Maxx Cold MCR27U User manual

Undercounter Refrigerator Manual
Undercounter
Refrigerator
Manual

▣Model –MCR27U
1. Technical Specifications
Amp 115V 3.2A
Connection 15 am
p
p
lu
g
Refrigerant
Name R134a
Q'ty (oz) 2.5
Q'ty (gram) 70
C
HP 1/5 HP
S
SD162C
L1U2
C
ompressor
S
amsung
SD162C
-
L1U2
2. Function Specifications
Temp Range ℉ 32℉ ~ 40℉
Capacity
Cubic Feet
7
Capacity
Cubic
Feet
7
Climate Class N
Max Ambient Temp ℉ 89.6℉
Min Ambient Temp ℉ 59℉
Castors 5” 4EA
Shelves 2EA
Doors 1EA
Exterior Finish Stainless Steel
Interior Finish Stainless Steel
3Sizes
3
.
Sizes
Exterior
Dimensions
Width(Inches) 27 1/2 inch
Depth (Inches) 30 inch
Height (Inches) 35 13/16 inch
Weight
LBS
143
lb
Weight
LBS
143
lb

▣Model –MCR36U
1. Technical Specifications
Amp 115V 3.2A
Connection 15 amp plug
N
R134
Refrigerant
N
ame
R134
a
Q'ty (oz) 2.5
Q'ty (gram) 70
Compressor
HP 1/5 HP
Samsung
SD162C
-
L1U2
Compressor
Samsung
SD162C
L1U2
2. Function Specifications
Temp Range ℉ 32℉ ~ 40℉
Ca
p
acit
y
Cubic Feet 9
py
Climate Class N
Max Ambient Temp ℉ 89.6℉
Min Ambient Temp ℉ 59℉
Castors 5” 4EA
Shelves 4EA
Doors 2EA
Exterior Finish Stainless Steel
Interior Finish Stainless Steel
3Sizes
3
.
Sizes
Exterior
Dimensions
Width(Inches) 36 5/16inch
Depth (Inches) 30 inch
Height (Inches) 35 13/16 inch
Weight
LBS
172
lb
Weight
LBS
172
lb

▣Model –MCR48U
1. Technical Specifications
Amp 115V 6.0A
Connection 15 amp plug
Refrigerant
Name R134a
Q'ty (oz) 3.5
Q'ty (gram) 100
Compressor
HP 3/8 HP
Samsung
SK1A1C
L2W
Compressor
Samsung
SK1A1C
-
L2W
2. Function Specifications
Temp Range ℉ 32℉ ~ 40℉
Capacity
Cubic Feet
12
Capacity
Cubic
Feet
12
Climate Class N
Max Ambient Temp ℉ 89.6℉
Min Ambient Temp ℉ 59℉
Castors 5” 4EA
Shelves 4EA
Doors 2EA
Exterior Finish Stainless Steel
Interior Finish Stainless Steel
3Sizes
3
.
Sizes
Exterior
Dimensions
Width(Inches) 48 5/16 inch
Depth (Inches) 30 inch
Height (Inches) 35 13/16 inch
Weight
LBS
194
lb
Weight
LBS
194
lb

▣Model –MCR60U
1. Technical Specifications
Amp 115V 6.0A
Connection 15 amp plug
Refrigerant
Name R134a
Q'ty (oz) 3.5
Q'ty (gram) 100
Compressor
HP 3/8 HP
Samsung
SK1A1C
L2W
Compressor
Samsung
SK1A1C
-
L2W
2. Function Specifications
Temp Range ℉ 32℉ ~ 40℉
Capac
it
y
Cub
i
c
F
ee
t1
6
Capac y
Cub c ee
6
Climate Class N
Max Ambient Temp ℉ 89.6℉
Min Ambient Temp ℉ 59℉
Castors 5” 4EA
Sh l
4EA
Sh
e
l
ves
4EA
Doors 2EA
Exterior Finish Stainless Steel
Interior Finish Stainless Steel
3. Sizes
Exterior
Dimensions
Width(Inches) 60 3/8inch
Depth (Inches) 30 inch
Height (Inches) 35 13/16 inch
Weight LBS 236 lb

▣Model –MCR72U
1. Technical Specifications
Amp 115V 6.1A
Connection 15 amp plug
Refrigerant
Name R134a
Q'ty (oz) 5.3
Q'ty (gram) 150
Compressor
HP 3/8 HP
Samsung
SK1A1C
L2W
Compressor
Samsung
SK1A1C
-
L2W
2. Function Specifications
Temp Range ℉ 32℉ ~ 40℉
Capacity
Cubic Feet
20
Capacity
Cubic
Feet
20
Climate Class N
Max Ambient Temp ℉ 89.6℉
Min Ambient Temp ℉ 59℉
Castors 5” 4EA
Shelves 6EA
Doors 3EA
Exterior Finish Stainless Steel
Interior Finish Stainless Steel
3Sizes
3
.
Sizes
Exterior
Dimensions
Width(Inches) 72 3/8inch
Depth (Inches) 30 inch
Height (Inches) 35 13/16 inch
Weight
LBS
269
lb
Weight
LBS
269
lb

▣ Cabinet - 1
Stainless BOLT – M5
HINGE BOTTOM(LEFT) HINGE BOTTOM(RIGHT)
HINGE TOP ASSEMBLY

▣ DOOR
DOOR GASKETHINGE SHAFT
SPRING RIGHT
SPRING LEFT

▣ Cabinet - 2
Duct
Louver
Evaporator Fan Motor Kit
REF-Thermostat Kit
Evaporator
Shelf Pilaster
Shelf Clip
Shelf
Shelf
Clip
Hinge Bottom

▣ Machine room (Refrigeration)-1
Back Panel
Back
Panel

▣ Machine room (Refrigeration)-2
Condensing Unit Disassembly – MCR27U / 36U / 48U / 60U / 72U
CAPILLARY Dryer
Condenser
SUCTION PIPE
Compressor
Unit Base
Hot Pipe
Condenser fan motor
Assembly
Evaporating pan (dish)
Condenser
fan
motor
-
Assembly

▣Compressor Wiring – SD162C-L1U
[MCR27U, MCR36U]
Overload Protector
4TM427PHBYY-53
PTC R l
PTC
R
e
l
ay -
J531Q33E100M200-2
Running Capacitor
250VAC-12㎌

▣ Compressor Wiring – SK1A1C-L2W
[MCR48U, MCR60U, MCR72U]
Overload Protector
4TM795TFBZZ-53
PTC R l
PTC
R
e
l
ay -
J531Q34E220M350-3
Running Capacitor
250VAC-12㎌
Starting Capacitor
125VAC-125㎌

▣ Wiring Diagram
[MCR27U, MCR36U]
HARNESS COMP
Compressor Type [SD162C-L1U]
HARNESS MAIN
POWER CORD

▣ Wiring Diagram
[MCR48U, MCR60U, MCR72U]
HARNESS COMP
Compressor Type [[SK1A1C-L1U2]
Ref.3Dr/72Model
HARNESS MAIN
POWER CORD
