MasterChef ICM305-WHITE User manual

Product no. 085-3137-6/G45323
LARGE CAPACITY ICE MAKER
Model: ICM305-WHITE Product No: 043-2372-0
TM
INSTRUCTION MANUAL
Toll-free: 1-855-803-9313
Read this manual thoroughly before using and save it for future reference
Made in China
Imported by Trileaf Distribution,
Toronto, Canada M4S 2B8

Product no. 043-2372-0/ICM305-WHITE | Contact us: 1-855-803-9313
2
IMPORTANT INFORMATION
3
IMPORTANT INFORMATIONSPECIFICATIONS & FEATURES
TM
When using an electrical appliance, basic safety precautions should always be followed to reduce
the risk of fire, electric shock, and/or injury, including the following:
1. Read all instructions before using.
2. Remove all packing material and carefully check your ice maker to ensure it is in good condition
and that there is no damage to the ice maker or power cord and plug.
3. Before using the Ice maker for the first time, please wait 2 hours aer positioning it, and keep
the transparent lid open for at least 2 hours.
4. Pure water should not be used in this unit, mineral water is recommended.
5. Ensure the voltage is compliant with the voltage range stated on the rating label, and ensure the
grounding of the socket is in good condition.
6. If the supply cord is damaged, it must be replaced by the manufacturer or its service agent or a
similarly qualified person in order to avoid a hazard.
7. Do not tilt the machine more than 45 degrees during transport, and do not invert the machine.
This may damage the compressor and the sealing system.
8. To protect against risk of electric shock, do not pour water on cord, plug and ventilation,
immerse the appliance in water or any other liquid.
9. Unplug the appliance aer using or before cleaning.
10. Keep the appliance 3 1/4" (8 cm) from other objects to ensure good ventilation..
11. Do not use accessories which are not recommended by Manufacturer.
12. This appliance can be used by children aged 8 years and above and persons with reduced
physical, sensory or mental capabilities or lack of experience and knowledge if they have been
given supervision or instruction concerning use of the appliance in a safe way and understand the
hazards involved. Children should not play with the appliance. Cleaning and user maintenance
should not be made by children without supervision. Children should be supervised to ensure that
they do not play with the appliance.
13. Do not use the appliance near flames, hot plates or stoves.
14. Do not switch on the power button repeatedly (allow 5 min. before turning appliance on) to
avoid damaging the compressor.
15. Metal sheet or other electric objects should not be inserted into the appliance to avoid fire and
short circuit.
16. Do not use outdoors.
17. Never clean with scouring powders or hard implements.
18. Please keep the instruction manual.
19. Warning: Do not store explosive substances such as aerosol cans with a flammable propellant
in this appliance.
20. This appliance is intended to be used in household and similar applications such as
– staff kitchen areas in shops, oces and other working environments;
– farm houses and by clients in hotels, motels and other residential type environments;
– bed and breakfast type environments;
– catering and similar non-retail applications
21. The refrigerant and insulation blowing gas is flammable, when disposing of the appliance, do
so only at an authorized waste disposal centre. Do not expose to flame.
Fire warning sign. Caution risk of fire.
Model Number：ICM305-WHITE
Product No: 043-2372-0
Daily Ice Output：44 lb (20 kg) / 24 hours
Ice Sizes：2 sizes: small and large
Ice Storage Capacity：2 L
Refrigerant：R600a 1.09 oz (31 g)
Water Reservoir Capacity：2.6 L
Voltage: 120 V ~ 60 Hz
Power Consumption: 150 W
Unit Dimensions：10 5/8 x 14 3/8 x 12 13/16" (27 x 36.5 x 32.6 cm)
※ Quick ice making
※ Two different sizes of ice can be made
※ Ice full prompt, when the water is insucient
※ Bullet shaped ice
※ 12 ice bullets per batch
※ Auto-clean function

Product no. 043-2372-0/ICM305-WHITE | Contact us: 1-855-803-9313
4
PARTS LIST
5
CONTROL PANEL OPERATION
TM
1. Buttons
2. Control panel
3. Top cover
4. Transparent lid
5. Micro switch bracket
6. Evaporator
7. Water box
8. Ice shovel board
9. Ice basket
10. Water reservoir
11. Front big body
12. Motor bracket
13. Rear big body
14. Cooling port
1) POWER: Plug in the power and the source indicator flashes. Press the POWER button, the
power indicator light will turn on. The ice making cycle will start and will produce ice per size
selected. Aer the ice making is completed, the ice will be moved into the ice basket.
2) SELECT: Select the ice size mode. Each time you start the machine, the default mode is large
ice making mode, and the indicator light of the selected mode is on. It takes more than eight
minutes to make small ice, and more than nine minutes to make large ice. It is recommended to use
large ice mode for ambient temperature above 25°C (77°F) and small ice mode for ambient
temperature below 20°C (68°F).
3) CLEAN: Add water to water reservoir. Press power button and then clean button. The water
pump will draw water through appliance. Repeat this cycle. Cleaning cycle is approximately 4
minutes.
4) ADD WATER: Water shortage alarm: When this red light is on, it means there is not enough
water in the water reservoir. You will need to add water and press the POWER button to restart
the machine.
5) ICE FULL alarm: When the ice reaches the maximum amount in the ice storage container, the
“ICE FULL” light flashes and the machine will stop operating. The ice in the ice basket will need to
be removed. When the ice position is lower than the full sensor position, the machine automatical-
ly restarts.
POWER: Power switch SELECT: Mode selection
CLEAN: Cleaning button SMALL: small ice size selection
LARGE: large ice size selection
ICE FULL: ice full alarm ADD WATER: water shortage alarm
Ice shovel

6
OPERATING INSTRUCTIONS
CLEANING & MAINTENANCE
7
TROUBLESHOOTING
TM
1. Please note, if a power failure occurs due to disconnection of the power cord, or the power
button has been pushed off during an ice making cycle, small ice chips may form and lodge in the
automatic shovel causing it to jam. If this occurs, the ice chips may be removed by disconnecting
the power cord and gently pushing the shovel to the rear of the cabinet and removing the ice chips,
then restarting.
2. Please check if the water reservoir is level when the ice shovel cannot move the ice to the ice
basket. If not, please push the ice shovel gently by finger, then press POWER button to restart.
Step 1
Open the lid and add water to the reservoir.
Note: There is a MAX level in the reservoir. The water should not exceed the MAX level. If the
water exceeds the MAX level, you need to open the bottom drain plug to release the excess
water. Replace transparent lid.
Step 2
Plug in the power, and press the POWER button to start the machine.
Step 3
Select the size of the ice you want to make. NOTE: The default is large ice.
Note:
1. When the indoor temperature is below 20°C (68°F), choose small ice. Large ice is recom-
mended for indoor temperatures above 25°C (77°F).
2. When the cycles are used for the first time, the ice produced will be small and irregular.
3. When the ice basket is full, remove the ice immediately, do not let the ice overflow
the ice basket.
1. Clean the inner liner, ice collecting tray, water reservoir, ice shovel and evaporator frequently.
When cleaning, unplug the unit and remove the ice cubes. Use a diluted solution of water and
vinegar to clean the inside and the outside surface of the ice maker. Do not spray ice maker with
chemicals or diluted agents such as acids, gasoline or oil. Rinse thoroughly before starting.
2. Keep ventilation openings in the appliance enclosure, or in the built-in structure, clear of
obstruction. Do not use mechanical devices or other means to accelerate the defrosting process,
other than those recommended by the manufacturer.
3. When using the machine aer being idled for a period of time, it may not have enough water to
pump for air retard, and the indicator of “ADD WATER” will keep lighting. At this time, you just
need to press the POWER button again and the machine will enter normal state.
4. To ensure the cleanliness of ice, please change the water in water reservoir at least once per
day. If the ice maker has not been used in a long time, drain any water out and clean.
5. If the compressor does not work due to water shortage, ice is too full, power failure, and other
reasons, when the machine is started again, the compressor will delay 3 minutes before starting.
6. Please use pure water, mineral water is recommended, when making ice and aer long periods
of no use.
PROBLEM POSSIBLE CAUSE SUGGESTED SOLUTIONS
The compressor works
abnormally with a buzzing
noise.
The voltage is lower than
recommended.
Stop the ice maker and do
not restart until the voltage
is normal.
Water shortage indicator
light is on.
1. There is no water.
2. The pump is full of air.
1. Add some water until it
reaches MAX position.
2. Press POWER button to
restart.
The ice making procedure
is correct, but there is no
ice coming out.
1. The compressor has no
refrigerant.
2. Compressor damage.
3. The fan motor is damaged.
Call the service hotline.
The ice made is too large
and pieces are sticking
together.
1. The incorrect ice cube
size was chosen.
2. Ice from previous cycles
le in water reservoir.
1. Select small size.
2. Remove the ice when in the
standby mode.
Indicator lights on display
are not on. Blown fuse/ No power. Replace fuse / Turn power on.
All indicators flash
simultaneously.
1. The water reservoir is blocked
by ice.
2. The motor is stuck, or the
motor is off, or the motor is
damaged.
3. Micro switch damage.
1. Unplug the power and remove
the ice blocking the tray. Plug
power in and press the power
button; ice maker will restart in
3 minutes.
The machine is always
working, but the water is
always warm.
The solenoid valve has failed. Replace the solenoid valve.
When the ice basket is full,
the machine does not
prompt ICE FULL.
1. Ice full sensor damaged.
2. Solar ray interference.
1. Replace the red ice full sensor.
2. Move indoors to make ice.
3. Call the service hotline.
Product no. 043-2372-0/ICM305-WHITE | Contact us: 1-855-803-9313

8
WARNING
9
WARRANTY CARD
TM
1-Year Limited Warranty
This product carries a one (1) year warranty against defects in workmanship and materials. Trileaf
Distribution agrees to replace the defective product free of charge within the stated warranty
period, when returned by the original purchaser with proof of purchase. This product is not guaran-
teed against wear, misuse and/or abuse.
If the control panel is damaged, it must be replaced by the manufacturer's service organization or
a person qualified to repair it in order to avoid danger.
Ice must be made from drinkable water or drinks.
It is normal for the compressor and condenser surface to reach temperatures between 70°C
(158°F) and 90°C (194°F) during operation and surrounding areas may be very hot.
Due to fast freezing, ice cubes may appear “Cloudy”. This is air trapped in the water and will not
affect quality or taste of ice.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their
safety.
Children should use this product under adult supervision.
Do not immerse in water.
1) Warning–keep ventilation openings in the appliance enclosure or in the built-in structure clear
of obstructions.
2) Warning–do not use mechanical devices or other means to accelerate to defrosting process
other than those recommended by the manufacturer.
3) Warning–do not damage the refrigerant circuit.
4) Warning–do not use electrical appliance inside the food storage compartments of the
appliance unless they are of the type recommended by the manufacturer.
Correct Disposal of this product
This symbol indicates that this product should not be disposed with other household
wastes. To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, recycle it responsibly to promote the sustainable reuse of
material resources.
Product No:
:
(
NO ：
)
Product name :
Date of purchase
:
Place of purchase :
Note: Please fill out this form in detail and keep it with the invoice received when purchasing this product.
