679 Smoker Drawer (with Handle) 1
35a 549766 Lid- Smoker Box 1
Item Part No Description Qty
Item Part No Description Qty

When ordering spares: PLEASE QUOTE PART NUMBER & DESCRIPTION, NOT illustrated number. Item Qty = 1 per part unless stated differently.
BOLD TEXT = Assemblies. Descriptions starting with * = items included in the assemblies & may not be available as a spares item.
Determine the left or right hand sides by standing in the operating position (standing at the handle).
553225 & 553226
BBQ - ORIGIN DELUXE
Page 4
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
1 548600 Drawer SS 1
1a 549787 Drawer- Fascia Panel SS 1
1b 548603 Drawer- Handle SS 1
2 548631 Slider- Drawer SS 2
3 548632 Bracket- Slider SS 2
4 549777 Panel- Top, Trolley SS 1
4a 547664 Rubber Stopper, 15dia 2
4b 5211830 Bracket- Left Door 1
4c 5211832 Bracket- Right Door 1
5 548623 Panel- Side, RH Trolley SS 1
6 548624 Panel- Back, SS 1
7 548622 Panel- Side, LH SS 1
8 548615 Door Assy LH SS 1
8a 547130 *Hinge- Top, Door 1
8b 547131 *Hinge- Bottom, Door 1
9 548614 Door Assy RH SS 1
8a 547130 *Hinge- Top, Door 1
8b 547131 *Hinge- Bottom, Door 1
10 559334 Handle- Door, Tube insert 2
11 559206 Bracket- Handle, Door 4
12 559321 Apron- LH SS 1
13 559320 Apron- Front, SS 1
14 559322 Apron- RH, SS 1
15 559324 Panel- Bottom, Trolley SS 1
15a 548239 *Magnet- Door 2
16 559571 Weight- Bottom Panel 1
17 559225 Castor- Locking, Plate Mount 2
18 559225 Castor- Locking, Plate Mount 2
19 548637 Transformer- USB 1
20 548718 Harness Only, Light Hood & USB 1
21 548636 USB Port 1
22 548634 Switch- LED Lights 1
23 548635 Light- Hood, Halogen 2
549828 *Bulb- Hood, Halogen 1
24 548638 Bottle Opener 1
Item Part No Description QtyItem Part No Description Qty
Not Illustrated
549789 Bolt Pack- S/S BBQ Drawer 1

When ordering spares: PLEASE QUOTE PART NUMBER & DESCRIPTION, NOT illustrated number. Item Qty = 1 per part unless stated differently.
BOLD TEXT = Assemblies. Descriptions starting with * = items included in the assemblies & may not be available as a spares item.
Determine the left or right hand sides by standing in the operating position (standing at the handle).
553225 & 553226
BBQ - ORIGIN DELUXE
Page 5
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
Data Plate 546943.b.0
1 559239 Motor- Rotisserie 1
2 556297 Prongs (each) 2
3 559223 Rod Only-Motor Side(550mm) 1
4 559224 Rod Only-Handle Side(400mm) 1
5 559497 Alignment Collar & Screw 1
6 559769 Handle (6mm thread) 1
7 559494 Bracket- Rotisserie 1
559218 Rotisserie Set, 4/6 Burner 945mm
Name Model IAPMO
Approval
Injector
(mm)
Pressure
(kPa) Inp/Burn (MJ/h) Total (MJ/h)
BBQ MASP
ORIGIN BG6286BE-WS GMK10178
ULPG: BBQ
S/B
0.93
0.92 2.75 6 x 11.70 1 x 10.99 81.19
NG: BBQ
S/B
1.38
1.62 1.00 6 x 9.60
1 x 12.80 70.4
BBQ MASP
ORIGIN PLUS BG6286BS-WS-RRB GMK10178
ULPG:
BBQ
S/B
R/B
0.93
0.92
0.98
2.75
6 x 11.70
1 x 10.99
1 x 12.70
93.89
NG:
BBQ
S/B
R/B
1.38
1.62
1.68
1.00
6 x 9.60
1 x 12.80
1 x 12.70
83.10
BBQ MASP
ORIGIN DELUXE BG6286BS-WS-RRB GMK10178
ULPG:
BBQ
S/B
R/B
0.93
0.92
0.98
2.75
6 x 11.70
1 x 10.99
1 x 12.70
93.89
NG:
BBQ
S/B
R/B
1.38
1.62
1.68
1.00
6 x 9.60
1 x 12.80
1 x 12.70
83.10
BBQ MASP
ELITE BG6284BE-WS-RB GMK10178
ULPG:
BBQ
S/B
R/B
1.10
0.92
0.98
2.75
4 x 17.50
1 x 10.99
1 x 12.70
93.69
NG:
BBQ
S/B
R/B
1.60
1.62
1.68
1.00
4 x 13.00
1 x 12.80
1 x 12.70
77.50
BBQ MASP
EQUIP 6 BG6286BE-WS GMK10178
ULPG: BBQ
S/B
0.93
0.92 2.75 6 x 11.70 1 x 10.99 81.19
NG: BBQ
S/B
1.38
1.62 1.00 6 x 9.60 1 x 12.80 70.4
BBQ MASP
SUPREME BG6286BS-WS-RB GMK10178
ULPG:
BBQ
S/B
R/B
0.93
0.92
0.98
2.75
6 x 11.70
1 x 10.99
1 x 12.70
93.89
NG:
BBQ
S/B
R/B
1.38
1.62
1.68
1.00
6 x 9.60
1 x 12.80
1 x 12.70
83.10
Gas Supply Pressure, ULPG
Min: 2.70kPa; Max: 3.45kPa
Gas Supply Pressure, NG: 1.13 kPa
Gas Type: NZ: Universal LPG or NG
AUS: ULPG or NG
Complies to:
Standard AS/NZS 5263.1.7
Minimum Clearance :
From Top of BBQ: 1000mm, From Sides: 430mm, From Rear : 430mm
Distributed by
MASPORT LIMITED
Read the instructions before using the
appliance
USE OUTDOOR ONLY
Do not install in, or connect to the consumer piping or gas
supply system of a boat or caravan
WARNING: Parts of this appliance may be
very hot, keep young children away
546943.B.0
MASPORT LIMITED
320 Ti Rakau Drive, East Tamaki, Auckland 2013,
New Zealand
MASPORT AUSTRALIA PTY LIMITED
27 Commercial Drive, Dandenong South, Victoria
3175, Australia
For storage and cylinder exchange, disconnect hose at the cylinder only, do not disconnect hose from the appliance.
DO NOT REMOVE
Made in P.R.C

When ordering spares: PLEASE QUOTE PART NUMBER & DESCRIPTION, NOT illustrated number. Item Qty = 1 per part unless stated differently.
BOLD TEXT = Assemblies. Descriptions starting with * = items included in the assemblies & may not be available as a spares item.
Determine the left or right hand sides by standing in the operating position (standing at the handle).
553225 & 553226
BBQ - ORIGIN DELUXE
Page 6
Issue A.0
May 2021 PB
ECN # 12800
IPL Ref # 753225
Optional Extras Continued
547137 Interchangeable Cooking System P/E Gloss 1
555231 *Kebab Rack (each) 2
547136 *Grill, P/E Gloss (390 x 485) 1
559761 *Kebab Skewers 7mm x 400mm 8
559762 *Pizza Stone 290mm 1
547134 *Grill Insert, P/E Gloss Insert dia 290mm 1
547135 *Plate Insert, P/E Gloss Insert dia 290mm 1
547223 *Handle- Grill Insert, P/E Gloss 1
559761 Kebab Skewers (each) 1
555231 Kebab Rack (each) 1
Cooking Grills
559219 Grill- C/I Powder Coated Black 390 x 485 1
559640 Grill- C/I P/Enamel, Matt Black 390 x 485 1
559520 Grill- C/I P/Enamel GlossBlack 390 x 485 1
559765 Grill- C/I P/Enamel , Matt Black390 x 485 (K/Rack) 1
547141 Grill- P/Enamel, Gloss FAD 130 x 485 each 1
(ree are required per set-up)
(Kebab Rack ready)
Cooking Plates
559220 Plate- C/I Powder Coated Black 390 x 485 1
559641 Plate- C/I P/Enamel, Matt Black 390 x 485 1
559521 Plate- C/I P/Enamel GlossBlack 390 x 485 1
Natural Gas Conversion
548979 KIT- NG 210 6 Burner + RB 2017 1
Packaged Items
759345 Burner- 210 Series 2 Per Pack
759745 Cover- BBQ, Home Design UV Packaged 1 Per Pack
547598 Deluxe S/Steel 18 Piece Pack 1 Per Pack
