Maytag MSD2454FRQ User manual

iiSi!iiiii
_iiiiiiiiiiii_
!_!i!iiiiiiiiiiiii_ii_!iiiiiiiiiiiil;_!!!iiiiiiiiiiiiiiiiiii_!!iiiiiiiiiiiiii_i_!i'_'¸¸
iiiiiii_i__!iiiiiiiiiiiiiiiiiii__i_!:iiiiiiiiiiL_ii!iiiiiiiii!iiiiiiiiiiii_!iiiiiiiiiiiiii_''_
_hould _ou n_ assis_ee_ it is helpful to have the
.€our
¢_frig_rator. T_i_ i_ on a data plate located at the top of
:the _esh food _bmpamnem. Record these numbers
Model Number
Serial Number
Revision Number
Date of Purchase
I
I
I
]
For additional questions, please contact us:
Maytag Appliances Sales Company
1-800-688-9900 USA
1-800-688-2002 CANADA
1-800-688-2080 TTY USA
(Mon.-Fri., 8am-8pm Eastern Time)
lntemet: htlp ://www.mayta g.eom
_ MAYI'AG

Important Safety Instructions.................................._
N
]°
• Use the refrigerator only for its intended purpose.
To prevent possibility of hazard due to electrical
shock, never plug the refrigerator into a receptacle
which has not been grounded adequately and in
accordance with the local and national electrical
codes. See the _,waming and grounding instructiuns.
Unplug the refrigerator before cleaning or replacing a
light bulb.
•In case of power failure, minimize door openings. If
the power thilure is of a long duration, protect the
food by placing blocks of dry ice on top of the
packages or check with a local frozen foods locker
about temporary storage. Frozen foods which have
thawed completely should not be refrozen and should
be discarded.
•Any electrical service cord that becomes frayed or
damaged should be immediately repaired or replaced.
Never unplug your appliance by palling on the power
cord.
• Your refrigerator should not be operated in the
presence of explosive fumes.
• Children should not climb, hang or stand on the
shelves of this refrigerator.
Impo_ta_. Child entrapment and suffocation are
not problems of the past. Junked or abandoned
refrigerators are still dan,gerous.., even if they will
sit tbr "just a few days. If you are getting rid of
your old refrigerator,
please follow the
instructions below
to help prevent
accidents.
• Take off the
doors.
•Leave the
shelves in place
so that children
may not easily
climb inside.
1
This appliance is equipped with a three-pronged
grounding plug for your protection against possible
electrical shock hazards. It must be plugged into a
grounding receptacle. Where a standard two-prong wall
receptacle is encountered, it is the personal
responsibility and obligation of the customer to have it
replaced with a properly grounded three-prung wall
receptacle. Do not under any circumstances, cut or
remove the third (ground) prong from the power cord.
Do not use an adapter plug. Do not use an extel_siun
cord.
GROUNDING PLUG
GROUNOINGTYPE
WALL RECEPTACLE
Save These Instructions

lnstallation ...... ....... ....... .....+..........**., .... ..............._
Your new refrigerator was packed carefully for
shipment. Remove and discard shelf packing clips (if
used) located just above each shelf where they hook
onto the frame. To remove plastic clips, wiggle the clips
sideways and pull straight out.
Location
•Allow for a free flow of air through the front base
grille.
•Install the refrigerator where the room temperature
will not go below 55 *F. With temperatures below 55 °,
the refrigerator will not run frequently enough to
maintain proper temperature in the freezer.
•Allow a minimum 1/2" clearance on the sides, top
and back for ease of installation. If the refrigerator is
placed with the door hinge side against a wall, you
may want to allow additional space so the door can be
opened wider.
•Use caution when installing the unit on vinyl or
hardwood floors so as not to nmrk or otherwise
damage the flooring. A piece of plywood, a rug or
other material should be used to protect the floor
while positioning the unit.
Energy-Saving ?3ps
•Locate the refrigerator away from heat-producing
appliances such as the range or dishwasher, heat vents
and direct sunlight.
• Level the refrigerator and do not block ventilation
around the front grille
•Keep the freezer full to near capacity so less cold air
will escape during door openings. When the freezer is
less than two-thirds full, place milk cartons hall" full
of water in the freezer.
• Let hot dishes cool slightly before putting into the
refrigerator or freezer.
• Cover liquids
• Wipe moisture from the outside of containers before
placing them into the refrigerator.
• Avoid opening the doors too often.
Levering
To enhance appearance and to maintain optimal
performance, the refrigerator must be level. Your
refrigeratur has wheeLs which can be adjusted for
leveling:
Remove the lower hinge covers (see fig. 1). To do
this, grasp each cover near the hinge and apply pres-
sure. The attachment tabs will snap out, allowing
removal of the covers.
• Adjust the wheels with a screwdriver (see fig. 2).
•To lock the cabinet in place, turn down both leveling/lock
feet, located near the front wheels (see fig 3).
• Replace the hinge covers.
• If the floor is not level and it is necessary to raise the
rear of the cabinet, we suggest rolling the rear wheels
onto a piece of plywood or other shim material.
Fig. !
TURN CLOCKWISE TO
RAISE CABINET CORNER
_1_ TURN COUNTER-CLOCKWISE
TO LOWER CABINET
Fig. 2
Fig. 3
2

Temperature Controls ..........................................
Your refrigerator has Maytag's Dual Cool TM freshness desiLm to control fresh and frozen food temperatures. The controls
are located at the top front of the fresh lbod compartment.
To adjust the controls, move the slide to the left or right as needed.
Initial Dual Cool TM Control Settings
•The refrigerator and freezer controls have settings
from 1 (warmest) to 9 (coldest). Initially set both
controls on 5.
•Let the refrigerator run at least 8-12 hours before
adding food.
Dual Cool" Control Guide
Refrigerator: Move Control to:
Too Warm Next higher setting
Too Cold Next lower setting
Freezer: Move Control to:
Too Warm Next higher setting
Too Cold Next lower setting
Tara refrigerator Off:
Move the freezer control to OFF.
Adjusting the Dual CooF Controls
Warm Cabinet Surfaces
At times, the front of the refrigerator cabinet may be
warm to the touch. This is anormal occurrence that
helps prevent moisture from condensing on the cabinet.
The condition will be more noticeable when you first
start the refrigerator, during hot weather and after
excessive or lengthy door openings.
No Defrosting
Your refrigerator is designed to defrost automatically,
• 24 hours after adding food, you may decide that one
or both compartments should be colder or warmer. If
so, adjust the control(s) as indicated in the table above.
• Except when starting the refrigerator, do not change
either control more than one number at a time.
•Allow 24 hours for temperatures to stabilize before
resetting.
• Changing either control will have some effect on the
temperature of the other compartment.
3

Interior Features....... ................ ........ ....... ..... .... ..._
Fresh Food Compartment
Tempered Glass Cantilever Shelves
These shelves are adjustable so the refrigerator interior
can be customized for varying food storage needs.
To remove a shelf: Unload. Lift up the rear of the shelf
slighdy, pull the shelf straight out.
To move a shelf to a different position: After
removing, tilt up the front edge of the shelf. Insert the
hooks into the desired openings and let the shelf settle
into place. Be sure the shelf is securely locked at the rear.
Spill-Catcher- Shelves (select models)
Spill-Catcher" shelves have a spill retainer edge to
contain spills and make cleanup easier.
Some Spill-Catcher TM shelves feature the Easy Glide
slide-out feature, To slide out, grasp the front of the
shelf and pull forward. Push the shelf in to return to
original position,
Elevator" Shelf (select models)
The Elevator" shelf is equipped with aspill-retaining
edge and the Easy Glide slide-out feature. It can be
adjusted up or down without unloading. To slide out,
grasp the front of the shelf and pull forward. Push the
shelf in to return to original position.
To adjust the Elevator TM shelf: Pull out the knob on the
crank handle. Rotate the crank clockwise to raise the
shelf, and counterclockwise to lower the height of the
shelf.
To remove: To remove the Elevator TM shelf for
occasional cleaning, completely unload the shelf and
pull the shelf forward. When the shelf stops, press up on
the tabs located underneath its outside edges, then
continue pulling forward, clear of the frame.
To replace: Align the shelf to the frame and push it all
the way back. It is not necessary to press up on the tabs
for reinstallation.
In ordinary use, the Elevator" sbelf frame assembly does
NOT require removal. Though unlikely, and not
recommended, the correct remowal procedure is as
follows:
•Unload the shelf completely.
•Slide the shelf forward about two inches and
manually move the two rear latches toward the shelf
center.
•While supporting the entire shelf and frame from
tmderneath, lift slightly and rotate the assembly
approximately 30°to allow the rear mechanism to
clear the vertical rear side mils.
• The entire assembly can then be moved forward and
clear of the refrigerator compartment.
•To reinstall, reverse the remowal procedure. Be sure
the shelf is in a level position. When the sliding
shelf is pushed to the rear. it will reposition the rear
latches to their correct operating position.
SLIDE OUT SHELF
style may vary
4

Interior Features (continued).......... ........ ..... .. ....... .._
The Pick-Off Door Bins (select models) are designed
to accommodate gallon-ph_s sized containers. They are
adjustable and easily removed. To remove: Lift the bin
up until it clears the retainers on the door liner, then
pull the bin straight out. Reverse this procedure to
replace the bin.
The Dairy Compartment, located in the refrigerator
door, may be equipped with a Keeper or Butter Dish.
Keepers (select models) fit in refrigerator door bins to
secure bottles and other containers in place when the
door is opened or closed. Keepers are adjusted by
sliding side to side.
The Tall Bottle Retainer (select models) prevents tall
bottles from tipping forward. It is adjusted by sliding
side to side.
The Egg Cradle (style may vary/select models) holds a
"dozen-plus" eggs. It can be removed to carry to a
work area or to be washed.
The Multi-Use Rack (select models) provides a place
for storing wine horizontally. The rack also holds canned
beverages or an egg carton. Position the rack on the left-
hand side of a refrigerator shelf, Note: The Multi-Use
Rack cannot be positioned on an Elevator" Shelf.
Tilt-Out Refrigerator Door Bins (select models) tilt
out to conveniently load or retrieve awkward containers
such as tall liter bottles or bagged items.
The 12-Pack Rack (select models) suspends from any
of the spill-proof refrigerator shelves. It hooks over the
framework wires under tbe she!£ The sloped design
allows cans to roll forward as one is removed.
5

Special Storage Areas
To remove any of the styles of storage drawers described
below, follow these directions:
Pull the drawer out until it stops. Tilt the drawer front up
and pull out. To replace the drawer, align the drawer in
the tracks, lift the drawer front and slide the drawer back
in,
A djusti- Temp TM (bottom drawer - select
models)
This drawer is designed to provide a short-term storage
area for fresh meats, cheeses and luncheon meats.
The tenaperature control for this drawer is located on the
left side wall of the refrigerator, near the front of the
drawer. The "cool" setting maintains a temperature
within the drawer consistent with the surrounding fresh
food compartment. To achieve a lower temperature
within the drawer, side the control towards the "cold"
setting. A lower temperature within the drawer is
recommended when storing flesh meat, poultry or fish.
o ........................,,.....
I
II I
Adjusti- Temp rM (top drawer -select models)
The temperature control for this drawer is located on the
shelf front above the drawer. Slide the control left or
right. The "cheese" setting provides a temperatUre
similar to that of the sx_rrounding fresh food
compartment. The "meat" setting provides a lower
temperature within the drawer which is recommended
when storing fresh meat, poultry or fish.
Humidity Controlled Crisper(s)
(select models)
Crisper drawers are designed for fruit and vegetable
storage.
Slide Humidity Controls
Some crisper drawers are designed with adjustable
humidity controls located above the drawers. Slide the
control to the left for fruit storage (lower humidity) or to
the right for vegetable storage (higher humidity).
Automatic Humidity Control
Some crispers are equipped with an Automatic Humidity
Control system, eliminating the need for trmnual htanidity
slide controls on the drawer. A fabricqike material*
covers ,small air vents in the shelf insert above the crispers.
This material controls the flow of moisture out of the
crisper. If a food spill should occur on the air vent or
fabric-like material, wipe with a clean, damp cloth.
*Maytag Automatic Humidity Control system features a unique.
patented material called Shape Memory Polymer (SMP) that when
laminated to Fabric, becomes DIAPLF2(. D1APLEX is manufactured
by Mi(subishi. DiAPLE_
Snack Center Drawer (select models)
This drawer provides a convenient storage area for
miscellaneous food and snack items. This drawer does
not have the adjustable temperature and humidity
capabilities.
ClirnateZone TM Storage _%
Drawers (select models) ¢ll_;_ne"
t_ghnol_y
ClimateZonff _ storage drawers provide "_'_
accurate temperature control for storing meats, fruits and
vegetables. The top drawer has a Meats, Citrus and
Produce setting. The middle drawer has a Citrus and
Produce setting. CfimateZone TM drawers are equipped
with Automatic Humidity Control. The drawers operate
electronically with a numerical temperature display for
each selection.
6

Interior Features (continued) ..... ..... ......... ....... .......
ClimateZone TM Storage Drawers (continued)
ClimatcZone TM Technology can also be turned off by
pressing Normal on the keypad. When turned off, the
drawers operate as standard sealed crisper drawers
without atemperature display.
Settings Set Temperature
Temperature Display Range*
Citrus 38°F(3°CI 37-39 ° F (3-4 °C/
Produce 34°F (1 ° C) 33-35 ° F(1-2 ° C)
Meats 31°F (-1 °C) 30-32 °F(-1-0 ° C)
*Varying factors such as environment, door openings, refrigerator
control settings, etc. may cause the temperature display on die drawer
to fluctuate outside the range of temperatures listed above. This is
normal. For best results, set the refrigerator and freezer controls at
the midpoint (5).
Changing from Fahrenheit to Celsius
To toggle from Fahrenheit to Celsius modes, press the
Citrus and Produce buttons sinmltaneously and hold.
Initially an "F" will appear in the display to confirm
the current display mode.
After holding the Citrus and Produce buttons for
approximately 3 seconds the letter in the display will
toggle to a "c". Once the letter changes, the citrus and
produce buttons can be released. The display mode has
been changed and the temperature will now be displayed
in degrees Celsius.
To change back to Fahrenheit mode, follow the same
procedure.
ClimateZone TM Light Bulb Replacement
A light is located behind the upper ClimateZone TM
compartment. The bulb part number is 61004862; see
your Maytag dealer for replacement or call 1-800-688-
8408 to order directly.
To remove the compartment assembly for bulb
replacement: Unplug the refrigerator. Unload and
remove shelf located above the ClinrateZone TM drawers.
Unload and remove the drawers. Remove two 1/4" hex
screws located on the left-hand side. Lift the top
compartment assembly upward (approx. 1 inch) and pull
forward (approx. 2-3 inches). The assembly should rest
on its supports.
Replace the bulb: Unscrew bulb and replace.
Caution: Handle the light bulb with care to prevent
breakage. The bulb may be hot from use.
To replace: Lift the assembly back into its original
position. Align the screw holes. Make sure the
assembly is pushed firmly to the left of the refrigerator
cavity. Replace the two screws. Replace the drawers
into the assemblies, replace the shelf above the
assemblies, and reconnect the power to the refrigerator.
Removal of the ClimateZone TM
Compartment Assemblies for Cleaning
Unplug the refrigerator. Unload and remove shelf
located above the ClimateZone TM drawers. Unload and
remove the drawers. Remove two 1/4" hex screws
located on the lett side. Lift the top compartment
assembly upward (approx. 1 inch) and pull forward
(approx. 2-3 inches). The assembly should rest on its
supports. Disconnect the power cords to free the
assembly, then pull completely out. Repeat with second
compartment assembly.
To replace: Lift the lower assembly back into its original
position leaving enough space to reach the power cords.
Reconnect the assembly power cords. Push the assembly
in all the way to the original position. Align the screw
holes. Make sure the assembly is pushed firmly to the
left of the refrigerator cavity. Replace the two screws.
Repeat with top assembly. Replace the drawers into the
assemblies, replace the shelf ahove the assemblies, and
reconnect the power to the refrigerator.
7

ChillKeeper" (select models)
The ChillKeeper TM compartmem is located in the
refrigerator door and is designed to quick chill items and
to store beverages. The ChillKeeper TM shelf can be
detached, inverted and snapped onto the uppermost tabs
in the compartment if two-tier storage is not needed.
To open: Grasp the opening on the right side of the
compartment cover and swing to the left. The cover will
automatically latch when closed.
To remove a freezer basket: Slide the basket out until
it stops. Depress tabs located at the rear of each side of
the basket, continue sliding forward until basket is out.
To replace, line the basket up with the support rails and
slide it into place.
StairStep" Freezer Baskets (select models)
StairStep '_ freezer baskets interact for easier access to
contents in the lower part of the freezer.
Pull the lower basket forward to gain access to its
contents. Continue pulling the lower basket to open the
upper basket as well. Reverse to close both baskets.
Pulling the upper basket open provides access to its
contents. The lower basket will also move tbrward
however, it will not open.
To remove the baskets: Pull forward on the upper
basket until it stops. Lift up slightly and continue
pulling forward. The baskets are removed together.
Reverse the above procedure to replace the baskets.
The ChillKeeper" control is
located on the left wall of the
refrigerator. Move the slide to
"Cold" to provide colder
temperatures in the
ChillKeeper TM.
The ChillKeepe_' utility drawer is located at the bottom
of the compartment. The lockable utility drawer
provides storage for items such as batteries, film and
prescription medications. The lock is located on the left
side of the drawer. To unlock and open the drawer, move
the pin to the "Unlock" position and slide the drawer
out. To close, slide the drawer back in and move the pin
into the "Lock" position.
Freezer Compartment
The freezer shelves (wire or glass) and baskets rest on
support rails molded into the wall of the freezer. Select
models offer freezer shelves that slide forward for easier
access to items at the rear of the shell:
To remove afreezer shelf: Completely unload the shelf
and lit_ straight up. Tilt the shelf sideways and pull
straight out. To replace, reverse this procedure.
The freezer basket(s) (number will vary by model) slide
out for more convenient access to the frozen foods.
Drop-Down Freezer Door Baskets
(select models}
These baskets provide convenient storage space for
frozen food items that tend to shift, such as bagged
vegetables.
8

lce Service.......... ...... ..... ............. ,....... ........ ............ _
Models Without an Automatic
ice Maker
The freezer compartment is equipped with ice cube trays
and an ice storage bin. The bin stacks on top of the
stacked ice cube trays. To release the ice cubes from a
tray, hold the tray upside down over the bin and twist
both ends.
The refrigerator is automatic ice maker ready. The
number tbr the ice maker kit needed appears on the data
plate (see front cover).
Models with an Automatic Ice
Maker
Adjustable Ice Level (select models)
Some ice makers are equipped with a sensor ann to adjust
the amount of ice in your ice storage tray for times when
less ice is needed.
To adjust the amount of ice produced: Push the plastic
sensor ann inward and rotate to the desired capacity.
Wire I.av_
Arm
until the supply of ice cubes raises the wire lever ann,
shutting the ice maker off.
To manually stop the operation of the ice maker, move
the wire lever ann into the up (off) position.
Certain sounds may accompany the various cycles of the
ice maker.
•buzzing of the water valve
•running of the water as the tray fills
• rattling of the ice cubes falling into an empty ice bin.
lfthe ice is not used frequently, the ice cubes will become
cloudy, shrink, stick together and taste stale. Empty the
ice storage bin periodically and wash it in lukewarm
water. Be sure to dry the bin before replacing it.
Dispenser Models
To check the ice level or gain access to the ice bin, lift
open the door on the ice bin.
To remove the bin, first tam off the ice maker. This is
done by opening the door on the ice bin and moving the
ice maker wire lever up to the "oft" position. Then reach
under the bin front and pull down on the back edge. After
it snaps free, pull the bin straight forward. To replace the
ice bin, align the bottom rails to the corresponding shelf
grooves and push it straight back until it stops and
latches. Make sure the tabs at the back of the bin that
turn the spiral auger are positioned between the prongs
from the auger motor. Turn the ice maker on by
lowering the wire ann.
Beverages and foods should not be placed in the ice
storage bin for qtdek chilling. These items can block the
wire lever arm, causing the ice maker to malfunction.
After your refrigerator has been connected to the water
supply, move the wire lever ann into the down position.
This will start its operation. The ice maker will fill with
water when the freezer reaches the proper temperature. It
may be 8 to 12 hours before the ice maker furnishes any
usable ice cubes.
Discard all the cubes from the first two or three batches
made. These initial ice cubes may be irregularly shaped,
discolored, or contain impurities from the new water
supply piping.
When the ice cubes are ejected it is normal for several
cubes to be joined together at the ends, They can easily
be broken apart. The ice maker will continue to make ice
9
