Masterplug ARCDKG User manual

POWER designed with outdoor activities in mind, this range provides
safe power solutions for garden and light DIY use
Masterplug Help Line Visit our website at
www.masterplug.com
Stafford Park 1 Telford TF3 3BD ENGLAND
03300 249 279 Luceco PLC
Supplied by
PRODUCT IMAGES LINE DIAGRAMS
ARCDKG
PRODUCT INFORMATION
Part Number
Product Dimensions
Sockets
ARCDKG
Height 112mm x Width 50.5mm x Depth 72.3mm
1
TECHNICAL SPECIFICATIONS
Standard(s)
Voltage
Maximum Current
Maximum Load (Wattage)
Rated Trip Current
RCD Type
Trip Speed
This product is certied to applicable British safety standards
BS 7071 1992
240VAC, 50Hz
13 Amps
3120W
30mA
Non-latching
40mS (Typical-at current 150mA).
Double pole RCD contact break BS7071
IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN
FEATURES
OUTDOOR
RCD safety adaptor
1
SOCKET
72.3
50.5 68.1
54.3
44.2
112
• Added protection against fatal electric shocks
• One socket for connecting devices to the RCD adaptor
• Maximum load 3120 Watts, 240V AC
• 30mA trip speed 40ms (typical) to provide fast protection
• Non-latching (every time the supply to the RCD is interrupted it will trip and will need to be reset)
• Double pole contact break
• Ideal for home appliance spike protection
• Manufactured to BS 7071 1992
SAFETY WARNING
PLEASE READ CAREFULLY AND USE IN ACCORDANCE WITH OUR SAFETY INSTRUCTIONS BELOW
Unplug from the mains before any inspection of the appliance.
Keep children away from sockets and electrical appliances.
Seek expert advice or contact the Masterplug Helpline on 03300 249 279 if you have difculty setting your
Masterplug RCD Adaptor if your RCD repeatedly trips when in use.
Store and use your RCD between -5 °C and +40 °C.
Use your RCD as a substitute for taking normal precautions when using mains electrical power.
Use in conditions where the atmosphere is loaded with ammable vapour.
Immerse in liquid or use in wet and humid conditions.
Drop the unit, and stop use if the case becomes damaged.
Use above an altitude of 2,000 metres above sea level.

Masterplug Help Line Visit our website at
www.masterplug.com
Stafford Park 1 Telford TF3 3BD ENGLAND
03300 249 279 Luceco PLC
Supplied by
WHERE CAN I USE MY SAFETY RCD ADAPTOR
You can use your Masterplug Safety RCD Adaptor with any 240 volt electrical appliance but it is particularly valuable on appliances
such as:
Appliances that might cut or drill through their own cable:
Hedge cutters, lawn mowers, jig and circular saws, grinders, drills, shredders, carving knives, etc.
Appliances that might come into contact with moisture or water:
Lawn mowers, pressure washers, water pumps, steam irons, kettles, washing machines, hair curlers and driers, etc.
Appliances that are vulnerable to the entry of ngers, hair and foreign bodies:
Toasters, fan heaters, electric res, hair driers, etc.
Appliances that can be interfered with by children:
Christmas tree lights, train sets, etc.
RCD TYPE: NON-LATCHING
Active (non-latching) - RCD’s switch off if power to them is turned off. Every time the appliance is turned off, the RCD will trip
and have to be reset by going to the socket.
USER INSTRUCTIONS
Please read these operating instructions before use and always strictly observe the test procedure before each application to ensure
safe use.
STAGE 1
•Insert the RCD adaptor into a 13 amp mains socket and switch on.
STAGE 2
•Press the RESET button. The ORANGE indicator should appear.
STAGE 3
•Press the TEST button. The ORANGE indicator will disappear from the CLEAR window.
•DO NOT USE IF THE ORANGE INDICATOR REMAINS
STAGE 4
•Press the RESET button. The RCD has now been set for safe use provided the ORANGE indicator shows in the CLEAR
window.
ENVIRONMENTAL PROTECTION
This symbol is known as the ‘Crossed-out Wheelie Bin Symbol’. When this symbol is marked on a product or battery. It
means that it should not be disposed of with your general household waste. Some chemicals contained within electrical/
electronic products or batteries can be harmful to health and the environment. Only dispose of electrical/electronic/
battery items in separate collection schemes, which cater for the recovery and recycling of materials contained within.
Your co-operation is vital to ensure the success of these schemes and for the protection of the environment.
WHAT IS A SAFETY RCD ADAPTOR
Your Masterplug Safety RCD Adaptor continuously monitors the power supply to an electrical appliance and cuts off the power
within 40 milliseconds if an earth current fault is detected. This is fast enough to prevent a fatal electrical shock. Electrical
appliances can become dangerous if the wiring becomes loose, if they or their power cords become damaged or if they get
wet. Electrocution is also possible if ngers, wet hair or other conductive bodies enter the appliance. In all these cases your
Masterplug Safety RCD Adaptor will instantly cut off the electricity before a potentially fatal electric shock occurs.
