Maytag MGD5700TQ0 User manual

TOP AND CONSOLE PARTS
1
For Model: MGD5700TQ0
(White)
10−07 Litho in U.S.A.(LAN) Part No. W10116425 Rev. B
29"GAS DRYER

TOP AND CONSOLE PARTS
2
For Model: MGD5700TQ0
(White)
W10116425
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10150648 Sheet,
Cycle Feature
W10151609 Use & Care Guide
W10118081 Wiring Diagram
2
W10113080 Wire, Jumper
(Buzzer On/Off)
3 694419 Buzzer, Mini
4
W10118608 Seal, Harness
5 8533971 Screw, 8−18 x 5/8
6
W10112576 Panel, Rear
Console
7 8530169 Switch,
Temperature
8
W10117655 Switch,
Push−To−Start
9 8566184 Timer Assembly
60 HZ.
10 8565972 Screen, Lint
11 8536939 Clip, Spring
12 359625 Screw, 8−18 x 1/2
13 688983 Screw, 8−18 x 5/8
14
W10112599 Top
15 237446 Washer (Top/chute)
16
W10120796 Harness, Wiring
17 717252 Plug, 2−way
18 8565981 Bracket, Harness
19 3394427 Clip−Harness
20 337686 Screw, 8−18 x 3/4
21 693995 Screw, Hex
Washer Head
22 8558178 Control,
Electronic
23 3391885 Connector, Edge
24 3397269 Connector−Timer
25 3401144 Connector,
(PTS Relay)
26 3403499 Connector,
2−Position
(Gas Valve)
27 3403498 Connector,
3−Position
(Gas Valve)
28 3405156 Switch,
Wrinkle Guard
29 3395683 Connector, Motor
30
W10112267 Foam Seal,
Console Bracket
33 3347243 Connector
6−Circuit
35
W10086710 Shell & Console
Assembly
(Includes
Illus. 37)
36 8312709 Clip−Console
37
W10112569 Badge Assembly
38
W10110030 Timer Knob
Assembly
39
W10110029 Knob, Control (3)
40 94614 Terminal, Female
41 3936144 Connector

CABINET PARTS
3
For Model: MGD5700TQ0
(White)
W10116425

CABINET PARTS
4
For Model: MGD5700TQ0
(White)
W10116425
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 697776 Screw, 10−32 x 5/8
(External Ground)
2 343641 Screw, 10−16 x 1/2
3 693995 Screw, Hex Head
4 8541400 Bracket, Cabinet
5 3396795 Cover, Block
6 3404162 Clamp, Motor
(W/Shield)
7 3396805 Panel, Rear
8 3403630 Plug−Strike
9 3980175 Clamp−Elbow
10 3406107 Door Switch
Assembly
11 697773 Screw, 6−20 x 7/8
12 98669 Locator, Top
13 341029 Clamp−Pipe
14 3404413 Plug−Hole
15 18849 Pad, Top Hinge
16 3392100 Foot, Dryer
279810 Foot−Optional
(Extended Length)
(Package of 2)
(Not Included.)
17 660658 Clamp, Motor
18 8530603 Cabinet
(Includes
Illus. 4)
19 98234 Clip, Ground (2)
20 18776 Lock, Front Top (2)
21 3403447 Panel Front
23 685203 Clip, Felt Pad (2)
24 3389441 Catch, Door
Assembly
25 3405246 Seal, Door
27 342055 Screw, 8−18 x 1/2
28 3405514 Hinge, Door
29 8066206 Motor Assembly
60 HZ.
30 8066184 Pulley 60 Hz.
31 3400500 Bolt,
5/16−18 x 3/4
33 3403431 Strike, Panel
35 3402341 Door, Rear
36 3402335 Door, Front
37 8565970 Handle, Door
38 3406129 Seal & Bearing
Assembly
39 3394975 Plug, Front Panel
40 344020 Cord, Power
41 3394083 Clip, Front Panel
42 8066217 Hinge, Top (2)
43 691366 Idler & Pulley
Assembly
44
W10131364 Belt, Drive
45 348780 Base, Motor
46 8318272 Burner Assembly,
60 Hz.
(See Pages 7 &
8 For Further
Burner Breakdown)

BULKHEAD PARTS
5
For Model: MGD5700TQ0
(White)
W10116425

BULKHEAD PARTS
6
For Model: MGD5700TQ0
(White)
W10116425
Illus. Part
No. No. DESCRIPTION
1 348368 Lint Chute
Assembly
2 489463 Screw, 8−18 x 5/8
3 3388703 Washer−Support
4 347139 Seal, Lint
Chute
5 90767 Screw, 8−18 x 3/8
6 487909 Screw, 8−15 x 1/2
7 3392519 Thermal Fuse
8 8066086 Drum Hole
Plug
9 8318268 Thermostat,
Internal−Bias
10 694089 Wheel, Blower
11 8577230 Housing, Blower
12 3398161 Clip
13 343641 Screw, 10−16 x 1/2
14 8530285 Box, Heater
15 3403140 Thermostat, 205 F
(96 C)
18 8066049 Funnel, Burner
19
W10136369 Socket Assembly
20 3406124 Bulb
22 3977373 Bracket, Drum
Light
23 3406022 Bracket, Bulkhead
24 3390647 Screw, 8−18 x 1/2
25 280010 Kit,
Thermal Cut−Off
(Includes
Illus. 15)
26 3401707 Wire, Jumper
27 3976479 Pad, Sensor
28 690997 Ring, Tri
29 3399506 Shaft, L.H.
30 3399507 Shaft, R.H.
31 3397590 Roller, Support
32 348197 Washer, Support
33 3359452 Nut, 3/8−16
34 3403414 Bulkhead
35 338906 Sensor, Radiant
36 3402841 Lens, Drum Light
37 692526 Ring, Bearing
38
W10109200 Screw, 11−16 x 3/4
39 3406130 Seal, Rear Drum
40 695587 Drum Assembly
41 692490 Baffle, Drum (2)
42 3976434 Bracket, Support
43 90296 Clip
44 3403636 Baffle, Drum (1)
45 339956 Seal
46 696302 Shield, Exhaust

BA−150
8318272 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
For Model: MGD5700TQ0
(White)
W10116425 7

Illus. Part
No. No. DESCRIPTION
BA−150
8318272 BURNER ASSEMBLY
USE WITH TYPE 1 − NATURAL
AND TYPE 4 LIQUEFIED PROPANE AND BUTANE GASES
1 8318272 Burner Assembly
60 Hz.
(Type 1)
(White Rodgers)
2 688617 Tube, Burner
3 694298 Bracket, Ignitor
4 686590 Ignitor
5 3393909 Screw & Washer
(8−32 x 5/8)
6 343641 Screw, 10−16 x 1/2
7 693986 Base, Burner
8 3387057 Screw, 8−18 x 3/8
9 Orifice, Burner
234826 Type 1
229742 Type 4 (Butane)
234868 Type 4 (Propane)
10 8318277 Valve, 60 Hz.
(Includes Pipe &
Illus. #7)
11 694421 Screw,
8−32 x 1/2 (2)
12 694538 Bracket, Coil
13 694540 Coil, 60 Hz.
(2 Terminal)
(Main)
14 694539 Coil, 60 Hz.
(Split)
(3 Terminal)
(Pilot Position)
15 694424 Leak Limiter
16 694423 Screw, Regulator
Adjustment
17 694422 Spring, Regulator
20 239822 Plug, Pipe
25 341029 Clamp, Pipe
694572 Conversion Kit
(Type 1)
to Type (4) L.P.G.
Following Parts Not Illustrated
8
For Model: MGD5700TQ0
(White)
W10116425

OPTIONAL PARTS (NOT INCLUDED)
9
For Model: MGD5700TQ0
(White)
W10116425
Illus. Part
No. No. DESCRIPTION
ACCESSORY PARTS
279948 Kit,
Dryer Repair
346764 Kit, Hold−Down
(Gas Dryer Mobile
Home Installation)
3406839 Dry Rack
8522199 Kit, Dryer
Vent Testing
PAINT, TOUCH−UP (1/2oz.)
72017 White
PAINT, PRESSURIZED SPRAY
(12 oz.)
350930 White
350938 Primer, Gray
PAINT, BULK (1 qt.)
799344 White (Uncut)
