AIR COMPRESSORS
INSTRUCTION, USE AND
MAINTENANCE MANUAL
TI008G0001
ING. ENEA MATTEI SpA
Strada Padana Superiore 307 - 20090 VIMODRONE (MI)
Tel +39 - 02253051 (16 linee) - Fax +39 - 0225305243
933GB
900a
TI008G0001
The hard copy of this manual will be available for more than 10
years after the end of the production of the relative machine.
The content of this document cannot be used, reproduced or
disclosed to third parties without the explicit written consent of
Ing. ENEA MATTEI S.p.A.
Ing. ENEA MATTEI S.p.A. reserves the right to modify the
characteristics of the machine subject of this document without
prior notice.
Copyright 2008 by Ing. ENEA MATTEI S.p.A.
This Instruction Manual meets all the requirements of 98/37/
EEC Directive.
It is to be considered valid for both the machines with the CE
Marking and those without it.
Important Note
This manual should always be used together with the “MAES-
TROXS User’s Manual”, code TECA2G-007.
Versions
- AC 6000
- AC 6000 plus
Voltages/Frequencies
- V 230/50 Hz - V 400/50 Hz
- V 230/60 Hz - V 460/60 Hz
Standard: 3F +
Plus: 3F +
Forward
900
0.01
TI008G0001
General Index
General Information
- Symbols in the manual Page 1.01
- Purpose of Document Page 1.02
- Required Qualications for Operators Page 1.03
- Identication data of the Manufacturer and the Machine and the location of
the nameplate “CE MARKING” Page 1.04
- General Delivery Notes - Final inspection - General Safety Warnings Page 1.05
- Settings at the Customer’s expense Page 1.09
- Instructions on how to request interventions - Instructions on how to order
spare parts - The manufacturer’s address Page 1.10
General Information - SAFETY
- Dangers and residual risks and General Information Page 2.01
- Responsibilities Page 2.04
- Description of Pictograms Page 2.05
Description of Machine
- General Description of Machine Page 3.01
- Technical Data and Overall Dimensions Page 3.11
Transportation and handling Page 4.01
Installation
- Position of compressor Page 4.02
- Electrical connection Page 4.03
- Connection to the air network Page 4.04
- Dimensions of compressed air distribution piping Page 4.05
- Heat recovery Page 4.06
Safety Devices Page 5.01
Commands and control Page 5.02
Use of compressor
- Foreword Page 6.01
- Operation modes Page 6.02
- MAESTROXS Page 6.04
- Operational Failures Page 6.05
- Start - Stop Page 6.06
Maintenance Page 7.01
- Réguler Checksums Page 7.02
- Check of oil level - Cleaning and/or replacing the air suction lter -
Cleaning the oil/air radiator Page 7.03
- Cleaning the pre-lters- Cleaning and/or replacing the oil return valves Page 7.04
- Replacing the oil lter Page 7.05
- Replacing the oil/air separator elements Page 7.06
- Oil change Page 7.08
Lubricants Page 8.01
Troubleshooting Page 9.01
The electrical motor Page 10.01
Storage - Decommissioning and dismantling Page 11.01
Condensate discharge in optional kit Page 12.01
Attachments:
Form to request Technical Service
Form to request spare parts
Parts to be replaced during maintenance
“Technical Data” Sheets
1.01
Symbols in the manual
In this manual some symbols are used that to attract the reader’s attention and underline some particu-
larly important aspects of the treatment.
The table below gives the list and describes the meaning of the different symbols used.
MEANING and NOTES
Danger
It indicates a danger with the risk for accident, even fatal, for the user.
Pay careful attention to text block with this symbol.
Warning
It warns against a possible deterioration of the machine or personal item of the user.
Notice
It shows either a notice or a note on the key functions or useful information.
Further information
This symbol introduces text blocks containing further information.
This information has no direct relationship with the description of a function or with pro-
cedure development.
They could be cross-references to other documents or other sections of this manual.
Damage risk
It indicates a high damage risk of a piece, for example, using a wrong tool or by mounting
something with the incorrect procedure.
Visual Check
It recommends the reader to carry out a visual check. This symbol can also be found in
the instructions for use. The user is required to read a measure value, to check some
warning signs, etc.
Acoustic Check
It recommends the reader to carry out a sound acoustic check.
This symbol can also be found in theinstructions for use. The user is required to listen to
an operational noise.
SYMBOL
General Information
TI008G0001
☞
!
!
098
1.02
Purpose of Document
This manual contains the technical characteristics, the performance, the transportation and installation
rules, the instructions for use, and the preventive and corrective maintenance operations of the machine
manufactured by Ing. ENEA MATTEI S.p.A.
NOTE : This manual should be considered an integral part of the machine, and should
stay with it during the entire life span of the equipment.
Keep this manual and all of the attached documents in a place easily accessible to all staff
in charge of the control or the maintenance of the machine.
Ing. ENEA MATTEI S.p.A. reserves the right to subject the supply of further copies to the
repayment of charges and the acceptance of special provisions with respect to the legiti-
mate defense of intellectual, patent, and executive identity and functional property of the
product and/or its parts.
It is understood that forwarding all or part of this manual to third parties is not tolerated
unless with the prior written consent of Ing. ENEA MATTEI S.p.A. for both the text, the
illustrations and the diagrams attached.
Ing. ENEA MATTEI S.p.A. reserves the right to make changes without prior notice. Any
change, supplement or suppression of elements, components, functions or cycles of the
machine, not previously agreed upon with Ing. ENEA MATTEI S.p.A. releases the manu-
facturer from any responsibility whatsoever.
☞
General Information
This manual is for the user and the service engineer of the machine, and it aims at supplying them with
the basic technical data typical of the system, a technical description of the several operating groups
that form it as well as the essential use procedures and the information necessary to perform preventive
and corrective maintenance.
This manual is for staff with a sound knowledge of the processing technique, of mechanical and electrical
diagrams, and is for both those in charge for the use of the machine and the service engineers.
This manual is an integral part of the machine and contains information that aims at granting all staff
safe working conditions and guaranteeing perfect efciency during the life span of the machine.
For a correct use of the machine, it is assumed that the working environment is adequate to current
regulations concerning safety and hygiene.
Applied directives and technical standards
The machine has been designed, made, and inspected in compliance with the “safety and health es-
sential requirements” stated in attachment I to the European Directive 98/37/EEC.
The list below gives the reference Standards used by Ing. ENEA MATTEI S.p.A. to design, make, and
to make the nal inspection of the machine.
List of Directives and Technical Harmonized Standards
MACHINERY DIRECTIVE 98/37/EEC
ELECTROMAGNETIC COMPATIBILITY (EMC) DIRECTIVE 2004/108/CE
LOW VOLTAGE DIRECTIVE 2006/95CE
EN 1012-1 Compressors and vacuum pumps – Safety Requirements - Compressors.
TI008G0001
1.03
Required Qualications for Operators
The operator in charge of the operation or the maintenance of the machine should have all the profes-
sional requirements specic to each foreseen operation.
The operator should be trained and aware of his responsibilities.
Below is the description of the professional proles concerning the operators in charge of the machine
Entry Level Machine Operator (Qualication 1)
Qualied staff able to carry out simple tasks, i.e. to operate the machine with the use of
controls on the push-button, and to carry out typical simple functions of adjustments, start
or stop.
Second Level Machine Operator (Qualication 2)
Qualied staff able to carry out the task of qualication 1 and also to operate the machine with
disconnected safety protections to perform specic adjustments, start or stop functions.
☞Important
This qualication includes those responsibilities typically subdivided into two separate quali-
cations. For the operator in charge of our machines, a specialization course is held to train the
operator to be able to perform all of the actions necessary to operate the machine even with some
of the protections disconnected. However, this requires a certain competence by the operator
and extreme care by the manager of the factory so that the said operator carries out only the
established operations.
Mechanical Service Engineer
A qualied engineer able to operate the machine under normal conditions, to operate it with
disconnected protections, to intervene on mechanical parts to carry out all adjustments,
carry out maintenance and all of the necessary repairs.
This person is not empowered to carry out interventions on electrical systems with live
voltage.
Electrical Service Engineer
A qualied engineer able to operate the machine under normal conditions, to operate it with
disconnected protections. He/she is in charge of all electrical adjustments, maintenance
and repair.
He/she is able to operate with live voltage inside cabins and shunt boxes.
The Manufacturer’s Engineer
A qualied engineer from the manufacturer to perform complex operations in
special situations or according to that which has been agreed upon with the
user.
General Information
TI008G0001
099100101102103
104
TI008G0001
1.04
General Information
A specic plate on the machine gives the following in-
delible information on the CE MARKING:
Model
Code
Serial number
Year of manufacture
Delivery
Pressure
Power
Number of runs
Dryer
Tank Capacity
Total Weight
Name and address of manufacturer
The “CE MARKING” plate has been applied at the
base of the machine.
The relevant “DECLARATION OF CONFORMITY” has
been attached.
It is forbidden to remove the “CE MARKING” plate and/
or exchange it for other plates of machines of the same
model supplied to the Customer or the operator.
Should the “CE MARKING” plate be accidentally dam-
aged or removed from machine, the customer is required
to inform the Company.
251
602
Identication data of the Manufacturer and the Machine and the location of the nameplate “CE
MARKING”
Ing. ENEA MATTEI S.p.A. is identied as the machine’s manufacturer in conformity with the laws in
force with the following acts:
- Declaration of conformity - CE Marking – Instruction Manual
1.05
General Information
TI008G0001
General notes on delivery
Upon receipt of the machine please check that:
The supply complies with the order specication.
There are no damages due to transportation or other reasons.
(In the event of damage or missing parts, please inform immediately and in detail the forwarding agent
or Ing. ENEA MATTEI S.p.A.)
ALWAYS STATE THE MACHINE SERIAL NUMBER AS WELL AS THE PRINT NUMBER OF THIS
CATALOGUE WHEN MAKING ANY REQUEST TO Ing. ENEA MATTEI S.p.A. OR ONE OF THEIR
SERVICE CENTRES.
Final inspection
The manufacturer carries out the nal inspection of the machine directly, during the production phases,
in compliance with the company quality system.
A certicate of conformity is supplied together with the machine.
Ing. ENEA MATTEI S.p.A. is responsible for the machine under its original conguration.
Ing. ENEA MATTEI S.p.A. refuses any responsibility for improper use of the machine, for damages due
to operations which are not described in this manual or unreasonable jobs.
Safety precautions
The nal user should comply with the instructions given by the seller, concerning:
• safety devices already installed on the machine
• instructions for correct machine installation
• correct use and periodic maintenance of all the machine components, including safety devices
• regulations of current laws
The following safety precautions dene both the behaviour and obligations to be observed when carrying
out the activities listed in the manual, the instructions for the machine use and the way how to operate
under safety conditions, for the staff and the surrounding environment.
Machinary Directive
Machinary Directive means the DIRECTIVE OF THE EUROPEAN COMMUNITY COUNCIL 89/
392/CEE dated 14th June 1989 and its subsequent amendments that modify its content 91/368/CEE
dated 20th June 1991, 93/44/CEE dated 14th June 1993 and 93/68/CEE dated 22nd July 1993.
In June 1998 the Machinary Directive and its subsequent amendments were included into Directive
98/37/CEE without modications.
Machine
Machine means the functional assembly composed of: control unit, processing unit, working and rest-
ing equipment, systems (electrical, pneumatic, hydraulic, cooling, lubrication systems) and any group
completing the system functionality.
Working area
Working area means the protected volume limited by guards to prevent injuries and aimed at operation
during the machine processing.
1.06
General Information
TI008G0001
Authorized staff
Authorized staff means personnel duly trained and appointed to perform the activities listed below and
that make up the operating instructions for the machine.
Appointed staff
Appointed staff means the personnel who, although not participating materially in the work, supervise
the work of others, for example the responsible engineer.
Transport
Transport means all those operations regarding the handling of the machinery or part of it
Installation
Installation means the mechanical, electrical and uid system integration of the machine into a produc-
tion reality, in compliance with specied requirements.
Commissioning
Commissioning means the functional check of the machine installed.
Operation
Operation means the operating mode at which the machine produces compressed air according to all
settings and controls inserted by the control device.
Decommissioning
Decommissioning means to disconnect mechanically and electrically the machine from a production
line.
Dismantling
Dismantling means dismantling and eliminating the machine components.
Maintenance and repair
Maintenance and repair means the regular check and/or replacement of parts or components of the
machine and any action to identify the cause of failure, ending with the machine resetting to the design
operating conditions.
Improper use
Improper use means using the machine out of the limits specied in the technical documentation.
Applicability
The regulations should be applied when performing following activities:
• Transport, installation and setting up
• Manual operation
• Continuous operation
• Decommissioning and dismantling
• Maintenance and repair
that compose the use procedures foreseen for the machine.
1.07
General Information
TI008G0001
Installation and commissioning
“The installation and commissioning are only permitted to authorised staff.
During installation, handle the machine components as indicated in this manual; if lifting is necessary,
verify rst the correct xing of specic devices for lifting and use adequate slings and equipment.
The machine installation should be as free as possible from any material preventing or limiting its
view.
If there are any, remove xing brackets or eyebolt blocking devices, previously tted to allow the trans-
port.
Check that all the machine safety devices are correctly xed and there are no moving or loose parts.
Also check soundness of the control unit components.
Connect the machine pneumatic system to the air distribution system and carefully check that pressure
is set to the correct value.
Check consistency between the voltage set on power transformers and the voltage value of the electri-
cal supply.
Before connecting the machine electrical system, check that the mains isolator is blocked in the open
position.
Verify that accident preventing guards are correctly installed and in perfect state.
According to the different national law regulations, the Customer might be required to inform
the Certied Authorities of the installation and set up and/or to undergo a system check if the
machines are provided with tank (SPV) or pressure devices (PED).
Periodic inspections are also foreseen.
The machine safety is not guaranteed in case of removal, by-pass or tampering of the
safety devices on the machine.
To stop the machine during an emergency, press the emergency stop button.
☞
Operating the machine
Only authorised and duly trained staff or at least with a sufcient technical experience should operate
the machine. The staff in charge of operating the system should be aware that the knowledge and ap-
plication of safety regulations is in an integral part of their job.
Unskilled personnel should not access the operating area and the machine control panel when the
system is live.
Before starting the machine, carry out following operations:
• Carefully read the technical documentation;
• Get information about the operation and position of emergency stop devices on the machine;
• Know which protections and safety devices are tted on the machine, their position and operation.
It is forbidden to either disconnect or partially remove the protections and safety devices. The same
applies for danger signals located in particular areas of the machine. It is strictly forbidden to access
the working area and the control and power cabins during operation of the equipment (even partial) or
immediately after it is switched off.
Protections and safety devices should be kept in perfect state so as to allow right operation; in case of
failure they should be repaired or replaced.
The use of not authorised components and accessories for the protections and safety devices may lead
to malfunctioning and dangerous situations for the operating staff.
1.08
General Information
TI008G0001
Decommissioning and dismantling
Only authorised staff is allowed to decommission and remove the machine.
Before setting the machine out of operation it is necessary to disconnect the mains isolator and block
it in the open position.
Discharge oils and uids, remove all moving parts.
Disconnect the mains isolator cable, by cutting out the power wires and then the earth wire.
Disconnect the power supply cable from the machine main switch and remove it.
Disconnect the machine pneumatic equipment from the air distribution system.
Remove the machine from the working area following the instructions given in this manual. Before lifting
it, verify the correct use of lifting devices and use only suitable equipment.
Waste disposal should be performed in compliance with the laws in force in the country where the ma-
chine is installed.
❑ Installation, setting up and use of compressor should be carried out in compliance with the standards
and the rules in force concerning safety at work.
❑ The owner of the machine is responsible for its good maintenance, an essential condition to ensure
safe operation.
Those machine parts that due to improper use or wear do not ensure safe operation should be
quickly replaced.
❑ Only trained, authorised and skilled staff should perform the installation, use, maintenance and
repairs.
❑ In case of difference between the instructions given in this manual and those foreseen by current
laws concerning safety, it is recommended to apply the more restrictive ones.
Maintenance and repair
Only authorised personnel should carry out maintenance, troubleshooting and repairs.
Any maintenance and repair in progress should be signalled by a specic sign, stating the maintenance
condition and placed on the control panel until completion of the job, even if temporarily interrupted.
All operations for installation, maintenance or replacement of components on the machine or on the
control unit should be performed with switched off system.
Therefore, the main switch should be on OFF (OPEN) position and blocked with the safety lock to prevent
any movement to the ON position.
For compressors equipped with INVERTER, before performing any maintenance job, wait at
least
5 minutes after you have disconnected the electricity supply.
Before acting, people in charge of maintenance should rst check following conditions:
• that any receiver under pressure has been exhausted.
Before intervening on pneumatic or lubricating systems and specically on pipes, receivers, hoses and
other components under pressure, the staff in charge of maintenance should reduce the internal pres-
sure of the plant down to the ambient pressure value.
Faulty components must be replaced with others having the same code.
If during troubleshooting it is necessary to carry out jobs with the control unit and the machine live, all
precautions should be taken, as required by the safety standards to operate under dangerous voltages
and with moving parts.
At the end of the maintenance and troubleshooting jobs, all disconnected safety devices should be
reset.
Maintenance, repair and troubleshooting should be ended by the checking of the machine operation
and of all its safety devices.
1.09
General Information
TI008G0001
Settings to be made by customer
Unless different contractual agreements are taken, the following items are normally at customer’s ex-
pense:
❑ room preparation (including building works, such as foundations or canalizations, etc, if required);
❑ anti-slip, levelled ooring;
❑ observing the dimensions given in the layout drawing when preparing the site and when installing
the machine itself;
❑ preparation of auxiliary services, suitable for the system requirements (such as electricity supply,
pneumatic system, etc)
❑ preparation of the electrical equipment in compliance to Directive 2006/95/EEC;
❑ adequate lighting complying with EN 60204-1 Standard;
❑ any safety devices upstream and downstream of the electrical supply lines (like differential switches,
earthing systems, safety valves, etc) foreseen by the current laws in the country of installation;
❑ earthing equipment complying with CEI 64-8 Standard;
900a
1.10
General Information
TI008G0001
For any kind of information on the use, maintenance, installation, etc. Ing. ENEA MATTEI S.p.A. is
always available to meet the Purchaser’s requests.
However, any enquiry should be made in clear terms, with references to this manual and always stating
the data on the machine id plate.
For any communication with the service centre, always indicate the machine model, the serial number
and year of manufacture, helping to identify every single machine and, when possible, specify the kind of
problem or the defect found, for instance: electrical, mechanical fault or defects in the machining quality,
and describe the same in the “TECHNICAL SERVICE REQUEST FORM” enclosed to this manual.
Please contact the nearest local service department, or refer to the headquarters in Italy.
Instructions on how to order spare parts
In the course of time a machine may need the replacement of those parts subject to wear.
The Purchaser may order the parts to be replaced.
It is compulsory to always buy original spare parts.
To order spare parts always indicate following data with the utmost accuracy:
1 Machine type and model
2 Serial number
3 Exact description of the item
4 Code and/or reference (if available)
5 Quantity
To simplify and speed up the delivery of spare parts, it is suggested to forward orders by compiling the
“SPARE PARTS REQUEST FORM” enclosed with this manual and send it to M.T.A. S.p.A. or to the
closest distributor.
The manufacturer’s address
Any request for intervention of the technical service by the customer or explanations on technical aspects
of this document should be made to:
Technical and Spare Parts Service
Corso Italia, 47 – 24049 VERDELLO - ZINGONIA (Bergamo) - Italy
TEL: +39 - 035/4186400 (Automatic search) FAX: +39 - 035/4186490
C.P. N° 69 Zingonia
075
2.01
General Information - Safety
TI008G0001
• Protection and segregation of the electrical/electronic driving equipment of the machine by metallic
box, to avoid accidental contacts with live equipment in case the metallic box is open; the electric box
is IP 54 protected; IP 20 is the protection degree of the internal devices against accidental contact.
• Suitable panels or protection to cover moving parts.
• Electrical devices to detect faults of the machine electrical supply and malfunction of motor electrical
devices.
To operate the machine under any operating condition, including maintenance, it is not
necessary that more than one person be present.
Using more than one person is superuous and, in any case, not allowed for safety
reasons.
The employer should instruct the staff on the risks of accidents, on safety devices and on the
general rules concerning prevention and protection, as established by the European Community
Directives and by the current legislation in the country where the machine is installed.
The operator should be aware of the location and operation of all controls and of all
the machine features.
The operator should also have read the entire manual.
Only skilled engineers should carry out maintenance jobs, after having duly prepared the
machine.
Any unauthorized tampering or replacement of one or more parts of the machine, or the
adoption of accessories that modify the use of the machine and the use of different ma-
terials than those recommended in this manual, may be a potential risk of accidents.
It is strictly forbidden for the machine to be operated by two persons contemporane-
ously, one inside the guards and one on the control panel.
WARNING !!!
Our machine IS NOT SUITABLE for use in areas with potentially explosive atmos-
phere.
!
098
WARNING !!!
For compressors equipped with INVERTER, before performing any maintenance job,
wait at least 5 minutes after you have disconnected the electricity supply.
!
098
!
!
!
098098901
During the design phase all hazardous areas have
been considered and, therefore, all necessary precau-
tions have been taken to avoid risks to people and
damage to the machine components.
To guarantee both health and safety of those ex-
posed, the machine is equipped with appropriate
safety devices:
• EMERGENCY button to stop the machine immedi-
ately
• Fixed protections. located in areas with exclusive
access for routine maintenance. They are xed by
devices that need special tools for their removal, or
they are locked with screws.
Dangers and residual risks
2.02
General Information - Safety
TI008G0001
After having carefully considered all possible risks concerning the use and maintenance of the machine,
all measures have been adopted to eliminate risks and limit dangers to exposed people.
Although the machine is equipped with safety devices, the following residual risks remain, which can be
eliminated or reduced by the relevant precaution:
• Risk of bruises, tearing, cuts during the handling of tools and/or elements.
• Risk of bruises during machine intervention.
Operation
❑ The operator should use the personal protection devices.
❑ Use the compressor only for the kind of application for which it is designed (air compression for
industrial use).
❑ Before starting, ensure that compressor is lled with oil.
❑ Please refer to Section 8 of this manual for the oil type to be used.
❑ Never operate the compressor if there is a possibility of inhaling smoke or toxic or ammable va-
pours.
❑ Never operate the compressor at higher pressures than those indicated in the id plate.
The air delivered by the compressor must not be used for breathing, although it is ltered
and puried from oil.
❑ If hoses are used to distribute the air, ensure they are properly sized and suitable for the operating
pressure, and not damaged or worn.
Please remember that rubber hoses should be replaced at regular intervals.
❑ Never remove the oil ller plug when the machine is running or there is still pressure inside the
compressor: there would be hot oil leak.
❑ Although it has an acceptable sound pressure level, the machine can produce a much higher noise
if the room is narrow and reverberating. Please note that the continuous presence of an operator
is unnecessary.
For safey against noise, in compliance with local laws in force, and if necessary, place specic warn-
ing signs near the machine and equip personnel with suitable protections.
Installation
Besides fullment of rules and regulations issued by the authorities, it is recommended to con-
sider the following:
❑ The compressor will perform most efciently if installed in a suitable, well ventilated area and far
from heat sources.
❑ Should any duct be installed for the suction and cooling of air, always use the data and recommen-
dations given in Section 4 and preferably obtain expert advice during the design stage.
❑ In case of outdoor installation (not suggested for very cold climates) it is necessary to place the
machine under a roof or covering, to protect it against weather.
❑ Be careful that no foreign materials clogg the radiator and cause rises of the operating tempera-
ture.
❑ The intake air must be clean and free from ammable vapours, which could cause res or explo-
sions.
❑ As the machine is air cooled, adequate ventilation must be ensured to prevent it from overheating
and thus avoiding the recirculation of the expelled hot air.
❑ Control and safety devices should never be tampered with.
❑ If one or more compressors are installed on a single pneumatic line, it is essential that each unit is
equipped with a detect valve.
❑ Electrical connection should be conforming to current regulations. The machines should be earth
connected and protected by a magneto-thermal switch against possible short circuits.
❑ It is essential to install a mains isolating switch upstream of the compressor.
2.03
General Information - Safety
TI008G0001
Maintenance
The person responsible for operation of the compressor should check periodically that all instructions
for operation and maintenance are followed by the operator.
WARNING !!!
Fill in the specic “Maintenance Sheet” supplied with the machine.
Only trained staff should carry out maintenance, with the compressor off and with no pressure inside the
same. Also disconnect the compressor from the pneumatic equipment.
Cut out the electricity supply by acting on the mains isolator located upstream of the compressor electric
board and indicate with a special sign that the machine MUST NOT BE RESTARTED.
WARNING !!!
An adequate cleaning of both the machine and the place where it is installed is highly
recommended.
For cleaning DO NOT USE ammable uids or products not complying with current
regulations.
In case of doubts about the compressor operation or of any of its components, it is
recommended to contact the after sales service of Ing. Enea Mattei S.p.A.
The following should be also considered:
❑ Before intervening on the machine, disconnect the electrical supply by means of the mains isolator.
In fact, the machine is equipped with an automatic start system, starting the same at any time, if
required by the compressed air system.
❑ The key for opening/closing the electric box doors should be given only to skilled personnel.
❑ Maintenance operations should be always carried out with compressor not operating.
❑ Before carrying out any job on the compressor unit, ensure through the gauge that there is no pres-
sure inside.
❑ Only use suitable tools for the kind of job.
❑ Never use solvents and ammable products to clean the machine or individual parts.
❑ Never carry out weldings or other jobs requiring considerable heat near the machine, specically
near the electrical system and the oil circuit.
❑ Do not make modications or weldings on vessels under pressure.
❑ Do not leave tools, rags or other loose items on the motor or on the compressor.
❑ The lubricating oil, especially if exhausted, may damage the skin: protect hands with gloves or spe-
cic protecting products for the skin.
❑ Do not wear clothes contaminated by lubricating oil
❑ Absolutely avoid contaminating the ground with lubricating oil.
❑ To prevent pollution, store the exhausted lubricant into suitable containers and in a safe place. For
oil disposal follow what suggested by internal rules and current regulations.
❑ In case of topping up, use the same oil as already contained in the machine.
Mixtures are harmful for both the oil and the compressor life.
❑ After any maintenance, start the machine and check that all control, stop or alarm devices are work-
ing correctly; also verify that temperature and pressure values are the correct ones.
❑ Make checks and overhauls as foreseen in this Manual, and use only original spare parts.
Failing to make checks or using non original spare parts may cause problems that jeopardize the
machine operation and the manufacturer’s warranty will be no longer valid.
!
098
!
098
2.04
General Information - Safety
TI008G0001
Responsibilities
Ing. Enea MATTEI S.p.A. refuses any responsibility for injuries to people, animals or damages to objects,
caused by:
❑ non-observance of the mentioned precautions;
❑ improper use of compressed air or of the machine in general;
❑ non-observance of normal safety regulations or domestic rules in the work eld;
❑ non-observance of the instructions during handling and transport of the machine;
❑ wrong machine installation;
❑ defects due to the electric power distribution;
❑ lacks in periodic maintenance;
❑ unauthorised jobs or modications;
❑ use of non original or unsuitable spare parts for the involved model;
❑ non-observance of the instructions, even if only partially;
❑ possible inefciencies caused by malfunction or non-use of the compressor
WARNING !!!
It is recommended to use the compressed air delivered directly by compres-
sors only for manufacturing processes. For any other use, please ALWAYS
CONTACT the distributor, the technical service or the manufacturer BEFORE-
HAND.
!
098
900a
2.05
General Information - Safety
TI008G0001
Description of Pictograms
Pictograms have been applied on the machine to
explain following situations:
Danger
Obligation
Prohibition
Special indications (example: direction of rotation
of the fan, etc)
Many accidents are often caused by the non-
observance of the simplest safety rules or poor
knowledge of the instructions given by the manu-
facturer.
To avoid possible danger situations, some of them
are highlighted through special signs represented
by suitable standardized symbols (pictograms).
Below is the list of the most common symbols ap-
plied to our machines:
Danger pictograms
These triangular signs are framed in black with a yellow background and the symbol is black.
Warning !
The machine is with remote control
or with automatic system and may
start without notice.
Warning !
Vessel under pressure.
Warning !
Risk of high temperature surface
(> 70 °C)
Warning !
Air delivery.
Warning !
Risk of electrical shock.
Prohibition pictograms
These circular signs are framed in red, with white background and the symbol is black.
No pressure in
the receiver.
No working on
the machine.
No voltage.
002907
105
106
107
108
109
110
111
112
2.06
General Information - Safety
TI008G0001
Description of Pictograms
Obligation pictograms
These are circular signs on a blue background, and
the symbol is white.
Read the instructions manual before
carrying out any operation on the
machine.
Use individual protective means
against noise.
Indication pictograms
These signs may vary in shape and
they give useful information.
Lifting point.
Direction of rotation.
003908
909
113114
115
116
Oil level
209.2
Combination of pictograms
The above shown combination of pictograms
means:
Warning ! Please refer to the Instruction Manual
before starting any activity.
118
Possibility to carry out jobs.
117
TI008G0001
3.01
Description of the Machine
Mattei rotary compressors of the AC Series are the result of over
80 years of investments in research and development, to improve
performance continuously, and at the same be environment-friendly.
The modulation operating mode is not available for compressors
of the AC 6000 series.
Designed for continuous industrial service, they guarantee constant
performance over time, low energy consumptions, reliability, func-
tionality and easy maintenance.
The compressor is supplied complete with all components described
below and equipped with optional devices.
Unless differently required, the unit is lled with Mattei Rotoroil 8000
F2 synthetic lubricant.
For special requirements regarding lubricant, please refer to section
8 of this manual.
937 936
Table of contents
Other Mattei Air Compressor manuals
Popular Air Compressor manuals by other brands
Robuschi
Robuschi ROBOX SCREW Series Operating and maintenance instructions
BUSCH
BUSCH MINK MM 1144 BP Installation and operating instructions
Clas Ohlson
Clas Ohlson LC04031 manual
Campbell Hausfeld
Campbell Hausfeld Oil Lubricated Portable Air Compressors operating instructions
Beta
Beta 1937N10 instructions
Joy
Joy TWISTAIR III Operator's manual
