Excel Power XL3500iDF User manual

OWNER’S MANUAL

XL3500iDF
3200W-GAS/3000W-LPG
3000W-GAS/2700W-LPG

1 - Recoil Starter
2 - Control Panel
3 - Fuel Cap
4 - Maintenance Cover
5 - Carrying Handle
6 - Wheel
7 - Telescopic Handle
8 - Panel LED Light
9 - LPG Inlet
10 - Support Leg
11 - Muffler/Spark Arrester
3 4 5
10 11
6 9
7
1 2
8

1.Operation button and eco indicator
2.Oil alarm lamp
3.Monitor
4.Overload indicator and rest button
5.Display toggle button
6.Circuit breaker(AC)
7.DC 5V USB
8.Circuit breaker(DC)
9.Fuel switch
10.LPG inlet
11.AC 230V receptacle
12.Parallel operation outlets
13.DC socket
14.AC 230V receptacle
15.Grounding terminal
12V
3 4 5 6 71 2
15 1014 8111213 9

230V
230V 50 60
