Maytag MED5900TW0 User manual

TOP AND CONSOLE PARTS
1
For Model: MED5900TW0
(White)
29" ELECTRIC DRYER
9−07 Litho in U.S.A. (drd) Part No. W10117335 Rev. B

TOP AND CONSOLE PARTS
2
For Model: MED5900TW0
(White)
W10117335
Illus. Part
No. No. DESCRIPTION
1 Literature Parts
W10088770 Use & Care Guide
W10089172 Dryer Cycle Sheet
W10112987 Tech Sheet
2
W10112576 Panel, Console
Rear
3 693995 Screw, 8−18 x 3/8
4
W10108400 Harness, Wiring
Center Control
5 3405281 Relay, Motor
6 3388228 Screw,8−18 x 11/32
7 3405151 Switch,
End Of Cycle
8 3405152 Switch,
Wrinkle Guard
9
W10111812 Control Assembly
10 8299771 Timer, 60 Hz.
11 8533971 Screw, 8−18 x 5/16
12 8299970 Switch,
Temperature
13 8566493 Relay, Heater
14
W10156101 Switch,
Push−To−Start
15 3405281 Relay, Heater
16 8579712 Console & Shell
Assembly (Includes
Items 17 & 18)
17 8312709 Clip, Console
18
W10112569 Badge Assembly
19 8536939 Clip, Spring
20
W10110035 Knob, Control (3)
21
W10110036 Knob, Timer
22
W10110037 Knob,
Push−To−Start
23 337686 Screw, 8−18 x 1/2
24 8565981 Bracket, Harness
25
W10118608 Seal, Harness
26
W10112267 Seal, Foam
Console Bracket
27
W10108380 Harness, Wiring
28 8565972 Screen, Lint
29 688983 Screw, 8−18 x 5/8
30
W10112599 Top
31 237446 Washer (Top/Chute)
32 3395683 Connector (Motor)
33 3394427 Clip, Harness
34 3401144 Connector
(PTS Relay)
35 3397269 Connector (Timer)
36 3347243 Connector,
6−Circuit
37 94614 Terminal
38 3936144 Connector

CABINET PARTS
3
For Model: MED5900TW0
(White)
W10117335

CABINET PARTS
4
For Model: MED5900TW0
(White)
W10117335
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 8530603 Cabinet
(Includes Item 4)
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, 8/18 x 3/8
4 8541400 Bracket, Cabinet
5 3396795 Cover,
Terminal Block
6 3392100 Foot, Dryer
279810 Foot, Optional
Extended Length
(Package Of 2)
(Not Included)
7 3396805 Panel, Rear
8 3394083 Clip,
Front Panel
9 98669 Locator, Top (2)
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 18776 Lock,
Front Top (2)
13 3403444 Panel, Front
14 98234 Clip, Ground
15 685203 Clip, Felt Pad (3)
16 3406129 Seal & Bearing
Assembly
17 3404413 Plug, Hole
18 3403431 Strike, Door
19 3403630 Plug, Strike
20 342055 Screw, 8−18 x 1/2
21 3405514 Hinge, Door (2)
22 3389441 Catch,
Door Assembly
23 3405246 Seal, Door
24 3402341 Door Rear
25 3402335 Door, Front
26 8565970 Handle, Door
27 3397659 Block, Terminal
28 3393008 Screw, 10−16 x 1/2
29 279393 Terminal Block
Kit (For
Terminal Block)
30 279318 Terminal, Tinned
& Brass (3)
(Includes Item 29)
31 8066217 Hinge, Top (2)
32 18849 Pad, Top Hinge (2)
33 697776 Screw, 10−32 x 5/8
34 3404162 Clamp, Motor
(W/Shield)
35 660658 Clamp, Motor
36 8066206 Motor Assembly,
60 Hz.
37 8066184 Pulley, 60 Hz.
38
W10131364 Belt, Drive
39 3400500 Bolt,
5/16−18 x 3/4
40 348780 Base, Motor
41 691366 Idler & Pulley
Assembly

BULKHEAD PARTS
5
For Model: MED5900TW0
(White)
W10117335

BULKHEAD PARTS
6
For Model: MED5900TW0
(White)
W10117335
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 487909 Screw, 8−15 x 1/2
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 696302 Shield, Exhaust
7 3976479 Pad−Sensor
8 8577274 Thermister
9 3977393 Thermal, Cut−Off
(Includes
Illus. 15)
10 694089 Wheel, Blower
11 8577231 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8541818 Box, Heater
15 3404153 Thermostat,
140 F
16 3977373 Bracket, Drum
Light
17 3401338 Element, Heater
18 8066086 Drum Hole
Plug
19 279457 Wire Kit, Terminal
(For Heater
Element Wiring
Harness Repair)
20 489463 Screw, 8−18 x 5/8
21 3390647 Screw, 8−18 x 1/2
22 3406126 Bulb
23 3402841 Lens, Drum Light
24 690997 Ring, Tri
25 3399506 Shaft, L.H.
26 3399507 Shaft, R.H.
27 3397590 Roller, Support
28 348197 Washer, Support
29 3359452 Nut, 3/8−16
30 3403413 Bulkhead
31
W10136369 Socket Assembly
32 692526 Ring, Bearing (2)
33
W10109200 Screw, 11−16 x 3/4
34 3406130 Seal, Rear Drum
35 695587 Drum Assembly
36 692490 Baffle, Drum (2)
37 3976434 Bracket, Support
38 90296 Clip
39 3403636 Baffle, Drum (1)
40 339956 Seal
41 3390719 Thermal−Fuse
(91C)

OPTIONAL PARTS (NOT INCLUDED)
7
For Model: MED5900TW0
(White)
W10117335
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
3406839 Dry Rack
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
