MAXTEK HG363 User manual

USER GUIDE
Gaming Headphones
MODEL NUMBER: HG363
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
1.
2.
3.
4 - 5.
6 - 7.
8.
9.
10.
11.
Welcome Section
Contents & Features
PS4 Setup
PS3 Setup
Xbox 360 Setup
PC/Mac Setup
Microphone Setup
Inline Controls
Specications
Contents

Welcome Section
Congratulations!
You have made an excellent choice with the purchase of this quality
MAXTEK®product.
By doing so you now have the assurance and peace of mind which
comes from purchasing a product that has been manufactured to
the highest standards of performance and safety, supported by the
high quality standards of Quesh Ltd.
We want you to be completely satised with your purchase so this
MAXTEK®product is backed by a comprehensive manufacturer’s
3 year warranty and outstanding after sales service through our
dedicated helpline.
We hope you enjoy using this product for many years to come.
If you require technical support or in the unlikely event that your
purchase is faulty, please telephone our helpline for immediate
assistance. Faulty product claims made within the 3 year warranty
period will be repaired or replaced free of charge provided that you
have a satisfactory proof of purchase (keep your receipt safe).
This does not affect your statutory rights. However be aware that the
warranty will become null and void if the product is found to have
been deliberately damaged, misused and/or disassembled.
1
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
2
Contents & Features
Contents
1 x Headphones
1 x Detachable Microphone
Features
 •CompatiblewithPC/Mac,Xbox360&PS4/3
 •Chatvolumecontrol
 •Gamevolumecontrol
 •2.5mmcontrollerinput
 •Inlinephonoconnectors
 •CompatiblewithUSB2.0,1.01&1.0
 •40mmstereodrivers
 •Detachableomnidirectionalmicrophone
 •Multiposeablemicrophoneboom
 •FoamMicrophonelter
•3.6m Headset cable length
 •0.5mGamepadcablelength

3
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
PS4 Setup
Connecting to a PS4 (HDMI - TV with RCA out)
•UsetheHDMIcabletoconnectyourPS4toyourTV/Monitor.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
whiteaudiooutRCAportsontheTV/Monitor.
•ConnecttheUSBjacktoanavailableUSBportonthePS4to
provide power to the in built amplier and use of the microphone.

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
4
PS3 Setup
Connecting to a PS3 (HDMI - TV no RCA out)
•UsetheHDMIcabletoconnectyourPS3toyourTV/Monitor.
•ConnectthecompositeadaptortotheAVportonyourPS3
•ConnectthewhiteandredRCAjackstothecorrespondingredand
white audio out RCA ports on the composite adaptor.
•ConnecttheUSBjacktoanavailableUSBportonthePS4to
provide power to the in built amplier and use of the microphone.
•SettheaudiooutputsettingonthePS3to‘AVMulti’
Conneting to a PS3 (HDMI - TV with RCA out)
•UsetheHDMIcabletoconnectyourPS3toyourTV/Monitor.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
whiteaudiooutRCAportsontheTV/Monitor.
•ConnecttheUSBjacktoanavailableUSBportonthePS3to
provide power to the in built amplier and use of the microphone.

5
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
PS3 Setup
Connecting to a PS3 (Composite)
•UsethecompositeadaptortoconnectyourPS3andusethe
yellowjacktoconnettoyourTV/Monitor.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
white audio out RCA ports on the composite adaptor.
•ConnecttheUSBjacktoanavailableUSBportonthePS3to
provide power to the in built amplier and use of the microphone.
•SettheaudiooutputsettingonthePS3to‘AVMulti’

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
6
Xbox 360 Setup
Connecting to an Xbox 360 (HDMI - TV no RCA out)
•UsetheHDMIcabletoconnectyourXboxtoyourTV/Monitor.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
whiteaudiooutRCAoutportsontheTV/Monitor
•ConnecttheUSBjacktoanavailableUSBportontheXboxto
provide power to the in built amplier.
•Finallyconnectthe2.5mmJackcabletotheXboxgamepadin
order to use the microphone.
Connecting to an Xbox 360 (HDMI - TV with RCA out)
•UsetheHDMIcabletoconnectyourXboxtoyourTV/Monitor.
•ConnecttheHDAVadaptortothecompositeoutport.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
whiteaudiooutRCAportsontheHDAVadaptor(notincluded).
•ConnecttheUSBjacktoanavailableUSBportontheXboxto
provide power to the in built amplier.
•Finallyconnectthe2.5mmJackcabletotheXboxgamepadin
order to use the microphone.

7
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Xbox 360 Setup
Connecting to an Xbox 360 (Composite)
•UsethecompositeadaptortoconnectyourXboxandusethe
yellowjacktoconnettoyourTV/Monitor.
•ConnectthewhiteandredRCAjackstothecorrespondingredand
white audio out RCA out ports on the composite adaptor
•ConnecttheUSBjacktoanavailableUSBportontheXboxto
provide power to the in built amplier.
•Finallyconnectthe2.5mmJackcabletotheXboxgamepadin
order to use the microphone.

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
8
PC/Mac Setup
Connecting to a PC/Mac
•UsetheUSBcabletoconnectyourheadsettoyourPC/Mac.
•Waitfortheoperatingsystemtodownloadandinstallthedrivers
from the internet.
•Youmayneedtosetuptheheadphonethrough‘PlaybackDevices’
fortheheadphonesand‘RecordingDevices’forthemicrophone.
Right click on the speaker icon and select the function you require
to setup. Make the required outputs the headset on the drop down
boxesandclick‘DefaultDevice’.Tonalisetheselectionclick
‘Apply’.
Please note:
The ‘Game’ volume wheel will be disabled.

9
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Microphone Setup
Connecting and setting up the microphone
•Connectthe3.5mmjackendofthemicrophoneintothe3.5mm
port on the left ear cup.
•Adjustthemicrophoneboomsothatthemicrophoneispositioned
at it’s full extent by the left corner of your mouth and below your lip
level by 2-3cm. Move the Microphone towards your chin till it is
about 3cm away. This will give you optimum vocal pickup.
Please note:
The position of the boom is so that you don’t breath into the microphone either
from the mouth or nose and cause unwanted noise/distortion.
For further adjustments these will have to be done through the
system/device setup options on the platform used.

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
10
Inline Control
Using the Inline Control
•The‘Chat’volumewheelwillcontroltheingamecommunication
audio levels.
•The‘Game’volumewheelwillcontroltheingameaudiolevel.
•The‘MuteMic’switchwillenableordisablethemicrophone.
•The‘PlatformSelection’switchallowsyoutouseXboxor
PS3. PS4 or PC with the headset.
Please note:
Listening to high volume for long periods of time may damage your hearing.
Further audio adjustments will have to be done through the
system/device setup options on the platform used.
Please note:
The ‘Game’ volume wheel will be disabled on PC. Audio controls will be from
the ‘Chat’ volume wheel only.
ChatVolumeWheel GameAudioVolumeWheel
Microphone Mute Switch Platform Selection Switch

11
After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Specification
Gaming Headset
 •CompatibleplatformsPC/Mac,Xbox360&PS4/3
 •USB,RCA&2.5mmconnectors
 •CompatiblewithUSB2.0,1.01&1.0
 •40mmSpeakers
 •32OHmSpeakerimpedance
 •20Hz-20KHzFrequencyresponse
 •6mmx2.7mmmicrophone
 •-52dBMicrophonesensitivity
 •Onmi-directionalmicrophone
 •50Hz-15KHzMicrophonesensitivity
 •3.6MHeadsetcablelength
 •0.5MGamepadcablelength

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Warranty
This product is guaranteed to be free from defects in workmanship and parts for a period of 36 months
from the date of purchase. Defects that occur within this warranty period, under normal use and care,
will be repaired, replaced or refunded at our discretion, solely at our option with no charge for parts and
labour. The benets covered by this warranty are in addition to all rights and remedies in respect of the
product the consumer has under existing U.K. laws.
Proof of Purchase
This warranty is valid for the original purchase and is not transferable.
Please keep your purchase receipt as proof of purchase and as proof of the date of when the purchase
was made. The receipt must be presented with the warranty card when making a claim under this
warranty.
Service during the Warranty Period
Please ensure the product is properly packaged so as to ensure that no damage occurs in transit. Also
make sure that you have included a detailed explanation of the problem.
Extent of the Warranty
This warranty is limited to defects in workmanship or parts. All defective products or parts will be
repaired or replaced. This warranty does not extend to accessories.
Normal Wear and Tear
This warranty does not cover normal wear and tear of the product or parts.
Exclusions
This warranty does not cover the following:
•Anydefectcausedbyaccident,misuse,abuse,improperinstallationoroperation,lackorreasonable
care, unauthorised modication, loss of parts, tampering or attempted repair by a person not
authorised by the distributor.
•Anyproductthathasbeendamagedbylightningstrikeeitherdirectlyorindirectly,oronamain’s
or vehicle outlet power surge or liquid ingress.
•Anyproductthathasnotbeeninstalled,operatedormaintainedinaccordancewiththe
manufacturer’s operating instructions provided with the product.
•Anyproductthathasbeenusedforpurposesotherthandomesticuse.
•TheproductifitislocatedoutsideoftheU.K.andIreland
•Anydamagecausedbyimproperpowerinputorimpropercableconnection.
Warranty Certificate

After Sales Support
UK/N.IRELAND HELPLINE NO:
REP.IRELAND HELPLINE NO:
WEBSITE:
EMAIL:
01270 508538
1800 995 036
www.quesh.co.uk
[email protected]
Warranty Card
Gaming Headphones
Please keep your purchase receipt together with your warranty card
Fault Description:
Name:
Address:
Date of purchase:
Location of purchase:
Service Helpline
QUESH LTD,
1 SOLWAY COURT,
CREWE BUSINESS PARK,
CW1 6LD
We recommend that you attach a photocopy of your receipt, showing the date of purchase, to this
warranty card and keep it for your reference. In the event of a product fault, please call the After Sales
Support team. Please ensure that you have the product details (as shown on this card) to hand so that
the support team are able to respond as quickly and efciently as possible.
Model Number: HG363
