Masterbuilt MB20090819 User manual

Welcome to the family. Let’s get started.
Master it. Masterbuilt.
Manual Code: 9809180041 190501-GSB
GRILL + FINISH ELEMENT
Manual applies to the following model number(s)
MB20090819 • MB20090919
• To avoid personal injury and/or property damage, please read and follow all of these instructions
before assembly and operation.
• Keep this manual for future reference.
WARNING

2
Parts List
BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
Tools needed: Adjustable Wrench, Phillips screwdriver • Approximate assembly time: 30 minutes
Actual product may differ from picture shown.
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT customer service at 1-800-489-1581 or support.masterbuilt.com.
STOP
Hardware List
1
2
4
3
NO QTY DESCRIPTION
1 1 Grill + Finish Heat Shield
2 1 Grill + Finish Element Bracket
3 1 Grill + Finish Element
NO QTY DESCRIPTION
4 1 Silicone Gasket
5 1 Disposable Pan
6 2 Grill + Finish Heat Shield Vent
5
6
M4 Hex Nut
Qty-4
B
ST4x10 Tapping Screw
Qty-10
A
M4 Split Lock Washer
Qty-1
D
M4 Star Washer
Qty-1
E
M4x10 Combination Screw
Qty-6
C

3
Assembly
1
2
NOTE: For clarity of illustrations, the smoker door is
not shown. The door does not have to be removed to
complete the assembly process.
Remove water bowl and racks from smoker.
Lift and remove upper
rack supports.

4
3
Assembly
Attach element bracket to heat shield with two screws.
A
A
2
1
1
1
2
Place heat shield into top of smoker and
secure with two screws and two flat
washers on each side.
X10 AA
AA
AA
AA
1
6
6
C
C
X4
C

5
4On the back of the smoker, remove six screws to remove the outer element panel, insulator and element gasket.
Assembly
Outer
Element
Panel
Insulator Element
Gasket
Inner
Element
Panel
Insulator
Remove four hex nuts, lock washer (D) and star washer (E) to remove inner element panel and insulator. Your smoker
may or may not have the lock washer and star washer. If it does not, they are provided with this kit to assemble the
element.
DE

6
Assembly
5Place silicone gasket onto back of element. Slide element through element bracket on heat shield,then align threaded
studs on element bracket with holes in back wall of smoker. On the back of the smoker, connect the yellow/green
ground wire to the top right threaded stud as shown below, then secure element with hex nuts. Place the element
gasket back into the opening.
X4
B
3
4
Yellow/Green
Ground Wire
Place star washer (E) over
the threaded stud first,
then the ground wire, lock
washer (D) and hex nut (B).
Element
Gasket
D
X1
E
X1
B
D
E

7
6Attach each round connector to the element terminals using a split lock washer, flat washer and M4 machine screw.
Connect the temperature probe plug. Connect the two female connectors to the male spades on the high temp limit
switch.
Assembly
Element Terminal
Round Connector
Temperature Probe Plug
Female Connectors
C
X2
C

8
Assembly
7Replace the insulator and outer elment panel
using the six screws previously removed.
8Reinstall upper rack supports.
Outer
Element
Panel
Insulator

9
Assembly
9Replace cooking racks, notched rack and water
bowl. Disposable pan will slide under notched
rack or sit on top of it.
5

10
Operating Instructions
TEMPTIME MP 1 MP 2 MP 3 MP 4
SETTING THE GRILL + FINISH ELEMENT
SETTING THE TIMER
1. Countdown Timer Option:
• Press the SET TIME button once-LCD display for hours will blink.
• Use the UP or DOWN arrows to set hours.
• Press the SET TIME button again to lock in hours. The minutes LCD will start blinking.
• Use the UP or DOWN arrows to set minutes.
• Press the SET TIME button to lock in minutes and start the timer.
2. Duration (Count-up) Timer Option:
• This timer will start counting from 00:00.
• Press and hold the SET TIME button once for LCD display to start counting from 00:00.Press again to
pause the timer and again to continue. Press and hold to cancel.
NOTE: When outside temperature is cooler than 65°F (18°C) and/or altitude is above 3,500 feet (1067m),
additional cooking time may be required.To ensure that meat is completely cooked use a meat
thermometer to test internal temperature or use meat probe, if included.
NOTE: You do not have to set the timer when cooking. The element will begin heating once the temperature
has been set.
• The top Grill + Finish element provides two unique benefits:
1. Food can be slow-smoked and then positioned under the top element to crisp meat or carmelize sauce.
2. The top element works similar to the broiler in an oven. Food can be cooked quicker when placed
under the top grill and finish element.
• Press the SET TEMP button once.LCD will display boTM (bottom heating element).
• Press the UP or DOWN arrows to select ToP (grill + finish element) and press SET TEMP again.
• Press the UP or DOWN arrows to select High/Medium/Low.
• Press the SET TEMP button again to lock in the setting.
• The grill and finish element icon will illuminate to indicate temperature has been set.
• To turn all elements off,press the SET TEMP button ,then press the UP or DOWN arrows to select OFF.
Press the SET TEMP button again.

11
Visit masterbuilt.com or complete form below and return to:
Attn: Warranty Registration
Masterbuilt Manufacturing, LLC
1 Masterbuilt Court | Columbus, GA 31907
Name: ___________________________ Address: __________________________________________
City: ______________________________________________________________________________
State/Province: ________ Postal Code: ________________ Phone Number: _______________________
E-mail Address: ______________________________________________________________________
*Model Number: ______________________________ *Serial Number: ___________________________
Purchase Date: _____- ______-_______ Place of Purchase: ____________________________________
*Model Number and Serial Number are located on silver label on back of smoker.
Masterbuilt 1-Year Limited Warranty
Masterbuilt warrants its products to be free from defects in material and workmanship under
proper assembly, normal use and recommended care for 1 year from the date of original retail
purchase.The Masterbuilt warranty does not cover paint finish as it may burn off during normal
use.The Masterbuilt warranty does not cover rust. Masterbuilt requires proof of purchase for
warranty claim,such as a receipt. Upon the expiration of such warranty, all such liability shall
terminate.
Within the stated warranty period, Masterbuilt, at its discretion, shall replace defective
components free of charge, with the owner being responsible for shipping. Should Masterbuilt
require return of component(s) in question for inspection, Masterbuilt will be responsible for
shipping charges to return requested item. This warranty excludes property damage sustained
due to misuse, abuse, accident, or damage arising out of transportation.
This express warranty is the sole warranty given by Masterbuilt and is in lieu of all other
warranties, expressed or implied including implied warranty, merchantability, or fitness for a
particular purpose. Neither Masterbuilt nor the retail establishment selling this product has
authority to make any warranties or to promise any remedies in addition to or inconsistent with
those stated above.Masterbuilt’s maximum liability, in any event, shall not exceed the purchase
price of the product paid by the original consumer/ purchaser. Some states do not allow the
exclusion or limitation of incidental or consequential damages. In such a case,the above
limitations or exclusions may not be applicable.
California residents only: Not withstanding this limitation of warranty, the following specific
restrictions apply; if service,repair, or replacement of the product is not commercially practical,
the retailer selling the product or Masterbuilt will refund the purchase price paid for the product,
less the amount directly attributable to use by the original buyer prior to the discovery of the
nonconformity. Owner may take the product to the retail establishment selling this product in
order to obtain performance under warranty. This express warranty gives you specific legal rights,
and you may also have other rights which vary from state to state.

Rest assured, we’re here to help.
Customer Service masterbuilt.com/contact
Masterbuilt Manufacturing, LLC
1 Masterbuilt Court | Columbus, GA | 31907
@masterbuilt 1.800.489.1581
masterbuilt.com

Bienvenue à la famille. Commençons!
Maîtrisez-le. Masterbuilt.
ÉLÉMENT DE GRIL ET DE FINITION
Le manuel s’applique au(x) numéro(s) de modèle(s) suivant(s)
MB20090819 • MB20090919
• Pour éviter les blessures et les dommages matériels, assurez-vous de lire et de suivre toutes ces
consignes avant l’assemblage et l’utilisation.
• Conservez ce manuel pour référence ultérieure.
AVERTISSEMENT

14
Liste des pièces
AVANT L’ASSEMBLAGE, LIRE ATTENTIVEMENT TOUTES LES INSTRUCTIONS.
Outils nécessaires: Clé ajustable, Tournevis cruciforme • Temps nécessaire pour l’assemblage: environ 30minutes
Le produit réel peut différer de l’illustration.
NE PAS RENVOYER AU DÉTAILLANT pour obtenir de l’aide pour l’assemblage, des pièces
manquantes ou endommagées. Veuillez prendre contact avec le service à la clientèle de
MASTERBUILT au 1-800-489-1581 ou à support.masterbuilt.com.
ARRÊTEZ
Liste de quincaillerie
1
2
4
3
NO QTÉ DESCRIPTION
1 1 Écran thermique de l’élément de gril et de finition
2 1 Support de l’élément de gril et de finition
3 1 Élément de gril et de finition
NO QTÉ DESCRIPTION
4 1 Joint d’étanchéité en silicone
5 1 Plat jetable
6 2 Écran thermique tuyau de l’élément de gril et de finition
5
6
Écrou hexagonal M4
Qty-4
B
Vis autotaraudeuse
ST4×10
Qté-10
A
Rondelle de
blocage fendue M4
Qté-1
D
Rondelle étoile M4
Qté-1
E
Vis de combinaison M4×10
Qté-6
C

15
Assemblage
1
2
REMARQUE: Pour rendre les illustrations plus claires,
la porte du fumoir n’est pas montrée. Il n’est pas
nécessaire d’enlever la porte pour faire l’assemblage.
Sortez la cuvette d’eau et les grilles du fumoir.
Soulevez et retirez les
supports de la grille
supérieure.

16
3
Assemblage
Fixez le support de l’élément à l’écran thermique en
utilisant deux vis.
A
2
1
1
2
Placez l’écran thermique sur le dessus
du fumeur et fixez-le avec deux vis et
deux rondelles plates de chaque côté.
A
1
X10
AA
AA
AA
AA
1
6
6
C
C
X4
C

17
4À l’arrière du fumoir, enlevez six vis afin d’enlever le panneau extérieur de l’élément,l’isolant et le joint d’étanchéité de
l’élément.
Assemblage
Panneau
extérieur
de
l’élément
Isolant
Joint
d’étanchéité
de l’élément
Panneau
intérieur
de
l’élément
Isolant
Retirez les quatre écrous hexagonaux,la rondelle frein (D) et la rondelle étoile (E) pour retirer le panneau interne de
l’élément et l’isolant. Votre fumeur peut avoir ou non la rondelle de blocage et la rondelle en étoile.Si ce n’est pas le
cas, ils sont fournis avec ce kit pour assembler l’élément.
DE

18
Assemblage
5Mettez le joint d’étanchéité en silicone sur l’arrière de l’élément.Glissez l’élément dans le support de l’élément situé
sur l’écran thermique,puis alignez les goujons filetés du support de l’élément avec les trous qui se trouvent dans
la paroi arrière du fumoir. À l’arrière du fumeur, connectez le fil de terre jaune / vert au goujon fileté en haut à droite,
comme indiqué ci-dessous, puis fixez l’élément avec des écrous hexagonaux. Remettez le joint d’étanchéité de
l’élément dans l’ouverture.
X4
B
3
4
Fil de mise à la terre
jaune/vert
Joint
d’étanchéité
de l’élément
Placez la rondelle en étoile
(E) d’abord sur le goujon
fileté,puis le fil de terre, la
rondelle frein (D) et l’écrou
hexagonal (B).
D
X1
E
X1
B
D
E

19
6Fixez chaque connecteur rond aux bornes de l’élément en utilisant une rondelle de blocage fendue, une rondelle de
blocage et une vis à métaux M4. Raccordez la fiche de la sonde de température. Raccordez les deux connecteurs
femelles aux cosses mâles du dispositif de protection contre la surchauffe.
Assemblage
Borne de l’élément
Connecteur rond
Fiche de la sonde de
température
Connecteurs femelles
C
X2
C

20
Assemblage
7Remettez l’isolant et le panneau extérieur
de l’élément en utilisant les six vis enlevées
précédemment.
8Réinstallez les supports de la grille supérieure.
Panneau
extérieur
de
l’élément
Isolant
