USB 2.0 Ranger®2301
1-Port USB 100m CAT 5e/6/7
Extender System
Quick
Start
Guide
12
34
Connect the REX to the AC adapter and
plug it into a power source.
Connect the LEX to the computer
using the included USB cable.
Attach the USB device to the REX.
Max 100m (CAT 5e/6/7 cable not included)
1Place extenders where desired and connect
the CAT 5e/6/7 extension link cabling to
the Link ports (RJ45) on the LEX and REX.
REX (back view)
REX (back view)
Computer
LEX (front view)
LEX (back view)
REX (front view)
Link
Link 5V DC
Link 5V DC
Before you get started, ensure that all the drivers required for your USB device(s) are installed.
LEX = Local Extender, REX = Remote Extender
▪Transparent USB extension
▪True plug and play; no software drivers required
▪Works with all major operating systems: Windows®,
macOS™, Linux® and Chrome OS™
Includes the ExtremeUSB® suite of features:
USB 2.0 Ranger 2301 LEX
USB 2.0 Ranger 2301 REX
USB 2.0 Cable
AC Power Adapter
Country Specific Power Cord
Quick Start Guide
Package Contents:
For additional details about conguring
and operating your Ranger 2301, refer
to the complete user guide online at:
www.icron.com/2301
For technical support visit:
www.icron.com/support
FCC Radio Frequency Interference Statement Warning
This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received including interference that may cause undesired operation.
CE Statement
We, Icron Technologies Corporation, declare under our sole responsibility that the USB 2.0 Ranger® 2301, to which this declaration relates, is in
conformity with European Standard EN 55022,EN 61000 and EN 55024.
IC Statement
This Class B digital apparatus complies with Canadian ICES-003.
WEEE Statement
The European Union has established regulations for the collection and recycling of all waste electrical and electronic equipment (WEEE).
Implementation of WEEE regulations may vary slightly by individual EU member states.Please check with your local and state government
guidelines for safe disposal and recycling or contact your national WEEE recycling agency for more information.
Product Operation and Storage
Please read and follow all instructions provided with this product, and operate for intended use only. Do not attempt to open the product casing as
this may cause damage and will void warranty. If a power supply is required for operation,use only the model provided with this product.When not
in use, product should be stored in a dry location between -20°C and 70°C. Detailed product user guides are available online at www.icron.com.
Limited Hardware Warranty
Icron Technologies Corporation warrants that any hardware products accompanying this documentation shall be free from significant defects
in material and workmanship for a period of two years from the date of purchase. Icron Technologies Corporation’s hardware warranty extends
to Licensee, its customers and end users.
The warranty does not include repair of failures caused by: misuse, neglect, accident, modification, operation outside a normal operating
environment, service of the device by non-authorized servicers or a product for which Icron is not responsible.
Hardware Remedies
Icron Technologies Corporation’s entire liability and the Licensee’s exclusive remedy for any breach of warranty, shall be, at Icron Technologies
Corporation’s option, either: (a) return of the price paid, or (b) repair or replacement of hardware, which will be warranted for the remainder
of the original warranty period or 30 days, whichever is longer.These remedies are void if failure of the hardware has resulted from accident,
abuse or misapplication.
Limitation of Liability
The hardware warranty set forth in this agreement replaces all other warranties. Icron Technologies Corporation expressly disclaims all other
merchantability and fitness for a particular purpose and non-infringement of third-party rights with respect to the hardware.
Icron Technologies Corporation dealer, agent or employee is not authorized to make any modification, extension or addition to this warranty.
Under no circumstances will Icron Technologies Corporation, its suppliers or licensors be liable for any costs of procurement or substitute products
or services, lost profits, loss of information or data, or any other special, indirect, consequential or incidental damages arising in any way out of the
sale of, use of, or inability to use Icron Technologies Corporation product or service, even if Icron Technologies Corporation, its suppliers or licensors
have been advised of the possibility of such damages.In no case shall Icron Technologies Corporation, its suppliers and licensors’liability exceed the
actual money paid for the products at issue.
Since some jurisdictions do not allow the limitation of implied warranties of liability for incidental, consequential, special or indirect damages, the
above limitation may not always apply. The above limitations will not apply in case of personal injury where and to the extent that applicable
law requires such liability.
Certification, Compliance and Warranty Information
©2019 Icron Technologies Corporation, A Maxim
Integrated Company. All rights reserved. Icron
Technologies Corporation,the Icron Technologies
Corporation logo and products referred to herein
are either the trademarks or the registered
trademarks of Icron Technologies Corporation. All
other trademarks are property of their respective
owners. Icron Technologies Corporation assumes
no responsibility for errors that may appear in this
document. Information contained herein is subject
to change without notice. 90-01432-A02
Obtaining Warranty Service
To obtain warranty service, you must contact Icron Technologies Corporation within the
warranty period for a Return Material Authorization (RMA) number. Icron Technologies
Corporation will not accept returns without an authorized RMA number. Be sure to include
the serial numbers of the LEX unit and REX unit in any of your email correspondence. Package
the product appropriately for safe shipment and mark the RMA number on the outside of the
package.The package must be sent prepaid to Icron Technologies Corporation.We recommend
that you insure or send it by a method that provides package tracking.The repaired or replaced
item will be shipped to you, at Icron Technologies Corporation’s expense, not later than thirty
days after Icron Technologies Corporation receives the defective product.
Address to return product:
Warranty/RMA Inquiries: www.icron.com/support
Icron Technologies Corporation
Att: RMA Coordinator
4664 Lougheed Hwy., Suite 221
Burnaby, BC V5C 5T5 Canada
www.icron.com
