Mayer MMDO9 User manual

Instruction Manual
MMDO9
60cm Built-in Electric Oven

Warning
1) Read instructions carefully before installing or using this product to operate your appliance
safely and correctly. Retain the instruction manual and installation instructions for future
use for subsequent users.
2) The images shown in these instructions are for guidance only.
3) This appliance was designed and created exclusively for standard household use. Do not use
it for commercial or industrial purposes, or for any other purpose than for which it was
designed.
4) Check the appliance for damage after unpacking it. Do not connect the appliance if it has
been damaged in transport.
5) Only a licensed professional may connect appliances without plugs. Damaged caused by
incorrect installation or connection is not covered under warranty.
6) The appliance should be supervised during operation.
7) The appliance is not to be used by persons (including children) with reduced physical,
sensory or mental capabilities, or persons with a lack of experience or knowledge, without
supervision or instruction by a person responsible for their safety who understands the
safety hazards.
8) The appliance should not be played with, or played around.
9) The appliance should only be used indoors.
10) Do not modify, or attempt to modify any of the characteristics of this appliance. This poses a
safety risk.
11) Accessible parts may become hot during use. Children or persons with reduced physical,
sensory or mental capabilities should be kept away from the appliance. Never touch the
interior surfaces of the cooking compartment o the heating element of the appliance when
the appliance is in use.
12) Never place tin foil directly in contact with the oven floor as the buildup of heat may damage
the enamel.
13) Do not cover the cooking compartment floor with any sort of foil or greaseproof paper. Do
not place ovenware on the cooking cavity floor if a temperature of over 50 deg C has been
set. Doing so will cause heat to accumulate and cooking time will be affected, and the oven
floor may be damaged.
14) Over an extended period, moisture in the cooking cavity may lead to corrosion. Allow the
cooking cavity to dry after use. Do not keep moist foods in the closed cooking cavity for
extended periods of time. Do not store food in the cooking cavity.
15) The oven must be turned off when cleaning inside the oven.
16) Do not use harsh or abrasive cleaning agents, cleaning agents with a high alcohol content,
hard scouring pads or cleaning sponges, high pressure cleaners or steam cleaners to clean
the appliance. Do not attempt to clean the appliance while it is still hot.
17) Do not leave the oven door open for the purposes of cooling the oven down. The oven has
an automatic cooling system. Ensure that the oven door is fully closed before operations.
Even if the oven is only left open a crack, the front of nearby furniture may become heat
damaged over time.

Warning
18) If the door seal is very dirty, the appliance door may no longer close properly during
operation. Always keep the seal clean.
19) Only use oven safe cookware with the appliance. Mayer Marketing Pte Ltd is not liable for
damages from improper product usage.
20) Alcoholic vapours may catch fire in the hot cooking compartment. Never prepare food
containing large quantities of drinks with a high alcohol content in the appliance.
21) Open the appliance door with care – do not place items weighing over 15kg on the open
appliance door.
22) After using your oven, ensure that all controls are in their ‘stop’ position.
23) To prevent overheating, do not install this appliance behind a door. Ensure the area of
installation is well ventilated.
24) Do not carry or hold the appliance by the door handle. The door handle cannot support the
weight of the appliance and could break.

1
DEAR CUSTOMER,
The oven is exceptionally easy to use and extremely efficient.After reading the instruction
manual,operating the oven will be easy.
Before being packaged and leaving the manufacturer,the oven was thoroughly checked with
regard to safety and functionality.
Before using the appliance,please read the instruction manual carefully.
By following these instructions carefully you will be able to avoid any problems in using the
appliance.
It is important to keep the instruction manual and store it in a safe place so that it can be
consulted at any time.
Caution!
Do not use the oven until you have read this instruction manual.
The oven is intended for household use only.
The manufacturer reserves the right to introduce changes which do not affect
the operation of the appliance.
Please become familiar with these recommendations before installing and using your oven.
They were written for your safety and the safety of others.

2
TABLE OF CONTENTS
Safety instructions............................................................................................3
How to save energy..................................................................................................5
Description of the appliance....................................................................................7
Specifications of the appliance...............................................................................8
Installation...................................................................................................9
Operation....................................................................................................11
Cleaning and maintenance.....................................................................................15
Operation in case of emergency..........................................................................19
Baking in the oven-practical hints........................................................................20
Technical data........................................................................................................25

3
SAFETY INSTRUCTIONS
Safety Instructions
1) Ensure that the appliance is installed to a grounded power source.
2) A dedicated power circuit is recommended for the appliance. Additional electrical appliances
on the same circuit may exceed the current (amperage) rating for the circuit leading to the
circuit breaker tripping or fuse failing.
3) Avoid the use of an extension cord, which may overheat and cause a fire.
4) The appliance must be installed by a qualified professional in compliance with the
instructions provided. Mayer Marketing Pte Ltd is not liable for damages caused by improper
installation or operation of the appliance.
5) The appliance should not be connected to a power supply during servicing or if not in use for
an extended period.
This is a classified electrical appliance. As with any electrical appliance, basic precautions should
be followed in order to reduce the risk of harm to self, others and property.
The appliance becomes very hot during operation. Never touch the interior surfaces of the
cooking cavity, the heating elements and cooking accessories within the appliance during
operation. Make use of heat protection before interacting with the oven cavity when hot.
Loose food remnants, fat, grease and meat juices may catch fire. Before using the appliance,
ensure that the cooking cavity, heating elements and accessories are clean.
In case of fire or smoke within the cavity, do not open the appliance door as this may cause
the fire to spread into your home and cause severe burns. Immediately switch off the
appliance and unplug it from the mains, or switch off the circuit breaker in the fuse box.
Leave the fire to burn out on its own. If fire persists, call the fire department immediately
and get to safety.
This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities or lack of experience and knowledge without supervision and
instruction by a person responsible for their safety and who understands the associated
hazards.
Ensure that small items of household equipment, including connection leads do not touch
the hot appliance as the insulation material of such equipment are usually not resistant to
such high temperatures.
If the supply cord is damaged, it must be replaced by a service agents of Mayer Marketing
Pte Ltd or similarly qualified persons. Mayer Marketing Pte Ltd is not liable for damages as a
result of improper installation or servicing of the appliance.
The appliance must be disconnected from the power supply whenever servicing or
installation work is being carried out.
Do not use the appliance in event of a technical fault. Faults should be serviced by service
agents of Mayer Marketing Pte Ltd. Contact information for the service centre is available on
the back of this instruction manual.

4
SAFETY INSTRUCTIONS
The panels adjacent to the oven should be made of heat resistant material.
Cabinets with a veneer exterior must be assembled with glues which can withstand
temperatures of up to 100 deg C.
Keep combustible materials such as curtains, drapes, linens, paper etc. out of contact away
from the appliance when in operation. Do not use this appliance in areas where gasoline or
other flammable liquids and their associated vapours may be present.
Ensure the appliance is installed in a well ventilated area.
The unit’s power cord must be connected to a properly grounded and protected 220 – 240V
electrical outlet. Always use ground fault protection where required by the electrical code.
Do not operate any appliance with a damage cord or plug or after the appliance
malfunctions, has been dropped, or damaged in any manner. Contact the authorized service
centre to arrange for servicing.
Use this appliance only as described in this manual.
Water in a hot cooking cavity may create hot steam. Never pour water onto the hot cooking
cavity or on accessories within the hot cooking cavity.

5
HOW TO SAVE ENERGY
Using energy i n a
way not
only
saves money but also
helps the
environment .So
let's save energy!
!
! Switch off the oven in good time and
make use of residual heat.
For long cooking times,switch
5 to 10 minutes before finishing
cooking,This saves up to 20% on energy.
Only use the oven when cooking larger
dishes.
Meat of up to 1 kg can be prepared more
economically in a pan on the cooker hob.
Important!When using the timer,set
appropriately shorter cooking times
according to the dish being
prepared.
!
! Do not install the cooker in the direct
vicinity of refrigerators/freezers.
Otherwise energy consumption increases
unnecessarily.
responsible
Here
are some ways to do so:
Open the appliance door as infrequently
as possible when the appliance is in use.
the
appliance
!
!
Open the appliance door as infrequently
as possible when the appliance is in use.
Leave frozen food to defrost before
cooking it in the cooking cavity.

6
UNPACKING DISPOSAL OF THE APPLIANCE
During transportation,protec-
tive packaging was used to
protect the appliance against
any damage.After unpack-
ing,please dispose of all
elements of packaging in a
way that will not cause dam-age to the
environment.All materials used for packaging
the appli-ance are environmentally friendly;they
are 100% recyclable and are marked with the
appropriate symbol.
Caution! During unpacking,the packag- ing
materials(polythene bags,p o l y s t y r e n e
pieces,etc.)should be kept out of reach of children.
Old appliances should not sim-
ply be disposed of with normal
household waste,but should be
delivered to a collection and
recycling centre for electric and
electronic equipment.A symbol
shown on the product,the instruction manual
or the packaging shows that it is suitable for
recycling.
Materials used inside the appliance are
recyclable and are labelled with information
concerning this.By recycling materials or
other parts from used devices you are making a
significant contribution to the protection of our
environment.
Information on appropriate disposal centres
for used devices can be provided by your
local authority.
▲
▲

1 Oven function selection knob
2 Temperature control knob
3 Timer
4 Red temperature regulator signal light
5
Oven door handle
3
21
3
2
1
4
5
CONTROL PANEL

Oven shelf
Baking tray
8

600
530
!
! This is a built-in oven, and its back wall
and one side wall can be placed next to a
high piece of furniture or a wall.Coating
or veneer used on fitted furniture must be
applied with a heat-resistant adhesive
(100℃).This prevents surface deforma-
tion or detachment of the coating.
! Make an opening with the dimensions
given in the diagram for the oven to be
fitted.
! Make sure the mains plug is disconnected
and then connect the oven to the mains
supply.
! Insert the oven completely into the opening
without allowing the four screws in the
places shown in the diagram to fall out.
Product Dimensions
Height: 595mm
Width: 595mm
Depth: 530mm
Aperture Dimensions
600mm
560mm
560mm(min)
9
The
kitchen area should be dry and well
ventilated. When installing the oven, ensure
easy access to all control elements.
The

10

11
OPERATION
Before first
! Remove packaging,clean the interior
of the oven
! Take out and wash the oven fittings
with warm water and a little washing-
up liquid.
! Switch on the ventilation in the room
or open a window.
!
Important!
The inside of the oven should only be
washed with warm water
use:
appliance.
Heat the ovengradually, from the lowest
available temperature to the highest available
temperature with temperature increments
being 10deg C at a time. Allow the oven to
remain at each set temperature for
approximately 10mins before further increasing
the temperature.
and
bio-degradable washing solutions.
Use a mixture of baking soda and water
for a quick and easy clean.

Oven functions and operation.
The oven can be warmed up using the bottom
and top heaters. Operation of the oven is
controlled by the oven function knob-to set a
required function you should turn the knob to
the selected position.
The oven can be switched off by setting both
of these knobs to the position “●”/”○”.
Oven on and off
12
Turn the control knob clockwise to the manual
operation symbol . So that the cooking time
can be no limited.
To stop the oven by turning the control konb to 0.
0
50
100
150
200
250
Turn the knob to set the required temperature.
When the oven has achieved the programmed
temperature, the red light next to the
temperature selection knob will be off. During
pre-heat, the light will be on.
Cooking functions
Heat the oven conventionally. Also
known as traditional heat.
Conventional heat with a fan for
improved heat distribution within the
cooking cavity.

13
&
Note:
Note:

14
In ovens with the function Fan & Combined
Grill, pre-heating up to 150 deg C may be up
to 50% quicker using this function.
switching
insert prepared ingredients into oven
adjust function to desired if different from
Fan & Combined Grill
.
.
.
.
Set the oven function to Fan & Combined Grill.

By ensuring proper cleaning and mainte-
nance of your cooker you can have a sig-
nificant influence on the continuing fault-free
operation of your appliance.
15
! Bio-degradable or natural cleaning products are
recommended e.g. baking soda, lemon,
vinegar etc.
Otherwise, specialised oven cleaners may also
be used.

16
Replacement of the oven light bulb
Oven light bulb
G9
Caution!
may
The oven chamber should only be washed with
warm water and asmall amount of bio-
degradable washing up solution. Alternatively,
mix baking soda with water for a quick fix.
Do not use cleaning products containing
abrasive materials for the cleaning and
maintenance of the glass front panel or
the oven chamber to prevent damage
to these surfaces.
C

17
▲
Removing the doors
a. The oven door is fully open。
b. The latch hinges completely lifted。
c. Gently close the oven door until you hear
the sound of engagement, once they reach
a clamping position, with both hands holding
the door and continue to push, pull up at the
same time so that the hinge bolt removed
from the oven
d.
e.
c.
.
C
▲
Remove the inner glass panel
b. Remove the inner glass .
A
B
a. Press and hold the two sides of the grid with
both hands to pull it out .
Pull out the grid
Right
Left
After cleaning, align the hinge with
the oven door. Latch and push
it
until it catches.
Take care to ensure
that the hinge and door are properly
aligned to avoid door damage.
If in doubt, contact the service centre -
information is listed on the back of this user
manual.
With the oven door fully opened, push the
latch down to it's initial position to complete
the oven door installation.
Locate the glass stopper and remove it.
Remove the glass
for cleaning.
To reinstall
the inner glass, simply gently place it back
onto the door and reinsert the glass
stopper to secure the glass in place.
