Maytag MDBH945AWW Manual

Repair
Parts
List
MODEL NUMBER
MDBH945AWW
When requesting service or ordering parts, always
provide the following information:
- Product Type - Part Number
- Model Number - Part Description
DISHWASHER
©2005 Maytag Services

Section: CONTROL PANEL
DW11-84
Model: MDBH945AWW
1

CONTROL PANEL
No. Part No. Description
Section:
Series Qty
1 99003397 PANEL, CONTROL (WHT) 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, PANEL 10 4
2 99002931 VENT SEAL, CONTROL PANEL 10 1
3 99002579 HANDLE, LATCH (WHT) 10 1
4 99002751 SWITCH, DOOR 10 2
5 99003347 LATCH ASSEMBLY 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 2
6 99002576 HOUSING, BOARD (BASE) 10 1
7 99003466 BOARD, CONTROL 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, HOUSING 10 1
8 99002575 HOUSING, BOARD (TOP) 10 1
- 99002986 WIRE HARNESS, MICROPROCESSOR 10 1
2
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: DOOR
DW12-79
Model: MDBH945AWW
3

DOOR
No. Part No. Description
Section:
Series Qty
1 99002770 PANEL, DECO (W/DAMPER-WHT) 10 1
2 99002673 VENT HOUSING ASSEMBLY 10 1
- Y912620 SCREW Note: SCREW, REINFORCEMENT 10 3
3 99002586 REINFORCEMENT, INNER DOOR 10 1
- 99001075 SCREW Note: SCREW, BRACKET 10 4
4 99002930 BRACKET, HINGE (RT) 10 1
4 99002929 BRACKET, HINGE (LT) 10 1
5 Y99002587 INSULATION, DOOR 10 1
6 903233 FOAM STRIP, INSULATION 10 1
- 99002756 PUSHNUT, STAINLESS 10 2
7 99002589 SEAL, DOOR (BTM) 10 2
- Y912620 SCREW Note: SCREW, DOOR 10 11
8 99002970 DOOR, INNER (W/DAMPER) 10 1
9 99003316 BRACKET, DISPENSER MOUNTING 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, BRACKET 10 6
10 99002270 SEAL, BASE 10 1
11 99002611 RINSE AID/DETERGENT DISPENSER 10 1
12 99002614 KNOB, RINSE AID (W/O-RING) 10 1
13 99002186 SEAL, DOOR VENT 10 1
14 99002590 BEZEL, DOOR VENT 10 1
4
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TRACK & RACK ASSEMBLY
DW15-137
Model: MDBH945AWW
5

TRACK & RACK ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99003218 RACK ASSEMBLY (UPR) 10 1
- 99002017 CAP, RACK (LIGHT GRAY) 10 1
2 99002621 TRACK, RACK 10 2
- 99002623 STOP, RACK (GRAY) 10 4
3 99002947 TUB WHEEL ASSEMBLY (GRAY) 10 8
- 99002740 SCREW, TRUSS HEAD (10-18X.75) Note: SCREW, WASH ARM 10 1
4 99002624 ARM, WASH (UPR) 10 1
5 99002945 CLIP, UPR WASH MANIFOLD (BACK) 10 1
6 99002679 WASH MANIFOLD ASSY (UPR) 10 1
7 99002669 CLIP, UPR WASH MANIFOLD (FRT) 10 1
8 99002781 WHEEL ASSEMBLY (UPR) 10 4
- 99002017 CAP, RACK (LIGHT GRAY) 10 1
9 99003219 RACK ASSEMBLY (LWR) 10 1
10 99002780 WHEEL ASSEMBLY (LWR) 10 8
11 99002617 BASKET, SILVERWARE (W/COVER) 10 1
12 99002618 COVER, SILVERWARE BASKET 10 1
13 99002619 HANDLE, SILVERWARE BASKET 10 1
14 99002620 BASKET, AUXILLARY (BLUE) 10 1
6
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: TUB
DW13-113
Model: MDBH945AWW
7

TUB
No. Part No. Description
Section:
Series Qty
1 99002629 BRACKET, WATER VALVE 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
2 99002975 VALVE, WATER 10 1
- 99002553 SCREW-#8X7/16 HEX WASHER HEAD Note: SCREW, VALVE 10 2
3 911856 CLAMP, SPRING 10 1
4 99002852 HOSE, INJECTOR 10 1
- 99002646 SEAL, AIR/WATER INLET 10 1
5 99002645 INLET, AIR/WATER 10 1
6 99002588 SEAL, DOOR 10 1
7 99002648 BRACKET, CABINET MOUNTING 10 2
- 99001194 SCREW, ACCESS PANEL Note: SCREW, PANEL (WHT) 10 2
8 99002766 PANEL, TOE (W/DAMPER-WHT) 10 1
9 99002695 INSULATION, TUB (TOP/SIDES) 10 1
- 99002640 FASTENER, INSULATION 10 2
10 99002610 BRACKET, SPRING ADJUSTMENT 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
11 99002598 SPRING, DOOR 10 2
12 99002605 CABLE, DOOR 10 2
13 99002606 LINK, DOOR CABLE 10 2
14 99002608 ROLLER, CABLE BRACKET 10 2
15 99002609 SHOULDER BOLT, CABLE BRACKET 10 2
16 99002607 BRACKET, CABLE 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 4
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, SUPPORT 10 4
17 99002927 SUPPORT, HINGE (RT) 10 1
17 99002928 SUPPORT, HINGE (LT) 10 1
- 99002692 SCREW, TRIM MOUNTING 10 8
18 99002649 STRIP, TRIM 10 2
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
19 99002637 BRACKET, JUNCTION BOX SUPPORT 10 1
20 99002635 LEG, LEVELING 10 4
21 99002638 COVER, JUNCTION BOX 10 1
- 912365 SCREW Note: SCREW, COVER 10 1
22 99002630 FLOAT 10 1
- 99002749 SCREW, STEEL HEX HD PLASITE Note: SCREW, PLATE 10 1
23 99002943 PLATE, SWITCH MOUNTING 10 1
24 99002631 SWITCH, FLOAT 10 1
25 99002634 CLIP, THERMOSTAT 10 1
26 99002633 THERMOSTAT, LIMITING 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, BRACKET 10 2
27 99002636 BRACKET, SUPPORT (LT) 10 1
28 99002971 HEATER (W/GASKET) 10 1
- 99002973 GASKET, HEATER 10 2
29 99002626 BRACKET, HEATER SUPPORT 10 2
30 99002972 NUT, HEATER 10 2
31 99002860 SUPPORT, FRONT (W/SEALS)(WHT) 10 1
- 99001194 SCREW, ACCESS PANEL Note: SCREW, SUPPORT 10 2
8
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WATER DISTRIBUTION ASSEMBLY
DW14-72
Model: MDBH945AWW
9

WATER DISTRIBUTION ASSEMBLY
No. Part No. Description
Section:
Series Qty
1 99002642 MANIFOLD, MAIN 10 1
2 99002643 BRACKET, MANIFOLD MOUNTING 10 2
3 99002674 STATION, DOCKING (W/FLAPPER) 10 1
4 99002676 WASH ARM, TOP (W/RETAINER) 10 1
5 99002753 RETAINER, TOP WASH ARM 10 1
10
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: PUMP & MOTOR
DW14-81
Model: MDBH945AWW
11

PUMP & MOTOR
No. Part No. Description
Section:
Series Qty
1 99002654 CAP, WASH ARM 10 1
2 99002678 WASH ARM, LOWER (W/SHIELDS) 10 1
3 99002653 SHIELD, RADIANT 10 2
4 99002979 GUARD, FILTER (GRAY) 10 1
- 99002666 SCREW Note: SCREW, GUARD 10 3
5 99002677 DISCHARGE HOUSING ASSY (UPR) 10 1
- 99002664 SCREW, DISCHARGE HOUSING 10 6
6 99002659 WASH IMPELLER ASSEMBLY 10 1
- 99002660 SCREW, IMPELLER 10 1
- 99002668 SCREW, STAINLESS PAN HEAD Note: SCREW, FILTER/FLOWPLATE 10 3
7 99002661 FILTER/FLOWPLATE ASSEMBLY 10 1
8 99002658 CHOPPER 10 1
9 99003341 SEAL KIT, METAL CHOPPER SLEEVE 10 1
10 99003430 WASH MOTOR ASSY SEAL NOT INCL 10 1
- 912615 SCREW, #8X1/2 HEX WASHER HEAD Note: SCREW, SENSOR 10 2
- 99002651 O-RING, TURBIDITY SENSOR 10 1
11 99002650 SENSOR, TURBIDITY 10 1
12 99002663 GASKET, PUMP 10 1
- 99003440 SHIELD, CAPACITOR 10 1
13 99002665 CAPACITOR, MOTOR 10 1
- 99002601 SCREW 10-32X.400 (T-20 HEAD) Note: SCREW, CAPACITOR 10 1
- 99002815 FLAPPER, DRAIN PUMP VALVE 10 1
14 99002750 DRAIN PUMP ASSEMBLY 10 1
15 99003058 FLAPPER, DRAIN FILTER 10 1
16 99002857 O-RING, DRAIN PUMP 10 1
17 99002752 BRKT, DRAIN PUMP (W/GROMMET) 10 1
- 99002657 SCREW, DRAIN PUMP MOUNTING 10 1
- 99002656 CLAMP, DRAIN HOSE (1-3/8") 10 1
18 99002652 HOSE, DRAIN 10 1
12
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

SUPPLEMENTAL INFORMATION
No. Part No. Description
Section:
Series Qty
- Y6920187 MANUAL, USE & CARE 30 1
- 6919560 MANUAL, USE & CARE 10 1
- 16026393 TECH SHT,DISHWASHER 10 1
- 16021814 TALL TUB SERVICE MANUAL 10 1
- 99003027 GUIDE, ENERGY 10 1
- 99002854 MISC. PARTS PACKAGE 10 1
13
*Color Code (-)=Not Shown #=Series, Serial Prefix or Run No., N=Not Available

Section: WIRING INFORMATION
15003703
Model: MDBH945AWW
14
