Introduction
Windy31Characteristics
ScenarioI/II
1.Featuresandconfiguration
1.1Features
1.2Configuration
1.3ProductDescription
1.4InstallationRequirements
1.5StructureDiagramofWindy31
2.InstallationWindy31‐11n
2.1beforeInstallation
2.2Windows7
2.3WindowsVISTA
2.4WindowsXP
3.HowtousedWindy31‐11n
3.1Windy31ManagerSetting
3.2WirelessLANAdapterSetting
4.OptionalConfiguration
4.1WirelessLANconnectioninWindowsVISTA
4.2WirelessLANconnectioninWindowsXP
4.3DirectlyinputIPAddress
5.TroubleShooting
Contents
3
5
7
13
18
23
2

Introduction
TheUSB‐typewirelessportablegatewaythatcombinesaWireless
Router,AccessPoint(AP)andWirelessLANAdapter allinone!
Allthreeofthesefunctionsallowtheusertotrulyexperiencewireless
freedom,aswellastheconvenienceofportability.
Becauseofitssmallsize,userscanvirtuallycarryitwherever theygo.
ConvenientlybepluggedrightintoyourPC,PDA,orlaptop’sUSBport
3‐in‐1WirelessBroadbandRouter
1. WirelessBroadbandRouter
TheWindy31ishighlyportableanduserfriendly,allowingthehosttoeasilyconnect
othersurroundingWi‐Fienabledproducts,suchaslaptops,PDAs,andWi‐Fiphones
totheinternetwithoutthehassleofwires.
2. WirelessLANAdapter
TheWindy31canconvenientlybepluggedrightintoyourcomputer,PDA,orlaptop’s
USBport.Youcanwalkintoanycafé,library,office,school,airport,oranyother
placethatprovideswirelessinternetservice,andlettheauto‐runinstallation
programdotherest.
3. WirelessAccessPoint(WAP)
TheWINDY31canwirelesslynetworkupto32differentclientstogetherbybeing
pluggedintoasinglehostcomputer.Manageallyourlocalnetworks,easily
sharedocuments,andbestofall,gowireless!
WINDY31Characteristics
Auto‐installationwithoutaCD
Easymode‐changingfromLAN/AP/Router
ConvenientUser‐Interface
WindowsVista/7Compatible!
3

ScenarioI
IfyouwanttoaccesstheinternetinapublicareasuchasaSeminar,
TradeShow,Library,Hotel,orAirport:
‐Existing :Onlyawirelessinternetservicesubscribercanusetheinternet
‐Windy31 :PlugtheWindy31intoanycomputerthatisconnectedtothe
internet,andyoucanusetheinternetservicethroughyourlaptop
ScenarioII
Ifyouwanttoshareyourinternetconnectionwithfriendsorco‐
workerswithoutpayingforeachadditionallineatawireless
serviceprovidedfromAirport,Hotel,Conferenceroom,Tradeshow,etc.
‐Existing :Nochoicefornon‐subscribers.Youhavetopayforeachuser.
‐Windy31 :PlugtheWindy31intothesubscriber’scomputerandsharethe
connectionwithfriendsandco‐workersatnoadditionalcost.
Client2Client1Client3
InternetISP)
WiFi‐Pone
WINDY31
Client3
Internet(ISP)
Router Hub
Client1
WiFi‐Pone
Client2
HOSTPC
Windy31typicalConfiguration(AtHomeorOffice)
4

1.1Features
Convenienttouseanywhereandanytime
‐Portable,slimandcompactdesigntofitinonehand(USBmemorysticksize)
‐Theonlythingrequiredisinternetconnectedcomputer,easyandfastinternet
connectionsharing
Fastinstallationandeasysetting
‐ConnectWindy31intocomputerforautoinstallationofdriverandutilityprograms
(SeparateinstallationCDanddrivernotnecessary)
‐EasyGUI‐typesettingscreen
Speed
‐SupportWireless802.11b(11Mbps)speed
802.11g(54Mbps)speed
802.11n(Max.150Mbps)speed
Security
‐AccesscontrolwithWEP(64,128bit)/WPA‐PSK/WPA2‐PSK(ASE)andMACaddress
1.2Configuration
PleasecheckWindy31productconfigurationsasshownbelow.
Pleasecontacttheselleryoupurchasedfromimmediatelyif contents
ofproductisdamagedormissing.
1.3ProductDescription
USBtypeBroadbandRouter QuickinstallGuide
1.Featuresandconfiguration
5

1.4InstallationRequirements
BeforeinstallingWindy31,Pleasecheckwhetheryourcomputer
configurationmatchestherequirementsshownbelow.
‐IntelPentiumIVorabove
‐512Mbytessystemmemoryorabove
‐WindowsXP/VISTA/7OperatingSystems(Supportauto‐installationforWindows
XPorabove)
‐USB1.1orUSB2.0
‐Requiresmorethan30Mbytesofusableharddiskspace
Internet
(ISP)
•x‐DSLModem
•CableModem
•ExclusiveLine
•PPP
•Nespot
•HSDPA
•WIBRO
•AutoInstallation
•DynamicLoading
PSP
Nintendo
PDA/PMP
PC/Laptop
i‐phone
upto32clients
Wi‐FiPhone
6
1.5Configuration
6

2.1UsagePrecautions
Checklistbeforeinstalling
1. PleasebesurethatWindy31mustbeinsertedtoacomputerwhich isconnectedto
Internet.
2. ComputertobeinstalledwithWindy31musthavemorethanoneLANAdapter.
3. PleasecheckyourcomputerforVirusandSpyware,beforeinstallation.SomeViruses
andSpywaresmayinterferewithautomaticinstallationofWidny31driverandutility
programs
Installation
1)InsertWindy31intoUSBportofLaptoporDesktopPCandprogramwill
automaticallyrunasshownbelow.
2)Afterprograminstallation,thefollowingscreenwillappear oneafteranotherin
theright‐sideofWindowsTaskbar,showingthattheUSBdeviceacknowledges
andisinstallingWindy31.
2.2Windows7
2.InstallationWindy31
7

2)Pleasewaituntil“Windy31GatewayManager” windowappears,“Windy31settingin‐
progress"and"settingcomplete"windowsaredisplayedasshownbelow.This
processwilltakesomeminutesasitisinstallingtheWindy31Gateway.(Installation
timemaydifferaccordingtocomputerconfiguration)
3)InStep3,After“Programhasbeensuccessfullyinstalled“ appears,click“OK”.Then,
Windy31hascompletedinstallation.
ConnectionmethodmaydifferaccordingtoWirelessLANdevice,pleaserefertoWireless
LANusagemethod.(Forwirelessdeviceusagemethod,pleaserefertowirelessdevice
productmanualorpleasecontacttheprovider.)
Duringinstallation,WindowsSecurityAlertmaydisplay“Keepblocking” &“Unlock” pop‐
upforsecurity,pleaseselectthebutton“Unlock”.(Ifyouselect“Keepblocking” blocked,
thentherewillbenonetworkconnection.)
8

1)InsertWindy31intoUSBportofLaptoporDesktopPCandprogramwill
automaticallyrunasshownbelow
2)Afterprograminstallation,thefollowingscreenwillappearoneafteranotherin
theright‐sideofWindowsTaskbar,showingthattheUSBdeviceacknowledges
andisinstallingWindy31.
Duringinstallation,WindowsSecurityAlertmaydisplay“Keepblocking” &“Unblock” pop‐
upforsecurity,pleaseselectthebutton“unblock”.
(Ifyouselect“keepblocking” blocked,thentherewillbenonetworkconnection.)
①②
③
Installation
2.3WindowsVISTA
9

3) Pleasewaituntil“Windy31GatewayManager” windowappears,“Windy31settingin‐
progress"and"settingcomplete"windowsaredisplayedasshownbelow.
ThisprocesswilltakesomeminutesasitisinstallingtheWindy31Gateway.
(Installationtimemaydifferaccordingtocomputerconfiguration)
4)InStep3,After“Programhasbeensuccessfullyinstalled“ appears,click“OK”.Then,
Windy31hascompletedinstallation.
ConnectionmethodmaydifferaccordingtoWirelessLANdevice,pleaserefertoWireless
LANusagemethod.(Forwirelessdeviceusagemethod,pleaserefertowirelessdeviceproduct
manualorpleasecontacttheprovider.)
1010

1)InsertWindy31intoUSBportofLaptoporDesktopPCandprogramwill
automaticallyrunasshownbelow.
①②
2)Afterprograminstallation,thefollowingscreenwillappear oneafteranotherin
theright‐sideofWindowsTaskbar,showingthattheUSBdeviceacknowledges
andisinstallingWindy31.
Duringinstallation,WindowsSecurityAlertmaydisplay“Keepblocking” &“Unblock”
pop‐upforsecurity,pleaseselectthebutton“unblock”.(Ifyouselect“keepblocking”
blocked,thentherewillbenonetworkconnection.)
Installation
2.4WindowsXP
11

3) Pleasewaituntil“Windy31GatewayManager” windowappears,“Windy31settingin‐
progress"and"settingcomplete"windowsaredisplayedasshownbelow.
ThisprocesswilltakesomeminutesasitisinstallingtheWindy31Gateway.
(Installationtimemaydifferaccordingtocomputerconfiguration)
4)InStep3,After“Programhasbeensuccessfullyinstalled“ appears,click“OK”.
Then,Windy31hascompletedinstallation.
ConnectionmethodmaydifferaccordingtoWirelessLANdevice,pleaserefertoWireless
LANusagemethod.(Forwirelessdeviceusagemethod,pleaserefertowirelessdeviceproduct
manualorpleasecontacttheprovider.)
12

Config
3.1Windy31GatewayManagersetting
①SSID:Nametobeusedinwireless(DefaultisWindy31‐XX)
②MCS:Assign11ndatatransmissionspeed
③Channel:Assignwirelesschannel,automatically.
④WirelessMode:AssignwirelessLANmode(802.11b=11Mbps/802.11g=54Mbps)
⑤UseMacaddress:AssignSSIDasMACaddress.
⑥SecuritySettings:Assignwirelesssecuritysettings
(Pleaserefertotheinstallationguideformoredetails)
⑦Area(Countrycode):Assignchannelrangeusedbyeachcountries.
⑧WirelessLANconnectionlist:Listofwirelessdevice'sMACaddressconnectedtoWindy31.
⑨Bridgeadapter:AllowInternet‐connectednetworkcardchange
⑩SwitchtoLANcardmode:ButtontouseWindy31asLANAdapter.
(InLANAdaptermode,Windy31Gatewayfunctionscannotbeused)
ScreenshownbelowisWindy31GatewayManagerSettingscreen.
Formoreinformation,Pleaserefertoourwebsite[www.windy31.com]
1 2 3
456
8
9
7
10
3.Windy31ManageSetting
13

About
AccessControl
Internetaccessbyotheruserscanbecontrolledin“AccessControl” menuofWindy31
Gatewaybelow.
Softwareupgrade
①Disable:DisableAccessPolicy.
②AllowAll:AlltheMacaddressesaccesstotheinternetlisted inthetablecanbe
accessedtotheinternet.
③RejectAll:AlltheMacaddresseslistedinthetablecannotbeaccessedtotheinternet.
Click“AutoUpdate”,toconfirmthatyouareusingthelatestsoftware.Ifyouarecurrentlyusing
theoldsoftware,thesoftwareupdatewillbeappeared.
14

3.2WirelessLANAdaptersetting
①SelectAPasconnectionmodefromAPlist
②Rescan :ScanWirelessAP
③Connect :ConnecttoselectedAPwithwireless
④AddtoProfile :AddtheselectedAPtoProfile
⑤SwitchtoGatewaymode:SwitchtoWindy31WirelessRoutermode
HowtoconfigurePCsettingforusingWindy31asWirelessLANAdapter.
RouterMode(GW‐mode)whenchangingmodesinGWGatewaywindow
manager“switchtoLANCardMode"buttonshouldbe.
WirelessLANconnection
Formoreinformation,pleaserefertoourwebsite[www.windy31.com]
¾WINDOWSVISTA/7
ScanAP AddtoProfile Profile
Selectprofile OK
1 2 3 4
5 6
SelectAP
15
1
23
4
6

SiteSurvey
3.Connect2.SelectAP
①SelectAPasconnectionmodefromAPlist
②Rescan :ScanWirelessAP
③Connect :ConnecttoselectedAPwithwireless
④AddtoProfile :AddtheselectedAPtoProfile
⑤SwitchtoGatewaymode:SwitchtoWindy31WirelessRoutermode
1.ScanAP
HowtoconfigurePCsettingforusingWindy31asWirelessLANAdapter.
RouterMode(GW‐mode)whenchangingmodesinGWGatewaywindowmanager
“switchtoLANCardMode"buttonshouldbe.
WirelessLANconnection
Formoreinformation,pleaserefertoourwebsite[www.windy31.com]
¾WINDOWSXP
16

LinkStatus
Profile
①SelectAPtoconnect
②Add:Addtoprofile.
③Delete:DeleteProfileordisconnectwirelessconnection
④Edit :Modifyprofileconfiguration
⑤Activate :connecttotheselectedAPwithwireless
(Mustclick“Activate” buttonforusingwirelessservice)
LinkStatusdialogbelowshowswirelessspecificconnection
Formoreinformation,Pleaserefertoourwebsite[www.windy31.com]
17

4.1WirelessLANconnectioninWindowsVISTA/7
TousewirelessLANservice,WirelessLANAdaptermustbeinstalledinyour
computer.
‐WirelessLANconnectionprogram(WLANAutoconfig)isembeddedinWindows
VISTA.
‐Ifwirelessserviceisdisabled,wirelessLANcannotbeused.
‐PleaserefertoWindowsVISTAusermanualforfurtherinformationonwireless
LANAutoconfig.
PleaserefertotheproductmanualofWirelessLANAdapterpurchasedorcontact
WirelessLANAdaptermanufacturers/salesrepresentativesforinstallinguser'swireless
LANAdapterorapplicationprogram.
Start ControlPanel NetworkandSharingCenter
OptionalConnection
Managewirelessnetworks
4.OptionalConfiguration
18
18

Addanetworkthatisinrangeofthiscomputer Connect
‐"SuccessfullyconnectedtoWindy31‐xx."messageappearsandcheckbox“Savethis
network” savedthen,click"Close"buttontocompletewirelessnetworkconnection.
19
Windy31‐XX
Connect
19

Start ControlPanel
‐Ifthemessage"ThiscomputerisconnectedtoUnidentifiednetwork"appears,
click“Addition” buttoninwirelessnetworkmanagementandcheckthefollowing
serviceitem.
NetworkandSharingCenter Managewirelessnetworks
WLANAutoconfig
‐Confirmwhetherservicehasbegunnormallyaftertheselectionof
"WLANAutoconfig"inservices(Local).
20
Start ControlPanel AdministrativeTools Service
20
