CABINET PARTS
1
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
01−08 Litho In U.S.A. (rrm) Part No. W10180316 Rev. A
REFRIGERATOR

CABINET PARTS
2
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 Literature Parts
W10142143 Service &
Wiring Sheet
W10178139 Energy Label
2225623 Modular Icemaker
Service Sheet
Use & Care Guide
W10131413 Bilingual
W10131421 Trilingual
Following May Be Purchased
DO−IT−YOURSELF
REPAIR MANUALS
677969 Do−It−Yourself
Manual, Ref./ Fzr.
2 2189410 Hinge (Top)
3 2166108 Roller, Front (2)
4 2189356 Clip, Grille
5 489385 Clamp, Tube
(Water Supply Line)
6 2179826 Rivet
7 489427 Screw
8 549193 Clamp, Cord
9 489497 Screw
10 2254618 Hinge, Center
11 2183852 Shim, Hinge
Center
12 488886 Screw
13 8281265 Screw
14 2254473 Hinge Butt
15 3400504 Screw
16 Fitting, Water Tube
(Not Serviced)
17 Hole Plug (6)
2201012 White
2200924 Bisque
2183998 Black
18 Seal, Front
(Not Serviced)
19 Seal, Rear
(Not Serviced)
20 Corner Filler (2)
2201014 White
2200926 Bisque
2201017 Black
21 Grille
(Includes
Illus. 4 & 24)
2254386 White
2254389 Bisque
2254388 Black
22 489341 Washer
23 487576 Washer
24 2254385 Clip, Grille
25 Cover, Hinge
2213360 White
2213364 Bisque
2213363 Black
26 Rail, Center
(Not Serviced)
27 2254578 Cover, Unit
28 Cabinet (Not a
Serviceable Part)

DOOR PARTS
3
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316

DOOR PARTS
4
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION
1 Refrigerator Door
(Includes
Illus 9 & 17)
2183898 White
2205281 Bisque
2200712 Black
2225433 Stainless Steel
2 Cover, Trim
2193143W White
2193143T Bisque
2193143B Black
5 Handle,
Refrigerator
2254533W White
2254533T Bisque
2254533B Black
6 489357 Screw
8 8281146 Screw
9 Door Gasket,
Magnetic
2202874 Mist Beige
2202881 Black
10 13035001 Nameplate
11 2188234 Shelf, Flip−Up
12 2180027 Trim, Door Shelf
13 8281206 Screw
14 2204810 Door Bin (3)
15 Freezer Door
(Includes
Illus. 17 & 18)
2182487 White
2205279 Bisque
2200710 Black
2225434 Stainless Steel
16 Hole Plug,
Handle
2189000 White
2200936 Bisque
2189009 Black
17 2314293 Thimble
18 Door Gasket,
Magnetic
2214966 Mist Beige
2214968 Black
19 2189202 Bracket, Door
Stop (2)
20 489276 Screw
21 Hole Plug
2212648 White
2212649 Bisque
2212651 Black
22 2156007 Plug, Trim
23 2156006 Plug, Trim
24 2218113 Compartment Door
25 Handle, Freezer
2320412W White
2320412T Bisque
2320412B Black
26 2159291 Trivet−Door (FC)
28 2195949 Trim, Door
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION

LINER PARTS
5
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316

LINER PARTS
6
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION
1 Liner (Not A
Serviceable Part)
2 2197380 Grommet (2)
3 2254359 Gasket, Evaporator
Cover (2)
4 2304099 Defrost Timer
5 2212485 Thermostat Tube,
Barrier
6 8534009 Screw
7 2310057 Wire Assy.
Control Box
8 2162085 Socket, Light
9 2179858 Damper, Air
10 2315539 Fan Motor
11 2163777 Fan Blade
12 2212982 Control Box
13 2210489 Thermostat Assy.
(Includes
Illus. 5 & 18)
14 489478 Screw
15 488208 Screw
16 2320192 Cover, Evaporator
17 527949 Light Bulb (2)
18 2200831 Weight, Thermal
19 1118894 Rocker Arm
Switch
20 2210509 Valve
21 2176281 Cover, Air
Diffuser
22 2200863 Knob, Thermostat
23 2254354 Air Tower
24 2189452 Air Diffuser,
Bottom
26 2210390 Air Separator
Assembly
27 2254454 Bracket
Evap. Fan, Rear
29 2254453 Bracket,
Fan Motor
30 2320183 Retainer, Screw
31 2204639 Shield, Heat
32 2321800 Defrost, BI−Metal
33
W10129791 Wire Assembly
Freezer Compt.
(Includes Item 32)
34 2302536 Knob, Damper
35 2179859 Post, Damper
36 2205079 Seal, Rear
Thermostat
37 2163810 Bracket,
Damper Knob

UNIT PARTS
7
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316

UNIT PARTS
8
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
1 2320188 Plate, Unit
Mounting
2 2169104 Insulation,
Sound Dampening
3 2214960 Condenser
4 2315531 Heater, Defrost
5 2254250 Evaporator Assy.
6 8533859 Screw
7 2254294 Drain Pan
8 2319835 Grommet−Cond.(4)
9 2176301 Bracket, Heater
10 2300638 Extension, Air
Baffle
11 2201184 Support Block
12 Cover
4387731 Service
13 Overload
4390624 Service
(Includes Relay)
14 Grommet (4)
1100826 Production
4387558 Service
15 2225929 Start−Device
(Production
Compressor Only)
17 2150304 Roller (2)
18 2221797 Rivet
19 2182338 Clip, Heater
20 489373 Screw, Compressor
24 2183454 Relay
(Service Only)
25 2255113 Strap
26 Capacitor
2169373 Production
1118576 Service
28 2218994 Compressor
(Includes Items
12, 13, 14 & 29)
29 Drier
2317845 Service
30 2155774 Clamp
31 2315541 Air Baffle
32 2188874 Motor, Condenser
33 2187382 Wire Assy. Unit
34 2225834 Fan Blade
35 2205384 Tube, Discharge
36 2225237 Tube, Suction
37 2154109 Tube, Process
38 488500 Screw
39 3400518 Screw
40 2254574 Evaporator Tray
Following Parts Not Illustrated
and Optional Parts Not Included
978025 Valve, Access
(1/4")
978026 Valve, Access
(5/16")
978027 Valve, Access
(3/8")
978028 Valve, Access
(1/2")
978029 Valve, Access
(5/8")
978030 Valve, Access
(3/4")
876764 Valve, Access
(3/16")
REFRIGERANT CHARGE
4.00 Ozs.
(R134A)

SHELF PARTS
9
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316

SHELF PARTS
10
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION
1 2254352 Ice Bucket
2 2201107K Shelf, Cantilever
(Complete)
3 2314548 Cover, Crisper
4 2218130 Crisper Pan
(13−Inch)
(Includes
Illus. 23 & 24)
5 2300520 Shelf, Ladder
Center
6 2314477 Support, Crisper
Cover
7 2320366 Trim−Crisper
Pan−10"
8 2176275 Shelf
9 2218129 Crisper Pan
(10−Inch)
(Includes
Illus. 23 & 24)
10 2221693 Glass, Crisper Cover
11 2210522 Shelf, Ladder (2)
12 489478 Screw
13 2201111 Shelf, Cantilever
Meat Pan
(Complete)
14 2218127 Meat Pan
15 2320357 Trim−Crisper
Pan−13"
16 2188711 Trim, Shelf Side
17 2188686 Trim, Shelf Rear
18 2201101E Shelf, Catnilever
19 2188684 Trim, Shelf Front
20 2200985 Glass, Half Shelf
21 2163762 Cup, Shelf Mtg.
22 2201105 Shelf, Cantilever
Meat Pan
23 2176222 Slide, Humidity
Control
24 2212446 Body, Humidity
Control
25 2176356 Trim−Meat Pan

ICEMAKER PARTS
11
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316

ICEMAKER PARTS
12
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION
1 488878 Clamp, Tube
2 2181939 Insert, Tube
3 628379 Clip, Fuse
4 2181943 Tube Water
5 2315576 Valve Solenoid
(Single)
6 78562001 Adjuster−Ice Level
7 2210495 Clip, Water Valve
8 79191001 Cover
9 489442 Screw
10
W10122527 Mold & Heater
Assembly (Also
Order 542638
Silicone Grease)
11 628515 Cup, Water Fill
12 627843 Ejector
13 2182124 Ice Striper
14 2194712 Support
15 2315522 Retainer
Thermostat
16 628397 Thermostat (Also
Order 542369
Cement
Alumilastic)
17 8533917 Screw
18 489276 Screw
19
W10138107 Shut Off Arm
20 2187464 Harness, Wiring
21 628320 Bracket
22 626680 Module Assembly
(Includes Item 24)
23 489478 Screw
24 489136 Screw,
3−24 x 23/64
25 488208 Screw
26 489442 Screw, 8−18 x 1/2
100
W10122496 Icemaker,Complete
Assembly

13
OPTIONAL PARTS
For Models: MTF1842EEW00, MTF1842EEQ00, MTF1842EEB00, MTF1842EES00
(White) (Bisque) (Black) (Stainless Steel)
W10180316
Illus. Part
No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION Illus. Part No. No. DESCRIPTION
Parts Not Illustrated and
Optional Parts (Not Included)
978941 Insulation,
Fiberglass
(63−1/2" x 35−1/2"
x 2−5/8")
212643 Sealer, Gum
(4 Feet)
479502 Tape, Vinyl
(3/4" x 108")
876305 Kit, Insulation
(14 Pcs.
3" x 24" x 48")
876370 Kit, Insulation
(2 Pcs.
3" x 24 " x 48")
876029 Kit, Foam Slab
(30" x 32−1/2" x
1−1/2")
505587 Sealer, Mastic
(1 Qt.)
511873 Touch−Up, White
Porcelain (2 Oz.)
542638 Grease, Silicone
(1/2 Oz.)
542639 Cement,
Alumilastic
(1−1/4 Oz.)
606755 Bag, Insulation
(36−5/8" x 46")
799833 Kit, Evaporator
Repair
(Aluminum Epoxy)
799832 Kit, Porcelain
Repair (White)
503695 Cork Sealer
(1/4 Pound)
Customer Touch−Up Material
350942 Primer, White
(12 Oz. Spray Can)
350939 Enamel, Black
(12 Oz. Spray Can)
350930 Enamel, White
(12 Oz. Spray Can)
4392901 Enamel, Biscuit
(12 Oz. Spray Can)
72017 Brush Touch−Up Kit
(White)
72032 Brush Touch−Up Kit
(Black)
4392899 Brush Touch−Up Kit
(Biscuit)
Refinishing Material
799344 Enamel, White
(1 Qt. Uncut)
4392900 Enamel, Biscuit
(1 Qt. Uncut)
799340 Enamel, Black
(1 Qt. Uncut)
833938 Kit, Terminal
Connector
Important: The spray paint is
not to be used where the paint
may make contact with the door
gaskets.
ACCESSORIES
31462 Cleaner,
Stainless Steel
TORX SCREW WRENCH
1117510 Torx Key
