Mattel Juice Box User manual

™
MM
MMPP PP33 33 aa aann nndd dd PP PPhh hhoo oott ttoo oo VV VViiiiee eeww wwee eerr rr 11 11....00 00
II
IInn nnss sstt ttrr rruu uucc cctt ttiiiioo oonn nnss ss
CC
CCoo oonn nntt ttee eenn nntt ttss ss
Software Requirements
Installing The Software
Getting Started
Running Juice Box™ Software
Downloading Music or Pictures
Ripping Music from CDs
Using your Selections with the Juice Box™ player
Quickstart
Juice Box™ player FAQ
SS
SSoo ooff fftt ttww wwaa aarr rree ee RR RRee eeqq qquu uuiiiirr rree eemm mmee eenn nntt ttss ss
The following system is required to run the Juice Box™ card reader software:
Personal computer running Windows® 98SE or higher operating systems.
500 MHz processor or greater.
128 MB of available RAM.
100 MB of available hard drive space.

CD-ROM drive.
Built-in USB port.
Color monitor with minimum resolution of 800x600 pixels; High Color (16-bit) or True Color
(24-bit) recommended.
II
IInn nnss sstt ttaa aalllllllliiiinn nngg gg tt tthh hhee ee SS SSoo ooff fftt ttww wwaa aarr rree ee
This program was designed and manufactured to work within existing industry standards.
Computers with Windows® 2000, Windows® XP or Windows® XP Pro may need
administrator privileges to install this software. See your computer user's guide for
details.
1. Insert the Juice Box™ card reader software CD into your CD-ROM drive.
2. If the AutoPlay feature is enabled for your CD-ROM, left-click on the Install button and
skip the next two steps.
3. If you don't have AutoPlay enabled, left-click on the Start Menu. Then select Run from
the Windows® Taskbar.
4. Type d:setup.exe (d: refers to your CD-ROM drive. If your CD-ROM drive letter is not d:
please use the appropriate drive letter instead.)
5. Follow the instructions that appear on your screen.
After installation is complete, you will find an icon for the Juice Box™ card reader
software on your desktop. You will also find an icon in the Juice Box™ menu item within
Programs under the Start Menu in the Windows® Taskbar.
Caution: After installing the Juice Box™ Card Reader software, you must have the USB-
compatible card reader plugged into the computer in order to access all of the functions
of this software.
GG
GGee eett tttt ttiiiinn nngg gg SS SStt ttaa aarr rrtt ttee eedd dd
Installing the USB Card Reader

In order to transfer music or pictures from your computer to the Juice Box™ player, you
must have your USB-compatible card reader installed. The reader can be plugged into any
USB port available on your computer.
Using a USB Extension Cord (if needed)
If your USB port is located in the back of the computer, you can use the USB cable as an
extension so that your card reader is still accessible from the front.

Creating a Juice Box™ formatted chip
The Juice Box™ media player tags most SD or MMC storage chips with a special code so
that the Juice Box™ software recognizes the chip as suitable for downloads. Tagging a
chip takes a few simple steps:
Take the new SD or MMC storage chip and insert it into the Juice Box™ Flash Card
adapter, label-side up. The Flash Card adapter is a converter that allows standard storage
chips to act like Juiceware™ media chips.
Insert the loaded Juice Box™ Flash Card adapter (label-side up) into a Juice Box™ media
player.
Turn on the Juice Box™ media player.
The Juice Box™ media player will automatically tag your storage chip with the proper
code. First, turn OFF the Juice Box™ media player, then take the storage chip out of the
Flash Card adapter, insert it into the card reader and it's ready to use!

RR
RRuu uunn nnnn nniiiinn nngg gg JJ JJuu uuiiiicc ccee ee BB BBoo ooxx xx™™ ™™ SS SSoo ooff fftt ttww wwaa aarr rree ee
In order to access all of the features of the Juice Box™ software, a card reader with a
properly formatted chip must be connected to your computer.
After properly installing it, you can access the Juice Box™ software by clicking on the
Juice Box™ icon on your desktop or by going into the Start Menu and finding
the Juice Box™ icon under your Programs menu.
The following features can be found within the Juice Box™ program:
Import
Allows you to import files to enter into either the picture or music library.
Delete
Deletes highlighted files in either the picture library, the music library, or from off
the storage chip.
Download
Downloads highlighted files from the music or picture library to a properly
formatted SD or MMC storage chip.
Rip CD
Loads in the CoffeeCup® CD & MP3 Ripper (powered by CoffeeCup® software),
allowing you to take songs from a CD and drop it into your music library.
Settings
Allows the user to change the default directory for the picture or music libraries.
Help
Pulls up the instruction manual.

DD
DDoo ooww wwnn nnlllloo ooaa aadd ddiiiinn nngg gg MM MMuu uuss ssiiiicc cc aa aann nndd dd PP PPiiiicc cctt ttuu uurr rree eess ss
To download files to play on your Juice Box™ media player, first click on the Library tab -
either Music or Picture - which you want to use. You can then import files into the chosen
Library by clicking the Import button.
The Import button takes you to a default directory (generally, the My Music or My Pictures
directory on your desktop computer). You can either select files from that directory or use
the taskbar to navigate to another directory.
Highlight the files you want to load and then double-click on them (for a single file) or
press Enter to import multiple files. If you are trying to import music and picture files at
the same time, the Juice Box™ software will automatically sort them into the appropriate
library.

The selected files will then be copied to the Juice Box™ Libraries. Your music can be
sorted through its ID3 tag, allowing cataloguing by Name, Artist, or Album. Pictures are
simply arranged alphabetically.
You may then download the files to your SD or MMC storage chip simply by highlighting
the files in your library and pressing the Download button. You can continue to download
files in this manner until the storage chip is filled. The status of the storage chip's memory
is presented at the bottom of the screen with a graphical representation showing how
much free memory is left.
MM
MMuu uuss ssiiiicc cc DD DDee eett ttaa aaiiiillll
The storage chip that comes included with the Juice Box™ MP3 Starter Kit holds 32Mb of
storage, approximately a CD's worth of music.
The maximum bitrate playable on the Juice Box™ media player is 128kbps. While songs
with higher bitrates may be loaded onto the storage chip, these songs will experience

drop-out and decompression problems when played on the Juice Box™ media player and
may stop the player from working altogether without warning.
PP
PPiiiicc cctt ttuu uurr rree ee DD DDee eett ttaa aaiiiillllss ss
The Juice Box™ software recognizes JPG, BMP, PNG, and GIF picture formats.
Pictures downloaded to the storage chip are converted to a .jbp (Juice Box™ Picture)
format. The resolution of this format is 240x160.
Double clicking on a picture will preview it in the new format; on some personal
computers this may make the picture appear smaller and less sharp. Such issues will be
immediately resolved when the picture is shown in its proper format on the Juice Box™
player.
PP
PPrr rree eevv vviiiiee eeww wwss ss
You can preview the file you want downloaded by double-clicking on it with the mouse.
MP3s will play by accessing whatever MP3 music program you have designated as your
default player in Windows® operating system. If you Don't have an MP3 player installed
on your PC, you will not be able to preview an MP3. You can download one from
www.winamp.com
Pictures will appear in their .jbp format, at a resolution of 240x160. They may also be
rotated so that the picture is oriented correctly for display.
RR
RRiiiipp pppp ppiiiinn nngg gg ff ffrr rroo oomm mm CC CCDD DDss ss
Utilizing CoffeeCup® software, the Juice Box™ program allows you to 'rip' songs off of a
standard CD and download them to a properly formatted SD or MMC chip.

To rip songs, do the following steps:
Insert your CD into the CD-ROM drive.
Left-click the Rip CD button.
The song information for the CD should list automatically. This software reads the CD
information contained in the id3 tags and will reveal it in the track list.
Select the track(s) you want to rip by clicking on the check box to the left of the songs or
click the topmost check box to highlight all of the songs.
Click the Make MP3s button to start the ripping process.
Caution: For the program to operate properly, your display font size must be set to 96 dpi
or higher. Right click on your desktop and select Properties, select the Settings tab and
click on Advanced. You should be able to change the font setting under the General tab.
The program displays each song's progress through the Status bar, which graphically
represents how much longer you have until full extraction.

The Ripping Menu also has three other features: Settings, Edit Album, and Burn CDs.
Settings
Settings lets you alter the bitrate setting of the music you are trying to record. Please
remember that the Juice Box™ player does not support bitrates higher than 128kbps.
