Matrix DPS Series User manual

1
INTRODUCTION
DPS series programmable power supply provides continuous adjustable output voltage and current as well as
automatic shift between constant voltage and current. It features with high stability & reliability, high accuracy, 4
groups memories by using digital technology, panel lock, output ON/OFF function, voltage & current limit setting
with password, and intelligent temperature control and alert function.
DPS series power supply has three outputs: two with adjustable output voltage and one fixed output voltage
(2.5V, 3.3V, 5V selectable, for DPS-3033GL-3 only).The two adjustable outputs provide both manual and
programmable control modes. When it is turned on, the unit is default) and in manual model. Pressing TIMER
button to set parameters. Pressing RUN or STOP button to turn on or off programmable control output.
As a constant voltage (CV) and constant current (CC) source, DPS series is able to, even at the maximum
output current, provides a fully rated and continuously adjustable output voltage. For a big load, DPS series can be
used as a CV source, the output current can be adjusted via a current regulator on the front panel; when used as a
CV source, the maximum output voltage can be controlled via voltage regulator on the front panel. That is to say,
the power supply will automatically shift from CV source to CC source when the output current reaches the target
value.
CAUTION:
1. The power supply must be operated under the rated line voltage. If the power supply is meant
to work for a long time, it is suggested to use 60%~70% load to as to avoid rapid aging.
2. Avoid frequent short-circuit operations.
3. Do not turn on the power supply when the output terminal is with heavy load. Turn the output
voltage adjustment knob to the lowest value, next connect the load, and then turn on the power
supply. Adjust the voltage/current adjustment knob to set the wanted values.
！

2
2. GENERAL AND PRODUT MODELS
2.1 General
Power source: 110V/220V±10%, 50/60Hz
Operation environment: Indoor use Altitude: <2000m
Relative humidity: <80% Temperature: 1 ℃~40℃
Category: II Pollution degree: II
Storage temperature: -10℃~70℃
Weight: 7.0kgs DPS-3033GL-3, 8.0kgs for DPS-3055GL-3&DPS-6022GL-3
Dimension: 300L*220W*148H (mm)
2.2 Accessories
Power cord: 1pcs
Users manual: 1 pcs
2.3 Product Models
Model Max.Output Voltage/Current Fixed Output Fuse
Voltage Current Input Voltage
110VAC 220VAC
DPS-3033GL-3 30VX2 3AX2 2.5V, 3.3V,5V T6.3A
250V T4A 250V
DPS-3055GL-3 30Vx2 5AX2 NO T6.3A
250V T6.3A 250V
DPS-6022GL-3 60Vx2 2AX2 NO T6.3A
250V T4A 250V

3
DPS-3055GL-3 & DPS-6022GL-3: CH1&CH2 output power limit within 100W.
3. SPECIFICATION
Technical specifications of DPS series should be tested in 30 minutes after unit warm up.
Testing environment: +20 ℃~+30℃
Specifications are subject to changes without notice.

4
Model DPS-3033GL-3 DPS-3055GL-3 DPS-6022GL-3
Output 0~30V/3Ax2 0~30V/5Ax2 0~60V/2Ax2
Constant Voltage Operation
Line regulation CV≤0.01%+3mV CV≤0.02%+3mV CV≤0.02+5mV
Load regulation CV≤0.01%+3mV CV≤0.02+5mV CV≤0.02+5mV
Recovery time ≤100µS (50% load change, minimum load 0.5A)
Ripple&Noise ≤2mV rms (5Hz~1MHz) ≤3mV (5Hz~1MHz)
Temperature ≤300ppm/℃
Programmable Control Features
Programmable point 4 4 4
Programmable time 1 sec.~60min.60sec. 1 sec.~60min.60sec. 1 sec.~60min.60sec.
Time accuracy ±1 sec. ±1 sec. ±1 sec.
Cycling Cyclable Cyclable Cyclable
Model DPS-3033GL-3 DPS-3055GL-3 DPS-6022GL-3
Output 0~30V/3Ax2 0~30V/5Ax2 0~60V/2Ax2
Rising time Empty load 10mS~250mS 10mS~250mS 10mS~250mS
0.5A load 10mS~250mS 10mS~250mS 10mS~250mS
Falling time Empty load 1.0S 1.0S 1.0S
0.5A load 10mS~250mS 10mS~250mS 10mS~250mS
CH3 Output (DPS-3033GL-3 only)
Regulation Line regulation≤5mV, load regulation≤15mV
Ripple&Noise ≤2mV rms

5
4. SAFETY INSTRUCTION
Voltage range 2.5V, 3.3V, 5V selectable
Output current 3A
Insulation degree Between base and output terminal ≥20MΩ/500V DC
Between base and power cord ≥30MΩ/500V DC
Display accuracy 3 & 1/2 digits LED display ≤±0.5%+2d

6
This section contains important safety instructions. Read the following before any operation to ensure your
safety and to keep the best condition for the power supplies.
4.1 Safety Symbols
The following symbols may appear in the manual or on the products:
DANGER High Voltage
ATTENTION refer to Manual
Protective Conductor Terminal
(ground) Earth Terminal

7
4.2 Safety Guidelines
Operation to power outlet and power cord: please use polarized power cord and polarized power outlet
for the instrument to ensure the case, output terminal are properly grounded.
To avoid damage, don’t remove the upper case, front or rear panel during operation to the power supply.
Do not touch the upper case or rear panel (heat sink). They are heating bodies and may cause scald.
Operation environment: The power supply should be operated in an environment with good ventilation
and with temperature at 23℃±5℃. Do not operate the power supply in environment with temperature
over 40℃.
Storage: Do not place any other instruments or inflammables on the power supply.
Abnormal operation: Do not apply high voltage or current which is over the rated voltage to the power
supply. Do not connect the positive and negative output terminals on the front panel continuously in the
way of instant short-circuit.
Grounding: Make sure to connect the input and output terminals to earth during the operation to ensure
your safety and the safety of nearby instruments.

8
Fault shooting: In case of any abnormal phenomenon, please forward the power supply to qualified
technical personnel.
4.3 About AC Input Voltage
The AC input voltage for DPS series is 110V/220V selectable±10%, 50/60Hz. When the power source is
higher than the rated voltage by +10%, please set the output current to 70%~80% of the rating output current to
avoid damage to the power supply.

9
5. PANEL INSTRUCTION
5.1 Front Panel

10
1) POWER : Power switch.
2) Meter V : Displays CH1 output voltage.
3) Meter V : Displays CH2 output voltage.
4) Meter A : Displays CH1 output current.
5) Meter A : Displays CH2 output current.
6) CV indicator: It turns on when CH1 is under constant voltage.
7) CV indicator: It turns on when CH2 is under constant voltage.
8) CC indicator: It turns on when CH1 is under constant current.
9) CC indicator: It turns on when CH2 is under constant current.
10) Sec indicator: It turns on when the unit works under programmable mode.
11) Min indicator: It turns on when the unit works under programmable mode.
12) SAVE1234: Store the settings of voltage, current and time value of programmable point. Short press of the
button recalls the saved settings. Long press of the button stores the settings. The button
background light turns on when recalling or storing. Any changes to recalling or storing settings, the
background light will turn off. All settings (except OUTPUT mode) will be stored. Time value of

11
programmable point is invalid when under manual mode.
13) TIMER: It is used to set the programmable parameter T and displays current switch.
When setting the programmable parameter T, the current meter displays the target time value. The
TIMER button background light and Sec. & Min. indicators turn on. Adjust the time by second and
minute respectively using the VOLTAGE and CURRENT knob.
When displaying the current, the current meter displays the current value. The TIMER button
background light and Sec. & Min. indicators turn off. Adjust the voltage and current value respectively
using the VOLTAGE and CURRENT knob.
14) RUN/STOP: Starts or stops the programmable mode. It also turns the programmable output on or off.
15) LOCK: Lock the buttons and knobs on the front panel (except OUTPUT button), to prevent wrong operation to
the panel. The LOCK button background light turns on. Long push this button, the background light
turns off.
16) CH2: It is used to switch to CH2 mode to adjust the voltage and current.
17) CH1: It is used to switch to CH1 mode to adjust the voltage and current.
18) OUTPUT: Turns the output on or off. The button background light turns on when the output is turned on and off
when the output is turned off.

12
19) VOLTAGE: It is used to adjust the voltage of CH1 and CH2. Pressing TIMER button, it is used to adjust the time
by minute.
20) CURRENT: It is used to adjust the current of CH1 and CH2. Pressing TIMER button, it is used to adjust the
time by second.
21) Switch button: Switched to select the CH3 output voltage from 2.5V, 3.3V and 5V.
22) FINE indicator: It turns on when there is fine adjustment to voltage and current as well as when the power
supply is in the mode of repeating programmable mode .
23) OVER LOAD : It turns on when CH3 output current is high than rated current.
24) Output terminal: CH3 negative “-” output terminal.
25) Output terminal: CH3 positive “+” output terminal.
26) Output terminal: CH1 negative “-” output terminal.
27) Output terminal: CH1 positive “+” output terminal.
28) Output terminal: CH2 negative “-” output terminal.
29) Output terminal: CH2 positive “+” output terminal.
30) GND terminal: Connects the case to the earth.

13
5.2 Rear panel

14
31) Power outlet.
32) Fuse holder.
33) Voltage selector(selects suitable voltage according to different regions.)
34) Cooling fan: reduce the inside temperature of the power supply to keep it at best condition.
6. OPERATION INSTRUCTION
6.1 Power source
According to local use, select suitable input voltage via the voltage selector. The input voltage is 110V/220V
selectable ±10%, 50/60Hz.
6.2 Operation Instruction
To avoid electronic shock, the power supply must be earthed.

15
6.2.1 Independent Mode
The power supply is under independent mode after it’s turned on. CH1 and CH2 channels are two
independent channels. They can be used independently or simultaneously.
A. Adjust the voltage and current knob to set the targeted CH1 or CH2 output voltage and current (limited
value).
B. Connect a load when CH1 or CH2 is used independently or simultaneously.
C. Press OUTPUT button to turn on the output. Press the button once again to turn off the output.
6.2.2 Programmable Mode
Different from manual mode, programmable mode applies written program points, automatically recalling
these program points to give output. Each program point has running time limit, maximum 60 minutes and 60
seconds.
Those buttons that are related to programmable mode are Save 1 2 3 4, TIMER, RUN/STOP, and OUTPUT
(start repeat of programs) buttons.
Set and store programmable points (CH, V, I, T)
One programmable point consists of point position (i.e. address of the programmable point) and its
parameters (i.e. voltage V, current Iand running time T). DPS series power supply has four programmable points.

16
These points are to be stored in memory unit 1 2 3 4 respectively.
A. Select channel: In manual mode, pressing CH1 or CH2 switches to correspondent channel.
B. Set targeted voltage, current and time value: In manual mode, after selecting one channel, set the
targeted voltage and current value by rotating their corresponding knobs. Pressing TIMER to set the T
value. The current meter will display running time and the time indicate will turn on. Rotating voltage knob
sets the time by minute and current knob by second.
C. Store parameters: After all parameters are set, long push one of the memory unit button (save 1 2 3 4) to
store the settings and short push to recall the settings.
Run the programs (start point, repeated running, demo)
A. Program start point: Pressing RUN/STOP button starts running the programs by countdown, at the
same time reads settings from memory units 1 2 3 4. If user recall any one of the four memory units
and use it as start point, programmable control will starts from this point. If no memory unit recalling,
the power supply will start at memory unit 1 in default.
B. Running programs repeatedly:
In the process of running program, program is running repeatedly while pressing VOLTAGE or
CURRENT knob, and the FINE indicator lights.When the running program is not under repeat mode,
turned on LOCK button, programs runs from start point”1” to end point”4”, and then stop running, but

17
still keep output. Turned off LOCK button, programs runs from start point”1” to end point”4”, then stop
running and output is also turned off.
C. Demo: In the process of running program, when turned OUTPUT on, the program is demonstrating
accompanied with power output; turned off OUTPUT, it is demonstrating without power output.
D. Under running program, pressing RUN/STOP button to stop running, but still keep output; pressing
RUN/STOP button a second time, the program continues to running by countdown.
Example 1. Single programmable point (set voltage at 24V, current at 2A, Time: 2minutes and 30 seconds)
In the manual mode, the first, Rotating VOLTAGE and CURRENT knob to set voltage and current separately at
24V and 2A. The second, pressing TIMER button to set time at 2 minutes and 30 seconds by rotating VOLTAGE
and CURRENT knob, then long pushed button of “4” to save program, in this case, program point saved in
MEMORY 4. The third, turn on OUTPUT and RUN/STOP button, this program is running by countdown, and it will
stop running and output be turned off when the time is end up.
Example 2. Four programmable point
Using the same method above mentioned, To set and save different voltage, current and time in the four points” 1,
2, 3, 4”, then turned on OUTPUT and RUN/STOP, these four program is running one after one by countdown,
when the time is used up, the program be stopped running, at the same time, power output also be turned off.
Example 3. output voltage of the Square waveform pulse (set voltage at 5V, current at 1A, width of pulse at 3

18
seconds)
Set and save voltage, current, time of point “1” and point “3” separately at 5V,1A, 3 seconds, using the same way,
set point”2” and point “4” at voltage of 0V, current at 1A, time at 3 seconds, then turned on OUTPUT and
RUN/STOP button. The program is running, when you push VOLTAGE or CURRENT button, the Repeat
indicator lights, meanwhile, the program is running repeatedly, and
the targeted pulse voltage is displayed as 5V with 1A current and 3 seconds width of pulse.
6.2.3. Memory save and recall
Save key”1, 2, 3, 4”
a. Press any one for 1 second to save current settings into current memory group. For example, press
“save 1” to save current settings into memory 1.
b. Press any one for 3 seconds to recall previous saved settings from current memory group. For example,
press “save 1” to recall previous settings saved in memory 1.
6.2.4 CH3 Output (DPS-3033GL-3 only)
CH3 mode has the output of 2.5V, 3.3V, 5V, maximum 3A. Output voltage can be selected using the voltage
selector switch.
a. Press OUTPUT key to turn off output.

19
b. Connect load to the CH3 positive and negative output terminal.
c. Press OUTPUT key to turn on output.
d. When the output current is over rating 3A(overload), the overload turns red, and the output voltage and
current gradually turns down to enable protection. To restore the CH3 output, lower the load and make the
output current less than 3A until the overload indicator turns off.
6.2.5 Output ON/OFF
OUTPUT key is a ON/OFF switch that controls the output of all CH1, CH2 and CH3 outputs. Press the key, to
turns on output and the indicator turns on. Press the key once again to turns off the output, and the indicator
turns off.
6.2.6 Voltage&Current Limit Setting with Password
When the front panel is unlock, OUTPUT at OFF, input password “022 011”. To input password, set the CH1&CH2
voltage at 0.22V(preset) and current at 0.11A (preset). Then press the LOCK key for 3 seconds to go into
voltage&current limit setting.
At this moment, there is reminder voice sound for 3 times and the LOCK indicator turns on, and then the previously
preset limits are recalled. The LOCK indicator turning on means that the power supply is under voltage&current
limitsetting mode, adjust the front panel knows to set voltage&current limits or recall previous settings.

20
Then the LED displays current limit settings that can be adjusted, but make sure that the output voltage>0.50V,
output current>0.50A. press LOCK key for 3 seconds to save current settings, there will be reminder voice sound
for 3 times and the LOCK indicator turns off and the LED display maximum limit.
Under voltage&current limit setting mode, press the LOCK key for 1 second to exit limit setting and to go into front
panel lock mode. The limit settings will not be updated. (NOTE: if CH1voltage<0.50V, CH1 current<0.50A, CH2
voltage<0.50V, CH2 current<0.50A, there will be limit function and limit setting will not be enabled.) adjustment
exceeds limit settings, there will be reminder voice.
6.3 Constant voltage and constant current characteristics
The DPS series automatically switches between constant voltage (CV) and constant current (CC) mode
according to load condition. That is to say, when the output current reaches targeted value, DPS series will
automatically switch to constant current mode; and vice visa. The CV mode and CC mode switch point is called
crossover point. Below figure shows the relations between crossover point and load.
