MB QUART MBQT-FPOD-1 User manual

Page 1 of 15
Installation Instructions
Model: Honda Talon
Description: Front Speaker Pod Install
Part Number: MBQT-FPOD-1
Assembly Time: 150 Mins (2.5-Hours)
No. Component Name Qty
1 6.5” Rear Pod Speakers (MBQT-FPOD-1) 2
2NA2-400.2 Amplier 1
Parts List
1Bojo Tool
2 Panel Clip Pliers
3 10mm open box wrench
4 10mm and 12mm socket
5 ½” socket
6 Rachet
7Small at head screwdriver
8Phillips screwdriver
9 3mm and 5mm Allen Wrench
10 ¼” and ½” drill bit or stepper bit
11 1” hole saw
12 Drill
13 Rotary tool similar to a Dremel
14 Heat Gun or Lighter
15 Crimper
Tools Required
Before you begin, read through these instructions and check that
all parts are present. Always disconnect negative battery terminal,
prior to installation. Please note that MB Quart cannot assume any
responsibility for damage resulting from incorrect installation.

Page 2 of 15
Disassembly
● Remove hood by turning
two latches
● Remove four 10mm bolts, four
push pins and ve 5mm allen
bolts to remove top of dash
● Remove half mud guard with six
push pins

Page 3 of 15
Disassembly
● Lift up the bottom half of the
steering column rubber boot
● Remove the two push pins behind
the rubber boot
● Remove the two push pins on the
bottom of steering column cover

Page 4 of 15
Disassembly
● Remove the bottom steering
wheel cover
● Remove one 5mm allen bolt and
one push pin from the drivers kick
area
● Remove two 5mm allen bolts from
behind glove box door

Page 5 of 15
Disassembly
● Remove one push pin in the back
of the glove box
● Remove three push pins from
below the glove box
● Remove glove box

Disassembly
Page 6 of 15
● Remove one 5 mm allen bolt and
one push pin from passenger kick
area

Front Speaker Pod Installation
Page 7 of 15
● Drill a ½” hole, 5/8” down from the
edge, and 2 ¼” over (Control the
depth of bit to not go to deep)
● Pass the wire from the driver side
pod through the hole you drilled
● Position pod and lightly thread a
5/16” bolt and washer from the front
fender area into the threaded insert
on the back of the pod

Front Speaker Pod Installation
Page 8 of 15
● Install the M6 x 40mm bolt and
washer through the enclosure into
the factory bolt location
● Tighten the 5/16” bolt in the
fender area
● Repeat previous steps on
passenger side

Amplier Adjustment
Page 9 of 15
● Adjust the NA2-400.2 amplifiers gain
and crossover settings as pictured
NOTE
Gains all to the last “L” on Level
HPF to 100Hz going just past “P” on LP
LPF is turned all the way down
X-Over to HP

Wiring Installation
Page 10 of 15
● Connect the speaker harness to
the NA2-400.2 amplier and route
the driver and passenger speaker
leads to the appropriate kick area
● Connect bullets of amplier
harness with respective front
kick pods
● If you don’t already have a buss
bar installed you can connect
to factory wiring (we highly
recommend a buss bar kit)
These are available from many
aftermarket companies like XTC
Power Products

Reassembly
● Install one push pin in the back of
the glove box
● Install three push pins from below
the glove box
● Install glove box
Page 11 of 15

Reassembly
● Install the bottom steering wheel
cover
● Install two 5mm allen bolts from
behind glove box door
Page 12 of 15
● Install the two push pins on the
bottom of steering column cover

Reassembly
● Replace the bottom half of the
steering column rubber boot
● Install the two push pins behind
the rubber boot
Page 13 of 15
● Install half mud guard with six
push pins

Reassembly
● Install hood by turning
two latches
● Install four 10mm bolts, four push
pins, and ve 5mm allen bolts to
remove top of dash
Page 14 of 15

Page 15 of 15
MBQT-FPOD-1 REV 01
