MAXIVOLT MV Series Instruction manual

MV-100
MV-100C
MV-200
MV-200N
MV-200P
MV-201
MV-202
MV-300
MV-300P
MV-301
MV-302
MV-400
MV-400P
MV-401
MV-402
MV-600
MV-600P
MV Series
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
CONTENTS
Important Notes
Installation Instructions, Wiring Diagrams, Dimensional Drawings
Operation and Maintenance
Warranty

Breaker must be ‘off’ during installation. Do not install surge protective device with power ‘hot’.
Do not connect any two SPD wires to the same bus. The SPD may be damaged and warranty voided by
improper connection.
30 inches of wire is provided for installation. Cut wires as short as possible and keep free of sharp
bends. Sharp bends in the wire create impedance. For optimum performance, lead wires should be as
short as possible and free of sharp bends.
Do not add wire to the SPD. This will impair the performance of the SPD and will void the warranty. The
SPD will perform best (faster response time) with the shortest wire length possible. Do not use wire nuts,
kernies, etc. when installing SPD.
Never install the SPD without utilizing mounting feet (unless recessed).
Do not modify the SPD in any way. The SPD may be damaged and void the warranty.
©2020 MAXIVOLT
01
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
IMPORTANT NOTES
MUST BE INSTALLED BY LICENSED ELECTRICIAN
Safety First! Know Your Voltage!
Always Use a Volt Meter!

Read Important Notes before installing SPD. Breaker must be disconnected during installation.
Mount SPD as close as possible to connection points, using mounting feet.
Insert wires through knock-out and tighten with locknut.
Cut wires as short as possible without straining or creating sharp bends to connect.
Connect SPD lead conductors in accordance with wiring diagrams on page 4.
Remove fuse(s) and turn power on. Light(s) should glow brightly.
Disconnect power and replace fuse(s). Turn power on. Light(s) should remain off.
Techical Support
806.583.4773
Monday - Friday, 8:00 - 5:00 (CSD/CDT)
02
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
©2020 MAXIVOLT
INSTALLATION INSTRUCTIONS

03
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
©2020 MAXIVOLT
DIMENSIONAL DRAWINGS
inches
[mm]
VOLTAGE
120 / 240 VAC
1 Ø / 3 WIRE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
10 kA
LISTED
IEC
61643-1
®
®
®
MV-100
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
VOLTAGE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 600 V
KTK-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
100 kA
LISTED
IEC
61643-1
®
®
®
MV-400
277 / 480 VAC
3 Ø / 4 WIRE
MV-300
MV-300P
MV-400
MV-400P
MV-600
MV-600P
MV-100
MV-200
MV-200N
MV-200P
MV-302
MV-100C
MV-201
MV-202
MV-301
MV-401
MV-402
MV-100C
Surge Protective Device
Made in USA
Maxivolt Corporation
Amarillo, Texas
800-583-4773
LISTED
IEC
61643-1
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
VOLTAGE
120 / 240 VAC
1 Ø / 3 WIRE
FUSE
REPLACE ONLY
WITH
BUSS®
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
®
®®

Phase A
Phase B
Phase C
VOLTAGE
240 VAC
3 Ø / 3 WIRE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
10 kA
LISTED
IEC
61643-1
®
MV-200P
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
®
®
04
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
©2020 MAXIVOLT
WIRING DIAGRAMS
VOLTAGE
120 / 240 VAC
3 Ø / 4 WIRE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
10 kA
LISTED
IEC
61643-1
®
MV-200N
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
®
®
Phase A
(Hi-Leg)Phase B
Phase C
Neutral
MV-100
MV-100C
MV-202
MV-302
MV-200
MV-300
MV-400
MV-600
MV-200P
MV-300P
MV-400P
MV-600P
MV-200N
MV-201
MV-301
MV-401
MV-402
VOLTAGE
120 / 240 VAC
1 Ø / 3 WIRE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
10 kA
LISTED
IEC
61643-1
®
®
®
MV-100
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
Phase A
Phase B
Neutral
Phase A
Phase B
Phase C
Neutral
VOLTAGE
120 / 240 VAC
3 Ø / 4 WIRE
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
FUSE
REPLACE ONLY
WITH BUSS
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
LOCATION
TYPE 2
(CLASS II)
SCCR
10 kA
LISTED
IEC
61643-1
®
MV-200
Surge Protective Device
Made in USA
MAXIVOLT CORPORATION
Amarillo, Texas
800-583-4773
®
®
Phase A
Neutral
MV-201
Surge Protective Device
Made in USA
Maxivolt Corporation
Amarillo, Texas
800-583-4773
LISTED
IEC
61643-1
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
VOLTAGE
220 VAC
1 POLE / 2 WIRE
FUSE
REPLACE ONLY
WITH
BUSS®
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
®®
Phase A
Phase B
MV-202
Surge Protective Device
Made in USA
Maxivolt Corporation
Amarillo, Texas
800-583-4773
LISTED
IEC
61643-1
WARNING
DO NOT OPEN
ELECTRICAL
SHOCK
VOLTAGE
220 / 380 VAC
2 POLE / 3 WIRE
FUSE
REPLACE ONLY
WITH BUSS®
5 AMP 250 V
AGC-5 WHEN
LIGHT IS ON
®

05
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
©2020 MAXIVOLT
OPERATION & MAINTENANCE
Add the following to your routine inspection forms:
Visual Inspection
Ensure the device has power. All lights on the faceplate of the device should be off.
If a light is on, it indicates a blown fuse and/or internal component damage.
If a light is on, disconnect power to the device and replace the fuse directly below the light that is
on. It is imperative that you replace the fuse with the exact same fuse type, which is indicated on
the faceplate of the device. Substituting a different fuse compromises the performance and
Safety of the device. After replacing the blown fuse(s), energize the device. If the lights remain
off, the device is operational, and no further action is required. If a light comes on, there is internal
component damage. The device needs to be uninstalled and replaced.
TECHNICAL SUPPORT
800.583.4773
Monday - Friday, 8:00 - 5:00 (CSD/CDT)

06
MV SERIES
INSTALLATION, OPERATION, & MAINTENANCE
MANUAL
©2020 MAXIVOLT
WARRANTY
Five (5) Year
Limited Warranty
MVC, Inc. warrants to the original consumer purchaser that the electrical component parts of this MV-Se-
ries Unit are free from defects in material and workmanship at the time of purchase under normal use and
conditions. The term of this warranty begins on the purchase date and continues for a period of five (5)
years.
In the event of a defect, or other failure of the MV Series Unit not caused by any misuse or damage to the
MV Series Unit while in the possession of the consumer, MVC, Inc. will repair or replace the MV Series unit
with a new or re-manufactured equivalent, or, at MVC, lnc.’s option, refund the purchase price. However,
MVC, Inc. will not elect refund unless it is unable to provide replacement, and repair is not commercially
practicable or cannot be made within a commercially reasonable time.
THE CONSUMER IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE MV SERIES UNIT OR
REFUND OF THE PURCHASE PRICE. THIS LIMITED WARRANTY REPRESENTS THE TOTAL LIABILITY OF
MVC, INC. FOR ANY WARRANTED PART. MVC, INC. DISCLAIMS ANY OTHER EXPRESS OR IMPLIED WARAN-
TIES INCLUDING WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. MVC,
INC. SHALL NOT BE LIABLE FOR ANY INDIRECT, SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPAIRED WARRANTY LASTS, OR THE EX-
CLUSION OR LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATION OR
EXCLUSION MAY NOT APPLY TO YOU. THIS WARRANTY GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY
ALSO HAVE OTHER LEGAL RIGHTS, WHICH MAY VARY FROM STATE TO STATE.
This warranty does not cover: (1) installation, set-up, testing, or adjustment; (2) removal or reinstallation;
(3) defects occurring after purchase due to improper installation, repair, modification, accident, tampering,
misuse, abuse, or negligence; or (4) damage to the unit from fire, flood, or other catastrophe. This warranty
is void if the rated capacity of the MV Series Unit is exceeded, if the MV Series has been opened or disas-
sembled in any manner, or if the serial number of the MV Series Unit has been altered or removed. This
warranty extends exclusively to the original purchaser of the MV Series Unit, and subsequent purchasers
are not covered by this warranty agreement.
To obtain warranty performance, the consumer must deliver to MVC, Inc.: (1) the defective MV Series Unit;
(2) a receipt, bill of sale, or other original evidence showing the date of purchase; and (3) the consumer’s
return address and daytime telephone number. If shipped, the MV Series Unit must be packaged so that it
is protected from possible shipping damage, and should be addressed to: MVC, Inc., 800 S. Rusk, Amaril-
lo, Texas 79106, attention Warranty Claim. To obtain information on warranty performance, call toll free:
1-800-583-4773. A Warranty Information Form should be filled out and included in the package containing
the MV Series Unit. This form can be requested from MVC, Inc. at the toll free number listed above.
