MaxTech XT-5871 User manual

Part#MAN119Rev.1.0 CX1566
XT-5871
USER'S MANUAL
•0.28 mm Dot Pitch
•1280 x 1024, Non-Interlaced
•120 Hz Refresh Rate
•PowerSavingOperation(VESADPMS)
•Anti-Glare Screen
•Full Screen Display
•Digital Controls
•Low Radiation
•Plug and Play
•Three-Year Warranty
Features

1
Table of Contents
Section 1 General Information ...................................................2
Section 2 Installation..................................................................3
Section 3 Monitor Controls and LEDs ........................................ 4
Section 4 Troubleshooting .........................................................5
Appendix A Specifications.............................................................6
Appendix B Video Cable Pinout ....................................................7
Appendix C Power Saving Modes (DPMS)....................................7
Appendix D Three Year Warranty..................................................7
Appendix E Notices.......................................................................9
IMPORTANT
• Read all these instructions. Save for later use.
• Do not expose this unit to rain or moisture.
• Do not use this unit with an extension cord or any outlet other than a three prong outlet.
• Do not open the cabinet. There are no user serviceable components inside. Refer all
servicing to a qualified technician.
• Do not cover the vent holes in the case. These are to allow for ventilation.
• Do not insert sharp objects into the monitor. They may cause accidental fire or failure.
• The socket-outlet should be installed near the equipment and should be easily acces-
sible.
• Follow all instructions and warnings on the product.
• Do not place the product on any unstable surfaces.
• Operate from power source indicated on the label.
• Do not allow anything to rest on the power cord.
• Unplugthis product fromthewall outlet andreferservicingto qualified servicepersonnel
under the following conditions:
A. When the power cord or plug is damaged or frayed.
B. If liquid has been spilled into the product.
C. If the product has been exposed to rain or water.
D. If the product does not operate normally when the operating instructions are
followed. Adjust only those controls that are covered by the operating instructions
since improper adjustment of the other controls may result in damage and will often
require extensive work by a qualified technician to restore the product to normal
operation.
E. If the product has been dropped or the cabinet has been damaged.
F. If the product exhibits a distinct change in performance, indicating a need for
service.

2
Section 1 - General Information
Congratulations on purchasing a MaxTech 15-inch high resolution color monitor.
The monitor uses one of the finest CRTs available in the industry. The 0.28 mm
dot pitch non-glare tube provides a crisp and vivid color display for all popular
applications. The monitor complies with the MRP-I standard to reduce electro-
magneticemissions.Advancedelectronicsanddigitalcontrolsmakeittheperfect
monitorforapplicationsrangingfromhomecomputingtobusinesspresentations.
The monitor is compatible with VGA, SVGA, and XGA display adapters. It
operates at resolutions ranging from 640 x 350 to 1280 x 1024 with unlimited
colors. The monitor is PnP (Plug and Play) compliant to simplify setup and
configuration in Windows 95 or other PnP operating systems.
1.1 Precautions When Using the Monitor
When setting up and using your monitor, pay special attention to the following:
• Toeliminateeyefatigue,donotuseyourmonitoragainstabrightbackground
or where sunlight or other light sources will shine directly on the monitor.
• Your monitor should be placed just below eye level for optimum viewing.
• Allow adequate ventilation around the monitor so that heat from the monitor
can properly dissipate.
• Neitherthemonitoritselfnoranyotherheavyobjectshouldrestonthepower
cord. Damage to a power cord can cause fire or electrical shock.
• Keep the monitor away from high capacity transformers, electric motors and
other strong magnetic fields.
• Do not use your monitor in a damp, dusty or dirty area.
• Handle the monitor with care when transporting.
• Unplug the monitor during electrical storms
Section 2 - Installation
2.1 Attaching the Base
• Carefully place the monitor on its side or top (see Figure 2-1).
• Insertthehooksontheswivelbaseintotheslotsinthebottomofthe monitor.
Push down and forward on the base until the it snaps into place.
• Place the display upright in an appropriate location.

3
2.2 Connecting the Cable
• Plug the 15-pin male connector on the video cable into the output connector
on the rear of your computer system. The video output connector on your
computermaybeeither in a location similar to Figure 2-2 oronanexpansion
board. Secure the cable to the computer using the thumbscrews on the 15-
pin connector.
• Attach the power cord to the monitor and plug it into an AC outlet.
• The monitor is now ready for use.
Expansion boards
COM1 COM2 LPT1 VIDEO
Figure 2-2 Monitor Connections
Figure 2-1 Connecting the Base

4
Section 3 - Monitor Controls and LEDs
2
3
4
5
6
7891011121314
Figure 3-1 Controls and LEDs
1

5
1. Master Power (On rear): Push to provide power to the monitor. This switch
should be left ON for daily operation. Use the front panel On/Off control (5) to
turn the monitor display on and off.
2. Adjust: Press plus (+) to increase the setting for the selected control (9
through 14). Press minus (-) to decrease the setting.
3. Brightness Control: Adjusts the display brightness.
4. Contrast Control: Adjusts the contrast of the display.
5. ON/OFF: Press this switch to turn the monitor display on, press again to turn
the monitor display off.
6. Power Saving Indicator: When lit, the monitor is in the DPMS OFF mode.
7. Degauss: Press to clear color impurity of the display.
8. Recall: Press to reset the factory defaults for the display.
9. Trapezoid: Select to adjust the angle of the sides of the display to make the
display rectangular.
10. Pincushion:Selecttoadjustthecurvatureofthesidesofthedisplaytomake
the sides straight.
11. Vertical-Position: Select to adjust the vertical position
12. Vertical-Size: Select to adjust the display height
13. Horizontal-Position: Select to adjust the horizontal position
14. Horizontal-Size: Select to adjust the display width.
Section 4 - Troubleshooting
No picture, no LEDs lit.
•Check that the AC cord is plugged into an outlet and the monitor.
•Turn on the Master Power switch.
No picture, one of the selection LEDs is lit.
•Check that video cable is connected completely.
•Adjust brightness and contrast controls.
•Check connector for bent pins.
No picture, power saving indicator (2) on.
•Monitor is in DPMS OFF mode. Press a key or move the mouse.
•Monitor is off. Press front panel On/Off switch.
•Check connector for bent pins.

6
Image is not centered
•Adjust Vertical Position and Horizontal Position controls.
Appendix A - Specifications
Picture Tube Size 15-inch diagonal
Dot pitch 0.28mm
Horizontal Freq 30-66KHz
Vertical Freq. 50-120 Hz
Resolution (Max.) 1280 x 1024
Video Dot Rate 100 MHz
Data Area 10.2 in. x 7.7 in.
Maximum Refresh Rates
Resolution Refresh (Vertical) Frequency
640 x 480 120Hz
800 x 600 100 Hz
1024 x 768 75 Hz
1280 x 1024 60 Hz
Input voltage 110~240VAC, 50/60 Hz
Front controls On/Off,Brightness,Contrast,Horizontal-Size, Horizontal-
Position,Vertical-Size,Vertical-Position,Pincushion,Trap-
ezoid, Recall, Degauss
Rear Control Master Power
Power 80 W (Max.)
Consumption
Power saving
Display Power Management Signaling (DPMS)
SUSPEND/STANDBY mode 20W (Max.)
OFF mode 1W (Max.)
Low Radiation MPR-I
Standard
Plug and Play DDC1, DDC2B
Operating Temperature 5°~35°C
Environment Humidity 30~80%
Connector 15 Pin D-Sub
Dimensions 12.88 x 14.13 x 15.63 in.
Specifications subject to change without notice.

7
Appendix B - Video Cable Pinout
Appendix C - Power Saving Modes (DPMS)
VESA Display Power Management Signaling (DPMS) defines a method for a
computertosignalthemonitortoreduceitspowerconsumptionwhenidle.DPMS
features must be supported by both the computer and the monitor. The monitor
supports DPMS “SUSPEND” “STANDBY” and “OFF” modes. Computer support
of DPMS requires the use of a DPMS compliant video card driver.
The monitor enters DPMS STAND-BY or SUSPEND mode when the computer
turns off either the Horizontal or Vertical Synchronization signal. These power-
saving modes reduce the monitor’s power consumption to 20W. While in these
modes the selection indicator LEDs flash consecutively from right to left and then
back. When the synchronization signals are re-enabled the monitor returns to
normal operation.
The monitor enters DPMS OFF mode when the computer turns off both the
HorizontalandVerticalSynchronizationsignals.Thismodereducesthemonitor’s
power consumption to 1W. When the synchronization signals are re-enabled the
monitor returns to normal operation.
Appendix D - Three Year Warranty
MAXTECH warrants to the original buyer of this product against defects in
61
5
10
11
15
Figure B-1 Pin Layout and Pin Assignment Chart
PIN SIGNAL PIN SIGNAL
1Red 9 No Pin
2Green 10 Ground
3 Blue 11 Ground
4No Pin 12 SDA
5Ground 13 Hor. Synch.
6Red Return 14 Vert. Synch
7Green Return 15 Data Clock
(SCL)
8Blue Return

8
material and workmanship for three years from the date of purchase.
Except as specified below, this warranty covers all defects in material or
workmanship in this product. The following are not covered by the warranty:
1.Any product whichisnotdistributed inNorthAmericaby MAXTECH orwhich
is not purchased in North America from an authorized MAXTECH Dealer.
2.Any product on which the serial number has been defaced, modified or
removed.
3.Damage, deterioration or malfunction resulting from:
a.Accident, misuse, abuse, neglect, fire, water, lightning or other acts of
nature,commercialorindustrialuse,unauthorizedproductmodification,or
failure to follow instructions supplied with the product.
b.Repair or attempted repair by anyone not authorized by MAXTECH.
c. Any shipment of the product (claims must be presented to the carrier).
d.Removal or installation of the product.
e.Any other cause which does not relate to a product defect.
4.Cartons, carrying cases, batteries, external cabinets, magnetic tapes or any
accessories used in connection with the product.
MAXTECH will pay all labor and material expenses for covered items, but we will
not pay for the following:
1.Removal or installation charges.
2.Costs of initial technical adjustments (set-up), including adjustment of user
controls.
3.Payment of shipping charges.
HOW TO OBTAIN WARRANTY SERVICE
Intheeventtheproductrequiresservice,calltheMaxTechServiceCenterat(562)
921-4438 between 9:00 a.m. and 6:00 p.m. (PST Monday through Friday). When
you are instructed by the Technical Support Representative to return the product
to MaxTech for repair, you will be given an RMA (Return Merchandise Authoriza-
tion) number. You must have an RMA Number to return the product for
service . Use the following procedure to return the product to MaxTech:
1. Return the product in its original package and packing (if possible).
2. Be sure to include your name, address, day-time telephone number, RMA
number, and a brief description of the problem (also enclose a check for
out-of-warranty repair).
3. After wrapping the package securely for shipping, print your name, return
address and the RMA # clearly on the outside of your package.
4. Ship the unit prepaid via UPS or the U.S. Postal Service to the address
provided by the technician when you call. We recommend that the unit be
insured.
This warranty is valid for products sold in North America only. Contact your local
authorized distributor or dealer for the warranty offered in other areas.
All warranty services must be performed by Authorized Service Centers. There
are no user serviceable parts inside the unit. Do not remove any components or
attempt to service the unit by any unauthorized service center. This warranty is

9
voided if the product has been abused, misused, modified, or repaired by an
unauthorized service center.
LIMITATION OF IMPLIED WARRANTIES
All implied warranties, including warranties of merchantability and fitness for a
particular purpose, are limited in duration to the length of this warranty.
EXCLUSION OF DAMAGES
MAXTECH'S liability for any defective product is limited to the repair or replace-
ment of the product, at our option. MAXTECH shall not be liable for:
1. Damage to other property caused by any defects in this product, damages
based upon inconvenience, loss of use of the product, loss of time, commer-
cial loss; or
2. Any other damages, whether incidental, consequential or otherwise.
Some states do not allow limitations on how long an implied warranty lasts and/
ordo notallowtheexclusion or limitationofincidentalor consequentialdamages,
so the above limitations and exclusions may not apply to you.
HOW STATE LAW RELATES TO THE WARRANTY
This warranty gives you specific legal rights, and you may also have other rights
which vary from state to state.
Appendix E - Notices
FCC Class B Statement
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy, and if not installed and used in accordance with the instructions, may
cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this
equipmentdoescauseharmfulinterferencetoradioortelevisionreception,which
can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and the receiver
• Connect the equipment into an outlet on a circuit different from that to which
the receiver is connected
• Consult the dealer or an experienced radio / TV technician for help

10
Notice:Shieldedcables,ifany,mustbeusedinordertocomplywiththeemission
limits. Any change or modification not expressly approved by the Grantee of the
equipmentauthorizationcouldvoidtheuser’sauthoritytooperatetheequipment.
Canadian DOC Compliance Statement
This equipment does not exceed Class B limits for radio noise emissions for a
digital apparatus, set out in the Radio Interference Regulations of the Canadian
Department of Communications. Operation in a residential area may cause
unacceptable interference to radio and TV reception requiring the owner or
operator to take whatever steps necessary to correct the interference.
Cet équipement ne dépasse pas les limits de Class B d'émission de bruits
radioélectriques pour les appareils numériques, telles que prescrites par le
Règlement sur le brouillage radioélectrique établi par le ministère des Commu-
nications du Canada. L'exploitation faite en milieu résidentiel peut entraîner le
propriétaire ou l'opérateur à prendre dispositions nécessaires pour en éliminer
les causes.
Disclaimer, Copyright, And Other Notices
The information contained in this manual has been validated at the time of this
manual's production. The manufacturer reserves the right to make any changes
andimprovementsintheproductdescribedinthismanualatanytimeandwithout
notice. Consequently, the manufacturer assumes no liability for damages in-
curred directly or indirectly from errors, omissions or discrepancies between the
product and the manual.
All registered trademarks are the property of their respective owners.
Copyright © 1997 MAXTECH. All rights reserved. No reproduction of this
document in any form is allowed without written permission from MAXTECH.
First Edition
GZ/DR - Version 1.0
