MDG76PC
(Phase 7.3 Coin Gas DSI)
Installation Manual
WARNING: Foryoursafetytheinformationin
thismanualmustbefollowedtominimizetherisk
of fire or explosion or to prevent property
damage,personalinjury or death.
— Donot storeor usegasoline orother flammable
vapors and liquids in the vicinity of this or any
otherappliance.
— WHATTODO IFYOU SMELLGAS:
• Donottryto lightanyappliance.
• Donottouch anyelectricalswitch; do not
useanyphoneinyourbuilding.
• Cleartheroom, buildingorareaof all
occupants.
• Immediatelycallyourgassupplierfroma
neighbor’sphone. Followthe gas supplier’s
instructions.
• Ifyoucannotreach yourgassupplier,call
thefiredepartment.
— Installationand servicemust beperformed bya
qualified installer, service agency or the gas
supplier.
AVERTISSEMENT: Assurez-vous de bien
suivrelesinstructionsdonnéesdanscettenotice
pourréduire auminimum lerisque d’incendie
ou d’explosion ou pour éviter tout dommage
matériel,touteblessureou lamort.
— Ne pas entreposer ni utiliser d’essence ni
d’autres vapeurs ou liquides inflammables à
proximité de cet appareil ou de tout autre
appareil.
— QUEFAIRESIVOUSSENTEZUNEODEUR
DEGAZ:
• Nepastenter d’allumerd’appareils.
• Netouchez àaucun interrupteur. Ne pas
vousservirdes téléphonesse trouvant dans
lebâtiment.
• Évacuezlapièce,le bâtimentoulazone.
• Appelezimmédiatementvotrefournisseur
degazdepuisunvoisin. Suivez les
instructionsdufournisseur.
• Sivousnepouvezrejoindrelefournisseur
degaz,appelez leservice des incendies.
— L’installationetl’entretiendoiventêtreassuréspar
uninstallateurou unserviced’entretienqualifié
ouparle fournisseurdegaz.
040703JEV/mcronan PartNo.113184
RETAINTHESEINSTRUCTIONSINASAFE
PLACE FOR FUTURE REFERENCE

“IMPORTANTNOTETOPURCHASER”
Informationmustbeobtainedfromyourlocalgassupplierontheinstructions
tobefollowed iftheuser smellsgas. Theseinstructions mustbeposted ina
prominentlocationnearthedryer.
FORYOUR SAFETY
Donot store or use gasolineor
otherflammablevaporsand
liquidsinthevicinityofthisor
anyotherappliance.
POURVOTRESÉCURITÉ
Nepas entreposer niutiliser d’essence
nid’autresvapeursouliquides
inflammablesàproximitédecet
appareilou detout autre appareil.
Retain This Manual In ASafe Place For Future Reference
Our products embody advanced concepts in engineering, design, and safety. If this product is properly maintained, it will
provide many years of safe, efficient, and trouble free operation.
ONLY qualified technicians should service this equipment.
OBSERVE ALL SAFETY PRECAUTIONS displayed on the equipment or specified in the installation manual included with
the dryer.
The following “FOR YOUR SAFETY” caution must be posted near the dryer in a prominent location.
We have tried to make this manual as complete as possible and hope you will find it useful. The manufacturer reserves the
right to make changes from time to time, without notice or obligation, in prices, specifications, colors, and material, and to
change or discontinue models.
Important
For your convenience, log the following information:
DATE OFPURCHASE________________________________ MODELNO. __________________________________________
DEALER’SNAME __________________________________________________________________________________________
Serial Number(s) ________________________________________________________________________________________
________________________________________________________________________________________
________________________________________________________________________________________
For replacement parts, contact the dealer from which the dryer was purchased or contact:
MAYTAG CO.
403 West Fourth Street North
Newton, Iowa 50208
[phone]

IMPORTANT
YOUMUSTDISCONNECTANDLOCKOUTTHEELECTRICSUPPLYANDTHEGAS
SUPPLY BEFORE ANY COVERS OR GUARDS ARE REMOVED FROM THE
MACHINETOALLOWACCESSFORCLEANING,ADJUSTING,INSTALLATION,OR
TESTING OF ANY EQUIPMENT PER OSHA (Occupational Safety and Health
Administration)STANDARDS.
WARNING
CHILDRENSHOULD NOTBEALLOWEDTOPLAYONORNEARTHEDRYER(S).
CHILDRENSHOULDBESUPERVISEDIFNEARDRYERSINOPERATION.
CAUTION
DRYERSSHOULDNEVERBELEFTUNATTENDEDWHILEINOPERATION.
FORYOURSAFETY
DONOTDRYMOPHEADSINTHEDRYER.
DONOTUSEDRYERINTHEPRESENCEOFDRYCLEANINGFUMES.
WARNING
UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch,
or the heat circuit devices ever be disabled.
“Caution: Label all wires prior to
disconnection when servicing controls. Wiring
errors can cause improper operation.”
«Attention: Au moment de l’entretien des
commandes,étiqueteztouslesfilsavantde
les débrancher. Des erreurs de câblage
peuvent entraîner un fonctionnement
inadéquatetdangereux.»

WARNING
The dryer must never be operated with any of the back guards, outer tops, or service
panelsremoved. PERSONALINJURYORFIRECOULDRESULT.
IMPORTANT
PLEASEOBSERVEALLSAFETYPRECAUTIONSdisplayedontheequipmentand/or
specified in the installation manual included with the dryer.
Dryer mustnot beinstalled or stored in an area where it willbe exposed to water or weather.
The wiring diagram for the dryer is located in the front electrical control box area.
DRYER MUST NEVER BEOPERATEDWITHOUTTHELINTFILTER/SCREENIN
PLACE,EVENIFANEXTERNALLINTCOLLECTIONSYSTEMISUSED.
WARNING
IMPORTANT
Dryer must be installed in a location/environment, which the ambient temperature
remains between 40° F (4.44° C) and 130° F (54.44° C).

SECTION I
IMPORTANT INFORMATION ...............................................................................3
A. ReceivingandHandling ............................................................................................................... 3
B. SafetyPrecautions ...................................................................................................................... 4
SECTION II
SPECIFICATIONS/COMPONENT IDENTIFICATION.....................................6
A. Specifications ............................................................................................................................. 6
B. ComponentIdentification ............................................................................................................ 8
SECTION III
INSTALLATION PROCEDURES .........................................................................10
A. LocationRequirements ............................................................................................................. 10
B. Unpacking/SettingUp ............................................................................................................... 11
C. DryerEnclosureRequirements .................................................................................................. 13
D. FreshAirSupplyRequirements ................................................................................................. 14
E. ExhaustRequirements ............................................................................................................... 15
F. ElectricalInformation ................................................................................................................ 19
G. GasInformation ........................................................................................................................ 23
H. Preparation ForOperation/Start-Up ......................................................................................... 27
I. PreoperationalTests ................................................................................................................. 28
J. PreoperationalInstructions ........................................................................................................ 30
K. ShutdownInstructions............................................................................................................... 30
SECTION IV
ROUTINE MAINTENANCE ..................................................................................31
A. Cleaning ................................................................................................................................... 31
B. Adjustments ............................................................................................................................. 32
C. Lubrication ............................................................................................................................... 32
Table of Contents

SECTION V
DATA LABEL INFORMATION .............................................................................33
A. DataLabel ............................................................................................................................... 33
SECTION VI
PROCEDURE FOR FUNCTIONAL CHECK OF REPLACEMENT
COMPONENTS........................................................................................................35

3
SECTIONI
IMPORTANTINFORMATION
A. RECEIVINGAND HANDLING
The dryer is shipped in a protective stretch wrap cover with protective cardboard corners and top cover (or
optional box) as a means of preventing damage in transit. Upon delivery, the dryer and/or packaging, and
wooden skid should be visually inspected for shipping damage. If any damage whatsoever is noticed, inspect
further before delivering carrier leaves.
Dryers damaged in shipment:
1. ALL dryers should be inspected upon receipt and before they are signed for.
2. If there is suspected damage or actual damage, the trucker’s receipt should be so noted.
3. If the dryer is damaged beyond repair, it should be refused. Those dryers, which were not damaged in a
damaged shipment, should be accepted, but the number received and the number refused must be noted
on the receipt.
4. If you determine that the dryer was damaged after the trucker has left your location, you should call the
delivering carrier’s freight terminal immediately and file a claim. The freight company considers this
concealed damage. This type of freight claim is very difficult to get paid and becomes extremely difficult
when more than a day or two passes after the freight was delivered. It is your responsibility to file freight
claims. Dryer/parts damaged in transit cannot be claimed under warranty.
5. Freight claims are the responsibility of the consignee, and ALL claims must be filed at the receiving end.
Manufacturer assumes no responsibility for freight claims or damages.
IMPORTANT: The dryermustbe transportedand handledinan uprightposition at ALLtimes.

4
B. SAFETY PRECAUTIONS
WARNING: Foryoursafety,theinformationinthismanualmustbefollowedto minimize theriskof
fireorexplosion ortoprevent propertydamage,personal injury,or lossoflife.
WARNING: Thedryermust neverbe operated with anyoftheback guards, outer tops, or
servicepanelsremoved. PERSONALINJURYOR FIRE COULDRESULT.
1. DO NOT store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
2. Purchaser/user should consult the local gas supplier for proper instructions to be followed in the event the
user smells gas. The instructions should be posted in a prominent location.
3. WHAT TO DO IF YOU SMELL GAS...
a. DO NOT try to light any appliance.
b. DO NOT touch any electrical switch.
c. DO NOT use any phone in your building.
d. Clear the room, building, or area of ALLoccupants.
e. Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions.
f. If you cannot reach your gas supplier, call the fire department.
4. Installation and service must be performed by a qualified installer, service agency, or gas supplier.
5. Dryer(s) must be exhausted to the outdoors.
6. Although Maytag produces a very versatile dryer, there are some articles that, due to fabric composition or
cleaning method, should not be dried in it.
WARNING: Dryonly waterwashed fabrics. DONOT dry articlesspotted orwashed indry cleaning
solvents,acombustibledetergent,or“all purpose”cleaner.
EXPLOSIONCOULDRESULT.
WARNING: DONOT dry ragsor articlescoated orcontaminated withgasoline, kerosene,oil, paint,
orwax.
EXPLOSIONCOULDRESULT.
WARNING: DONOTdrymop heads. Contaminationbywax orflammable solventswillcreate a
firehazard.
WARNING: DONOT useheat fordrying articlesthat containplastic, foam, spongerubber,or
similarlytexturedrubbermaterials. Dryinginaheatedbasket (tumbler)maydamage
plasticsor rubberand maybe afire hazard.

5
7. A program shouldbeestablished for the inspection and cleaning of lint in the burner area, exhaust ductwork,
and area around the back of the dryer. The frequency of inspection and cleaning can best be determined
from experience at each location.
WARNING: Thecollectionof lintinthe burnerareaandexhaust ductworkcancreate a potentialfire
hazard.
8. For personal safety, the dryer must be electrically grounded in accordance with local codes and/or the
National Electrical Code ANSI/NFPA NO. 70-LATEST EDITION, or in Canada, the Canadian Electrical
Codes Parts 1 & 2 CSA C22.1-1990 or LATEST EDITION.
NOTE: Failureto dosowillVOIDTHEWARRANTY.
9. UNDER NO CIRCUMSTANCES should the dryer door switches, lint drawer switch, or the heat circuit
devices ever be disabled.
WARNING: PERSONALINJURYORFIRE COULDRESULT.
10. This dryer is not to be used in the presence of dry cleaning solvents or fumes.
11. Remove articles from the dryer as soon as the drying cycle has been completed.
WARNING: Articlesleftin the dryerafterthedrying and coolingcycleshavebeen completedcan
createa firehazard.
12. READ AND FOLLOW ALL CAUTION AND DIRECTION LABELS ATTACHED TO THE
DRYER.
13. For safety, proper operation, and optimum performance, the dryer must not be operated with a load less
than sixty-six percent (66%), 50 lbs (22 kg) of its rated capacity.
WARNING: YOUMUSTDISCONNECTAND LOCKOUTTHE ELECTRICSUPPLYAND
THEGAS SUPPLYORTHESTEAMSUPPLYBEFOREANYCOVERS OR
GUARDSARE REMOVEDFROMTHE MACHINETOALLOWACCESS
FORCLEANING,ADJUSTING,INSTALLATION,ORTESTINGOFANY
EQUIPMENTPEROSHA(Occupational Safety andHealthAdministration)
STANDARDS.
IMPORTANT: Dryer mustbeinstalledina location/environment,which theambient
temperatureremains between 40°F(4.44° C) and130°F (54.44° C).

6
SECTIONII
SPECIFICATIONS/COMPONENTIDENTIFICATION
A. SPECIFICATIONS
Gas
Shaded areas are stated in metric equivalents
* A minimum of 3/4” pipe must be supplied to the gas inlet for each dryer.
NOTE: Manufacturerreservestherightto make changesinspecificationsatanytime withoutnoticeor
obligation.
052103
BASKET (TUMBLER) DIAMETER 44-1/2” 113.03 cm
BASKET (TUMBLER) DEPTH 24-7/8” 63.18 cm
BASKET
(TUMBLER) MOTOR 1 hp 0.746 kW
DOOR OPENING (DIAMETER) 31-3/8” 79.7 cm
BASKET (TUMBLER) VOLUME 22.4 cu.ft. 0.634 cu.m.
VOLTAGE AVAILABLE 120v 1ø, 60 Hz
HEAT INPUT 204,000 Btu/hr 51,408 kcal/hr
AIRFLOW 1,200 cfm 33.98 cmm
INLET PIPE CONNECTION 3/4” F.N.P.T.*
