Matelec SENTRY IP66 User manual

MATELEC AUSTRALIA. P 1800 281 282. F 1300 281 282
[e-mail]. WWW.MATELECAUSTRALIA.COM.AU
SUMMARY
The MATelec Australia Sentry Motion Sensor is an extremely reliable, IP66 rated PIR motion
sensor, suitable for a great range of applications.
SPECIFICATIONS
DOC: FSA-25000
SENTRY IP66 WEATHERPROOF MOTION SENSOR
Power Source: 220V - 240VAC
Power Frequency: 50HZ
Ambient Height: 3 - 2000 LUX (adjustable)
Time Range: 10 seconds - 30 minutes
Rated Load: 2000W Resistive (Incandescent)
1000W Inductive (Fluoro or LED)
Detection Distance: 6m to 18m
Detection Range: 120°
Installation Height: 1.8m - 2.5m
Power Consumption: 0.5W
Connection: 3 wire
Manual Override: Yes
Warranty: 3 years
Sentr
y

MATELEC AUSTRALIA. P 1800 281 282. F 1300 281 282
[e-mail]. WWW.MATELECAUSTRALIA.COM.AU
LOCATION
The Sentry needs to be carefully positioned to achieve optimum performance.
The optimum installation height is 2.5m.
To avoid nuisance/false switching, the sensor should not be installed near the following:
Heat sources, such as heater vents, air conditioners, other lights, reective sources, such
as glass & mirrors.
OPERATION OVERVIEW
The Sentry has both Automatic Mode, and Manual Override.
Auto Mode
In Automatic Mode, the lighting load will turn ON when movement is detected in the
sensing range, and the ambient light level is below the Lux setting. If no movement is
detected, and the delay time has expired, the load will turn OFF automatically.
Manual Override
Manual Override mode is activated, with the switch in the ON position, turn OFF/ON
twice, within the space of 3 seconds.The unit will remain on, regardless of movement or
detection, for 8 hours, after which it will return to Auto Mode.
To deactivate Manual Override, prior to the 8 hours, switch OFF/ON once.

MATELEC AUSTRALIA. P 1800 281 282. F 1300 281 282
[e-mail]. WWW.MATELECAUSTRALIA.COM.AU
MOUNTING PROCEDURE
WARNING: ALL ELECTRICAL INSTALLATIONS MUST BE CARRIED OUT BY A SUITABLY
QUALIFIED ELECTRICIAN IN ACCORDANCE WITH AUSTRALIAN AND LOCAL REGULATIONS
After identifying a suitable location, wire up the sensor as per the diagram below:
PIR
BLUE
BROWN
RED
LOAD
N L
SUPPLY
Using the supplied weatherproof seal, mount the sensor using the xings provided.
SENSING INFORMATION
Height of Installation: 1.8-2.5m Detection Distance: Max. 18m
18m
1.8-2.5m
120°
Max: 18m

MATELEC AUSTRALIA. P 1800 281 282. F 1300 281 282
[e-mail]. WWW.MATELECAUSTRALIA.COM.AU
SET UP AND TEST
The sensor has 3 adjustment dials.With the sensor OFF, set the adjustment dials as follows:
• Turn the TIME dial to minimum (10 s)
• Turn the SENS dial to maximum (+)
• Turn the LUX dial to maximum (sun)
Switch the power ON.The sensor will take approximately 30 seconds to calibrate.After this
time, the sensor load will switch on.As soon as movement is detected. If no further
movement is detected, the sensor will switch off the load in approximately 10 seconds.
When testing the sensor, please move HORIZONTALLY ACROSS the beam, not DIRECTLY
TOWARD the beam.
Once the sensor has been tested, please adjust the settings to the desired ranges.
Fault Possible Issue Possible Solution
Load does not activate Power not turned on Switch on the power
Sensor is wired incorrectly Check wiring is according to diagram
Connected load is faulty Check load is operational
Load does not turn off Time settings too long Adjust to shorter time and retest
Manual Override is activated Refer to Manual Override section
False triggering Heat sources, Reective Sources, or
wind
Remove trigger sources, or change
sensor location
Load turns ON in daylight Lux settings incorrect Adjust accordingly
TROUBLESHOOTING
