Master Bilt MCR-33-101 User manual

ITEM NO. __________________________________________________
PROJECT __________________________________________________
LOCATION _________________________________________________
DATE _________________________ QTY. _______________________
FEATURES
CONSTRUCTION
• Stainless steel interior and exterior
with polyurethane foamed-in-place
insulation
• Interior light
• Door gasket heater
• High velocity forced air convection
through evaporator coil
• HACCP compliant recording ther-
mometer for blast chiller ambient
air temperature (requires printer to
have record)
• 4 food temperature probes with se-
quential readout display in MCR-33-
101, 8 probes in MCR-33-102
• Automatic chill cycle control with
food temperature probes
DOORS
• Door dimensions: 30" x 78"
• Flush mounted
• 36" high 16 ga. stainless steel kick-
plate on door exterior
REFRIGERATION SYSTEM
• An air- or water-cooled condensing
unit will be supplied depending on
application.
CONTROL PANEL
• HACCP compliant recording features
• Surface mounted on exterior of blast
chiller
• On/off switch
• Digital readout of interior ambient
temperature
• Digital cycle timer
• Microprocessor control system
enclosed in easily accessible box
• Automatic air defrost cycle
• Automatic hold cycle
• Audible alarm at end of chilling cycle
RACK
• Racks provided:
– MCR-33-101 .............................. 1
– MCR-33-102 .............................. 2
• Stainless steel construction
• Accomodates 26 pans, 12" x 20" x
21/2", two per each of 13 ledges
• Ledges on 41/2" spacing
• Each pan holds up to 10 pounds of
food for total rack quantity of 260 lbs.
• Rack dimensions: 241/2" wide x 27"
deep x 685/16" high
• Rack mounted on heavy-duty swivel
casters
COOLING TIME
• Maximum load of 260 pounds of
food requires approximately 90 min-
utes per cooling cycle depending on
food density and input temperature
of food
WARRANTY
• Standard limited one year extended
compressor (optional four year ex-
tended warranty available), one year
limited parts, limited 10 year panel
FEATURES
ROLL-IN MODELS PASS-THRU MODELS
❑ MCR-33-101 ❑ MCR-33-101PT
❑ MCR-33-102 ❑ MCR-33-102PT
MCR-33-101 &
MCR-33-102 SERIES
Roll-in & Pass-Thru
Blast Chillers
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
OPTIONS
❑ Optional nishes
❑ Add sufx “C” for correctional
model
❑ Printer package
❑ Extended four year compressor
warranty
Full-length
evaporator coil
and vertical fan
tower provide
evenly distributed
cooling.
MCR-33-101

MASTER-CHILL™MCR-33-101 & MCR-33-102 SERIES
ROLL-IN & PASS-THRU BLAST CHILLERS
BLAST CHILLER TECHNICAL SPECIFICATIONS
MCR-33-101 PLAN VIEW MCR-33-101 SIDE VIEW
DIMENSIONS
(in inches)
DIMENSIONS
(in millimeters) MAX.
MODEL L D* H* L D* H* VOLTS MCA FUSE SHIP WT. LB/KG
ROLL-IN
MCR-33-101 70 52 89 1778 1194 2184 208-230/1ph/4-wire 9 15 1500/682
MCR-33-102 70 98 89 1778 2362 2184 208-230/1ph/4-wire 16 20 3000/1364
PASS-THRU
MCR-33-101PT 70 52 89 1778 1194 2184 208-230/1ph/4-wire 9 15 1500/682
MCR-33-102PT 70 98 89 1778 2362 2184 208-230/1ph/4-wire 16 20 3000/1364
*Depth and height include control panel.
MCR-33-102 SIDE VIEW
LISTINGS HOOKUP
Hardwire, remote refrigeration.
2
MCR-33-102 PLAN VIEW
MCR-33-101 ELEVATION VIEW
MCR-33-102 ELEVATION VIEW

REFRIGERATION SYSTEM TECHNICAL SPECIFICATIONS
3
All condensing units must include a suction accumulator.
Pull down time reects time neces-
sary to lower listed quantity of food from 140°F to 40°F. All units listed contain R-404A refrigerant.
COND.
UNIT
MODEL* H.P.
BTUH
@ -10°F
SUCTION
TEMP.**
UNIT CONNECTION
SIZES
DIMENSIONS
SEE
DRAWING...
(PP. 4-5)
RECEIVER
PUMPDOWN
CAP. @ 90%
SHIP
WT.
(LB/KG) MCA** MOP** RLA** LRA** LIQUID SUCTION
MCR-33-101, 200 LB. CAPACITY, 2 HOUR PULL DOWN TIME
MSLZ0101C 3 10,653 3/8 7/8 M2 11.4 200/91 20 30 11.1 77
MHLZ0121B 3 11,559 1/2 1-1/8 M2 11.4 260/118 30 45 19 105
MCLZ0111B 3 10,372 1/2 7/8 M2 11.4 330/150 24 35 14.7 86
MCLZ0111C 3 10,343 1/2 7/8 M2 11.4 330/150 19 25 10 82
MCR-33-101, 200 LB. CAPACITY, 1.5 HOUR PULL DOWN TIME
MSLZ0151C 4 14,994 1/2 7/8 M2 11.4 230/105 32 40 15 99
BSLZ0400B 4 15,047 1/2 7/8 C 41.5 510/232 42 60 26.8 129
BSLZ0400C 4 15,047 1/2 7/8 C 41.5 510/232 32 40 15 99
BSLZ0400E 4 15,047 1/2 7/8 C 41.5 510/232 20 20 8.2 50
BCLZ0280B 3 15,529 5/8 11/8C 41.5 505/230 32 40 15 105
BCLZ0280C 3 15,529 5/8 11/8C 41.5 505/230 32 35 12.6 112
BCLZ0280E 3 15,529 5/8 11/8C 41.5 505/230 20 20 6.2 56
MCR-33-101, 250 LB. CAPACITY, 2 HOUR PULL DOWN TIME
MSLZ0151C 4 14,994 1/2 7/8 M2 11.4 230/105 32 40 15 99
MCLZ0141B 3 13,799 1/2 13/8M2 11.4 500/227 28 40 16.7 105
MCLZ0141C 3 13,903 1/2 11/8M2 11.4 500/227 26 35 12.8 112
BSLZ0400B 4 15,047 1/2 7/8 C 41.5 510/232 42 60 26.8 129
BSLZ0400C 4 15,047 1/2 7/8 C 41.5 510/232 32 40 15 99
BSLZ0400E 4 15,047 1/2 7/8 C 41.5 510/232 20 20 8.2 49.5
BCLZ0280B 3 15,529 5/8 11/8C 41.5 505/230 32 40 15 105
BCLZ0280C 3 15,529 5/8 11/8C 41.5 505/230 32 35 12.6 112
BCLZ0280E 3 15,529 5/8 11/8C 41.5 505/230 20 20 6.2 56
MCR-33-101, 250 LB. CAPACITY, 1.5 HOUR PULL DOWN TIME
MSLZ0181C 5 18,945 1/2 11/8M3 15.2 240/109 36 55 21.4 123
MDLZ0201C 3 19,518 1/2 11/8M3 15.2 530/241 38 45 16.8 102
MCR-33-101, 250 LB. CAPACITY, 1.3 HOUR PULL DOWN TIME
BSLZ0600C 6 21,651 1/2 7/8 C 41.5 550/250 41 60 23.9 156
BCLZ0400C 4 21,531 5/8 13/8C 41.5 530/230 44 60 26.3 161
BCLZ0400E 4 21,531 5/8 13/8C 41.5 530/230 22 30 10.2 60
BSLZ0600E 6 21,651 1/2 7/8 C 41.5 550/250 21 25 9.3 70
MCR-33-101 250 LB. CAPACITY, LESS THAN 1 HOUR PULL DOWN TIME
BCLZ0750C 71/237,322 7/8 13/8D 53.4 730/332 55 80 31.5 161
BCLZ075UE 71/237,322 7/8 13/8D 53.4 730/332 32 40 16.1 83
MCR-33-101 250 LB. CAPACITY, LESS THAN 1 HOUR PULL DOWN TIME – WATER COOLED CONDENSING UNITS
SCLZ075WC 71/239,600 5/8 13/8D 78.4 730/332 50 80 31.5 161
SCLZ075WE 71/239,600 5/8 13/8D 78.4 750/341 32 40 16.1 83
MCR-33-102, 400 LB. CAPACITY, 2 HOUR PULL DOWN TIME
MSLZ0221C 6 23,018 1/2 11/8M5 17 250/114 39 60 23.9 156
MDLZ0231C 4 22,958 1/2 11/8M3 15.2 530/241 42 60 26.3 161
BCLZ040LC 4 23,171 5/8 13/8C 41.5 530/241 45 70 26.3 161
MCR-33-102, 400 LB. CAPACITY, 1.5 HOUR PULL DOWN TIME
MDLZ0291C 6 29,187 5/8 13/8M5 17 560/255 47 70 28.2 161
MCR-33-102, 500 LB. CAPACITY, 2 HOUR PULL DOWN TIME
MDLZ0291C 6 29,187 5/8 13/8M5 17 560/255 47 70 28.2 161
BSLZ0750C 71/226,006 1/2 7/8 C 41.5 550/250 54 80 30.9 189
BCLZ0600C 6 26,466 5/8 13/8C 41.5 560/255 46 70 28.2 161
BCLZ0600E 2 26,466 5/8 13/8C 41.5 560/255 26 35 13.3 80
*VOLTAGE KEY:
“B” sufx = 208-230 or 230 volt, 60 cycle, one phase
“C” sufx = 200-230 or 208-230 volt, 60 cycle, three phase
“E" sufx = 460 volt, 60 cycle, three phase
**Based on 90°F ambient
***Electrical ratings for condensing unit only. See National
Electrical Code if units are combined on a single circuit.

4
BASE “C”
BASE “D”
BASE “E”
COND.
UNIT
MODEL* H.P.
BTUH
@ -10°F
SUCTION
TEMP.**
UNIT CONNECTION
SIZES
DIMENSIONS
SEE
DRAWING...
(PP. 4-5)
RECEIVER
PUMP-
DOWN
CAP. @ 90%
SHIP
WT.
(LB/KG) MCA** MOP** RLA** LRA** LIQUID SUCTION
MCR-33-102, 500 LB. CAPACITY, 1.5 HOUR PULL DOWN TIME
MDLZ0331C 6 32,417 5/8 13/8M5 17 560/255 50 70 30.3 150
BCLZ0750C 71/237,322 7/8 13/8D 53.4 730/332 55 80 31.5 161
BCLZ0750E 71/237,322 7/8 13/8D 53.4 730/332 32 40 16.1 83
MCR-33-102, 500 LB. CAPACITY, LESS THAN 1 HOUR PULL DOWN TIME
BCLZ1500C 15 70,782 7/8 15/8F 116.1 990/450 90 125 52.6 278
BCLZ1500E 15 70,782 7/8 15/8F 116.1 990/450 51 70 26.3 139
MCR-33-102, 500 LB. CAPACITY, LESS THAN 1 HOUR PULL DOWN TIME – WATER-COOLED CONDENSING UNITS
SCLZ100WC 10 54,800 7/8 13/8E 105.3 910/414 66 100 42 215
SCLZ100WE 10 54,800 7/8 13/8E 105.3 910/414 34 50 18.6 106
*VOLTAGE KEY:
“B” sufx = 208-230 or 230 volt, 60 cycle, one phase
“C” sufx = 200-230 or 208-230 volt, 60 cycle, three phase
“E" sufx = 460 volt, 60 cycle, three phase
**Based on 90°F ambient
***Electrical ratings for condensing unit only. See National Electrical Code if units are combined on a single circuit.
REFRIGERATION SYSTEM TECHNICAL SPECIFICATIONS

5
MASTER-CHILL™MCR-33-101 & MCR-33-102 SERIES
ROLL-IN & PASS-THRU BLAST CHILLERS
REFRIGERATION SYSTEM TECHNICAL SPECIFICATIONS (cont.)
BASE “F”
BASE “M2”
BASE “M3”
BASE “M5”

NOTE: All specications subject to change without notice.
1287 - 2/08-web
©Master-Bilt Products division of Standex International, Inc. All rights reserved. Printed in U.S.A.
908 Highway 15 North • New Albany, MS 38652
PHONE: [phone] or 662-534-9061 • FAX: [phone] or 662-534-6049 • www.master-bilt.com
BID SPECIFICATIONS
Item no. MCR-33-______
Provide______ ( ) Roll-in or
Pass-thru Blast Chiller(s)
Master-Bilt model number
MCR-33-______.
Blast chiller to be provided
with stainless steel construction
and polyurethane foamed-in-
place insulation. Blast chiller will
feature high velocity forced air
convection through evaporator
coil.
Probes with sequential read-
out display will be supplied for
food temperature recording (four
probes in MCR-33-101 model,
eight in MCR-33-102).
An automatic chill cycle
control with food temperature
probes is also supplied.
A thermometer will be pro-
vided for recording blast chiller
ambient air temperature. Ther-
mometer will require optional
printer for record of tempera-
tures.
Roll-in blast chillers will con-
tain one 30" x 78" ush mount-
ed, polyurethane foamed door.
Pass-thru models will contain
two doors. Doors will be provid-
ed with a 36" high 16 ga. stainless
steel kickplate on the exterior.
Doors will also be supplied with a
hold-open feature, magnetic gas-
kets and gasket heater.
Blast chillers will be provided
with an air- or water-cooled con-
densing unit depending on ap-
plication requirements.
Blast chiller will be equipped
with a standard exterior mount-
ed control panel featuring the
following:
• On/off switch
• Digital readout of interior ambi-
ent temperature and probe tem-
peratures
• Digital cycle timer for timed
chilling
• Microprocessor control system
enclosed in easily accessible box
• Automatic defrost cycle and
hold cycle
• Audible alarm at end of chill-
ing cycle
• Six programmable one-touch
preset chilling programs for
easy use
Blast chillers will be supplied
with stainless steel racks (one
rack for MCR-33-101/33-101PT,
two for MCR-33-102/33-102PT)
mounted on heavy-duty swivel
casters. Racks accommodate
26 pans, 12" x 20" x 21/2", two
per each of 13 ledges. Each pan
holds up to 10 lbs. of food for to-
tal rack quantity of 260 lbs. Di-
mensions of rack are 241/2" wide
x 27" deep x 685/16" high.
Blast chillers to have standard
limited one year extended com-
pressor warranty (optional four
year extended warranty avail-
able) with one year limited parts
and limited 10 year for panels.
Blast chillers will be UL and
C-UL listed and UL EPH classied.
