Maverick ET-733 REDI CHEK User manual

INSTRUCTION MANUAL MODEL ET-733 REDI CHEK
WIRELESS BBQ & MEAT THERMOMETER
Introduction
Congratulations on your purchase of the ET-733 REDI CHEK BARBECUE Thermometer, a
programmable radio frequency food thermometer. You will now be able to remotely monitor the
temperature of grilling food and the temperature inside your grill from anywhere in your home.
Components
1. 1– Receiver unit
2. 1– Transmitter unit
3. 2– Detachable stainless steel probes to be used for both Food and BBQ
4. 2– Probe clips
5. 4– AAA batteries.
Receiver Features
3
5
4
6 8
7
● LCD(LiquidCrystalDisplay)–Displaysallicons,temperatureandtime.
● BATTERYCOMPARTMENT–Holds2AAAbatteries.
● STAND–Swingsoutandallowyoutostandthereceiverontabletop.
Buttons
1. Power–PresstoturnON/OFFthereceiver.
2. ALERT, ºC /ºF–PresstoturnON/OFFthealarm.Pressandholdfor2secondstoswitchbetween
ºC and ºF display.
3. LIGHT/MODE–PresstoturnontheLCDbacklightfor5seconds.Presstoswitchbetween
BarbecueandFoodwhileinSETup.
4. SET–Pressandholdfor2secondstoenterSETup.
5. HI–Switchesbetweenprobe1andprobe2duringSETup.RaisesBarbecueandFoodset
temperatures. Press and hold for 2 seconds to increase 10 degrees per.
6. LO–Switchesbetweenprobe1andprobe2duringSETup.LowersBarbecueandFoodset
temperatures. Press and hold for 2 seconds to decrease 10 degrees per.
7. TASTE–PresstochangethedonenesssettemperatureofMeatselectedwhileinSETup.
8. MEAT–PresstochangetheMeatselectedwhileinSETup.
Receiver LCD
ThereceiverLCDisseparatedinto3elds.
TheUpperelddisplaystheProbe#1or2,theModeBARBECUEorFOODandifintheFOOD
modetheMEATandTASTE.
TheMiddleelddisplaystheSETtemperatureandtheactualtemperatureforProbe1.
TheBottomelddisplaystheSETtemperatureandtheactualtemperatureforProbe2.
Transmitter Features
● LCD(LiquidCrystalDisplay)–displaystemperatureofbothprobe1andprobe2.Itwill
automatically switch between probe 1 and probe 2 displays.
(Note: Press the re-sync button to switch the display between ºC and ºF.)
● WIRESTAND–Allowsyoutostandthereceiverontabletoporitcanbereversedandusedas
a hanger.
● BATTERYCOMPARTMENT–holds2AAAbatteries.
● 1 – Plug-in for stainless steel probe.
● 2 – Plug-in for stainless steel probe.
Buttons
1. Re-sync – Transmit manually, terminates the auto registration process. Press and hold for 2
seconds to register the radio frequency with the receiver.
Press to select the temperature unit between ºC and ºF.
2. Power –Pressandholdfor2secondstoturnsON/OFFthetransmitter.
Installing batteries
Openthebatterycompartmentofthereceiverandinserttwo“AAA”batterieswithcorrect
polarity.Openthebatterycompartmentofthebyremovingthetwosmallscrewsandinserttwo
“AAA”batterieswithcorrectpolarity.
Registering Receiver & Transmitter
TheBarbecueThermometerneedsthereceivertoregisterandlockintheradiofrequencysignal
from the transmitter, every time the device is turned on. Proceed as follows to register.
1. Plug the stainless steel probe sensors into the corresponding plug in of the transmitter.
Note: The probes are identical and can be used for either meat or barbecue.
2. Turn on the receiver by pressing the power button 2 seconds.
3. Turnonthetransmitterbypressingthepowerbutton2seconds,foundonthebackofthe
transmitter. This needs to be done within 120 seconds of turning on the receiver in order for
the receiver to receive the Registration Code from the transmitter. If it doesn’t beep within
5-10secondsandthe“---”shownonLCDwasashingorissolid,pressthepowerbutton 2
secondstoturnOFFtheTransmitterandthenturnbackON.PressingandholdingtheRESYNC
button for2secondswillgetthesameresultasturningthetransmitterOFFandthenON.
4. Registration is completed when the unit beeps and the probe temperatures will appear on
LCD.
Loss link alert
IfthereceiveristakenoutofrangeorthereisabnormalexternalinterferenceoraftershuttingOFF
the transmitter, the receiver may not be able to receive the transmission from the transmitter. If
this happens over 4 minutes, the unit will alert you by beeping once for every 4 seconds to tell you
tore-syncthesignal.PressinganybuttononReceiverwillstoptheLossLinkbeep.
Toregaintransmissionsignal,movethereceiverclosetothetransmitter,turnOFFtheReceiver
andthenturnbackON.PressandholdtheRESYNCbutton of the transmitter 2 seconds within
120 seconds and the temperatures should appear on the receiver display.
Remarks:
According to FCC Part 15.231(e) rule, the RESYNC button can be activated once every 12
seconds manually. If the re-synchronization doesn’t succeed 1st time, wait for 12 seconds before
pressing & hold the RESYNC button again. Or you can press and hold the power button 2
seconds to turn OFF the Transmitter and then turn back ON again. It will produce the same result.
You can monitor 2 things at once and you select what you monitor. 1 Food and 1 Barbecue or 2
Foods or 2 Barbecues.
Food or Barbecue Mode selection
PressandholdtheSETbuttonfor2seconds.TheProbe#willashintheupperlefthandcorner.
Either(1)or(2).Whiletheprobe#isashingpresseithertheHIorLObuttontoswitchbetween
probe1orprobe2.PressSETbuttontoselectaprobe.
OnceaprobeisselectedeitherFOODorBARBECUEwillash.PressMODEbuttontoswitch
betweenFOODorBARBECUE.
IfFOODisselectedaMeat(Example:BEEF)willappearintheupperLCDeldandaHISET
temperaturewillappearinthemiddleeldifprobe1orinthebottomeldifprobe2.If
BARBECUEisselectedtheupperLCDeldwillbeempty.HISETandLOSETtemperatureswill
appearinthemiddleeldifprobe1orinthebottomeldifprobe2.
PressSETbuttontosetthemodeordon’tpressanythingandinafewsecondstheunitwillsetit.
Food selection
IfyoupressedSETinFOODmodethentheMeatwillashintheupperLCDeld.
FromthispointyoucanselectaMEAT,selectaTASTE(doneness)andyoucanmodifytheTASTE
set temperature to you own personal settings.
PressMEATbuttonandyouwillscrollthroughthe15pre-programmedmeatsBEEF,VEAL,LAMB,
PORK,CHICKEN,TURKEY,DEER,ELK,MOOSE,BUFFALO,RABBIT,BOAR,DUCK,BIRDANDFISH.
WhiletheMeatisashingpressTASTEtoselectaUSDAdonenesslevel(SETTemperature).

AlsowhiletheMeatisashingyoucanraiseandlowertheUSDAdonenesslevel(SETTemperature)
bypressingHItoraiseitorLOtolowerit.TheFOODtemperaturerangeis32ºF-572ºF.
PressingSETbuttonatanypointwillsetthecurrentsettings.Notpressinganybuttonsforafew
seconds will also do the same.
Barbecue selection
IfyoupressedSETinBARBECUEmodethentheHISETtemperaturewillashinthecorresponding
probeeld.PressHItoraiseitorLOtolowerit.TherangefortheHISETtemperatureis140ºF–572
ºF. Default temperature from the factory is 250 ºF.
PressSETtosettheHISETtemperature.TheLOSETtemperaturewillash.PressHItoraiseitorLO
tolowerit.TherangefortheLOSETtemperatureis32ºF–554ºF.Defaulttemperaturefromthe
factory is 200 ºF.
PressingSETbuttonatanypointwillsetthecurrentsettings.Notpressinganybuttonsforafew
seconds will also do the same.
Note: The unit will not allow you to set the maximum BARBECUE temperature below the
minimum BARBECUE temperature. It will automatically change the LO temp to 2 degrees below
the HI.
Activating the temperature alarm
YoucanpresstheALERT,ºC/ºFbuttontoactivatethetemperaturealarmforBothprobe1and2.
The alarm icons will appear above the actual temperature.
Thereceiverwillbeepwiththealarmiconandprobetemperatureashingif:
a) TheactualFOODtemperaturehasexceededyoursetmaximumFOODtemperature.
 (ThealertBeeps3timeseverysecondifthetemperatureiswithin6oC or 10 F of the set
temperatureandbeeps4timeseverysecondoncethesettemperatureisreached)
b) TheactualBARBECUEtemperaturehasexceededyoursetmaximumBARBECUEtemperature.
 (Beepstwiceineverysecond)
c) TheactualBARBECUEtemperaturehasfallenbelowyoursetminimumBARBECUE
temperature.
 (Beepsonceineverysecond)
Note if you press the ALERT, ºC /ºF button and the actual probe temperature is above the FOOD
set temperature or out of range of your BARBECUE set temperature then the Alert icon and the
actual probe temperature will ash immediately indicating the issue.
Note: The minimum BARBECUE temperature alarm will not be activated until the actual
BARBECUE temperature goes above the set minimum temperature.
For example: You set the minimum BARBECUE temperature as 220 ºF and press the ALERT, ºC /
ºF, to activate the alarm. The unit will NOT beep or ash even if the actual BARBECUE
temperature is below 220 ºF. It assumes that your BARBECUE is not up to temperature. Only when
the actual BARBECUE temperature goes over 220 ºF, then falls below 220 ºF, can the alarm be
activated, the unit will beep and ash.
Note: The unit will retain your Barbecue & Food alert temperature settings even after the unit is
turned off.
Procedure for typical use in an outdoor barbecue
Monitor 1 FOOD and 1 BARBECUE
ThefollowingtypicalexampleswillgothroughthestepstohavetheET-733REDICHEKBARBECUE
alarmyouifapieceofmeatBEEFiscookedto173ºFandifyourbarbecuetemperaturefalls
below 225 ºF or goes above 275 ºF.
Set up barbecue
1. Follow the registration procedure.
2. PlaceBEEFonthebarbecuegrillrack.
3. Insertprobe1intothecenterofthickestportionofthemeat.Avoidtouchingboneorheavy
fat areas.
3. Clipprobe2togrillrackofbarbecuegrillrack.
4. Positiontheprobesensorwiressotheywillnotcomeintocontactwithamesandexitthe
barbecuewithoutbeingpinched/crushedbythecover.
5. Stand/hangthetransmitterawayfromheatsourceofbarbecue.DONOTputtransmitteron
closed cover or under the cover. The transmitter is water proof for use in rain.
Probe 1: FOOD, BEEF, WELL DONE, SET TEMPERATURE 173 ° F
1. PressandholdSETbuttonfor2seconds.
2. PressHIorLObuttontoswitchashingprobeinupperlefthandcornerto(1).
3. QuicklypressSET.
4. PressMODEbuttonsoFOODisdisplayed.
5. QuicklypressSET.
6. PressMEATbuttonuntilBEEFisdisplayed.
7. QuicklyPressTASTEbuttonuntilW.DONEisdisplayed.
8. QuicklyPressHIbuttonuntil173isdisplayedasHISET.
9. Press set.
Probe 2: BARBECUE, 225 °F LO SET, 275 °F HI SET
1. PressandholdSETbuttonfor2seconds.
2. PressHIorLObuttontoswitchashingprobeinupperlefthandcornerto(2).
3. QuicklypressSET.
4. PressMODEbuttonsoBARBECUEisdisplayed.
5. QuicklypressSET.
6. PressandholdHIorLObuttonuntil275isdisplayedasHISET.
7. QuicklypressSET.
8. PressandholdHIorLObuttonuntil225isdisplayedasLOSET.
9. Press set.
Helpful Hints
Ifthereceiverand/orthetransmitterdisplayLLLorHHHinsteadoftheprobetemperature,
waitforprobetoreachroomtemperature.IfLLLorHHHisstilldisplayedoryougetafalse
temperature,squeezetheprobejacksharderintothetransmitterandtwistthembackand
forthsotheymakegoodcontact.Iftheproblemstillpersistsitislikelytheinternalprobewirehas
shorted out either through moisture or heat damage.
Do not immerse the probe in water while cleaning.
Donotallowtheprobeorprobewiretocomeintocontactwithames.
Withinthewarrantyperiod,returndefectiveprobetoaddressbelowalongwithreturnaddress
and we will send you a replacement probe at no charge.
If the temperature displayed seems to read too high or the temperature seems to increase too
quickly,checktomakesuretheprobetipisnotpokingthroughthefoodtooutside.Reposition
theprobetipinthecenterofthethickestpartoffood.Avoidtouchingboneorheavyfatareas.
Cautions:
1) Alwayswearaheatresistantglovetotouchthestainlesssteelprobesensorsorwiresduringor
justaftercooking.Donottouchwithbarehands.
2) Keepthestainlesssteelprobesensorsandwiresawayfromchildren.
3) Cleanthestainlesssteelprobesanddrythoroughlyaftereachandeveryuse.
4) Donotusethereceiverintherain.ItisNOTrainproof.Thetransmitterisrainproofbutnot
water tight. Do not immerse in water.
5) Donotexposetheplugsofthestainlesssteelprobesorthepluginholesofthetransmitterto
water or any liquid. This will result in a bad connecting and faulty readings.
6) Donotexposethereceiverortransmittertodirectheatorsurface.
7) Donotusestainlesssteelprobesinmicrowaveoven.
8) TheBarbecueThermometerregisterstemperaturesaslowas32ºF(0ºC)andashighas572ºF
(300ºC).LLLwillbedisplayedbelow32ºFandHHHwillbedisplayedabove572ºF.Donotuse
the stainless probe sensor above 572 ºF. Doing so will deteriorate the wire.
9) NotIntendedforUsebyPersonsages12andUnder.
Cleaning
1) Alwayswearaheatresistantglovetotouchthestainlesssteelprobesensorsorwiresduringor
justaftercooking.Donottouchwithbarehands.
2) Keepthestainlesssteelprobesensorsandwiresawayfromchildren.
3) Washthemetalprobetipswithhotsoapywateranddrythoroughly.Donotimmersethe
probe in water while cleaning.
4) Wipethetransmitterandreceiverwithdampcloth.Donotimmerseeitherinwater.
Information to user
Warning: Changes or modications to this unit not expressly approved by the party responsible for
compliance could void the users’ authority to operate the equipment.
Note: This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the
interferencebyoneormoreofthefollowingmeasures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to which the receiver
is connected.
 - Consultthedealeroranexperiencedradio/TVtechnicianforhelp.
Thisdevicecomplieswithpart15oftheFCCRules.Operationissubjecttothefollowing
twoconditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevice
must accept any interference received, including interference that may cause undesired
operation.
LIMITED NINETY DAY WARRANTY
MaverickIndustriesInc.warrantstheET-733REDICHEKBARBECUEThermometertobefreeof
defectsinparts,materialsandworkmanshipforaperiodof90days,fromdateofpurchase.
Shouldanyrepairsorservicingunderthiswarrantyberequired,contactMaverickCustomer
ServicebyemailormailforinstructionsonhowtopackandshiptheET-733REDICHEKBARBECUE
ThermometertoMaverick’sNationalServiceCenterlocatedasfollows:
Maverick Customer Service
94 Mayeld Ave.
Edison NJ 08837
Telephone: [phone]
email: [email protected]
DonotsendanypartsorproducttoMaverickwithoutobtainingaReturnAuthorizationNumber
and instructions.
ThiswarrantyisVOIDifinstructionsforusearenotfollowed;foraccidentaldamage;for
commercialuse;fordamageincurredwhileintransit;oriftheET-733REDICHEKBARBECUE
Thermometer has been tampered with.
Thiswarrantygivesyouspeciclegalrightsandyoumayalsohaveotherrightswhichvaryfrom
state to state.
Replacement Probes
Topurchase,outofwarranty,stainlesssteelreplacementprobespleasemailusachecktothe
addressbelowandspecifyprobetype:
 ET-7336ftHybridProbe$20.00/ea
 Setof6ftHybridprobes$33.00/set
Allpricesincludeshipping&handling.NJresidentsadd7%salestax.
Attn Customer Service
Maverick Industries, Inc.
