Lock
Unlock
Trunk
Panic Alarm
Trunk Request Switch
Door Request Switch
Key
21
ADVANCED KEYLESS ENTRY SYSTEM
 • Thissystemallowsyoutolock/unlock
thedoors,openthetrunklid,andeven
starttheenginewithoutevertakingthe
keyout.
While Carrying the Advanced Key…
 •  Unlock the driver’s doorbypushing
thedriver’sdoorrequestswitchonce.
 • Unlock both doorsbypushingthe
driver’sdoorrequestswitchtwice
ORbypushingthepassenger’sdoor
requestswitchonce.
 • Lock both doorsbypushingthe
driver’sdoororpassengerdoor
requestswitchonce.
 • Open the trunkbypushingthetrunk
requestswitchonce.
 • Open the front windowsbypushing
theunlockbuttonontheadvancedkey
andthenpushingagainandholding;
releasetostop.
Advanced Key (Rear)
STARTING THE ENGINE
While Carrying the Advanced Key…
 • Start the enginebypushingthestartknobinandturningit(likea
normalkey)whilepushingtheclutchpedal(manualtransmission)orthe
brakepedal(automatictransmission).
 • Shut the engine OFFbyturningthestartknobtotheACCposition
andthenpushinginandturningtotheLockposition.
 •  T h e  KEY indicatorlightwillilluminateGREENwhentheadvanced
keyisdetected.IftheKEYindicatorlightashesGREEN,the
advancedkeytransmitterbatterypowerislow.
 • Iftheadvancedkeycannotbeusedduetoamalfunctionordead
advancedkeybattery,usetheauxiliarykeytolock/unlockthedoors
andtostarttheengine.
Key
Release
Auxiliary Key
(for opening the doors and
starting the engine)
KEYLESS ENTRY SYSTEM
Thissystemremotelylocksandunlocksthedoorsandthetrunk,andopens
thepowerwindows.
Release Button
• Pushtoextendkey.
• Push&holdtoretractkey.
Unlock
• Pushoncetounlock
driver’sdoor.
• Pushtwice(withinthree
seconds)tounlock
bothdoors.
• Pushtwiceandholdto
openfrontwindows.
Lock
• Pushoncetolock
bothdoors.
• Pushtwice(withinve
seconds)forhornsound
vericationthatboth
doorsarelocked.
Panic Alarm
• Pushforonesecondor
moretoactivatealarm.
• Pushlock,unlock,or
  panicalarmtoturn
  alarmoff.
Trunk
• Pushandholdto
opentrunk.
Advanced Key
Retractable Key
With the Auxiliary Key…
1Tostartengine,remove
thestartknobcover
bysqueezingboth
releasebuttonsand
pullingthecoveroff.
2Pushthekeyreleaseto
removetheauxiliarykey.
3Inserttheauxiliarykeyinto
thekeycylinderandturn
ittostarttheengine.
Release Buttons
www.MazdaUSA.com
1153366_13a_Mazda_MX5_SSG_070312_B.indd 2-3 7/3/12 4:46 PM

2
1
Behind Seat Storage
Moveseatbacksforwardtoaccessthe
seatbacktrimstorageboxes.
3 4
Seats
Seat Warmers
Thedriverandpassengerseatscanbe
warmedbyrotatingtheapplicableseat
warmerdialwhiletheignitionisON.
•Seattemperatureincreasesasthenumberonthedialincreases.
•Whentheseatwarmersarenotneeded,rotatethedialsto0.
SEAT CONTROLS
Height Adjustment Lever
Raiseorlowerseatheightbyrepeatedly
pullinguporpushingdownonthelever.
Slide Release Lever
Pullleverupto
moveseatbackward
orforward.
Recline Lever
Pulluptoadjust
seatbackangle.
FUEL DOOR RELEASE
Thefueldoorreleaseisintheseatsideboxlocatedbetweentheseats.
1 Pullhandletoopentheseatsidebox.
2 Toopenthefueldoor,pullthefueldoorrelease.
FUEL REQUIREMENTS
91-octanefuelisrecommended.If91-octanefuelisnotavailable,fuelaslowas
87-octanecanbeusedtemporarilyforemergencypurposes.Useoffuellower
than91-octanecandecreaseperformance,causeknocking/enginenoise
andcandeteriorateshiftquality.Refuelingthevehiclewithcorrectoctane
fuelacoupleoftimeswillrestorevehicleperformanceandshiftquality.
FUEL DOOR
Toavoidscratchingthe
paintduringrefueling,
securethefuelllercap
tetheroverthehook
asshown.
www.MazdaUSA.com
Fuel
1153366_13a_Mazda_MX5_SSG_070312_B.indd 4-5 7/3/12 4:46 PM

LIGHTING/
TURN SIGNALS
(P. 9 )
CRUISE
CONTROL
WIPER/
WASHER
(P. 10)
BLUETOOTH®
HANDS-FREE/
AUDIO
(P. 2 5 )
HAZARD
WARNING
PASSENGER
AIRBAG OFF
INDICATOR1
AUDIO
( PP. 2 3 - 2 4 )
TILT STEERING
WHEEL LEVER
ACCESSORY
SOCKET
CLIMATE
CONTROL
(P P. 21-2 2 )
SEAT
WARMERS
(P. 3 )
AUX JACK
(P. 12 )
POWER
RETRACTABLE
HARDTOP
(If equipped)
(P. 18)
Driver’s View
5 6
HOOD
RELEASE
DYNAMIC
STABILITY
CONTROL (DSC)
TRUNK
RELEASE
1
Thisindicatorlightilluminatestoremindyouthatthefrontpassenger’sfront/sideairbagsandseatbelt
pretensionerwillnotdeployduringacollision.Thereasonforthisisthattheweightintheseatislessthan
approximately66lb.Alwayswearyourseatbeltandifafrontfacingchildseatmustbeused,youmust
deactivatethepassengerairbag.SeetheOwner’sManualforimportantinformationonthissafetyfeature.
www.MazdaUSA.com
1153366_13a_Mazda_MX5_SSG_070312_B.indd 6-7 7/3/12 4:46 PM

Instrument Cluster
78
INFO
BUTTON
TACHOMETE R
FUEL GAUGE ENGINE COOLANT
TEMPERATURE
GAUGE
DASHBOARD
ILLUMINATION1
SPEEDOMETER
ENGINE OIL
PRESSURE GAUGE
ODOMETER/
TRIP METER
NOTE: Lowambienttemperatureand/orhighaltitudecausestirepressurestodrop
andmayturntheTPMSwarninglighton.Ifthewarninglightcomeson,checkthetire
pressureandllthetiresassoonaspossible,preferablybeforemovingthevehicle
andwarmingupthetires.Tirepressureshouldbecheckedwhenthetiresarecold.
INFO
PushINFObuttontodisplaythe
followingbelowtheodometer:
•TripMeterA
•TripMeterB
•Averagefueleconomy
•AmbientTemperatureDisplay
NOTE:
•Tocleartripandaveragefuel
economy,pushandholdINFO
buttonwhendisplayed.
•Tochangetheambient
temperaturedisplaybetween
°Fand°C,pushandholdINFO
buttonwhendisplayed.
1Whenexteriorlightsareon,rotatetheknobtoadjustthebrightnessoftheinstrumentclusterandother
 dashboardilluminations.
AMBIENT
TEMPERATURE
www.MazdaUSA.com
Low Fuel Level
OFF
Dynamic Stability Control
(DSC)/Traction Control
System (TCS) Off
Indicator Light
DSCOFFswitchpushedand
TCS/DSCturnedoff.
ABS (Antilock Brake
System) Malfunction
Check Engine Light
Charging System Malfunction
Traction Control System
(TCS)/Dynamic Stability
Control (DSC)
On:TCS/DSCmalfunction
Flashing:TCS/DSCoperating
Malfunction Warning Light
Shift Lever Position Indicator
Automatic Transmission
Malfunction
Turn Signals/Hazard
Warning Indicator Lights
Key Warning RED
Advancedkeynotdetectedor
advancedkeybatteryisdead.
Key Detected (engine ready
to start) GREEN
On:Advancedkeydetected;engine
isreadytostart.
Flashing:Advancedkeybatteryislow.
Air Bag/Front Seat Belt
Pretensioner System
Malfunction
Headlight High Beams On
Seat Belt
Unbuckled/Malfunction
Security Indicator Light
Door Ajar
Brake Warning Light
Parkingbrakeon/lowbrake
uid/malfunction
Cruise Main Indicator
Light On (AMBER)/
Cruise Set Indicator
Light On (GREEN)
Tire Pressure
Monitoring System
(TPMS) Warning Light
On/WarningBeep:Lowtire
pressureinoneormoretires.
FL AT
TIRE
Flat Tire
Flattire/malfunction
GLOSSARY OF WARNING AND INDICATOR LIGHTS
NOTE: SeeOwner’sManualformoredetailsandexplanations.
1153366_13a_Mazda_MX5_SSG_070312_B.indd 8-9 7/3/12 4:46 PM

WINDSHIELD WIPER/WASHER CONTROL LEVER
9 10
Pull to dispense
washer uid
1
2
3
HI
LO
INT
OFF
MIST
Lights
LIGHTING CONTROL/TURN SIGNAL LEVER
Pull
to Flash
High Beams
Push for
High Beams
:Turnsfoglightsononly
whenheadlightsareon.
:Turnstail,parking,dashboard,
andheadlightson.
:Turnstail,parking,and
dashboardlightson.
www.MazdaUSA.com
Wipers
1153366_13a_Mazda_MX5_SSG_070312_B.indd 10-11 7/3/12 4:46 PM

Direct Mode
TomanuallyshiftgearswhileinDrive,thesteeringshiftswitchesmaybe
used.Aftermanuallyshifting,thetransmissionwillreturntonormaldrive
modeunderanyofthefollowingconditions:
 • 4secondsofsteadythrottle
 • Acceleratorpedalisfullydepressed(WideOpenThrottle)
 • Tachometerreachesredline
 • Vehicleisstoppedormovingataslowspeed
To Shift Up To A Higher Gear:
 • PulltheUPsteering
shiftswitch.
To Shift Down To A Lower Gear:
 • PushtheDOWNsteering
  shiftswitch.
6-SPEED MANUAL TRANSMISSION
 • Pushtheclutchpedalcompletelydown
  tostarttheengineandtoshiftgears.
 • ToplacethetransmissioninReverse,
  placeshifterintheneutralposition,
  pushtheshifterdown,movetotheleft
  andpushforward.
To Shift Up To A Higher Gear:
 • Tapshiftleverback(+)once.
OR
 • PulltheUPsteering
shiftswitch.
To Shift Down To A Lower Gear:
 • Tapshiftleverforward(-)once.
OR
 • PushtheDOWNsteering
  shiftswitch.
PORTABLE AUDIO PLAYER INTEGRATION USING THE AUX JACK
YourvehicleisequippedwithanAUXor
auxiliaryjackthatwillallowyoutoplay
yourportableaudioplayerthroughthe
vehicle’saudiosystem.Learnthesystem
whenparkedanddonotletitdistractyou
whiledriving.
NOTE: Youwillneedanaudiocablewithan
1/8inch(3.5mm)ministereoplug(available
asaGenuineMazdaaccessory)toconnect
yourportableaudioplayerintotheauxjack.
RefertotheOwner’sManualfor
additionalinformation.
1 LocatetheAUXjackbelow
theclimatecontrols.
2 Plug1/8inchministereoplugintothe
  portableaudioplayerandintotheAUXjack.
  Turnportableaudioplayeron.
3 Turnthevehicleaudiosystemon.
4 PushtheAUXbuttonontheaudiofaceorthe
  MODEbuttononthesteeringwheelcontrols.
5 Usetheportableaudioplayercontrolstoplaymusic.
IMPORTANT: Setthevolumelevelonyourportableaudioplayertothehighest
levelbeforedistortionstarts,thenadjustthevolumeontheaudiosystem.
AUTOMATIC TRANSMISSION
Sport A/T Manual Shift Mode
TheSportA/TManualShiftMode
givesyouthefeelofdrivingamanual
transmissionbyallowingyoutomanually
shifttocontrolenginerpmandtorque
whenmorecontrolisdesired.
To Use Manual Shift Mode:
 • ShiftleverfromDtoM.
NOTE:
•Changingtomanualmodecanbedonewhiledrivingthevehicle.
•Thetransmissionwillnotupshiftautomaticallyinmanualmode,evenifthe
tachometerreachesredline.
Auxiliary
Jack
11 12
Transmission
Higher
Gear
Lower
Gear
Down
Up
Thetransmissionwillautomaticallyadjusthowandwhenitshiftsgears
basedonroadconditionsandyourdrivingstyle.Thetransmissionmaystay
inalowergearlongerthanusualwhengoingupordownhillsordriving
aroundcorners.Thisfeaturegivesyoubettercontrolandamoreconnected
drivingexperience.
www.MazdaUSA.com
AUX Jack
1153366_13a_Mazda_MX5_SSG_070312_B.indd 12-13 7/3/12 4:47 PM

INSTANT MOBILITY SYSTEM (IMS)
TheIMSemergencyattirerepairkit
(locatedinthetrunk)isforatemporary
repairofaslightlydamagedattire,
resultingfromrunningovernails,or
similarsharpobjectsontheroadsurface.
RefertoyourOwner’sManualfor
completedetails.
• 3.5mmAudioCable
• AllWeatherFloorMats
• BluetoothCarKit
• CarCover
• CargoNet
• DoorEdgeGuards
• DoorSillTrimPlates
• EngineStartSwitch
• FrontMask
• Fuel-FillerDoor
• Hardtop
• In-Dash6-disc
 CD/MP3Changer
• iPod
®
Integration
• LicensePlateFrame
• PerimeterAlarm
 System
• PortableNavigation
 DevicesbyGarmin
®
• RearSpoiler
 (SoftToponly)
• ShiftKnobs
• SiriusXM
®
• SplashGuards
• Touch-UpPaint
• WheelLocks
• WindshieldSunscreen
GENUINE MAZDA ACCESSORIES
GenuineMazdaAccessoriesarebuilttothesamestandardsofqualityas
yourMazda.Thatmeanstheytright,workright,andlookgreat.Choose
fromawiderangeofinteriorandexterioraccessoriestomakeyourMX-5
Miatatyourpersonalityandlifestyle.Afterall,youarewhatyoudrive.
Personalize your MX-5 Miata with the following Genuine
Mazda Accessories:
Youraluminumwheelshaveaprotective
coatingonthem.Onlyuseamildsoapor
neutraldetergentwithaspongeorsoftcloth
tocleanthem.
CAUTION: Usingawirebrush,polishing
compound,solvent,oranytypeofabrasive
cleanermaydamagetheprotectivecoating.
ALUMINUM WHEEL CARE
13 14
Mirror
Auto-Dimming Mirror
 • Auto-Dimmingwillautomaticallydarkenyourrearviewmirrortoreduce
headlightglarefromvehiclesbehindyou.
 • Auto-Dimmingisactivatedeverytimethevehicleisstarted.
NOTE:
Inadditiontotheauto-dimmingmirror’srearlightsensor,thereisalsoa
frontlightsensor(notshown).Donotplaceorhanganyobjectsoverthefrontorrear
mirrorlightsensors,otherwise,theauto-dimmingmirrorswillnotoperateproperly.
HomeLink®
 • Thisfeatureprovidesaconvenientwaytoreplaceuptothree
transmitterssuchasgaragedooropeners,homelightingremotes
andotherradiofrequencydevices.
 • RefertoyourOwner’sManualforcompleteprogrammingdetails.
AUTO-DIMMING MIRROR AND HOMELINK®
Auto-Dimming
Indicator Light
Auto-Dimming
On
HomeLink Rear
Light
Sensor
Auto-Dimming
Off
OnOff
www.MazdaUSA.com
Wheel
1153366_13a_Mazda_MX5_SSG_070312_B.indd 14-15 7/3/12 4:47 PM

MANUAL CONVERTIBLE TOP
Whenraisingorloweringthemanualconvertibletop,thevehiclemustbe
stoppedonlevelgroundwithparkingbrakeset,windowsloweredaminimum
of1inchandallitemsintheconvertibletopstoragearearemoved.
To Lower:
1 PushreleasebuttonAwhilepullinglatchBrearwardtodisengage.
2 Pullfrontoftoprearwardtoreleasefromwindshieldheader.
3 Foldbacktopandpushrmlyonfrontoftoptosecurelylockin
openposition.
4 Raisewindblocker.
To Raise:
1 Lowerwindblocker. 2 Pullunlocklevertoreleasetop
fromopenposition.
  • Ifopeningfromoutsidevehicle,
   graspsideoftop,near 
   windshieldheader.
  • Ifopeningfrominside
   vehicle,useeitherhandle.
A
NOTE: Ifmanualsofttopdoesnot
foldeasily,thenslowlyloweritwhile
pushingdownontheupperpartof
rearglasswithyourhand.
B
CAUTION:Beforeloweringsofttop,please
paycloseattentiontothefoldingpointson
eachsideofthesofttop,otherwisedamage
couldoccur.
Convertible Top
15 16
GOOD - OK
TO LOWER
SOFT TOP
CAUTION: DO
NOT LOWER
SOFT TOP!
www.MazdaUSA.com
1153366_13a_Mazda_MX5_SSG_070312_B.indd 16-17 7/3/12 4:47 PM

3 Pullfrontoftopforwardtoclosedposition(againstthewindshieldheader).
NOTE: ManualConvertible
TopMaintenance:Remove
leavesorothermatterthatmay
accumulatearoundthearea
wherethesofttopmeetsthe
vehiclebodytopreventwater
drainageoutletsfrombecoming
clogged.Cloggedwaterdrainage
outletsmayresultinwater
intrusionintothepassenger
compartment.Fordetailed
maintenanceofthewater drains,
refertoMyMazda.com orconsult
anAuthorizedMazdaDealer.
POWER RETRACTABLE HARDTOP
Whenraisingorloweringthepowerretractablehardtop,thevehiclemustbe
stoppedonlevelgroundwithparkingbrakesetandignitionon.Shiftmanual
transmissiontoneutralorshiftautomatictransmissiontoParkorNeutral.
To Lower:
1 PushreleasebuttonAwhilepullinglatchBrearwardtodisengage.The
indicatorlightwillilluminatewhenthelatchisdisengagedindicatingthe
topcanbeopened.
  • Ifclosingfromoutsidevehicle,
   graspsideoftopnear 
   windshieldheader.
  • Ifclosingfrominsidevehicle, 
   graspeitherhandle.
2 Pushandholdtheopenbutton.
Theindicatorlightwillash
duringtheopeningoperation.
  • Windowsautomaticallylower,
   deckraises,toplowers,and 
   thendeckcloses.
NOTE: Abeepsoundsandthe
indicatorlightturnsofftoconrm
operationiscomplete.
4 Pushleverontoplatchforwarduntillockbuttonclicksandtoplatchis
securelylocked.
WARNING: If red indicator is
visible on release button, top
is not securely latched.
A
B
17 18
Convertible Top
Indicator
light
Open button
www.MazdaUSA.com
1153366_13a_Mazda_MX5_SSG_070312_B.indd 18-19 7/3/12 4:48 PM
