Garland ED-15B Manual

Garland Commercial Ranges Ltd.
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
General Inquires 1-905-624-0260
USA Sales, Parts and Service 1-800-424-2411
Canadian Sales 1-888-442-7526
Canada or USA Parts/Service 1-800-427-6668
Designer Series
Electric Broilers
Item: ______________________________
Quantity: __________________________
Project: ____________________________
Approval: __________________________
Date: ______________________________
Designer Series Electric Broilers
Models:
ED -15B ED-30B ED-42B
EDU-15B EDU-30B EDU-42B
Specifications:
Electric designer series broilers in three widths:
models ED-15B, 15" (381mm) wide; ED-30B, 30"
(706mm) wide and ED-42B, 42" (1067mm) wide.
Each 12" (305mm)section controlled by an infinite
switch. Designed as free standing or to be banked
with other ED series equipment. 24" (610mm) deep
x 13- 3/4" (349mm) high, easy clean design with
stainless steel front and sides, concealed grease
drawer behind lower hinged panel, grate lift
handle and optional broiler splatter shield. Ribs in
grate give distinct brand.
Standard Features:
• Stainlesssteelfrontand
sides
• Easycleandesignwith
recessed protected con-
trols and ample space
between elements and
side splash walls
• Gratelifthandle
• Concealedgreasedrawer
• Heat-Onindicatorlamps
• Infiniteswitchcon-
trolled; one per foot of
width
• One-Yearlimitedparts&
labor warranty
(USA&Canadaonly)
• "CE"approvedmodels
have prefix EDU
Model ED-15B
Optional Features:
 Stainlesssteelbackand
bottom
Broiler splatterguard, 15"
(381mm), 30" (705mm)
and 42" (1067mm) wide.
 S/Scomesin3pieces
which adds 10" to top
section of broiler.
24" (610mm) wide nickel
plated shelf to fit 30"
(705mm) splatterguard
or 36" (914mm) shelf to
fit 42" (1067mm) splatter
guard, please specify.
Note:Standsareavailable
seeform#CS24/CSD

Garland Commercial Ranges Ltd.
1177 Kamato Road,
Mississauga, Ontario
L4W 1X4 CANADA
General Inquires 1-905-624-0260
USA Sales, Parts and Service 1-800-424-2411
Canadian Sales 1-888-442-7526
Canada or USA Parts/Service 1-800-427-6668
Designer Series Electric Broilers
Form# ED-15B, ED-30B, ED-42B (09/19/13)
24"
[610mm]
2"
[51mm] 17 1/4"
[438mm]
3 1/2
[89mm]
WIDTH
13 3/4"
[349mm]
11 1/4"
[286mm]
4"
[102mm]
10"
[254mm]
Models
Total kW Load Nominal Amperes Per Line
North America Export
North
America Export Single Phase
Hi Line -3
Phase
Single
Phase
Hi Line - 2 or
-3 Phase
208V 240V
220V/
380V
240V/
415V
208V 240V 208V 240V 220V/
380V
240V/
415V
220V/
380V
240V/
415V
ED -15B, EDU-15B 2.7 2.7 2.7 2.7 13 12 N/A N/A 13 12 N/A N/A
ED-30B, EDU-30B 5.4 5.4 5.4 5.4 26 23 23 20 25 23 13 12
ED-42B, EDU-42B 8.1 8.1 8.1 8.1 39 34 23 20 37 34 13 12
Model Overall Dimensions Usable Cooking Surface Cu.
Ft.
Ship Wt.
Lb/kg
Height Width Depth Width Depth
ED -15B 13-3/4" (349mm) 15" (381mm) 24" (610mm) 11-1/2" (292mm) 19" (483mm) 670/41
ED-30B 13-3/4" (349mm) 30’ (762mm) 24" (610mm) 23" (584mm) 19" (483mm) 9100/45
ED-42B 13-3/4" (349mm) 42" (1067mm) 24" (610mm) 34-1/2" (876mm) 19" (483mm) 17 145/66
Garland products are not approved or authorized
for home or residential use, but are intended for
commercialapplicationsonly.Garlandwillnotpro-
vide service, warranty, maintenance or support of
any kind other than in commercial applications.
Installation Clearances
Side Rear
9" (229mm) 9" (229mm)
