Max BC-TC-C-WM-4 User manual

Wall Thermostat+
BC-TC-C-WM-4
Operating manual

2
Scope of delivery
Quan-
tity
Item
1x MAX! Wall Thermostat+
1x Clip-on frame
2x Plug
6x Screws
2x Adhesive stripes
2x 1.5 V LR03/micro/AAA batteries
3x Brief instruction in German/English, French/
Dutch and Polish/Italian
Scope of delivery

3
Table of contents
Table of contents
1 Information about this manual .............................4
2 Safety instructions.................................................4
3 Function.................................................................5
4 Device overview .....................................................7
5 Start-up .................................................................9
6 Setting date and time (dAt)..................................11
7 Mounting..............................................................12
8 Mounting in existing switches.............................15
9 Teaching-in..........................................................16
10 Teaching-out wireless components (UnL) ..........18
11 Operating Modes .................................................19
12 Child safeguard/operating lock...........................20
13 Setting heat pause (ON) ......................................20
14 Setting frost protection (OFF)..............................21
15 Configuration menu.............................................21
16 Restore factory settings (rES) .............................32
17 Error messages...................................................34
18 Maintenance and cleaning ..................................34
19 Information about radio operation......................35
20 Technical specifications ......................................36
1st English edition 07/2014
Documentation © 2014 eQ-3 AG, Germany
All rights reserved.
Translation of the original version in German.
Version 1.1

4
Information about this manual
1
InformatIon about thIs manual
Read this manual carefully before starting to use the de-
vice. Keep the manual so you can refer to it at a later date
if you need to. If you hand over the device to other persons
for use, please hand over the operating manual as well.
Symbols used:
Attention!
This indicates a hazard.
Note.
This section contains important additional in-
formation.
2
safety InstructIons
The device is not a toy; do not allow children to
play with it. Do not leave packaging material lying
around, as it can be dangerous in the hands of a
child.
Do not open the device: it does not contain any
components that need to be serviced by the user.
In the event of an error, please return the device
to the service department.
The device may only be operated indoors and must
be protected from the effects of damp and dust,
as well as solar or heat radiation.

5
Function
Using the device for any purpose other than that
described in this operating manual does not fall
within the scope of intended use and shall inval-
idate any warranty or liability. This also applies
to any conversion or modification work. The de-
vice is intended for private use only.
3
functIon
The MAX! Wall Thermostat+ is responsible for regulating
the room temperature within the MAX! system. With the
MAX! Wall Thermostat+up to 8 MAX! Radiator Thermo-
stats can be comfortably regulated in a room.
The MAX! Wall Thermostat+has an internal sensor that
measures the temperature in the room and cyclically
transmits it to the radiator thermostats.
Communication between the MAX! components is bidi-
rectional. This ensures that the information sent reach-
es the recipient.
The configuration of the MAX! Wall Thermostat+is made
according to the system variant used. You have the pos-
sibility to choose between the following two variants:

6
Function
MAX! House solution
This is the solution for the entire house. With
a MAX! Cube, all settings of connected devices
in the house can comfortably be made via the
MAX! software.
By using the MAX! Cube, several MAX! Radia-
tor solutions and MAX! Room solutions can be
connected to a MAX! House solution in a new
installation.
MAX! Room solution
In the room solution, the settings of all connected
devices in your room can comfortably be made via
the MAX! Wall Thermostat+. Up to 8 MAX! Radi-
ator Thermostats+and 8 MAX! Window Sensors
can be connected and controlled via the MAX!
Wall Thermostat+.
With a MAX! Cube, the solution can be extended
to a House solution.

7
Device overview
4
DevIce overvIew
(A) Mounting plate
(B) Clip-on frame
(C) Electronic unit/push-button
A
B
C

8
Device overview
D
G
HK
L
M
F
E
IJ
(D) Automatic mode (Auto), manual mode (Manu), holiday func-
tion ( ), boost function (
BOOST
), open-window function ( ) ,
operating lock ( )
(E)
Weekday, empty battery symbol ( ), radio sychronicity ( ) ,
comfort/reduction temperature ( ), time/date
(F) Bar chart of the programmed heating phases of the cur-
rent day
(G) Comfort temperature button ( ): switching to comfort
temperature
(H) Reduction temperature button ( ): switching to reduction
temperature
(I) Mode/Menu button: change the operating mode and open
the configuration menu; exit/back in the menu
(J) Boost/OK button: confirm settings and activate the boost
function
(K) (-) button: reduce the septpoint temperature, browse in
the menu
(L) (+) button: increase the septpoint temperature, browse
in the menu
(M) Setpoint/actual temperature

9
Start-up
5
start-up
5.1
InsertIng (replacIng) batterIes
As-delivered condition
When you are starting up the device for the first time,
first remove the mounting plate (A) on the rear of the
MAX! Wall Thermostat+.
• Hold the MAX! Wall Thermostat+firmly in one hand
and pull off the mounting plate at one corner.
Mounted condition
Once mounted, the MAX! Wall Thermostat+can easily
be pulled off the mounting plate and out of the frame.
• Pull sideways at the frame to remove the MAX! Wall
Thermostat+of the wall together with the frame.
Replacing batteries
• Turn the MAX! Wall Thermostat+over to remove or
insert the batteries.
• After removing the old batteries, please wait approx.
60 seconds.
• Insert two LR03/micro/batteries in the battery com-
partments (making sure that you insert them the
right way round).
• PuttheMAX!WallThermostat+backintotheframe(B).

10
Start-up
The empty battery symbol ( ) indicates that the
batteries need to be changed. If, in addition, a "V"
or "S" are displayed, the batteries of a taught-in
Radiator Thermostat (V) or Window Sensor (S)
have to be replaced.
Never recharge standard batteries. Do not throw
the batteries into a fire. Do not expose batteries
to excessive heat. Do not short-circuit batteries.
Doing so will present a risk of explosion.
Used batteries should not be disposed of with
regular domestic waste! Instead, take them
to your local battery disposal point.

11
Setting date and time (dAt)
6
Setting date and time
(dAt)
After inserting or replacing batteries the firmware ver-
sion number will be shown briefly. Accordingly, date and
time will be requested automatically. Settings can be
changed with the (+) and (-) buttons and confirmed with
the Boost/OK button.
• Set the year, month and date and confirm each set-
ting with the Boost/OK button.
Year: Month and day:
• Set the time and confirm your settings with the Boost/
OK button.
Hours: Minutes:
Once the time and date were entered, the MAX! Wall
Thermostat+changes back to normal operating mode.
If the MAX! Wall Thermostat+was taught-in to the
MAX! Cube, the current date and time will be
transferred automatically.

12
Mounting
During operation without Cube date and time can
be changed at any time via "dAt" in the configura-
tion menu (see sec. „6 Setting date and time (dAt)“
on page 11).
7
mounting
You can either use screws or adhesive strips to mount
the MAX! Wall Thermostat+to a wall in the frame sup-
plied or integrate it into an existing switch (see sec. „8
Mounting in existing switches“ on page 15).
Adhesive strip mounting:
• Choose a site for installation. The surface on which
you are mounting the push button must be clean, dry
and greaseless.
• For mounting of the assembled MAX! Wall Thermo-
stat+, attach the adhesive strips to the back side of the
mounting plate (A). You should be able to read the let-
ters on the back side (according to figure).

13
Mounting
<PA66>
• Remove the protective film from the adhesive strips.
• Press the assembled MAX! Wall Thermostat+with the
back side to the wall in the position where it should
subsequently be attached.
Screw mounting:
• Choose a site for installation.
Make sure that no electricity or similar lines run
in the wall at this location.
• Position the mounting plate on the desired site on the
wall. Make sure that the arrow on the mounting plate
is pointing upwards.
• Use a pen to mark the positions of 2 bore holes(1) (di-
agonally opposite) in the mounting plate on the wall.
The bore holes (2) can be used for installation with a
flush-mounting box.

14
Mounting
11
2
2
• Now drill the bore holes. If you are working with a
stone wall, drill the marked two 5 mm holes and insert
the plugs supplied. If you are working with a wooden
wall, you can pre-drill 1.5 mm holes to make screws
easier to insert.
• Usethescrewsandplugssuppliedtofastenthemount-
ing plate to the wall.
• Attach the MAX! Wall Thermostat+with the frame on
the mounting plate. Make sure that the arrows on the
back side of the wall thermostat point upwards and
that the clips on the mounting plate latch into the
openings on the wall thermostat.

15
Mounting in existing switches
8
mounting in exiSting SwitcheS
You can mount the MAX! Wall Thermostat+with the at-
tachment frame provided or use it with frames of other
manufacturers as well as integrate the electronic unit
into a multi-gang frame. In both cases, mounting with
adhesive strips and screws is possible. For mounting
with multiple combinations, make sure that the mount-
ing plate of the MAX! Wall Thermostat+is seamlessly
aligned to the already fixed mounting plate/retaining ring.
The MAX! Wall Thermostat+is designed to fit into frames
supplied by the following manufacturers:
Manufac-
turer
Frame
Berker S.1, B.1, B.3, B.7 glass
ELSO Joy
GIRA System 55, Standard 55, E2, E22, Event, Esprit
merten 1-M, Atelier-M, M-Smart, M-Arc, M-Star, M-Plan
JUNG A 500, AS 500, A plus, A creation

16
Teaching-in
9
teaching-in
In order to use the MAX! Wall Thermostat+in your in-
stallation, you must teach it in to the MAX! system. The
teach-in procedure depends on the system variant used.
Choose your system variant (House or Room solution)
and follow the instructions below.
MAX! House solution
In the MAX! House solution all settings and pro-
gramming (e.g. week programs) can be made via
the MAX! software.
• StartthelocalMAX!softwareandclickon"Newdevice".
• Press and hold down the Boost/OK button of the MAX!
Wall Thermostat+for at least 3 seconds to activate
teach-in mode.
1. 2.
> 3 s
• The antenna symbol appears in the display and the
MAX! Wall Thermostat+appears in the MAX! software.
• Click on "Next" in the software to give the device a
name and assign it to a room.
• The MAX! Wall Thermostat+is now integrated into

17
Teaching-in
the system and can be configured for each room via
the MAX! software.
As soon as the MAX! Wall Thermostat+has been
taught-in to the MAX! Cube, all data such as date,
time or week program are transmitted to it via ra-
dio connection.
If you want to add a MAX! Cube to your system sub-
sequently, a factory reset must be performed for
all devices (incl. MAX! Wall Thermostat+) prior to
teaching-in to a MAX! Cube. All settings including
your weekly profiles are deleted in this process.
MAX! Room solution
In the MAX! Room solution, you can control up to 8
MAX! Radiator Thermostats+and 8 MAX! Window
Sensors via the MAX! Wall Thermostat+. For this
purpose teach-in the devices directly to the MAX!
Wall Thermostat+. These then take over the set-
tings of the MAX! Wall Thermostat+(e.g. mode,
temperature, week program).
To teach in, proceed as follows:
• Put the device to be taught-in (e.g. MAX! Radiator
Thermostat+) into teach-in mode (according to the
corresponding operating manual).
• Press and hold down the Boost/OK button of the MAX!
Wall Thermostat+for at least 3 seconds to activate
teach-in mode.

18
Teaching-out wireless components (UnL)
1.
2.
> 3 s
• The antenna symbol ( ) and the remaining teach-in
time (30 seconds) will be displayed.
• If teach-in has been successful, the MAX! Wall Ther-
mostat+will change back to normal operating mode.
10
teaching-out wireleSS componentS
(UnL)
In the MAX! House solution, teaching-out of the
MAX! Wall Thermostat+will be made via the MAX!
software.
In the MAX! Room solution, use the function "UnL"
in the menu to teach-out devices that are taught-
in to the MAX! Wall Thermostat+(e.g. MAX! Ra-
diator Thermostat+). All radio components are
taught-out simultaneously.

19
Operating Modes
To teach-out devices, proceed as follows:
• Press and hold down the Mode/Menu button for more
than three seconds.
• Selectthe“UnL”menu itemwiththe (+) and(-)buttons.
• Confirm your selection using the Boost/OK button.
• "ACC" (accept) appears on the display. Confirm the
teach-out procedure using the Boost/OK button.
• All connected devices have now been taught-out from
the MAX! Wall Thermostat+.
11
operating modeS
You can choose between the operating modes auto, manu
and holiday function:
Auto: Week program – automatic temperature control
according to configured week program.
Manu: Manual operation – the temperature is set man-
ually with the (+) and (-) buttons.
Holiday function ( ): Setting a temperature, which has
to be maintained until a fixed point in time.
Boost (
BOOST
): Setting the boost function
In the MAX! House solution you can configure the
settings for the MAX! Wall Thermostat+via the
MAX! software.

20
Child safeguard/operating lock
In the MAX! Room solution you can change be-
tween the functions by pressing the mode button
shortly.
If the operating mode is changed on one device in
a room, this change is applied on all radiator ther-
mostats assigned to that room.
12
child Safeguard/operating lock
Operation of the MAX! Wall Thermostat
+
can be locked to
prevent settings being changed inadvertently (if somebody
touches the thermostat accidentally, for example).
• To activate/deactivate the operating lock, briefly
press the Mode/Menu and the Boost/OK button si-
multaneously.
• Onceactivated,theoperatinglocksymbol( )is shown
on the display.
13
Setting heat pauSe (on)
Battery life can be prolonged by switching the heating off
in summer. To achieve this, the valves are opened fully.
The calcification protection continues to run.
• In manual operation (Manu) press the (+) button until
“ON” is shown on the display.
• Exit manual operation (Manu) or press the (-) button
