Massive Audio D 3600 User manual

Congratulations!
And thank you for purchasing a “Massive Audio” D-Block Series
Amplifier for your car audio system. You now own an amplifier of
uncompromising design and engineering incorporating the latest
advances in circuitry. This handcrafted amplifier is designed to deliver
the demands of serious sound competitors. You will soon discover that
D Block Series amplifiers display a fine balance between high quality,
performance and reliability; all proven qualities of “Massive Audio”
products.
“Massive Audio” amplifiers are the result of the latest advancements in
technology using only the highest quality components and quality
control standards. In order to provide you with many years of listening
pleasure, we recommend you to have your new amplifier installed by
an Authorized “Massive Audio Dealer.” This will ensure the proper
installation of your product, and will also increase the length of your
warranty to ONE YEAR.
(Please see the warranty section for more details.)
Please take a moment to thoroughly read this manual to ensure that you
get the maximum benefit from this new addition to your car audio
system. When installed properly, this unit will provide years of
trouble-free performance.
Should your amplifier ever need service or replacement due to theft,
please record the following information, which will help protect your
investment.
Model #: _______________________________________
Dealer’s Name: ___________________________________
Date of Purchase: __________________________________
Installation Shop and Date:__________________________
2
· Massive Audio, Inc. warrants all manufactured amplifier
products to be free from defect in material and workmanship
for a period not to exceed ONE YEAR* from the date of
original purchase when installed by an authorized “Massive
Audio” dealer. Units that are not installed by an authorized
“Massive Audio” dealer maintain a warranty not to exceed 90
days from the original purchase date by the original purchaser.
· PrOducts that displays abuse such as power deficiency, over
driving the amplifier or clipping the input require
purchase of new PCB for replacement.
· “Massive Audio” obligations under this warranty are limited to
repairing or replacing, at its own sole option, any such
defective products. This warranty does not apply to equipment
that has been damaged by accident, negligence, or
misapplication or has been altered or modified in anyway.
This warranty applies only to the original purchaser who must
have properly registered the product within 30 days of
purchase.
Except as provided herein, Massive Audio, Inc. makes no warranties or
representations, express or implied, including any warranty implied by
law, whether for merchantability or fitness for a particular purpose and
shall be effective only for the period that this express warranty is
effective. SEE THE WARRANTY REGISTRATION CARD TO
ADDITIONAL INFORMATION.
17

16
3
Parametric Bass Boost EQ from 30Hz - 80Hz
Extreme power in a small footprint.

4
15
D 2400 D 3600 D 8000 D 16000
53x165x506 106x165x506
2.1x6.5x19.9 4.2x6.5x19.9
176F176F
176F
176F
350 W 650 W
1200 W
650 W 950 W
1800 W
950 W
1500 W 2000 W 4000 W
1900 W 3000 W
4000 W
2 x 40 0 0 W
INTERNAL
D 120 0
176F

For : D 8000
14
17
18
15
16
17
18
16
1718
1718
5
15

14. Q-CONTROL (Available on D8000 & D16000 only)
This knob adjusts the curve of the bassboost.Turning this knob clockwise will make the
boosted frequency narrow and sharp. Turning this knob counter clockwise will extend
the boosted frequency range. By combining the bassboost frequency and the bassboost
level you can achieve a perfect bass response that matches your system.
15. CLIP LIMIT SWITCH (Available on D8000 & D16000 only)
This switch controls the amount of clip limit (on/off). When it is switched on the
amplifier will control the output level at the clipping point and reduce the distortion.
This will keep your amplifier at a low distortion level at the clipped signal.
18. POWER - LED
17. PROTECTION - LED
16. LIMIT INDICATOR
6
This LED will light up when the output is clipped or the amplifier over heats.
When the limit indicator lights up, the amplifier will hold or reduce the output
power to protect the subwoofer and amplifier. Reduce the gain or cool down the
amplifier when this indicator lights up continuously.
For: D 1200 / D 2400 / D 3600
13

12
Model Fuse Wire
D1200 40 AMP 6 Gauge
D2400 80 AMP 4 Gauge
D3600 150 AMP 2 to 4 Gauge
D8000 300 AMP 0 to 2 Gauge
D16000 2 x 300AMP 2 x (0 to 2 Gauge)
7

For : D 1200
8
four
speakers mono
For : D 16000
11

10
For : D 2400 / D 3600
For : D 8000
9
