MasterCraft Maximum Hawkeye Laser 055-6746-0 User manual

1
Dual-beveling Compound Mitre Saw
055-6746-0
Owner’s Manual
Toll-Free Helpline
1-800-689-9928
MD
R

2
Table of contents
SECTION PAGE
I. Specifications...................................................................................... 2
II. Symbols............................................................................................... 3
III. General safety rules............................................................................. 4
IV. Specific safety rules for the mitre saw................................................. 6
V. Electrical information........................................................................... 8
VI. Know your mitre saw............................................................................ 10
VII. Glossary of terms.............. .................................................................. 11
VIII. Assembly and adjustments.................................................................. 13
IX. Operations .......................................................................................... 25
X. Maintenance........................................................................................ 40
XI. Troubleshooting guide......................................................................... 42
XII. Warranty.............................................................................................. 43
XIII. Replacement parts.............................................................................. 44
I. Specifications
MOTOR: 120 V 60 Hz 15 A
SPEED: 3800 RPM (no load)
BLADE: 12’’ (30.5 cm) (40-tooth) carbide-tipped
ARBOR DIAMETER: 5/8’’ (15.9 mm)
LASER: Class IIIa
LASER WAVELENGTH: 630–660 nm
LASER OUTPOWER: < 5 mW
CUTTING CAPACITY: 3 x 7 7/8” (7.8 x 20 cm) crosscut at 0° mitre, 0° bevel
3 1/2 x 5 1/2” (9 x 14 cm) crosscut at 0° mitre, 0° bevel
3 x 5 1/2” (7.8 x 14 cm) mitre at 45° mitre, 0° bevel
3 1/2 x 3 1/2” (9 x 9 cm) mitre at 45° mitre, 0° bevel
1 7/8 x 7 7/8” (4.8 x 20 cm) bevel at 0° mitre, 45° bevel
1 1/2 x 5 1/2” (3.8 x 14 cm) compound at 45° mitre, 45° bevel
STANDARD EQUIPMENT: dust bag, blade wrenches, AAA batteries, extension wings.
Dual-beveling Compound Mitre Saw 055-6746-0

3


II. Symbols
SAFETY ALERT: precautions that involve your safety.
PROHIBITION
READ AND UNDERSTAND OWNER’S MANUAL: to reduce the risk of injury,
user and all bystanders must read and understand Owner’s Manual before using
this product.
SUPPORT AND CLAMP WORK
KEEP HANDS AWAY FROM BLADE: failure to keep your hands away from the
blade will result in serious personal injury.
DANGER: indicates an imminently hazardous situation that will result
in death or serious injury if it is not avoided.
WARNING: indicates a potentially hazardous situation that could result
in death or serious injury if it is not avoided.
CAUTION: indicates a potentially hazardous situation that may result in
minor or moderate injury if it is not avoided.
CAUTION: used without the safety alert symbol, indicates a potentially
hazardous situation that may result in property damage if it is not
avoided.
DANGER

!
WARNING
WARNING ICONS
Your power tool and its Owner’s Manual may contain “WARNING ICONS” (a symbol
intended to alert you to and/or instruct you how to avoid a potentially hazardous
situation). Understanding and heeding these symbols will help you operate your tool
better and more safely. Shown below are some of the symbols you may see.
CAUTION
CAUTION
!
!
WEAR HEARING PROTECTION: to reduce the risk of induced hearing loss.

4
III. General safety rules
Safety is a combination of common sense, staying alert, and knowing how the mitre saw
works.
WARNING: To avoid mistakes that could cause serious injury, read this owner’s
manual carefully before plugging in the mitre saw.
1. READ and become familiar with this Owner’s Manual. LEARN the tool’s
applications, limitations, and possible hazards.
2. AVOID DANGEROUS CONDITIONS. DO NOT use power tools in wet or damp areas,
and DO NOT expose them to rain. Keep work areas well lit.
3. DO NOT use power tools in the presence of flammable liquids or gas.
4. KEEP the work area clean, uncluttered, and well lit. DO NOT work on floor surfaces
that are slippery because of sawdust or wax.
5. KEEP BYSTANDERS AT A SAFE DISTANCE FROM the work area, especially when
the tool is operating. DO NOT allow children near the tool.
6. DO NOT FORCE THE TOOL to do a job that it was not designed to do.
7. DRESS FOR SAFETY. DO NOT wear loose clothing, gloves, neckties, or jewellery
(rings, watches, etc.) when operating this tool. These items can get caught in moving
parts and draw the operator in. WEAR non-slip footwear, and tie back long hair.
8. WEAR A FACE MASK OR DUST MASK. Sawing operations produce dust.
9. UNPLUG the power cord from the electrical outlet before making adjustments,
changing parts, cleaning, or performing maintenance on this tool.
10. KEEP GUARDS IN PLACE AND IN WORKING ORDER.
11. AVOID ACCIDENTAL START-UPS. VERIFY that the power switch is in the OFF
position before plugging in the power cord.
12. REMOVE ADJUSTING TOOLS. VERIFY that all tools are removed from the mitre saw
before turning it on.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.

!

5
III. General safety rules (continued)
13. DO NOT LEAVE THE POWER SWITCH IN THE ON POSITION WHILE THE TOOL IS
UNATTENDED. Turn the power switch to the OFF position. DO NOT leave the tool
until it has come to a complete stop.
14. DO NOT STAND ON THE TOOL. Serious injury could result if the tool tips or is
accidentally jarred. DO NOT store anything above or near the tool.
15. DO NOT OVERREACH. Keep proper footing and balance at all times. Wear oil-
resistant rubber-soled footwear. Keep the floor clear of oil, scraps, and other debris.
16. MAINTAIN TOOLS PROPERLY. KEEP tools clean and in good working condition.
Follow instructions for lubricating and changing accessories.
17. CHECK FOR DAMAGED PARTS. Inspect moving parts for alignment, jamming,
breakage, improper mounting, or any other condition that may affect the operation of
the tool. Any part that is damaged should be properly repaired or replaced before use.
18. MAKE THE WORKSHOP CHILDPROOF. Use padlocks and master switches, and
ALWAYS remove starter keys.
19. DO NOT operate the tool while under the influence of drugs, alcohol, or medication that
may affect your ability to use the tool properly.
20. WHEN SERVICING, USE ONLY IDENTICAL REPLACEMENT PARTS.
21. DO NOT ALLOW ANYONE WHO HAS NOT CAREFULLY READ AND FULLY
UNDERSTOOD THIS OWNER’S MANUAL TO USE OR OPERATE THIS MITRE SAW.
22. WEAR HEARING PROTECTION to reduce the risk of induced hearing loss.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.
ALWAYS WEAR EYE PROTECTION.
A mitre saw can propel foreign objects into the eyes, which could
cause permanent eye damage. ALWAYS wear safety goggles (not
glasses). Ordinary eyeglasses only have impact-resistant lenses. They
are NOT safety goggles.
WARNING: Dust that is generated when cutting certain materials can be
hazardous to health. Always operate the mitre saw in a well-ventilated area, and
provide for proper dust removal. Use a dust collection system whenever possible.

!

6
IV. Specific safety rules for the mitre saw
1. USE ONLY CROSSCUTTING SAW BLADES. When using carbide-tipped blades, make
sure they have a negative hook angle. Do not use blades with deep gullets, because
they can deflect and contact the guard. The use of thin-kerf blades is not recommended.
2. DO NOT operate the mitre saw until it is completely assembled and installed according
to these instructions.
3. IF YOU ARE NOT thoroughly familiar with the operation of mitre saws, call the toll-free
helpline (1-800-689-9928) for further assistance.
4. ALWAYS hold the work firmly against the fence and table. DO NOT perform any
operation freehand.
5. KEEP HANDS out of the path of the saw blade. If the workpiece you are cutting would
cause your hands to be within 8 3/25” (20.6 cm) of the saw blade, the workpiece should
be clamped in place before making the cut.
6. BE SURE the blade is sharp, runs freely, and is free of vibration.
7. ALLOW the motor to come up to full speed before starting cut.
8. KEEP THE MOTOR AIR SLOTS CLEAN and free of chips or dust.
9. ALWAYS MAKE SURE all handles are tight before cutting, even if the table is positioned
in one of the positive stops.
10. BE SURE blade and collar are clean, and that the arbor screw is tightened securely.
11. USE only blade collars specified for your saw.
12. NEVER use blades larger or smaller in diameter than 12’’ (30.5 cm).
13. NEVER apply lubricants to the blade when it is running.
14. ALWAYS check the blade for cracks or damage before operation. Replace a cracked or
damaged blade immediately.
15. NEVER use blades recommended for operation at less than 3800 RPM.
16. USE the blade guards at all times.
17. ALWAYS keep the blade guards in place.
18. NEVER reach around the saw blade.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.

7
19. MAKE SURE the blade is not contacting the workpiece before the switch is turned ON.
20. NEVER unplug the saw with the switch in the ON position.
21. IMPORTANT: After completing the cut, release the power switch and wait for the
blade to stop before returning the saw to the raised position.
22. MAKE SURE the blade has come to a complete stop before removing or securing the
workpiece, changing the workpiece angle, or changing the angle of the blade.
23. NEVER cut ferrous metals or masonry with this tool.
24. NEVER cut small pieces.
25. PROVIDE adequate support to the sides of the saw table for long workpieces.
26. NEVER use the mitre saw in an area where flammable liquids or gases are present.
27. NEVER use solvents to clean plastic parts. Solvents may dissolve or otherwise
damage the material.
28. SHUT OFF and disconnect the power before servicing or adjusting the tool.
29. DISCONNECT the saw from the power source, and clean the machine before leaving it.
30. MAKE SURE the work area is clean before leaving the machine.
31. SHOULD any part of your mitre saw be missing, damaged, or fail in any way, or if any
electrical component should fail to perform properly, shut off the switch and remove the
plug from the power supply outlet. Replace missing, damaged, or failed parts before
resuming operation.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.
IV. Specific safety rules for the mitre saw
(continued)

!

8
WARNING: To avoid electrical hazards, fire hazards, or damage to the tool,
use proper circuit protection. Your saw is wired at the factory for 120 V operation.
Connect to a 120 V, 15 A circuit and use a 15 A time delay fuse or circuit breaker.
To avoid shock or fire, if power cord is worn or cut, or damaged in any way, have
it replaced immediately.

!
POWER SUPPLY AND MOTOR SPECIFICATIONS
The AC motor used in this saw is a universal, non-reversible type. See “MOTOR” in the
“PRODUCT SPECIFICATIONS” section on page 2.
V. Electrical information
GROUNDING INSTRUCTIONS
IN THE EVENT OF A MALFUNCTION OR BREAKDOWN, grounding provides a path
of least resistance for electric currents and reduces the risk of electric shock. This tool
is equipped with an electrical cord that has an equipment-grounding conductor and a
grounding plug. The plug must be plugged into a matching receptacle that is properly
installed and grounded in accordance with all local codes and ordinances.
DO NOT MODIFY THE PLUG PROVIDED. If it will not fit the receptacle, have the proper
receptacle installed by a qualified electrician.
IMPROPER CONNECTION of the equipment grounding conductor can result in risk of
electric shock. The conductor with the green insulation (with or without yellow stripes) is
the equipment grounding conductor. If repair or replacement of the electrical cord or plug is
necessary, do not connect the equipment grounding conductor to a live terminal.
CHECK with a qualified electrician or service person if you do not completely understand
the grounding instructions, or if you are not certain the tool is properly grounded.
USE only three-wire extension cords that have three-pronged grounding plugs with three-
prong receptacles that accept the tool’s plug. Repair or replace damaged or worn cords
immediately.
GUIDELINES FOR EXTENSION CORDS
USE THE PROPER EXTENSION CORD. Make sure your extension cord is in good
condition. Use an extension cord heavy enough to carry the current your product will draw.
An undersized cord will cause a drop in line voltage resulting in loss of power, overheating
and burning out of the motor. The table on the right shows the correct size to use depending
on cord length and nameplate ampere rating. If in doubt, use the next heavier gauge. The
smaller the gauge number, the heavier the cord.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.

9
V. Electrical information (continued)
WARNING: This tool must be grounded while in use to protect the operator
from electric shock.
MINIMUM GAUGE FOR EXTENSION CORDS (AWG)
(when using 120 V only)
Amperage Rating Total length of cord in feet
More Than Not More Than 25’ (7.6 m) 50’ (15 m) 100’ (30 m) 150’ (45 m)
0 6 18 16 16 14
6 10 18 16 14 12
10 12 16 16 14 12
12 16 14 12 Not Recommended

!
Three-pronged Plug
Grounding Prong
Properly Grounded
Three-pronged Receptacle
Make sure your extension cord is properly wired and in good condition. Always replace a
damaged extension cord or have it repaired by a qualified technician before using it. Protect
your extension cords from sharp objects, excessive heat and damp or wet areas.
Use a sep arate electrical circuit for your tool. This circuit must not be less than #12 wire
with a 20 A time-lag fuse or a #14 wire with a 15 A time-lag fuse.
NOTE: When using an extension cord on a circuit with a #14 wire, the extension cord must
not exceed 25’ in length. Before connecting the motor to the power line, make sure the
switch is in the off position and the electric current is rated the same as the current stamped
on the motor nameplate. Running at a lower voltage will damage the motor. This tool is
intended for use on a circuit that has a receptacle like the one illustrated in Fig. 1.
WARNING:
In all cases, make certain the receptacle is properly grounded. If you are not sure,
have a qualified electrician check the receptacle.

!
Do not expose to rain or use in damp locations.
KEEP THIS OWNER’S MANUAL IN A SAFE PLACE FOR FUTURE REFERENCE.

10
VI. Know your compound mitre saw
Table
Mounting Hole
Switch Handle
Motor
Lower Blade Guard
Mitre Handle
Mitre Scale
Upper Blade Guard
Cover Plate
Sliding Fence
Safety lock-off switch
Left Extension Bracket
Base
Table Insert
Bevel Lock Handle
Arbor Lock
Stop Latch Knob
Positive Stop Locking Lever
Saw Blade
Positive Mitre Detents Extension Table Lock Knob
Right Extension Bracket
ON/OFF Trigger Switch
Carry Handle
Belt Cover
Quick-cam Mitre Table Lock
Laser ON/OFF Switch
Fence
Hawkeye Laser®

11
VII. Glossary of terms
AMPERAGE (AMPS) – A measure of the flow of electric current. Higher ratings generally
means the tool is suited for heavier use.
ARBOR LOCK – Allows the user to keep the blade from rotating while tightening or
loosening the arbor bolt during blade replacement or removal.
BASE – Supports the table, holds accessories and allows for workbench or leg set
mounting.
BEVEL LOCKING HANDLE – Locks the mitre saw at a desired beveling angle.
BEVEL SCALE – To measure the beveling angle of the saw blade 0° to 45° left.
CARBIDE TIPPED – Extremely hard steel pieces with sharp cutting edges fastened to
cutting tools such as saw blades.
COVER PLATE SCREW – Loosen this screw and rotate the plate for access to the blade
arbor bolt.
EXTENSION CORD – An electric cord used between power tools and outlets to extend
the range of the tools. The more amperage your tool uses and the longer the distance, the
larger the size of the wire needed in your extension cord.
EYE PROTECTION – Goggles or spectacles intended to protect your eyes. Eye protection
should meet the requirements of ANSI Z.87.1 (USA) or CSA Z94.3-M88 (Canada).
FACE SHIELD – An impact-resistant shield that helps to protect your face from chips,
sparks, and small debris. Should only be used in conjunction with additional eye protection.
FENCE – Helps to keep the workpiece from moving when sawing. Scaled to assist with
accurate cutting.
GUARD – Protective device that forms a barrier between a hazardous object such as a
blade, wheel or cutter and the operator.
HOLD-DOWN LATCH – Locks the mitre saw in the lowered position for compact storage
and transportation.
OWNER’S MANUAL – Booklet accompanying your power tool that describes the hazards
and safe operation procedures, outlines basic tool operation, care and maintenance.
MITRE HANDLE – Used to rotate the table, and to rotate the saw to a right or left cutting
position.
MITRE SCALE – Measures the mitre angle 0° to 45° left and right.
MOUNTING HOLES – To mount the mitre saw to a stable surface.
ON/OFF TRIGGER SWITCH – To start the tool, push the safety lock-off button and
squeeze the trigger. Release the trigger to turn off the mitre saw.

12
VII. Glossary of terms (continued)
POSITIVE STOP LOCKING LEVER – Locks the mitre saw at a preset positive stop for the
desired mitre angle.
SWITCH HANDLE – The switch handle contains the trigger switch and safety lock-off
button. The blade is lowered into the workpiece by pushing down on the handle. The saw
will return to its upright position when the handle is released.
WARNING LABELS – Read and understand for your own safety. Make sure all labels are
present on machine and legible.
WRENCH STORAGE – Convenient storage to prevent misplacing the blade wrench.
WOODWORKING TERMS
ARBOR – The shaft on which a blade is mounted.
BEVEL CUT – An angle cut made through the face of the workpiece.
COMPOUND CUT – An angled cut to both the edge and face of a board, most common use
is with crown moulding.
CROSSCUT – A cut that runs across the board perpendicular to the grain.
FREEHAND – Performing a cut without using a fence (guide), hold-down or other proper
device to prevent the workpiece from twisting during the cutting operation.
HEEL – Misalignment of the blade.
KERF – The width of a saw cut, determined by the thickness and set of the blade.
KICKBACK – Sudden and unintended movement of the tool or workpiece. It is typically
caused by binding or pinching of the workpiece
MITRE CUT – A mitre is a type of joint where the two parts to be joined are cut at an angle,
and the finished joint typically forms a 90° angle. Also commonly spelled “miter”.
REVOLUTIONS PER MINUTE (RPM) – The number of turns completed by a spinning
object in one minute.
SAW BLADE PATH – The area of the workpiece or table top directly in line with the travel
of the blade or the part of the workpiece that will be cut.
SET – The distance between two saw blade tips, bent outward in opposite directions to
each other. The further apart the tips are, the greater the set.
THIN-KERF BLADE – Thinner than normal blades remove less material, smaller kerfs
are between .065 and .070”. Blade thinness may also increase the heat generated while
cutting.
WORKPIECE – The wood being cut. The surfaces of a workpiece are commonly referred to
as faces, ends and edges.

13
VIII. Assembly and adjustments
UNPACKING
1. Carefully remove the mitre saw from the carton.
2. Separate the parts.
3. Lay out all of the parts, and check them against the parts listed below. Examine all of the
parts carefully.
WARNING: If any part is missing or damaged, do not plug the mitre saw in until
the missing or damaged part has been repaired or replaced. For more information,
call the toll-free helpline, at 1-800-689-9928.

!
Blade Wrench Mitre Handle
Mitre Saw
Dust Bag
Hold-down Clamp AAA Batteries
Extension Wings

14
VIII. Assembly and adjustments (continued)
Estimated Assembly Time: 5-10 minutes
ASSEMBLY INSTRUCTIONS
WARNING: To avoid injury, do not connect this mitre saw to the power source
until it is completely assembled and adjusted and you have read and understood
this owner’s manual.
Fig. 1
INSTALLING THE MITRE HANDLE
(FIG. 1)
1. Thread the mitre handle (1) into the hole
(2) located at the front of the mitre table.
CUTTING HEAD (FIG. 2)
Raising
1. Push down slightly on the switch
handle (1).
2. Pull out the stop latch knob (2).
3. Allow the cutting head to rise to the up
position.
Locking
When transporting or storing the mitre saw,
the cutting head should always be locked in
the down position.
1. Push the cutting head down to its lowest
position.
2. Push the stop latch knob (2) into the
locking hole.
Fig. 2

!
WARNING:
● To avoid injury and damage to the saw, transport or store the mitre saw with
the cutting head locked in the down position. Never use the stop latch to hold
the cutting head in a down position for cutting operations.
● To avoid damage, never carry the mitre saw by the switch handle, the cutting
arm or the mitre table handle. Always use the designated carrying handle.

!
1
2
1
2

15
SAW BLADE WRENCH (FIG. 5)
1. For convenient storage and prevention
of loss, there is a slot (1) in the right
side of saw base (2) for storing the
blade wrench (3) when not in use.
Fig. 5
VIII. Assembly and adjustments (continued)
1
3
2
Fig. 3
INSTALLING THE DUST BAG (FIG. 3)
1. Squeeze the metal collar wings (1) of
the dust bag (2).
2. Place the dust bag neck opening around
the exhaust port (3), and release the
metal collar wings.
To empty the dust bag, squeeze the metal
collar and remove from exhaust port. Open
zipper on underside of bag and empty into
waste container.
1
2
3
NOTE: Check frequently, and empty bag before it gets full.
INSTALLING THE EXTENSION WING
ASSEMBLY (FIG. 4)
1. Insert the extension wing bars (1) into
the holes (2) in the base.
2. Thread one extension wing stop screw
(4) into the end of the rear extension
wing bar (1). Verify that the screw is
fully threaded into the corresponding
hole in the extension wing.
3. Repeat steps 1 through 2 for right side
extension wing.
Fig. 4
1
2
34
NOTE: The arm brackets (3) serve two purposes: To act as a stop block for repetitive cuts
and to level the workpiece when the extension wings are fully extended for additional work
support.

16
VIII. Assembly and adjustments (continued)
WARNING:
● Only use a 12’’ (30.5 cm) diameter blade.
● To avoid injury from an accidental start, make sure the switch is in the OFF
position and plug is not connected to the power source.

!
INSTALLING THE SAFETY HOLD-DOWN
CLAMP (FIG. 6)
1. Place the hold-down clamp assembly
(1) in one of the mounting holes (2) as
shown.
Fig. 6
1. Open the battery cover (1).
2. Insert the two supplied AAA batteries
in the case as per the diagram below.
If replacing the batteries, take out the
old batteries and place with new AAA
batteries. Dispose of old batteries
properly.
3. Close the battery cover (1).
NOTE: Replace the batteries with batteries
that have a rating of 1.5 V (Number 4
series and AAA size or equivalent).
1
2
2
INSERTING AND REPLACING THE LASER BATTERIES (FIG. 7)
• Unplug your mitre saw.
WARNING:
Failure to unplug your tool could result in accidental starting and cause possible
serious personal injury.

!
Fig. 7
AAA Battery
AAA Battery
1
2
2

17
VIII. Assembly and adjustments (continued)
Fig. 8
Fig. 9
3
4
Fig. 10
REMOVING AND INSTALLING THE
BLADE
Removing Blade (Fig. 8, 9, 10, 11)
1. Unplug the saw from the outlet.
2. Allow the blade assembly to rise to the
uppermost position. Raise the lower
blade guard (1) to the upper position.
3. Loosen the cover plate screw (2) using
a star-head screwdriver.
4. Rotate the cover plate (3) to expose the
arbor bolt (4).
5. Place the blade wrench over the arbor
bolt.
6. Locate the arbor lock (5) on the motor
below the mitre saw switch handle.
7. Press the arbor lock, holding it in
firmly while turning the blade wrench
clockwise. The arbor lock will engage
after turning the wrench. Continue to
hold the arbor lock to keep it engaged
while turning the wrench clockwise to
loosen the arbor bolt.
8. Remove the arbor bolt/washer (4),
outer blade collar (6) and the blade (7).
Do not remove the inner blade collar.
(Fig. 11)
NOTE: Pay attention to the pieces
removed, noting their position and direction
they face. Wipe the blade collars clean of
any sawdust before installing a new blade.
Also, the 12” (30.5 cm) blade has a 1”
(25.4 mm) arbor hole with a 5/8” (15.9 mm)
reducer (8) to mount onto the saw.
Fig. 11
1
2
5
4
6
7
8

18
VIII. Assembly and adjustments (continued)
Installing Blade (Fig. 8, 9, 10, 11)
Unplug the mitre saw before changing/installing the blade.
1. Install a 12’’ (30.5 cm) blade with a 5/8’’ (15.9 mm) arbor (or a 1” (2.5 cm) arbor with
a 5/8” (15.9 mm) reducer), making sure the rotation arrow on the blade matches the
clockwise rotation arrow on the upper guard and the blade teeth are pointing downward.
2. Place the blade collar (6) against the blade and on the arbor. Thread the arbor bolt (4)
onto the arbor in a counter-clockwise direction. (Fig. 11)
IMPORTANT: Make sure the flats of the blade collars are engaged with the flats on
the arbor shaft. Also, the flat-side of the collar must be placed against the blade.
3. Place the blade wrench on the arbor bolt.
4. Press the arbor lock (5), holding it in firmly while turning the blade counter-clockwise.
When it engages, continue to press the arbor lock in while tightening the arbor bolt
securely. (Fig. 10)
5. Rotate the cover plate (3) back to its original position until the slot in the cover plate
engages with the cover plate screw (2). While holding the lower blade guard, tighten the
screw with a star-head screwdriver. (Fig. 8, 9) NOTE: The lower blade guard must be
raised to the upright position to access the cover plate screw.
6. Lower the blade guard (1), and verify that the operation of the guard does not bind or
stick. (Fig. 8)
7. Be sure the arbor lock is released so the blade turns freely.
WARNING:
● To avoid injury, never use the saw without the cover plate secured in place.
It keeps the arbor bolt from falling out if it accidentally loosens and helps
prevent the spinning blade from coming off the saw.
● Make sure the collars are clean and properly arranged. Lower the blade into
the lower table, and check for any contact with the metal base or the mitre table.
● To avoid injury from an accidental start, make sure the switch is in the off
position, and the plug is not connected to the power source.

!

!

19
VIII. Assembly and adjustments (continued)
MOUNTING THE MITRE SAW
(FIG. 12, 13)
Mounting instructions
1. For stationary use, place the saw in the
desired location, directly on a workbench
where there is room for handling and
proper support of the workpiece. The
base of the saw has four mounting
holes. Bolt the base of the mitre saw
(1) to the work surface (5), using the
fastening method shown in Fig. 12.
2. For portable use, place the saw on a
3/4’’ (19 mm) thick piece of plywood.
Bolt the base of the mitre saw securely
to the plywood using the mounting holes
on the base. Use C-clamps to clamp this
mounting board to a stable work surface
at the worksite. (Fig. 13)
Fig. 12
Fig. 13
2
3
4
1
5
6
7
8
9
1. Mitre saw base
2. Hex head bolt
3. Rubber washer
4. Flat washer
5. Workbench
6. Flat washer
7. Lock washer
8. Hex nut
9. Jam nut
NOTE: Mounting hardware is not included with this tool. Bolts, nuts, washers, and screws
must be purchased separately.

20
VIII. Assembly and adjustments (continued)
WARNING:
To avoid injury from an accidental start, make sure the switch is in the off
position and the plug is not connected to the power source.
90° (0°) Bevel adjustment (Fig. 14, 15)
1. Loosen bevel lock handle (1), and tilt
the cutting arm completely to the right.
Tighten the bevel lock handle. Lower
blade.
2. Place a combination square (2) on the
mitre table with the rule against the
table and the heel of the square against
the saw blade.
3. If the blade is not 90° (0°) square
with the mitre table, loosen the bevel
lock handle (1), tilt the cutting head
completely to the left, loosen the lock
nut (3) on the bevel angle adjustment
bolt (4) and adjust the bolt (4) in or out
to increase or decrease the bevel angle
with a 10 mm wrench.
4. Tilt the cutting arm to back to the
right at 90° (0°) bevel and recheck for
alignment.
5. Repeat steps 1 through 4 if further
adjustment is needed.
6.
Tighten the bevel lock handle (1) and
lock nut (3) when alignment is achieved.
90° Bevel Pointer Adjustment (Fig. 16)
1. When the blade is exactly 90° (0°) to the
table, loosen the bevel indicator screws
(5) using a star-head screwdriver.
2. Adjust bevel indicators (6) to the “0”
mark on the bevel scale and retighten
the screw.
BEVEL STOP ADJUSTMENT (FIG. 14, 15, 16)

!
Fig. 15
Fig. 14
1
2
Fig. 16
5
6
4
3
