Masterplug 7 Day Electronic Timer - Compact Operation manual

OWER
masterplug
7 DAY ELECTRONIC TIMER - COMPACT
IMPORTANT
V
Don'tplug inan appliance where the load exceeds 13 Amp. Always ensure the plugofany appliance is fully inserted intothe timeroutlet.
Ifcleaningofthe timeris required,remove from mains powerand wipetimerwitha dry cloth.
DO NOTIMMERSETIMERINWATEROR ANY OTHER LIQUID. Heaters and similarappliances should never be leftunattended during operation. The
manufacturer recommends such appliances not be connected to timers.
f
KEYBOARD DEFINITION
1. MASTER CLEAR: Clear all data in memory including current time and all programs.
2. RANDOM: Set or cancel random function.
3. CLOCK: Set current time combined with buttons WEEK, HOUR, MIN. Select 12 or 24 hour mode combined with button TIMER. Activate summertime function
combined wftfi button ON/AUTOfOFF.
4. TIMER: Set programs combined with buttons WEEK, HOUR, MIN.Select 12 or 24 hour mode combined with button CLOCK
5. ON/AUTO/OFF: Select operating modes of timer.
6. WEEK: Set week combined with button CLOCK or TIMER.
7. HOUR: Set hour combined with button CLOCK or TIMER.
8. MIN: Set minute combined with button CLOCK or TIMER.
9. RSTra&'L-Oreswte programs or recall the overridden programs.
10. LED:Shows status ofpower output. When the indicator is ON,there is power output. When the indicatoris OFF, there is no power output.
INITIAL OPERATION
1. Plug the timer intoa regular 250 Volts power outletand turn the power on. Leave forapproximately 14 hours to charge
the Memory Back-up battery.
2. Clearall current information by pressing MASTERCLEAR button witha sharp object such as a pen or pencilafter charging.
3. The timer is now ready to be set up for use.
SETTING CURRENT TIME
1. Press CLOCK buttonand hold,simultaneouslypress WEEK button until the actualday is displayed.Continueby pressing HOURor
MIN button until the currenthouror minuteis displayed. Whensetting,the buttons WEEK, HOUR or MIN can be helddownforrapid forward counting.
2. Release both buttons. The week and time will be seL
3. To reset incorrect time, repeat above steps.
GENERAL FEATURES
10 ON/OFF programs with 1 minute step.
Output LED indicator.
Displaywrth
second.
MANUAL ON/AUTO/MANUAL OFF selectable.
Random function with a random advance of 10-31minutes between 6:00 PM and 6:00 AM.
12/24 hour mode selectable.
Summer time function available.
16 combinations of day or blocks of days available as follows:
MO TU WE TH FR SA SU
MO, TU, WE, TH, FR, SA, SU
MO, TU, WE, TH, FR
SA.SU
MO,TU,WE.TH,FR,SA
MO, WE, FR
TU.TH.SA
MO.TU.WE
TH. FR, SA
MO, WE, FR, SU
SPECIFICATIONS
Voltage: 240VAC, 50Hz
Max Load: 13(2)A,U,3120W
Min.Setting Time:1 Minute
.
Operatingtemperature: -10°Cto +40"C
Accuracy: +/-1 minute per month
Battery backup: NiMH 1.2V> 100hours
IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN
Masterplug Helpline: 0845 194 7584
Visit our Website: www.masterplug.com
make the right connection
J

masterplug
INDOOR POWER
7 DAY COMPACT ELECTRONIC TIMESWITCH
SETTING PROGRAMS
TIP: When verifying your programs ensure that the settings do not overlap, especially when using the
block option. If there are program settings overlapping, the timer ON or OFF willbe executed
according to program time, not by program number. Program OFF has the priorityover program ON.
1.
Press TIMER button and release. LCD shows ON_1. The first ON setting can be made now.
2.
Press WEEK button to set the day or block of days. Set the time by pressing HOUR and MINbutton.
3.
Press TIMER button again to finish the first ON setting and enter into the first OFF setting. LCD shows OFF_1. By repeating 2 to make the first OFF setting.
4.
Press TIMER button again to finish the first OFF setting and enter into the 2nd ON setting. Repeat 2 and 3 to program remaining settings. Press TIMER
buttonand hold for 2 seconds to enter fast advance.
5. Aftercompleting setting, press CLOCKbytton.The timer is ready to operate.
EXAMPLE:
Timeron at 5:15 PMand OFF at 10:30 PM everyday.
a. Press TIMERonce and release. LCDdisplays ON_1
b. Press WEEK tillLCD displays "MO,TU.WE,TH,FR,SA,SU"
c. Press HOUR till LCDdisplays 5:00 PM or 17:00
d. Press MINtillLCD displays 5:15 PM or 17:15
e. Press TIMERagain and release. LCDdisplays OFF_1.
f.Repeat the above b, c and d till LCDdisplays "MO.TU,WE,TH,FR,SA,SU" 10:30 PMor 22:30
v*.
MANUAL ON/AUTO/MANUAL OFF SETTING
1
Operating modes can't be changed during program settings.
1. Press ON/AUTO/OFF button to revert the three modes in turn.
2. The programs can only be executed inAUTOmode. When AUTOis selected, the timer operates as the programs. In MANUAL ONor MANUAL OFF mode all
programs are ignored and the timerdoesn't operate. When MANUAL ON mode is selected, power output is always ON.When MANUAL OFF mode isselected,
power output is permanently off.
3. When the mode is turned from MANUAL ONto AUTO,the timer will keep the setting of MANUAL ON untilto the next timer setting.
RANDOM FUNCTION
1. Press RANDOM button. LCD displays R(RANDOM).RANDOMfunction is activated.
2. When this function is ON, the settings willbe
executed with a random advance of 10-31 minutes between 6:00 PM and 6:00AM
3. Press the RANDOM button again to cancel this function. Random functioncan't be set during program settings.
4. The RANDOM function can only be executed in AUTO mode between 6:00PM and 6:00AM.
12/24 HOUR MODE
Press CLOCK and TIMER simultaneously to turn the time display
between 12 and 24 hour mode.
SUMMERTIME FUNCTION
1. Press CLOCKand ON/AUTO/OFF simultaneously. LCDshows S(Summertime). Clockadvances 1 hour.
2. To revert to wintersetting, press the twobuttons again. Clock moves backward 1 hour. S disappears inLCD.
IF IN DOUBT CONSULT A QUALIFIED ELECTRICIAN
Masterplug Helpline: 0845 194 7584
Visit our Website: www.masterplug.com
make the right connection
3
