MATSONIC MS8328E Series User manual

Mainboard User’s Manual
This publication, including all photographs, illustrations and
software, is protected under international copyright laws, with all
rights reserved. Neither this manual, nor any of the material
contained herein, may be reproduced without written consent of the
author.
The information in this document is subject to change without
notice. The manufacturer makes no representations or warranties
with respect to the contents hereof and specifically disclaims any
implied warranties of merchantability or fitness for any particular
purpose. Further, the manufacturer reserves the right to revise this
publication and to make changes from time to time in the content
hereof without obligation of the manufacturer to notify any person
of such revision or changes.
Trademarks
IBM, VGA, and PS/2 are registered trademarks of International
Business Machines.
Intel, Pentium/II/III, Pentium 4, Celeron and MMX are registered
trademarks of Intel Corporation.
Microsoft, MS-DOS and Windows 98/ME/NT/2000/XP are
registered trademarks of Microsoft Corporation.
PC-cillin is a registered trademark of Trend Micro Inc.
AMI is a registered trademark of American Megatrends Inc.
MediaRing Talk is a registered trademark of MediaRing Inc.
3Deep is a registered trademark of E-Color Inc.
Recovery Genius 21st, CD Ghost and Language Genius 21st are
trademarks of GoldenSoft Technology Co., Ltd.
SiS is a trademark of Silicon Integrated System Corporation.
Other names used in this publication may be trademarks and are
acknowledgedledged.
Copyright © 2002
All Rights Reserved
MS8328E Series, V2.1
S740/November 2002

Mainboard User’s Manual
II
Notice:
Owing to Microsoft’s certifying schedule is various to every
supplier, we might have some drivers not certified yet by
Microsoft. Therefore, it might happen under Windows XP that a
dialogue box (shown as below) pop out warning you this
software has not passed Windows Logo testing to verify its
compatibility with Windows XP. Please rest assured that our RD
department has already tested and verified these drivers. Just
click the “Continue Anyway” button and go ahead the
installation.

Mainboard User’s Manual
III
Table of Contents
Trademarks........................................................................ I
Chapter 1: Introduction..............................................................1
Key Features......................................................................2
Package Contents...............................................................5
Static Electricity Precautions...............................................6
Pre-Installation Inspection...................................................6
Chapter 2: Mainboard Installation...............................................7
Mainboard Components......................................................8
I/O Ports............................................................................9
Install A CPU.....................................................................9
Install Memory.................................................................11
Setting Jumper Switches...................................................12
Install the Mainboard........................................................13
Optional Extension Brackets.............................................15
Install Other Devices........................................................17
Expansion Slots................................................................19
Chapter 3: BIOS Setup Utility..................................................21
Introduction.....................................................................21
Running the Setup Utility..................................................22
Standard CMOS Setup Page.............................................. 23
Advanced Setup Page.......................................................24
Power Management Setup Page.........................................26
PCI / Plug and Play Setup Page .........................................27
Load Optimal Settings ...................................................... 28
Load Best Performance Settings ........................................28
Features Setup Page..........................................................28
CPU PnP Setup Page ........................................................30
Hardware Monitor Page....................................................31
Change Password.............................................................31
Exit .................................................................................32
Chapter 4: About the Software CD-ROM..................................33
Utility Software Reference................................................34

Mainboard User’s Manual
IV

1: Introduction
1
Chapter 1
Introduction
This mainboard has a Socket-462 processor socket for the AMD
K7type of processors. You can install any of these processors on
this mainboard. This mainboard supports front-side bus speed of
266MHz.
This mainboard integrates the SiS740 Northbridge and
SiS962/962L Southbridge chipsets that supporta DDR interface,
Ultra DMA 66/100/133function and remarkably high system
performance under all types of system operations.
This mainboard has a built-in AC97 Codec, providing a CNR
(Communication and Networking Riser) slot and a built-in
10BaseT/100BaseTX Network Interface. This mainboard also
supports the optional built-in IEEE1394a function (for SiS962 SB
only). There is an extended set of MATX I/O Ports including
PS/2 keyboard and mouse ports, four back-panel USB2.0 ports,
one parallel port, one VGA port and one serial port. Connecting the
Extended USB Module to this mainboard can add two extra
USB2.0 ports(onboard USB header USB1).
This mainboard has all features you need to develop a powerful
multimedia workstation. The board is Micro ATX size and has
power connectors for an ATX power supply.

Mainboard User’s Manual
2
Key Features
The key features of this mainboard include:
Socket-462 Processor Support
♦Supports AMD Athlon XP/Athlon/Duron processors
♦Supports 200/266 MHz Front-Side Bus
Memory Support
♦Three 184-pin DIMM sockets(DDR1 ~ DDR3) for DDR
memory modules
♦Maximum installed memory is 1.5GB
Expansion Slots
♦One CNR (Communication and Networking Riser) slot
♦Three 32-bit PCI slots for PCI 2.2-compliant bus interface
Onboard IDE channels
♦Primary and Secondary PCI IDE channels
♦Support for PIO (programmable input/output) modes
♦Support for Multiword DMA modes
♦Support for Bus Mastering and Ultra DMA 66/100/133
modes
Power Supply and Power Management
♦ATX power supply connector
♦Meets ACPI 1.0b and APM 1.2 requirements, keyboard
power on/off
♦Supports Suspend, Shutdown, Wake on LAN, Wake on
Modem, Wake on Alarm, Interrupt Wake-up from
Keyboard/Mouse

1: Introduction
3
AC97 Audio Codec: CMI9738
♦Compliant with AC’97 2.2 specification
♦Full-duplex Codec with independent and variable sampling
rate
♦Earphone Buffer Built-In, SNR up to 90db
♦4Ch DAC, support 4-channel speak-out
♦Advanced power management support
Built-in Ethernet LAN
♦Single chip 10Base-TX/100Base-T Physical Layer
Solution
♦Dual Speed –100/10 Mbps
♦MII Interface to Ethernet Controller/Configuration & Status
♦Auto Negotiation: 10/100, Full/Half Duplex
♦Meet All Applicable IEEE802.3, 10Base-T and 100Base-
TX Standards
Onboard I/O Ports
The mainboard has a full set of I/O ports and connectors:
♦Two PS/2 ports for mouse and keyboard
♦One serial ports
♦One parallel port
♦One VGA port
♦Six USB ports (Four back-panel ports, onboard USB
header providing two extra ports) —USB2.0
♦Audio jacks for microphone, line-in and line-out
Hardware Monitoring
♦Built-in Hardware Monitor circuit supports Thermal, Power
and Fan Speed monitor
Onboard Flash ROM
♦Supports Plug and Play configuration of peripheral devices
and expansion cards
USB 2.0
♦Compliant with Universal Serial Bus Specification
Revision 2.0

Mainboard User’s Manual
4
♦Compliant with Intel’s Enhanced Host Controller
Interface Specification Revision 0.95
♦Compliant with Universal Host Controller Interface
Specification Revision 1.1
♦PCI multi-function device consists of two UHCI Host
Controllercores for full-/low-speed signaling and one
EHCI Host Controllercore for high-speed signaling
♦Root hub consists 4 downstream facing ports with
integrated physical layer transceivers shared by UHCI and
EHCIHost Controller
♦Support PCI-Bus Power Management Interface
Specification release 1.1
♦Legacy support for all downstream facing ports
IEEE 1394a (Only for SiS962 SB)
♦Fully supports provisions of IEEE1394a-1995 for high-
performance serial bus and the P1394a draft 2.0 standard
♦Provides three fully compliant cables ports at 100/200/400
Mbits/s and available with one, two or three ports
♦Supports optional 1394a Annex J electrical isolation
barrier at PHY-link interface
♦Supports power-down feature to conserve energy in battery
powered application
♦Node power-class information signaling for system power
management
♦PC-Cillin2000 provides automatic virus protection under
Windows 98/ME/NT/2000/XP
♦MediaRing Talk provides PC to PC or PC to Phone
internet phone communication
♦Super Voiceis data, fax and voice communication software.
♦Recovery Genius 21st V5.0 provides the function to
recover, reserve and transfer hard disk data.
♦CD Ghost is the software stimulating a real CD-ROM to
perform equivalent function.
♦Language Genius 21st is the software to provide learning
tools of language and singing.

1: Introduction
5
♦PageABC is the software to help you create your own
home page.
Dimensions
♦Micro ATX form factor (220mm x 244mm)
Package Contents
Your mainboard package ships with the following items:
qThe mainboard
qThis User’s Guide
q1 UDMA66/100 IDE cable
q1 Floppy disk drive cable
qSupport software on CD-ROM disk
Optional Accessories
You can purchase the following optional accessories for this
mainboard.
qExtended USB module
qCNR v.90 56K Fax/Modem card

Mainboard User’s Manual
6
Static Electricity Precautions
Static electricity could damage components on this mainboard.
Take the following precautions while unpacking this mainboard
and installing it in a system.
1. Don’t take this mainboard and components out of their original
static-proof package until you are ready to install them.
2. While installing, please wear a grounded wrist strap if possible.
If you don’t have a wrist strap, discharge static electricity by
touching the bare metal of the system chassis.
3. Carefully hold this mainboard by its edges. Do not touch those
components unless it is absolutely necessary. Put this
mainboard on the top of static-protection package with
component side facing up while installing.
Pre-Installation Inspection
1. Inspect this mainboard whether there are any damages to
components and connectors on the board.
2. If you suspect this mainboard has been damaged, do not
connect power to the system. Contact your mainboard vendor
about those damages.

2: Mainboard Installation
7
Chapter 2
Mainboard Installation
To install this mainboard in a system, please follow the instructions
in this chapter:
qIdentify the mainboard components
qInstall a CPU
qInstall one or more system memory modules
qVerify that all jumpers or switches are set correctly
qInstall the mainboard in a system chassis (case)
qConnect any extension brackets or cables to connecting
headers on the mainboard
qInstall other devices and make the appropriate connections to
the mainboard connecting headers.
Note:
1. Before installing this mainboard, make sure jumper JP1 is
under Normal setting. See this chapter for information about
locating JP1 and the setting options.
2. Never connect power to the system during installation;
otherwise, it may damage the mainboard.

Mainboard User’s Manual
8
Mainboard Components
This diagram below identifies major components on the mainboard.
Note:Any jumpers on your mainboard that do not appear in
the illustration above are for testing only.

2: Mainboard Installation
9
I/O Ports
The illustration below shows a side view of the built-in I/O ports
on the mainboard.
Install A CPU
This mainboard has a Socket-462 that supports AMD K7
processors.
To ensure reliability, ensure that your processor has a
heatsink/cooling fan assembly.
Do not try to install a Socket-370/Socket-7 processor in the Socket-
462. A Socket-370/Socket-7 processor such as the PPGA Celeron,
FCPGAPentium-III, Pentium-MMX, or the AMD K5/K6 does not
fit in the Socket-462.
The following list indicates these processors are currently
supported by this mainboard.
Athlon XP: 2600+ MHz; FSB: 266 MHz
Athlon: 650 MHz~1.4 GHz, FSB: 200 MHz, 266 MHz
Duron: 550 MHz~1.2 GHz and up, FSB: 200 MHz

Mainboard User’s Manual
10
Installing a Socket-462 Processor
Install a processor into the ZIF (Zero Insertion Force) Socket-462
on the mainboard.
1. Locate the Socket-462 and CPUFAN. Unlock the socket by
pressing the locking lever slightly sideways, and then lift it to
the upright position.
2. On the processor, identify the Pin-1 corner by its beveled edge.
3. On the Socket-462, identify the Pin-1 corner. The Pin-1 corner
is at the end of the locking lever when locked.
4. Match the Pin-1 corner of CPU with the one of socket, and
insert the processor into the socket. No force is required and
the processor should drop into place freely.
5. Push down the locking lever and hook it under the latch on the
edge of the socket. This secures the CPU in the socket.
6. All processors should be installed with a combination
heatsink/cooling fan, connect the cable from the fan to the
CPU fan power connector CPUFAN 1.
CPUFAN1
Socket-462
Pin-1 Corner

2: Mainboard Installation
11
Install Memory
This mainboard accommodates three184-pin 2.5V unbuffered
Double Data Rate (DDR) SDRAM DIMM sockets. You must
install at least one memory module in order to work out the
mainboard.
When you install DDR200/DDR266 memory modules, the
memory bus can run up to 100/133 MHz.
The DDR SDRAM DIMMs can synchronously work with 100
MHz or operates over a 133 MHz system bus.
You must install at least one memory module in order to use the
mainboard. Each module can be installed with up to 1.5GB
memory capacity
Installation Procedure
To install a module, please follow these steps:
1. Push down the latches on each side of the DIMM socket.
2. Align the memory module with the socket. The DIMM
sockets are keyed with notches and the DIMMs are keyed
with cutouts so that they can only be installed correctly.
3. Check the cutouts on the DIMM module edge connector
matching the notches in the DIMM socket.
4. Install the DIMM module into the socket and press it firmly
down until it is seated correctly. The socket latches are
levered upwards and lock the edges of the DIMM.
5. Install any remaining DIMM modules.
DDR1
DDR2
DDR3

Mainboard User’s Manual
12
Setting Jumper Switches
Jumpers are sets of pins that can be connected together with
jumper caps. Jumper caps change the operating way of the
mainboard by changing the electronic circuits. If a jumper cap
connects two pins, these pins are SHORT; if it is removed, these
pins are OPEN.
Jumper JP1: Clear CMOS Memory
This jumper can clear the contents of the CMOS memory. You
may need to clear the CMOS memory if the settings in the Setup
Utility are incorrect and prevent your mainboard from operating.
To clear the CMOS memory, disconnect all the power cables from
the mainboard and then move the jumper cap into the CLEAR
setting for a few seconds.
Function Jumper Setting
Clear CMOS Memory Short Pins 1-2
Normal Operation Short Pins 2-3
JP1
1

2: Mainboard Installation
13
Install the Mainboard
Install the mainboard in a system chassis (case). The board is an
Micro ATX size mainboard with a twin-tier of I/O ports. You can
install this mainboard in an ATX case. Ensure that your case has an
I/O cover plate that matches the ports on this mainboard.
Install the mainboard in a case. Follow the instructions provided by
the case manufacturer using the hardware and internal mounting
points on the chassis.
Connect the power connector from the power supply to the PWR1
connector on the mainboard.
If there is a cooling fan installed in the system chassis, connect the
cable from the cooling fan to the SYSFAN1 fan power connector
on the mainboard.
Connect the cable from the PC speaker to the SPK1 header on the
mainboard.
Pin Signal Pin Signal
1 SPKR 2 NC
3 GND 4 +5V
SYSFAN1
AUDIO1
1
SW1
1
PWR1
1
J1
SPK1
1

Mainboard User’s Manual
14
Connect the case switches and indicator LEDs to the SW1 header.
Here is a list of SW1 header’s pin assignments:
Pin Signal Pin Signal
1 HD_LED_P 2 FPPWR/SLP
3 HD_LED_N 4 FPPWR/SLP
5 RESET_SW_N 6 POWER_SW_P
7 RESET_SW_P 8 POWER_SW_N
9 RSVD_DNU 10 KEY
If there are a headphone jack or/and a microphone jack on the front
panel, connect the cables to theAUDIO1 header on the mainboard.
Here is a list of AUDIO1 header’s pin assignments:
Pin Signal Pin Signal
1 AUD_MIC 2 AUD_GND
3 AUD_MIC_BIAS 4 AUD_VCC
5 AUD_FPOUT_R 6 AUD_RET_R
7 HP_ON 8 KEY
9 AUD_FPOUT_L 10 AUD_RET_L
This connector J1(LAN LED indicator) is attached to LAN device
that needs a LED indicator.
Pin Signal Pin Signal
1 ACT LED 2 ACT LED (+)
3 Link LED (+) 4 Link LED

2: Mainboard Installation
15
Optional Extension Brackets
For this mainboard, you can also obtain a USB module extension
bracket for more USB ports. Install them by following the steps
below.
Note: All the ribbon cables used on the extension brackets have a
red stripe on the Pin-1 side of the cable.
Extended USB Module
This module bracket has two USB ports for more USB devices
(USB port 5-6).
Pin Signal Pin Signal
1USBVCC1 2GND
3USBDT0-4KEY
5USBDT0+ 6USBDT1+
7KEY 8USBDT1-
9GND 10 USBVCC1
1. Locate the USB1 header on the mainboard.
2. Plug the bracket cable onto the USB1 header.
3. In the system chassis, remove a slot cover from one of the
expansion slots and install the extension bracket in the opening.
Secure the extension bracket in the chassis with a screw.
USB1
1

Mainboard User’s Manual
16
Extended IEEE1394a Header (Optional)
You can obtain one optional IEEE1394a header, and install them
by following the steps below.
JP2
Pin Signal Pin Signal
1 CPWR 2 GND
3 XTPB0M 4 XTPB0P
5 XTPA0M 6 XTPA0P
7 SHIELD 8 KEY
1. Locate the JP2 header on the mainboard.
2. Plug the bracket cable onto the JP2 header.
3. In the systemchassis, remove the blanking plate from the
corresponding expansion slot you want to use, and install
an extension bracket in there. Secure the extension bracket
in the chassis with a screw.
JP2
1
