MAT Industries PWZC164000 User manual

PRESSURE WASHER
OPERATION MANUAL
for model PWZC164000
Record All Information and attach sales receipt here for
future reference:
Purchase Date:__________________________
Serial #: ________________________________
Questions? 1-888-895-4549
Learn more about your pressure washer,
get answers to frequently asked questions,
and register on line at
www.powermate.com
IMPORTANT: Please make certain that the person who is to use this equipment carefully reads and understands these instruc-
tions before operating.
200-2839 // Rev. b6/23/2011 PRINTED IN U.S.A.
TABLE OF CONTENTS
Safety Guidelines/Definitions......................................................2
Consumer Safety Information.....................................................2
Important Safety Instructions.................................................. 2-5
Specifications .............................................................................5
Carton Contents .........................................................................5
Assembly Instructions.................................................................6
Operating Instructions .......................................................... 7-10
Maintenance.............................................................................11
Storage.....................................................................................11
Repairs.....................................................................................12
Troubleshooting Guide .............................................................12
Warranty...................................................................................13
Parts List & Exploded View ................................................14-17
Français.............................................................................. 18-30
Español............................................................................... 31-43

2 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
SAFETY GUIDELINES - DEFINITONS
• SAVE ALL INSTRUCTIONS
This manual contains information that is important for you to know and understand. This information relates to protecting YOUR SAFETY and
PREVENTING EQUIPMENT PROBLEMS. To help you recognize this information, we use the symbols below. Please read the manual and pay
attention to these symbols.
DANGER
Indicates an imminently hazardous situation which, if not avoided ,
WILL result in DEATH OR SERIOUS INJURY.
CAUTION
Indicates a potentially hazardous situation which, if not avoided, MAY
result in MINOR OR MODERATE INJURY.
WARNING
Indicates a potentially hazardous situation which, if not avoided,
COULD result in DEATH OR SERIOUS INJURY.
CAUTION
Used without the safety alert symbol indicates a potentially hazardous
situation which, if not avoided, MAY result in PROPERTY DAMAGE.
CONSUMER SAFETY INFORMATION
• SAVE ALL INSTRUCTIONS
WARNING This product may not be equipped with a spark arresting muffler. If the product is not equipped and will be used around
flammable materials, or on land covered with materials such as agricultural crops, forest, brush, grass, or other similar items, then an approved
spark arrester must be installed and is legally required by the state of California. It is a violation of California statutes section 130050 and/or
sections 4442 and 4443 of California Public Resources Code, unless the engine is equipped with a spark arrester, as defined in section 4442,
and maintained in effective working order. Spark arresters are also required on some U.S. Forest Service land and may also be legally required
under other statutes and ordinances.
WARNING CALIFORNIA PROPOSITION 65 WARNING
This product contains chemicals known to the State of California to cause cancer, birth defects and/or reproductive harm.
IMPORTANT SAFETY INFORMATION
• SAVE ALL INSTRUCTIONS
WARNING Do not operate this unit until you have read and understand this Operators Manual and the Engine Owners Manual for
Safety, Operation, and Maintenance Instructions.
READ AND SAVE THESE INSTRUCTIONS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Spilled gasoline and it’s vapors can become ignited from cigarette sparks,
electrical arcing, exhaust gases and hot engine components such as the
muffler.
• Shut off engine and allow it to cool before adding fuel to the tank.
• Use care in filling tank to avoid spilling fuel. Move pressure washer away from
fueling area before starting engine.
• Heat will expand fuel in the tank, which could result in spillage and possible
fire explosion. • Fill tank to ½˝(12.7 mm) below bottom of filler neck to provide space for fuel expansion.
• Operating the pressure washer in an explosive environment could result in
a fire. • Operate and fuel equipment in well-ventilated areas free from obstructions. Equip areas with fire extinguisher suitable for gasoline fires.
• Materials placed against or near the pressure washer can interfere with its
proper ventilation features causing overheating and possible ignition of the
materials.
• Never operate pressure washer in an area containing dry brush or weeds.
• Muffler exhaust heat can damage painted surfaces, melt any material sensi-
tive to heat (such as siding, plastic, rubber, vinyl, or the pressure hose, itself),
and damage live plants.
• Always keep pressure washer a minimum of 4´ (1.2m) away from surfaces
(such as houses, automobiles or live plants) that could be damaged form muffler
exhaust heat.
DANGER RISK OF EXPLOSION FOR FIRE

3 - ENG Copyright © 2011 MAT Industries, LLC200-2839
IMPORTANT SAFETY INFORMATION (CONT.)
• SAVE ALL INSTRUCTIONS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Improperly stored fuel could lead to accidental ignition. Fuel improperly
secured could get into the hands of children or other unqualified persons. • Store fuel in an OSHA-approved container, in a secure location away from work area.
• Use of acids, toxic or corrosive chemicals, poisons, insecticides, or any kind
of flammable solvent with this product could result in serious injury or death. • Do not spray flammable liquids.
DANGER RISK OF EXPLOSION FOR FIRE (CONT.)
WHAT CAN HAPPEN HOW TO PREVENT IT
• Breathing exhaust fumes will cause serious injury or death! Engine exhaust
contains carbon monoxide, an odorless and deadly gas. • Operate pressure washer in a well-ventilated area. Avoid enclosed areas such as garages, basements, etc.
• Never operate unit in a location occupied by humans or animals.
• Some cleaning fluids contain substances which could cause injury to skin,
eyes or lungs. • Use only cleaning fluids specifically recommended for high-pressure wash- ers. Follow manufacturers recommendations. Do not use chlorine bleach or any
other corrosive compound.
DANGER RISK TO BREATHING (ASPHYXIATION)
WHAT CAN HAPPEN HOW TO PREVENT IT
• Your pressure washer operates at fluid pressures and velocities high enough
to penetrate human and animal flesh, which could result in amputation or
other serious injury. Leaks caused by loose fittings or worn or damaged hoses
can result in injection injuries. DO NOT TREAT FLUID INJECTION AS A
SIMPLE CUT! See a physician immediately!
• Inspect the high-pressure hose regularly. Replace the hose regularly. Replace
the hose immediately if it is damaged, worn, has melted from contacting the
engine, or shows any signs of cracking, bubbles, pinholes, or other leakage.
Never grasp a high-pressure hose that is leaking or damaged.
• Never touch, grasp or attempt to cover a pinhole or similar water leak on the
high-pressure hose. The stream of water IS under high pressure and WILL
penetrate skin.
• Never place hands in front of nozzle.
• Direct spray away from self and others.
• Make sure hose and fittings are tightened and in good condition. Never hold onto the
hose or fittings during operation.
• Do not allow hose to contact muffler.
• Never attach or remove wand or hose fittings while system is pressurized.
• Injuries can result if system pressure is not reduced before attempting main-
tenance or disassembly. • To relieve system pressure, shut off engine, turn off water supply and pull gun trigger until water stops flowing.
•Use only hoses and accessories rated for pressure higher than your pressure
washer’s PSI.
DANGER RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
• High-velocity fluid spray can cause objects to break, propelling particles at
high speed.
• Light or unsecured objects can become hazardous projectiles.
• Always wear ANSI-approved z87.1 safety glasses. Wear protective clothing to
protect against accidental spraying.
• Never point wand at or spray people or animals.
• Always secure trigger lock when wand is not in service to prevent accidental
operation.
• Never permanently secure trigger in pull-back (open) position.
DANGER RISK OF INJURY FROM SPRAY

4 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
IMPORTANT SAFETY INFORMATION (CONT.)
• SAVE ALL INSTRUCTIONS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Unsafe operation of your pressure washer could lead to serious injury or
death to you or others. • Do not use chlorine bleach or any other corrosive compound. • Become familiar with the operation and controls of the pressure washer.
• Keep operating area clear of all persons, pets and obstacles.
• Do not operate the product when fatigued or under the influence of alcohol or
drugs. Stay alert at all times.
• Never defect the safety features of this product.
• Do not operate machine with missing, broken or unauthorized parts.
• Never leave wand unattached while unit is running.
• If proper starting procedure is not followed, engine can kickback causing
serious hand and arm injury. • If engine does not start after two pulls, squeeze trigger of gun to relieve pump pressure. Pull starter cord slowly until resistance is felt. Then pull cord rapidly to
avoid kickback and prevent hand or arm injury.
• The spray gun/wand is a powerful cleaning tool that could look like a toy to
a child. • Keep children away from the pressure washer at all times.
• Reactive force of spray will cause gun/wand to kickback, and could cause
the operator to slip or fall or misdirect the spray. Improper control of gun/wand
can result in injuries to self and others.
• Do not overreach or stand on an unstable support.
• Do not use pressure washer while standing on a ladder.
• Grip gun/wand firmly with both hands. Expect the gun to kickback when trig-
gered.
DANGER RISK OF FLUID INJECTION AND LACERATION
WHAT CAN HAPPEN HOW TO PREVENT IT
• Fuel or oil leak or spill could result in fire or breathing hazard. Serious injury
or death can result. Fuel or oil leaks will damage carpet, paint or other sur-
faces in vehicles or trailers.
• If pressure washer is equipped with a fuel shut-off valve, turn the valve to
OFF position before transporting to avoid fuel leaks. If pressure washer is not
equipped with a fuel shut-off valve, drain the fuel from tank before transporting.
Only transport fuel in an OSHA- approved container. Always place pressure
washer on a protective mat when transporting to protect against damage to
vehicle from leaks. Remove pressure washer from vehicle immediately upon
arrival at your destination.
RISK OF INJURY OR PROPERTY DAMAGE WHEN TRANSPORTING
OR STORING
DANGER
WHAT CAN HAPPEN HOW TO PREVENT IT
• Contact with hot surfaces, such as engines exhaust components, could
result in serious burn. • During operation, touch only the control surfaces of the pressure washer. Keep children away from the pressure washer at all times. They may not be able to
recognize the hazards of this product.
WARNING RISK OF HOT SURFACES
WHAT CAN HAPPEN HOW TO PREVENT IT
• Use of acids, toxic or corrosive chemical, poisons, insecticides, or any kind
of flammable solvent with this product could result in serious injury or death. •Do not use acids, gasoline, kerosene, or any other flammable materials in this product. Use only household detergents, cleaners and degreasers recommend-
ed for use in pressure washers.
• Wear protective clothing to protect eyes and skin from contact with spraying
materials.
WARNING RISK OF CHEMICAL BURN

5 - ENG Copyright © 2011 MAT Industries, LLC200-2839
IMPORTANT SAFETY INFORMATION (CONT.)
• SAVE ALL INSTRUCTIONS
WHAT CAN HAPPEN HOW TO PREVENT IT
• Spray directed at electrical outlets or switches, or objects connected to an
electrical circuit, could result in a fatal electric shock. • Unplug any electrically operated product before attempting to clean it. Direct spray away from electric outlets and switches.
WARNING RISK OF ELECTRICAL SHOCK
WHAT CAN HAPPEN HOW TO PREVENT IT
• Serious injury can result from attempting to lift too heavy an object. •The pressure washer is too heavy to be lifted by one person. Obtain assis-
tance from others before lifting.
WARNING RISK OF INJURY FROM LIFTING
SPECIFICATIONS
• SAVE ALL INSTRUCTIONS
MODEL..................................................................PWZC164000
OPERATING PSI..................................................................4000
OPERATING GPM..................................................................4.0
PUMP OIL CAPACITY.......................................................11 oz.
PUMP OIL TYPE....................................Commercial tractor fluid
CARTON CONTENTS
• SAVE ALL INSTRUCTIONS

6 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
ASSEMBLY INSTRUCTIONS
• SAVE ALL INSTRUCTIONS
1. Locate and remove all loose parts from the carton. (Fig. 1)
2. Cut four corners of the carton from top and bottom and lay the panels flat. (Fig. 2)
3. Rotate the handle (A) up away from the pressure washer until it stops, pull out the
pin (B) and rotate the handle until it stops. Let go of the pin and move the handle
slightly to lock in place.
4. Roll the unit off the carton and discard carton.
5. Attach the nozzle panel (C) to the handle (A) with the 2 screws (D) provided as
shown in Fig. 3. Insert the 5 nozzle tips into the grommets on the panel.
6. Connect high-pressure hose to pump outlet (E). Tighten securely. (Fig. 3)
7. Connect wand to gun. Tighten securely. (Fig. 4)
8. Attach high-pressure hose to gun. Tighten securely. (Fig. 5)
NOTE: The pump on this unit is shipped with oil and a plug in the head that needs
to be switched with the dipstick before operating the pressure washer for the first time.
9. Remove the plug (F) from the pump head and replace it with the dipstick supplied
with the pump. To check and change oil, refer to the “Maintenance” section of this
manual.
FIG. 5
FIG. 2FIG. 1
C
B
E
A
D
F
FIG. 3
FIG. 4

7 - ENG Copyright © 2011 MAT Industries, LLC200-2839
OPERATING INSTRUCTIONS
• SAVE ALL INSTRUCTIONS
Compare the illustrations with your unit to familiarize yourself with the location of various controls and adjustments. Save this manual for future
reference.
BASIC ELEMENTS OF A
PRESSURE WASHER
High Pressure Pump: Increases the pressure of the water supply.
Engine: Drives the high-pressure pump.
High Pressure Hose: Carries the pressurized water from the pump to
the gun and spray wand.
Spray Gun: Connects with spray wand to control water flow rate, direc-
tion, and pressure.
Chemical Hose: Feeds cleaning agents into the pump to mix with the
water. See How To Apply Chemicals/Cleaning Solvents instructions in
this section.
Quick Connect Nozzles: Allow the user to quickly and easily change
the degree of spray to fit the job at hand.
BASIC ELEMENTS OF AN ENGINE
Refer to the engine manual for location and operation of engine con-
trols.
Choke Control: Opens and closes carburetor choke valve.
Starter Grip: Pulling starter grip operates recoil starter to crank engine.
Engine Switch: Enables and disables ignition system
Quick Connect Nozzles stored in
this panel
High-Pressure
Hose
Chemical
Hose
Engine
Spray Gun
PRESSURE WASHER TERMINOLOGY
PSI: Pounds per Square Inch. The unit of measure for water pressure.Also used for air pressure, hydraulic pressure, etc.
GPM: Gallons Per Minute. The unit of measure for the flow rate of water.
CU: Cleaning Units. GPM multiplied by PSI. GPM x PSI = CU
Bypass Mode: Allows water to re-circulate within the pump when the gun trigger is not pulled.
CAUTION Allowing the unit to run for more than two minutes without the gun trigger pulled could cause overheating and damage to the
pump.
Chemical Injection System: Mixes cleaners or cleaning solvents with the water to improve cleaning effectiveness.
Water Supply: All pressure washers must have a source of water. The minimum requirements for a water supply are 20 PSI and 5 gallons per
minute.
High
pressure
Pump

8 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
OPERATING INSTRUCTIONS (CONT.)
• SAVE ALL INSTRUCTIONS
PRESSURE WASHER OPERATING FEATURES PRESSURE
ADJUSTMENTS
The pressure setting is preset at the factory to achieve optimum pressure and cleaning. If you need a lower pressure, it can be accomplished by
these methods.
1. Back away from the surface to be cleaned. The further away you are, the less the pressure will be on the surface to be cleaned.
2. Change to the 40° nozzle – this nozzle delivers a less powerful stream of water and a wider spray pattern.
CAUTION DO NOT attempt to increase pump pressure.A higher pressure setting than the factory set pressure may damage pump.
TO USE SPRAY WAND
The nozzles for the spray wand are stored on the top storage panel.
See chart to choose the correct nozzle for the job to be performed.
CHANGING NOZZLES ON SPRAY WAND
DANGER RISK OF FLUID INJECTION. Do NOT
direct discharge stream toward persons, unprotected skin, eyes or any
pets or animals. Serious injury will occur.
WARNING RISK OF FLUID INJECTION. Do NOT
attempt to change nozzles while pressure washer is running. Turn
engine off before changing nozzles.
1. Pull back the quick connect collar on the spray wand and hold it in
place.
2.
Insert the desired quick connect nozzle and hold in place.
3. Slide the quick connect collar forward until it locks into place.
4. Check that the quick connect nozzle is securely locked into the
spray wand.
0° 15° 25° 40° Soap
Spray
Pattern
Uses Powerful
pinpoint for
very intensive
cleaning
Intense clean-
ing of small
areas
Intense clean-
ing of medium
areas
Intense cleaning
of larger areas Applies clean- ing solutions
Surfaces* Metal or con-
crete
DO NOT use
on wood
Metal, concrete,
or wood Metal, concrete, or wood Metal, concrete, or wood Metal, concrete, or vinyl
* CAUTION The high pressure spray from your pressure washer is capable of causing damage
to surfaces such as wood, glass, automotive paint, auto striping and trim, and delicate objects such as
flowers and shrubs. Before spraying, check the item to be cleaned to assure yourself that it is strong
enough to resist damage from the force of the spray.
FIG. 6

9 - ENG Copyright © 2011 MAT Industries, LLC200-2839
HOW TO APPLY CHEMICALS
AND CLEANING SOLVENTS
Applying chemicals or cleaning solvents is a low pressure operation.
NOTE: Use only soaps and chemicals designed for pressure washer
use. DO NOT USE BLEACH.
To Apply Chemicals:
1. Make sure the chemical hose is pressed onto the barbed fitting (G)
located near high-pressure hose (E). (Fig. 7)
2. The other end of the chemical hose should be inserted into a
chemical container containing the appropriate pressure washer
cleaning solution.
NOTE: For approximately every 7 gallons of water pumped 1 gallon of
chemical/cleaning solution will be used.
3. Insert soap nozzle (per previous chart) into spray wand, see Use
Spray Wand paragraph in this section.
NOTE: Chemicals and soaps will not siphon when using any quick
connect nozzle other than the black soap nozzle.
OPERATING INSTRUCTIONS (CONT.)
• SAVE ALL INSTRUCTIONS
WARNING To reduce the risk of injury, read the pressure washer instruction manual and the engine instruction manual
before starting pressure washer.
DANGER RISK OF FLUID INJECTION AND LACERATION. When using the high-pressure setting, DO NOT allow the high-pres-
sure spray to come in contact with unprotected skin, eyes, or with any pets or animals. Serious injury will occur.
• Your washer operates at fluid pressures and velocities high enough to penetrate human and animal flesh, which could result in amputa-
tion or other serious injury. Leaks caused by loose fittings or worn or damaged hoses can result in injection injuries. DO NOT TREAT FLUID
INJECTION AS ASIMPLE CUT! See a physician immediately!
WARNING RISK OF FIRE, ASPHYXIATION AND BURN. NEVER fill fuel tank when engine is running or hot. Do not smoke
when filling fuel tank.
• NEVER fill fuel tank completely. Fill tank to 1/2” below bottom of filler neck to provide space for fuel expansion. Wipe any fuel spillage from
engine and equipment before starting engine.
• NEVER run engine in doors or in enclosed, poorly ventilated areas. Engine exhaust contains carbon monoxide, an odorless and deadly
gas.
• DO NOT let hoses come in contact with very hot engine muffler during or immediately after use of your pressure washer. Damage to hoses
from contact with hot engine surfaces will NOT be covered by warranty.
CAUTION RISK OF PROPERTY DAMAGE. NEVER pull water supply hose to move pressure washer. This could damage hose and/
or pump inlet.
• DO NOT use hot water, use cold water only.
• NEVER turn water supply off while pressure washer engine is running or damage to
pump will result.
• DO NOT stop spraying water for more than two minutes at a time. Pump operates in bypass mode when spray gun trigger is not pressed. If
pump is left in bypass mode for more than two minutes internal components of the pump can be damaged.
If you do not understand these precautions, please call 1-888-895-4549 to speak to a service representative for further instructions
Fig. 7
EG

10 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
STARTING
Prior to starting, refer to your engine manual for proper starting
procedure.
1. In a well ventilated outdoor area add fresh, high quality, unleaded
gasoline with a pump octane rating of 86 or higher. Do not overfill.
Wipe up spilled fuel before starting the engine. Refer to Engine
Owners Manual for correct procedure.
2. Check engine oil level. See Engine Owners Manual for correct
procedure.
3 Check pump oil level. See “Maintenance” section in this
manual.
4. Connect the water hose to the water
source. Turn the water source on to remove
all air from the hose. When a steady stream
of water is present, turn the water source off.
5. Verify the filter screen (H) is in water
inlet of pump. (Fig. 8)
NOTE: Cone side faces out.
6. Connect water source to pump inlet (G). NOTE: Water source must
provide a minimum of 5 gallons per minute at 20 PSI. (Fig. 9)
WARNING To reduce the possibility of contamination
always protect against back flow when connected to a portable
water system.
7. Connect high pressure hose to pump outlet (E).
8. If applying a chemical or cleaning solution, see How To Apply
Chemicals/Cleaning Solvents instructions in this section.
EG
FIG. 9
FIG. 8
H
OPERATING INSTRUCTIONS (CONT.)
• SAVE ALL INSTRUCTIONS
9. Insert the quick connect nozzle for the task being performed.
See How To Use Wand instructions in this section.
10. Turn water source on.
CAUTION RISK OF PROPERTY DAMAGE. Failure to do so
could cause damage to the pump.
11. Remove all air from the pump and high pressure hose by
depressing trigger until a steady stream of water is present.
12. Start engine. See Engine Owners Manual for correct procedure.
WARNING RISK OF UNSAFE OPERATION. If engine
does not start after two pulls, squeeze trigger of gun to relieve
pump pressure. Pull starter cord slowly until resistance is felt.
Then pull cord rapidly to avoid kickback and prevent hand or arm
injury.
13. Depress trigger on gun to start water flow.
WARNING RISK OF UNSAFE OPERATION. Stand on a
stable surface and grip gun/spray wand firmly with both hands.
Expect the gun to kick when triggered.
14. Release trigger to stop water
flow.
DANGER RISK OF
INJURY FROM SPRAY. Always
engage the trigger lock when gun
is not in use. Failure to do so could
cause accidental spraying.
SHUTTING DOWN
1. After each use, if you have applied chemicals, draw clean water
through chemical injection system to rinse system thoroughly.
CAUTION RISK OF PROPERTY DAMAGE. Failure to do so
could cause damage to the pump.
2. Turn engine off. See Engine Owner’s Manual.
CAUTION RISK OF PROPERTY DAMAGE. NEVER turn the
water off with the engine running.
3. Turn water source off.
4. Pull trigger on spray gun to relieve any water pressure in hose or
spray gun.
5. See Storage section in this manual for proper storage procedures.
Trigger Lock Engaged
FIG. 10

11 - ENG Copyright © 2011 MAT Industries, LLC200-2839
MAINTENANCE
• SAVE ALL INSTRUCTIONS
2. Clean filter by flushing it with water on
both sides.
3. Re-insert filter into water inlet of pump.
NOTE: Cone side faces out.
NOTE:
Do not operate pressure washer without
filter properly installed.
WARNING RISK OF BURN HAZARD. When perform-
ing maintenance, you may be exposed to hot surfaces, water
pressure or moving parts that can cause serious injury or death.
WARNING RISK OF FIRE HAZARD. Always discon-
nect, spark plug wire, let the engine cool and release all water
pressure before performing any maintenance or repair. The
engine contains flammable fuel. Do not smoke or work near open
flames while performing maintenance.
To ensure efficient operation and longer life of your pressure washer, a
routine maintenance schedule should be prepared and followed. If the
pressure washer is used in unusual conditions, such as high-temper-
atures or dusty conditions, more frequent maintenance checks will be
required.
ENGINE
Consult the Engine Owners Manual for the manufacturer’s recommen-
dations for any and all maintenance.
PUMP
The pump on this unit requires oil. The recommended oil
type to use is Commercial Tractor Fluid (Tractor Hydrau-
lic Fluid). Pump oil capacity is 11 oz.
To check the oil, remove the dipstick located on top of
the pump. The oil level should be between the max and
min lines. Make sure the oil does not go below the min
line.
To add oil, remove the dipstick and add oil unitl it is be-
tween the max and min line. Replace dipstick.
If there is a problem with the pump, contact an Autho-
rized Service Center.
NOZZLE CLEANING
If the nozzle becomes clogged with foreign materials, such as dirt, ex-
cessive pressure may develop. If the nozzle becomes partially clogged
or restricted, the pump pressure will pulsate. Clean the nozzle immedi-
ately using the nozzle kit supplied and the following instructions:
1.
Shut off the pressure washer and turn off the water supply.
2. Pull trigger on gun handle to relieve any water pressure.
3. Remove quick connect nozzle from the spray wand.
4. Remove any obstructions from the quick connect nozzle with the
nozzle cleaning tool provided and flush with clean water.
5. Re-attach the quick connect nozzle to the spray wand and turn on
the water supply.
6. Start pressure washer and test.
HOW TO CLEAN THE WATER
INLET FILTER
This screen filter should be checked periodically and cleaned if neces-
sary.
1. Remove filter by grasping end and removing it from water inlet of
pump as shown. (Fig. 11)
FIG. 11
H
STORAGE
• SAVE ALL INSTRUCTIONS
ENGINE
Consult the Engine Owners Manual for the manufacturer’s
recommendations for storage.
PUMP
The manufacturer recommends using a pump protector/winterizer
when storing the unit for more than 30 days and/or when freezing tem-
peratures are expected. If a pump protector/winterizer is not available,
RV antifreeze or windshield washer fluid needs to be run through the
pump as outlined in the steps below.
NOTE: Using a pump protector/ winterizer, RV antifreeze or windshield
washer fluid is to provide proper lubrication to the internal seals of the
pump regardless of temperature or environment.
1. Obtain a funnel, 6 oz. of RV antifreeze or windshield washer fluid,
and 16–36” of garden hose with a male hose connector attached to
one end.
CAUTION RISK OF PROPERTY DAMAGE. Use only
RV antifreeze. Any other antifreeze is corrosive and can damage
pump.
2. Disconnect spark plug wire.
3.
Connect length of garden hose to water inlet of pump.
4. Add RV antifreeze or windshield washer fluid to hose
as shown. (Fig. 12)
5. Pull engine starter rope slowly several times until antifreeze/
washer fluid comes out of high-pressure hose connection of pump.
6. Remove garden hose from water inlet of pump.
7. Reconnect spark plug wire.
FIG. 12

12 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
TROUBLESHOOTING GUIDE
• SAVE ALL INSTRUCTIONS
Problem Cause Correction
Engine will not start (see Engine
Manual for further engine trouble-
shooting)
1. No fuel
2. Pressure builds up after two pulls on the recoil starter
or after initial use.
3. Choke lever in the “No Choke” position.
4. Spark plug wire not attached.
5. Engine ON/OFF switch in OFF position.
6. Choke lever in the “Choke” position on a “hot” engine
or an engine that has been exposed to thermal heat for
a long period of time.
1. Add fuel.
2. Squeeze gun trigger to relieve pressure.
3. Move choke to the “Choke” position.
4. Attach spark plug wire.
5. Place engine ON/OFF switch in ON position.
6. Move choke to the “No Choke” position.
No or low pressure (initial use) 1. High pressure nozzle is not installed.
2. Low water supply.
3. Leak at high pressure hose fitting.
4. Nozzle obstructed.
5. Water filter screen clogged.
6. Air in hose.
7. Choke lever in the “Choke” position.
8. High pressure hose is too long.
1. See How to Use Spray Wand instructions in the Operation
Section.
2. Water supply must be at least 5 GPM @ 20 PSI.
3. Repair leak. Apply sealant tape if necessary.
4. See Nozzle Cleaning instructions in the Maintenance sec-
tion.
5. Remove and clean filter.
6. Turn off the engine, then the water source. Disconnect
the water source from the pump inlet and turn the water
source on to remove all air from hose. When there is a
steady stream of water present, turn water source off. Re-
connect water source to pump inlet and turn on water source.
Squeeze trigger to remove remaining water.
7. Move choke to the “No Choke” position.
8. Use high pressure hose under 100 feet.
Will not draw chemicals 1. Low pressure soap nozzle not installed.
2. Chemical filter clogged.
3. Chemical screen not in cleaning solution.
4. Chemical too thick.
5. Pressure hose too long.
6. Chemical build up in chemical injector.
1. See How to Use Spray Wand paragraph in the Operation
Section.
2. Clean filter.
3. Make sure end of chemical hose is fully submerged into
cleaning solution.
4. Dilute chemical. Chemical should be in the same consis-
tency as water.
5. Lengthen water supply hose instead of high pressure
hose.
6. Have parts cleaned or replaced by AWSC.
No or low pressure (after period of
normal use) 1. Worn seal or packing. 2. Worn or obstructed valves.
3. Worn unloader piston.
1. Have replaced by AWSC.
2. Have replaced by AWSC.
3. Have replaced by AWSC.
Water leaking at gun/spray wand
connection 1. Worn or broken O-ring. 2. Loose hose connection. 1. Check and replace. 2. Tighten.
Water leaking at pump 1. Loose connections.
2. Piston packing worn.
3. Worn or broken O-rings.
4.
Pump head or tubes damaged from freezing.
1. Tighten.
2. Have replaced by AWSC.
3. Have replaced by AWSC.
4. Have replaced by AWSC.
Pump Pulsates 1. Nozzle obstructed. 1. See Nozzle Cleaning paragraph in the Maintenance sec-
tion for the correct procedure.
AWSC= Authorized Warranty Service Center
REPAIRS
• SAVE ALL INSTRUCTIONS
To assure product SAFETY and RELIABILITY, repairs, maintenance and adjustment should be performed by an Authorized Warranty Service
Center. Always use identical replacement parts. For the location of the nearest Authorized Warranty Service Center call 1-888-895-4549 or visit
our website www.powermate.com.

13 - ENG Copyright © 2011 MAT Industries, LLC200-2839
LIMITED WARRANTY
• SAVE ALL INSTRUCTIONS
WARRANTY COVERAGE: MAT Industries, LLC (the Company)
Warrants to the original retail customer in North America that it will repair or replace, free of charge, any parts found by the Company or its
authorized service representative to be defective in material or workmanship. This warranty covers the cost of replacement parts and labor for
defects in material or workmanship.
NOT COVERED
· Transportation charges for sending the product to the Company or
its authorized service representative for warranty service, or for ship-
ping repaired or replacement products back to the customer; these
charges must be borne by the customer.
· Engine may be covered exclusively by a separate warranty from the
engine manufacturer as set forth in the engine Manual (if included).
· Damages caused by abuse or accident, and the effects of corrosion,
erosion and normal wear and tear.
· Warranty is void if the customer fails to maintain and operate the
product as instructed and recommended by the Company in the
owner’s manual.
· Warranty applies only if the product is used solely for consumer ap-
plications, and does not apply if the product is used for commercial or
business applications, or as rental equipment.
· The Company will not pay for repairs or adjustments to the prod-
uct, or for any costs or labor, performed without the Company’s prior
authorization.
WARRANTY PERIOD
Two (2) year from the date of purchase. For warranty service, the customer must provide dated proof of purchase and must notify the Com-
pany within the warranty period.
For warranty service: Call toll free 888-895-4549, or write to Sanborn Manufacturing Co., Product Services, 118 West Rock Street, P.
O. Box 206, Springfield, MN 56087.
EXCLUSIONS AND LIMITATIONS
THE COMPANY MAKES NO OTHER WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. IMPLIED WARRANTIES, INCLUDING WARRAN-
TIES OF MERCHANTABILITYAND OF FITNESS FOR A PARTICULAR PURPOSE, ARE HEREBY DISCLAIMED. THE WARRANTY SER-
VICE DESCRIBED ABOVE IS THE EXCLUSIVE REMEDY UNDER THIS WARRANTY; LIABILITY FOR INCIDENTALAND CONSEQUENTIAL
DAMAGES IS EXCLUDED TO THE EXTENT PERMITTED BY LAW.
This warranty gives you specific legal rights, and you may also have other rights which vary from state to state. Some states do not allow a
disclaimer of implied warranties, or the exclusion or limitation of incidental and consequential damages, so the above disclaimers and exclu-
sions may not apply to you.

14 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
PARTS LIST & EXPLODED VIEW
PRESSURE WASHER PWZC164000
4x4
2x
2x
2x 3
4x
2x 2x
2x
2x
4x
2x
2x
5x
4x
4x2
4x
4x
4x
1
2x5
2x
1
2331
5
6
7
4
8
9
10
28
14 13 712
26
25
21 22
23
20
19
18
17
16
11
27
34
11
35
24
Torque to 175-200 lb-in.
Serrez de 175 À 200 lbs-in.
Torsión hasta 19,8-22,6 N•m
Torque to 25-40 lb-in.
Serrez de 25 À 40 lbs-in.
Torsión hasta 2,8-4,5 N•m
Torque to 20-25 lb-in.
Serrez de 20 À 25 lbs-in.
Torsión hasta 2,3-2,8 N•m
Torque to 10-15 lb-in.
Serrez de 10 À 15 lbs-in.
Torsión hasta 1,1-1,7 N•m
Torque to 225-275 lb-in.
Serrez de 225 À 275 lbs-in.
Torsión hasta 25,4-31,1 N•m
NOTES:

15 - ENG Copyright © 2011 MAT Industries, LLC200-2839
PARTS LIST & EXPLODED VIEW
PRESSURE WASHER PWZC164000
ITEM
ART PART #
N˚/ P
NÚM / P
QTY.
QTÉ
CANT DESCRIPTION DESCRIPTION DESCRIPCÓN
1 025-0096 1 Engine Moteur Motor
2 N/A 4 Bolt, 5/16NC HHCS X1 1/2 Boulon Perno
3 N/A 4 Washer, flat 5/16 Rondelle Arandela
4 040-0437 1 Pump assy Ensemble du pompe Conjunto de bomba
5 N/A 4 Bolt, 3/8-16 UNC X 1.375" Boulon Perno
6 N/A 4 Washer, lock, 3/8 Rondelle Arandela
7 N/A 8 Washer, flat, 3/8 Rondelle Arandela
8 114-0779 1 Handle Poignée Empuñadura
9 114-0780 1 Hose hook Crochet pour tuyau Manguera gancho
10 093-0103 5 Grommet, .45 ID X .94 OD X .31 Grommet Ojal
11 N/A 6 Screw #10 X 1 Vis Tornillo
12 N/A 2 Bolt, 3/8"-16 x 2.25" Boulon Perno
13 N/A 2 Nut, nyloc 3/8-16 Écrou Tuerca
14 107-0077 1 Pin assy Assemblée Pin Ensamblaje
15 114-0770 1 Frame Frame Marco
16 115-0546 1 Panel Panneau El panel
17 N/A 2 Screw-5/16"-18 self tapping Vis Tornillo
18 N/A 2 Washer, fender, 5/16" ID X 1" OD Rondelle Arandela
19 094-0186 2 Vibration pad Tampon Almohadilla
20 N/A 4 Nut 5/16-18 Écrou Tuerca
21 110-0063 2 Wheel spacer Entretoise de roue Rueda espaciador
22 095-0084 2 Wheel, 12" flat free, 1/2" bore Roue Rueda
23 033-0001 2 Hub cap 1/2" Chapeau de moyeu Tapacubo
24 012-0168 1 Hose, 4000 PSI 3/8 X 50' Tuyau Manguera
25 145-0651 1 Lance, 28" Lance Lance
26 010-0030 1 Gun, 4000 PSI Gun Pistola
27 57835 1 Nozzle pack, 5 tips Pack buse Boquilla paquete
28 077-0179 2 Plastic cap 1.25" Cap Cap
29 57700 1 Chemical filter Filtre chimique Filtro químico
30 57701 1 Chemical hose, 1/4 ID 36" Boyau de produit chimique Química de la manguera
31 036-0109 1 Quick coupler Acoplador rápido Raccord rapide
32 098-4392 1 Warning label (not shown) D’avertissement étiquette Etiqueta de advertencia
33 098-4394 1 Warning label (not shown) D’avertissement étiquette Etiqueta de advertencia
34 115-0548 1 Nozzle panel (includes item 35) Panneau de tuyère (inclut l’article
35) Boquilla del panel (in- cluye el artículo 35)
35 N/A 2 Nut, #10-24 Écrou Tuerca
*N/A - These are standard parts available at your local hardware store.
*N/A - Estas son piezas estándar disponibles en su ferretería local.
*N/A - Ces pièces sont des pièces standard disponibles en quincaillerie.

16 - ENG 200-2839Copyright © 2011 MAT Industries, LLC
PARTS LIST & EXPLODED VIEW
PRESSURE WASHER ITEM # 040-0437 - PUMP
ITEM
ART PART #
N˚/ P
NÚM / P
QTY.
QTÉ
CANT DESCRIPTION DESCRIPTION DESCRIPCÓN
1 042-0134 1 Pump head (includes entire gray area) Tête de pompe Cabeza de bomba
2 062-0072 1 Plug Bouchon Tapón
3 8 Screw Vis Tornillo
4 6 O-Ring Joint torique Anillo tórico
5 6 Suct./Del. Valve Seat Siège de valve Asiento de válvula
6 6 Suct./Del. Valve Soupape Válvula
7 6 Spring Ressort Resorte
8 6 Suct./Del. Valve Cage Camp de valve Jaula de la válvula
9 6 O-Ring Joint torique Anillo tórico
10 062-0071 6 Plug and O-Ring Bouchon et joint torique Tapón y anillo tórico
11 3 Screw Vis Tornillo
12 1 Crankcase Flange Bride de carter de vilebrequin Reborde del cárter del motor
13 1 Alluminum Cover Couverture Cubierta
14 1 O-Ring Joint torique Anillo tórico
15 1 Ring Segment Anillo
16 1 Spacer Entretoise Espaciador
17 1 Ball Bearing Roulement Cojinete
18 056-0095 1 Oil Dipstick Jaugeur d’huile Varilla graduada del aceite
19 1 Housing Corps Compartimiento

17 - ENG Copyright © 2011 MAT Industries, LLC200-2839
PARTS LIST & EXPLODED VIEW
PRESSURE WASHER ITEM # 040-0437 - PUMP
ITEM
ART PART #
N˚/ P
NÚM / P
QTY.
QTÉ
CANT DESCRIPTION DESCRIPTION DESCRIPCÓN
20 3 Packing Head Ring Segment Anillo
21 3 Packing Emballage Embalaje
22 3 Back Ring Segment Anillo
23 3 Packing Emballage Embalaje
24 3 Packing Retainer Arrêtoir Detenedor
25 3 O-Ring Joint torique Anillo tórico
26 3 Oil Seal Joint Sello de aceite
27 3 Bolt Boulon Perno
28 3 Washer Rondelle Arandela
29 3 Ceramic Bushing Douille Buje
30 3 Washer Rondelle Arandela
31 3 O-Ring Joint torique Anillo tórico
32 3 Piston Guides Guides de piston Guías del pistón
33 3 Gudgeon Pin Pin Pin
34 3 Con. Rod Assembly Assemblée de bielle Asamblea de biela
35 1 Outer Seeger Agrafe Clip
36 1 Oil Indicator Indicateur d’huile Indicador del aceite
37 1 O-Ring Joint torique Anillo tórico
38 1 O-Ring Joint torique Anillo tórico
39 1 Cover Couverture Cubierta
40 4 Screw Vis Tornillo
41 4 Screw Vis Tornillo
42 1 Flange Bride Reborde
43 1 Oil Seal Joint Sello de aceite
44 1 Inner Seeger Agrafe Clip
45 1 Bushing Douille Buje
46 1 Bearing Roulement Cojinete
47 1 Eccentric Shaft Arbre Túnel
48 1 O-Ring Joint torique Anillo tórico
49 077-0202 1 Cap Chapeau Casquillo
50 036-0113 1 Suction Coupling Accouplement Acoplador
51 1 Thermo Valve Coupling Accouplement Acoplador
52 077-0201 1 Conical Cap Chapeau Casquillo
53 043-0226 1 Reg. Valve Kit + Seat Kit de valve de régulateur Kit de la válvula del regu-
lador
54 1 O-Ring Joint torique Anillo tórico
55 1 O-Ring Joint torique Anillo tórico
56 1 Spring Ressort Resorte
57 1 Check Valve Clapet anti-retour Válvula de cheque
58 1 O-Ring Joint torique Anillo tórico
59 031-0098 1 Injector Body Injecteur Inyector
60 031-0099 1 Check Valve Kit Kit de clapet anti-retour Kit de la válvula de cheque
61 043-0227 6 Valves Kit Jeu de Soupapes Juego de Válvulas
62 055-0084 1 Detergent Spring Ressort Resorte
63 079-0021 1 Detergent Ball Balle Pelota
64 036-0112 1 Hose nipple Manchon fileté Niple
65 068-0102 1 Suction fitting Raccord de succion Adaptador de succión
66 058-0183 1 Wing Nut Écrou Tuerca
67 118-0036 1 Water Filter Filtre Filtro
68 046-0334 1 Water Seal Kit Jeu de Joints l’eau Juego de Sello del agua
69 048-0134 1 Piston Kit Jeu de Piston Juego de Pistón
70 046-0335 1 Oil Seal Kit Jeu de Joints l’eau Juego de Sello del agua

LAVEUSE À PRESSION
GUIDE D’UTILISATION
pour modèle PWZC164000
Inscrivez tous les renseignements et agrafez le reçu de
caisse ici pour références futures :
Date d’achat :__________________________
N° de série : ________________________________
Questions? 1-888-895-4549
Apprenez encore plus en ce qui concerne votre laveuse à pres-
sion, obtenez des réponses aux
questions les plus fréquentes et enregistrez votre produit en
ligne à
www.powermate.com
IMPORTANT: Assurez-vous que toute personne qui utilisera cet équipement lise attentivement ces instructions avant de l’utiliser.
N° de pièce 200-2839 // Rev. B6/23/2011 IMPRIMÉ EN U.S.A.
TABLE DES MATIÈRES
Mesures de sécurité/Définitions ...............................................19
Renseignements sur la sécurité
du consommateur.....................................................................19
Mesures de sécurité importantes ....................................... 19-22
Fiche Technique .......................................................................22
Contenu de la boîte..................................................................22
Instructions d’assemblage........................................................23
Instructions d’utilisation ...................................................... 24-27
Entretien...................................................................................28
Entreposage.............................................................................28
Réparations..............................................................................29
Guide de dépannage................................................................29
Liste - Pèces et Diagramme Éclaté.................................... 14-17
Garantie....................................................................................30
English.................................................................................. 1-17
Español............................................................................... 31-43

19 - FR Copyright © 2011 MAT Industries, LLC200-2839
MESURES DE SÉCURITÉ – DÉFINITIONS
• CONSERVER TOUTES LES INSTRUCTIONS
Ce guide contient des renseignements importants que vous deviez bien saisir. Cette information porte sur VOTRE SÉCURITÉ et sur LA
PRÉVENTION DE PROBLÈMES D’ÉQUIPEMENT. Afin de vous aider à identifier cette information, nous avons utilize les symboles ci-dessous.
Veuillez lire attentivement ce guide en portant une attention particulière à ces symboles.
DANGER
Indique un danger imminent qui, s’il n’est pas évité, CAUSERA DE
GRAVES BLESSURES OU LAMORT.
ATTENTION
Indique la possibilité d’un danger qui, s’il n’est pas évité, PEUT causer
DES BLESSURES MINEURES OU MOYENNES.
AVERTISSEMENT
Indique la possibilité d’un danger qui, s’il n’est pas évité, POURRAIT
CAUSER DE GRAVES BLESSURES OU LAMORT.
ATTENTION
Sans le symbole d’alerte. Indique la possibilité d’un danger qui, s’il
n’est pas évité, PEUT causer DES DOMMAGES À LAPROPRIÉTÉ.
RENSEIGNEMENTS SUR LA SÉCURITÉ DU CONSOMMATEUR
• CONSERVER TOUTES LES INSTRUCTIONS
AVERTISSEMENT Il se peut que ce produit ne soit pas équipé d’un silencieux à pare-étincelles. Si le produit n’en est pas
équipé, et s’il est utilisé près de matériaux inflammables ou sur de la terre couverte de produits agricoles, forêts, broussailles, gazon ou au-
tres articles semblables, un pare-étincelles approuvé doit être posé, et est exigé par la loi en Californie. Selon la section 130050 de la loi de la
Californie, et les sections 4442 et 4443 du Code sur les ressources publiques de la Californie, ce produit ne peut pas être utilisé en Californie,
à moins que le moteur ne soit équipé d’un pare-étincelles, tel que décrit dans la section 4442, et à moins que l’appareil ne soit maintenu en bon
état de fonctionnement. Des pare-étincelles sont également requis sur certaines terres forestières des États-Unis et peuvent être exigés légale-
ment sous certains autres lois et arrêtés.
AVERTISSEMENT CALIFORNIE PROPOSITION 65 AVERTISSEMENT
Ce produit contient des produits chimiques connus de l’État de Californie comme causant des cancers, des anomalies congénitales et/ou
présentant des dangers pour la reproduction.
MESURES DE SÉCURITÉ IMPORTANTES
• CONSERVER TOUTES LES INSTRUCTIONS
AVERTISSEMENT N’utilisez pas cet appareil avant d’avoir lu et compris les instructions sur la sécurité, l’utilisation et l’entretien
de ce Guide de l’utilisateur et du Guide du propriétaire du moteur.
LISEZ ET CONSERVEZ CES INSTRUCTIONS
CE QUI PEUT SE PRODUIRE COMMENT L’ÉVITER
• Les cigarettes, étincelles, arc électrique, gaz d’échappement et des parties
chaudes du moteur telles qu’un silencieux peuvent enflammer l’essence
déversée et ses vapeurs.
• Éteindre le moteur et le laisser refroidir avant de remplir le réservoir d’essence.
• Être attentif et éviter de déverser de l’essence lors du remplissage du réser-
voir. Éloigner la laveuse haute pression de la zone de ravitaillement avant de
démarrer le moteur.
• Le combustible du réservoir se dilate sous l’effet de la chaleur et pourrait se
solder par un déversement et un incendie ou une explosion. • Laisser environ 127 mm (1/2 po) de dégagement sous le bord du goulot de remplissage pour permettre l’expansion de l’essence.
• Le fonctionnement de la laveuse haute pression dans un milieu explosif
pourrait se solder par un incendie. • Utiliser et faire le plein d’essence de l’équipement dans des zones bien déga- gées de tout obstacle. Installer un extincteur adéquat dans les zones de travail
pour combattre les incendies à base d’essence.
• Du matériel déposé contre ou près de la laveuse haute pression peut in-
terférer avec les fonctionnalités d’aération de l’équipement et provoquer une
surchauffe et l’allumage du materiel (risque d’incendie).
• Ne jamais utiliser la laveuse haute pression dans une zone avec arbustes ou
broussailles secs.
DANGER RISQUE D’EXPLOSION OU D’INCENDIE

20 - FR 200-2839Copyright © 2011 MAT Industries, LLC
MESURES DE SÉCURITÉ IMPORTANTES (SUITE)
• CONSERVER TOUTES LES INSTRUCTIONS
CE QUI PEUT SE PRODUIRE COMMENT L’ÉVITER
• La chaleur de l’échappement du silencieux peut endommager des surfaces
peintes, faire fondre tout type de matériel sensible à la chaleur (comme du
revêtement extérieur, plastique, caoutchouc, vinyle ou meme le tuyau haute
pression) et nuire aux plantes vivantes.
• Toujours éloigner la laveuse haute pression d’au moins 1,2 m (4 pi) de toutes
surfaces (telles que desmaisons, voitures, ou des plantes vivantes) qui pour-
raient être endommagées par la chaleur s’échappant du silencieux.
• De l’essence mal entreposée pourrait provoquer un allumage (incendie) ac-
cidentel. Ranger l’essence de façon sécuritaire pour en empêcher l’accès aux
enfants et à toutes autres personnes non qualifiées.
• Entreposer l’essence dans un contenant homologué par la Loi sur la santé et
la sécurité du travail dans un emplacement sécuritaire loin de la zone de travail.
• L’utilisation d’acides, de produits chimiques toxiques ou corrosifs, de poi-
sons, d’insecticides ou de toute sorte de solvant inflammable dans ce produit
pourrait provoquer des blessures graves ou la mort.
• Ne pas vaporiser des liquids inflammables.
DANGER RISQUE D’EXPLOSION OU D’INCENDIE (SUITE)
CE QUI PEUT SE PRODUIRE COMMENT L’ÉVITER
• Respirer les vapeurs d’échappement provoquera de graves blessures voire,
un décès ! Les gaz d’échappement des moteurs contiennent du monoxyde de
carbone, un gaz inodore et mortel.
• Utiliser la laveuse haute pression dans une zone bien aérée. Éviter les endroits
clos comme les garages, les sous-sols, etc.
• Ne jamais utiliser l’appareil dans un endroit habité par des hommes ou des an
maux.
• Certains liquides nettoyants contiennent des substances pouvant provoquer
des blessures à la peau, aux yeux ou au système respiratoire. • Utiliser uniquement des liquids nettoyants spécialement recommandés pour les laveuses haute pression. Suivre les recommandations des fabricants.
Ne pas utiliser de produit à blanchir au chlore ou tout autre composé corrosif.
DANGER RISQUE D’ASPHYXIE
CE QUI PEUT SE PRODUIRE COMMENT L’ÉVITER
• Votre laveuse haute pression fonctionne à des pressions de liquides et des
vitesses suffisamment élevées pour pénétrer la peau de l’homme et animale,
ce qui pourrait se solder par une amputation ou autre blessure grave. Des
fuites provoquées par des raccords lâches ou des tuyaux usés ou endomma-
gés peuvent se solder par des blessures par injection. NE PAS TRAITER UN
INJECTION DE LIQUIDE COMME UNE SIMPLE COUPURE ! Consulter un
médecin immédiatement !
• Inspecter périodiquement le tuyau haute pression. Remplacer immédiatement
le tuyau s’il est endommagé, usé, s’il a fondu en contact avec le moteur ou s’il
démontre un signe de fissure, des bulles, des trous d’épingle ou tout autre fuite.
Ne jamais saisir untuyau haute pression quifuit ou est endommagé.
• Ne jamais toucher, saisir ou essayer de couvrir un trou minuscule ou tout
autre fuite similaire sur le tuyau haute pression.
• Le jet d’eau EST sous haute pression et PÉNÈTRERAla peau.
• Ne jamais mettre les mains devantl’embouchure.
• Éloigner le jet, ne pas le diriger vers soimême ou autrui.
• S’assurer que le tuyau et les raccords sont serrés et en bon état. Ne jamais
s’agripper au tuyau ou aux raccords en cours de fonctionnement.
• Ne pas mettre le tuyau en contact avec le silencieux.
• Ne jamais attacher ou retirer le tube ou les raccords du tuyau avec le système
sous pression.
• Il y a risque de blessures si la pression n’est pas réduite avant d’essayer de
procéder à un entretien ou un démontage. • Pour décompresser le système, éteindre le moteur, fermer l’approvisionnement en eau et enclencher la détente du pistolet jusqu’à l’arrêt
complet de l’écoulement d’eau.
• Utiliser uniquement des tuyaux et accessoires classés pour des pressions
plus élevées que le PSI de la laveuse haute pression.
DANGER RISQUE D’INJECTION ET DE LACÉRATION
CE QUI PEUT SE PRODUIRE COMMENT L’ÉVITER
• Un jet de liquide à haute vitesse peut briser des objets et projeter les éclats
à haute vitesse.
• Des objets légers ou mal fixés peuvent se transformer en projectiles dan-
gereux.
• Toujours porter des lunettes de sécurité conformes à la norme ANSI Z87.1
Porter des vêtements protecteurs pour se protéger de jets accidentels.
• Ne jamais diriger la lance ou le jet vers une personne ou des animaux.
• Toujours fixer solidement le verrou de la détentelorsque le tube pulvérisateur
est inutilisé pour empêcher tout fonctionnement accidentel.
• Ne jamais fixer, de façon permanente, la détente en position arrière (ouverte).
DANGER RISQUE DE BLESSURE PAR JET
