mastro ADK2001 Assembly instructions

042_03
Installation, operating and
maintenance instructions
ELECTRIC TILTING COOKER
04/2006
ADK2001 · ADK2002
ADK2003 · ADK2004
ADK2005 · ADK2006
AEK2001 · AEK2002
AEK2003
AEK2004

042-03 - Electric tilting cooker 2
Models and dimensions page 3
Technical data 5
Installation instructions 6
Installation 6
Legal and technical requisites 6
Installation 6
Wiring 6
Unipotential 6
Connection to waterworks 6
Start-up 6
Using the appliance 7
Ignition 7
Tipping mechanism 7
Special precautions 7
Cleaning and taking care
of the appliance 7
What to do if not using the appliance for
a long time 7
What to do if something goes wrong 7
Maintenance 7
WEEE Directive 8
Wiring diagram 9-12
Warning 13
INDEX

042-03 - Electric tilting cooker 3
900
40
125
140 10 770 30
35
170
800
140 10 770 30
35
170
1200
900
40
125
BEC
A
D
BEC
A
D
F
F
AWater supply
BSwitch
CThermostat
DGreen pilot light
EYellow pilot light
FFlywheel
ADK20003 - AEK20003
ADK20005
ADK20001 - AEK20001
Dimensions

042-03 - Electric tilting cooker 4
900
40
125
140 10 770 30
35
170
800
140 10 770 30
35
170
1200
900
40
125
BEC
A
D
F
G
BEC
A
D
F
G
AWater supply
BSwitch
CThermostat
DGreen pilot light
EYellow pilot light
FUp button
GDown button
ADK20002 - AEK20002
ADK20004 - AEK20004
ADK20006
Dimensions

042-03 - Electric tilting cooker 5
Model
ADK20001 - AEK20001
ADK20002 - AEK20002
ADK20003 - ADK20005 - AEK20003
ADK20004 - ADK20006 - AEK20004
Voltage rating
230 V 3 AC / 400 V 3N AC
230 V 3 AC / 400 V 3N AC
230 V 3 AC / 400 V 3N AC
230 V 3 AC / 400 V 3N AC
Power
14.1 kW
14.6 kW
18.8 kW
19.3 kW
Lead wire / Section
4 x 4 mm2 / 5 x 2.5 mm2
4 x 4 mm2 / 5 x 2.5 mm2
4 x 6 mm2 / 5 x 4 mm2
4 x 6 mm2 / 5 x 4 mm2
ELECTRICAL DATA
2 - CHARACTERISTICS OF THE APPLIANCES
The data plate is located on the rigth hand side of the
control panel and contains all the data needed for connecting
it up to the mains electricity supply.
0051
TIPO/TYPE
CAT/KAT GAS/GAZ G30 G31 G20 G25
II2H3B/P P mbar 30 30 20 -
II2H3+ P mbar 30 37 20
-
-
II2H3+ P mbar 28 37 20 -
25II2L3B/P P mbar 30 30
II2ELL3B/P P mbar 50 50 20 20
II2E+3+ P mbar 28 37 20 25
II2H3B/P P mbar 50 50 20 -
I2E P mbar - - 20 -
--II2H3B/P P mbar 30 30
II2H3+ P mbar 28 37 20 -
--
--
I3B/P P mbar 30 30
I3+ P mbar 28 37
SE FI DK CZ SK SI
IT CH PT
ES IE GB GR
NL
DE
FR BE
AT CH
LU
EE LV LT
EE LV LT
NO MT CY IS HU
CY
MOD.
MOD.
ART.
N.
N.
Qn kW
m3/h
MADE IN ITALY
Predisposto a gas: - Gas preset: - Prevu pour gaz:
Eingestelt für Gas: - Preparado para gas: -
Geschuckt voor:
V AC kW Hz
THE APPLIANCE MUST BE CONNECTED IN COMPLIANCE WITH THE LAWS IN FORCE
AND INSTALLED IN A WELL-VENTILATED ROOM. READ THE INSTRUCTION MANUALS
BEFORE INSTALLING AND USING THE APPLIANCE.
THE APPLIANCE MUST BE INSTALLED BY QUALIFIED PERSONNEL.
3 - TECHNICAL DATA
Model
ADK20001
ADK20002
ADK20003
ADK20005
ADK20004
ADK20006
AEK20001
AEK20002
AEK20003
AEK20004
Descrizione
Electric tilting bratt pan
Electric tilting bratt pan - stainless steel tank
Electric tilting bratt pan - automatic lifting
Electric tilting bratt pan - automatic lifting - stainless steel tank
Electric tilting bratt pan
Electric tilting bratt pan - stainless steel tank
Electric tilting bratt pan - automatic lifting
Electric tilting bratt pan - automatic lifting - stainless steel tank
Electric tilting bratt pan
Electric tilting bratt pan - stainless steel tank
Electric tilting bratt pan - automatic lifting
Electric tilting bratt pan - automatic lifting - stainless steel tank
Electric tilting bratt pan
Electric tilting bratt pan - stainless steel tank
Electric tilting bratt pan - automatic lifting
Electric tilting bratt pan - automatic lifting - stainless steel tank
dimensions
(LxPxH)
800 x 900 x 875
800 x 900 x 875
800 x 900 x 875
800 x 900 x 875
1200 x 900 x 875
1200 x 900 x 875
1200 x 900 x 875
1200 x 900 x 875
800 x 900 x 530
800 x 900 x 530
800 x 900 x530
800 x 900 x 530
1200 x 900 x 530
1200 x 900 x 530
1200 x 900 x 530
1200 x 900 x 530
Tank dimension
(Capacity)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
720 x 620 x 190 (84)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)
1120 x 620 x 190 (126)

Warning!
- Do not use the appliance as a fryer!
- Beware of inexpert handling!
Ignition
Turn on the main switch upstream of the appliance. Turn
the thermostat from ‘0’ to any temperature between 50°C
and 300°C. The pilot lamps will come on.
The green one shows that the appliance is on, while the
yellow one shows that the resistances are on.
As soon as the required temperature is reached, the yel-
low light will go off.
To turn the appliance off, simply turn the knob back to ‘0’.
.
042-03 - Electric tilting cooker 6
Before beginning installation, remove all packaging from
the appliance.
Some parts are protected with an adhesive film which
should be carefully removed.
Any remnants of glue should be thoroughly cleaned using
suitable substances such as benzine.
Under no circumstances should abrasive substances be
used. Fit the legs to the appliance; the appliance must be
levelled using a spirit level. Slight irregularities can be le-
velled by adjusting the feet themselves.
The main switch or plug should be located in the vicinity of
the appliance and easy of access.
We recommend installing the machine under a range
hood so that all the fumes are removed as quickly as pos-
sible. If the appliance is to be installed near walls, dividing
walls, kitchen equipment or decorative pannelling, these
should be in non-inflammable material or covered with
non-inflammable material.
Make sure that all fire prevention standards and safety pre-
cautions are strictly adhered to.
Legal and technical requisites
When installing the appliance, the following safety stan-
dards must be adhered to:
- Local accident prevention standards
- Current CEI standards.
Installation
Installation, start-up and maintenance should only be car-
ried out by expert personnel. All work required to install
the appliance should be carried out in compliance with all
local standards and regulations.
The manufacturers decline all responsibility where poor
performance is due to incorrect installation in disregard of
the above conditions.
Warning!
In compliance with international regulations, when
connecting the appliance to the mains power supply, a
device with a minimum aperture of 3 mm between con-
tacts must be fitted upstream of the appliance, al-
lowing omnipolar disconnection of the appliance from
the mains.
Wiring
When choosing the lead wire, make sure it has the fol-
lowing characteristics: it should be at least of the H07 RN-F
type and its section should be large enough for the ap-
pliance (see "Technical specifications and dimensions",
page 5). Cable entry is underneath the front left-hand
corner.
The terminal board is located behind the left-hand side of
the control panel on the front.
Pass the wire through the core hitch and wire clamp, plug
the leads into their terminals on the board and secure
them.
The earth lead must be a little longer than the others so
that it is the last lead to disconnect if the wire clamp
breaks.
Unipotential
The appliance must be connected up to a unipotential sy-
stem. The connection screw is located underneath the ap-
pliance on the right hand side. It is labelled.
Connection to waterworks
Water inlet pressure must be between 50 and 300 kPa,
otherwise install a pressure regulator on the line before the
appliance.
Install a cut-off valve for each supply on the line before the
appliance.
Make connections according to regulations currently in
force.
Warning!
The manufacturers cannot be held responsible for any
damage due to inadequate or incorrect installation.
Under such circumstances the guarantee will be consi-
dered null and void.
Start-up
Before starting the appliance up, check that it has been
properly installed.
Clean the pan with hot water and detergent, then turn the
thermostat to maximum and allow to dry. (see "Special
precautions", page 7).
INSTALLATION INSTRUCTIONS
USING THE APPLIANCE

042-03 - Electric tilting cooker 7
Tipping mechanism
The tipping mechanism makes emptying the pan simple.
Manual:
To work the tipping mechanism, use the hand-wheel loca-
ted on the front of the appliance on the right-hand side.
To raise the pan, turn the hand-wheel anticlockwise; to
lower it, turn the hand-wheel clockwise.
Motor driven:
This mechanism is activated by means of two push but-
tons:
- upper (red) for tilting (up), lower (black) for return (down).
Special precautions
The grills, particularly those with the pan bottom not in
stainless steel, are treated in the factory with mineral oil to
protect them from rust.
The oil should be carefully removed before heating the
pan, using hot water and detergent, not chlorine based
(less than 30 ppm) . After washing, rinse with cold water
and heat to 300°C to dry, with the thermostat at the maxi-
mum . When the thermostat shuts down, the oven is ready
for cooking or, after protecting the bottom with a layer of
grease or cooking oil, ready to rest (after use). After every
use, especially when the pan is not in stainless steel, to
keep it in perfect condition and protect it from rust, repeat
the above operation of washing, drying and protecting
with grease or cooking oil.
If any rust should form on the bottom of the pan due to wa-
ter or moisture and lack of adequate protection after use, it
will continue to expand until it corrodes the pan. If this
should occur, the rust must be removed until the corroded
part is polished, using a pad of steel wool, for example, in
stainless steel and then washing, drying and protecting
as described above.
NOTE: Greasing or oiling the pan while still damp is
not only useless but absolutely dangerous as the rust
will continue to expand under the layer of grease.
Never use unmilled sea-salt with this appliance. It nevery
fully dissolves but forms a layer of deposit on the bottom
of the pan which can cause rust to form. Dissolve the salt
in water separately before using.
CLEANING AND TAKING CARE OF THE
MACHINE
Warning!
Never clean the appliance with jets of water, whether
direct or pressurised.
Allow the appliance to cool before cleaning.
Before starting to clean the appliance, disconnect from
the mains.
All steel parts should be washed in warm water, using a
neutral detergent. The pan must be thoroughly cleaned
with warm water and detergent, then well rinsed out and
dried with a soft cloth to get rid of all traces of detergent.
Thoroughly dry the appliance. Avoid using abrasive or
corrosive detergents which could damage the steel.
If stainless steel wool must be used, rub with and not
against the satin finish.
Never use ferrous materials which could cause rust to
form.
After cleaning, we recommend you grease the pan with
vegetable oil.
What to do if not using the appliance
for a long time
Thoroughly clean and dry the machine as described.
Disconnect the power supply. Grease the pan with vege-
table oil.
What to do if something goes wrong
If anything goes wrong, immediately turn the appliance
off, then turn off the power supply at the switch located
upstream of the appliance, and call the aftersales depart-
ment.
MAINTENANCE
All maintenance should be carried out by qualified per-
sonnel only. Before carrying out any maintenance work,
unplug the appliance or turn off the switch upstream of the
appliance.
Warning!
The tilting bratt pan has not to be used as a fryer. An
incorrect use can cause a fire into the oil tank.
WARNING:
• The first time you use the pan, wash it with soap and
water.
• Never use synthetic cloth to clean, only cotton, wool
or linen
• Never fill the bottom of the pan with grease
• Do not fill the pan with oil; it cannot be used for frying
because of the fire hazard represented by the oil ..

042-03 - Electric tilting cooker 8
THE 2002/96/EC DIRECTIVE (WEEE):
information to users
This informational note is meant only for owners
of equipment marked with the symbol shown in
Fig. A on the adhesive label featuring the tech-
nical specifications applied on the actual pro-
duct (the label also giving the serial number).
This symbol indicates that the product is classified, ac-
cording to the regulations in force, as an item of electrical
and electronic equipment and conforms to EU Directive
2002/96/EC (WEEE) meaning that, at the end of its service
life, it must be treated separately from domestic waste,
i.e. it must be handed in free of charge to a separate wa-
ste electrical and electronic equipment collection centre
or returned to the reseller when buying a new equivalent
item of equipment.
The user is responsible for delivering the unit at the end of
its life to the appropriate collection facilities. Failure to do
so shall result in the user being subject to the penalties
prescribed by the legislation in force on waste.
Suitable separated collection so that the unit no longer
used can be sent off for environmentally compatible recy-
cling, treatment and disposal helps avoid possible negati-
ve effects on the environment and on health and facilita-
tes the recycling of the product's component materials.
For more detailed information on available collection sy-
stems, contact the local waste disposal service or the
shop you purchased the unit from.
Producers and importers fulfil their responsibility for envi-
ronmentally compatible recycling, treatment and disposal
both directly and by joining a collective scheme.

S1
1
P1 P2
2
H1
H2
M1
F1
F2
C2
C1
R1 R1 R1
R1 R1 R1
L1 L2 L3
L1 L2 L3
T
mA
230 V 3 AC
ADK20001 - AEK20001
400 V 3N AC
21 22 23
11 12 13
A1
A2
21 22 23
11 12 13
A1
A2
L1 L2 L3 N T
2
1
21
11
21
11
mA
042-03 - Electric tilting cooker 9
mA Line input terminal board
S1 Switch
C1 Contactor
C2 Safety contactor
F1 Thermostat
F2 Safety thermostat
M1 Micro switch
H1 Green pilot light
H2 Yellow pilot light
R1 Resistances 4,7 Kw
Wiring diagrams

S1
1
P1 P2
2
H1
H2
M1
F1
F2
C2
C1
R1 R1 R1
ADK20003 - AEK20003
ADK20005
400 V 3N AC
21 22 23
11 12 13
A1
A2
21 22 23
11 12 13
A1
A2
L1 L2 L3 N T
2
1
21
11
21
11
mA
R1
R1 R1 R1
L1 L2 L3
L1 L2 L3
T
mA
230 V 3 AC
R1
042-03 - Electric tilting cooker 10
mA Line input terminal board
S1 Switch
C1 Contactor
C2 Safety contactor
F1 Thermostat
F2 Safety thermostat
M1 Micro switch
H1 Green pilot light
H2 Yellow pilot light
R1 Resistances 4,7 Kw
Wiring diagrams

S1
1
P1 P2
2
H1
H2
F2
C2
C1
R1 R1 R1
ADK20002 - AEK20002
400 V 3N AC
21 22 23
11 12 13
A1
A2
21 22 23
11 12 13
A1
A2
L1 L2 L3 N T
21
11
mA
R1 R1 R1
L1 L2 L3
L1 L2 L3
T
mA
230 V 3 AC
4 3
1 2
4 3
1 2
21
11
F1
Pu1 Pu2
M1
NO
M2
NC NC
NO
W2 U4 V2
U1 V1 W1
M
042-03 - Electric tilting cooker 11
mA Line input terminal board
S1 Switch
C1 Contactor
C2 Safety contactor
F1 Thermostat
F2 Safety thermostat
H1 Green pilot light
H2 Yellow pilot light
R1 Resistances 4,7 Kw
M1 Up micro
M2 Down micro/safety
Pu1 Up button
Pu2 Up button
MElectric motor
Wiring diagrams

S1
1
P1 P2
2
H1
H2
F2
C2
C1
R1 R1 R1
ADK20004 - AEK20004
ADK20006
400 V 3N AC
21 22 23
11 12 13
A1
A2
21 22 23
11 12 13
A1
A2
L1 L2 L3 N T
21
11
mA
4 3
1 2
4 3
1 2
21
11
F1
Pu1 Pu2
M1
NO
M2
NC NC
NO
W2 U4 V2
U1 V1 W1
M
R1
R1 R1 R1
L1 L2 L3
L1 L2 L3
T
mA
230 V 3 AC
R1
042-03 - Electric tilting cooker 12
mA Line input terminal board
S1 Switch
C1 Contactor
C2 Safety contactor
F1 Thermostat
F2 Safety thermostat
H1 Green pilot light
H2 Yellow pilot light
R1 Resistances 4,7 Kw
M1 Up micro
M2 Down micro/safety
Pu1 Up button
Pu2 Up button
MElectric motor
Wiring diagrams

042-03 - Electric tilting cooker 13
WARNING
THE MANUFACTURER CANNOT BE HELD RESPONSIBLE
FOR ANY INACCURACIES IN THIS BOOKLET DUE TO
COPYING OR PRINTING ERRORS.
DUE TO ITS POLICY OF CONTINUAL PRODUCT IMPRO-
VEMENT, THE MANUFACTURER RESERVES THE RIGHT
TO MAKE ANY CHANGES DEEMED NECESSARY.
THE MANUFACTURER CANNOT BE HELD RESPONSI-
BLE IF THE INSTRUCTIONS CONTAINED IN THIS MA-
NUAL ARE NOT OBSERVED.
