Congratulations on your purchase of the new Autotek Mean
Machine Series High Power subwoofer system.
The MW series subwoofers offer superior sonic accuracy,
high power handling, great sound quality with exotic build
materials and outstanding good looks.
As with all high quality car audio products, we recommend
professional installation by an authorised Autotek dealer.
Your dealers knowledge and experience can ensure a problem free
and cosmetically integrated installation.
If you choose to install the subwoofers yourself, please read the entire
manual very carefully.
1
2.5” 2-Ohm & 4-Ohm High-Temp Dual Voice Coils on most models
1” NBR Reinforced and Stitched Rubber Surround
100oz Double-Stack Magnet Assembly
Single Flat Nomex Spider With Woven Tinsel Leads
Polypropylene Cone With Woven Honeycomb Support Body
Nickel Plated Push & Insert Speaker Terminals
High Strength ABS Motor Cover
Heat Dispersing Ported Nickel Plated Back Plate
Ultra Ridged Stamped Steel Basket
Form Fitting Trim Piece to Conceal Mounting Screws
utotek
a

2
SUBWOOFER INSTALLATION AND WIRING DIRECTIONS
Enclosure Materials
Typically, 5/8” or 3/4” MDF (Medium Density Fiber Board) is best
for most applications. 3/4” MDF is recommended.
Enclosure Build Materials
Connecting joints need to be glued and screwed to ensure no
air escapes and joints do not separate under high pressure.
Mitered and rabbit joints also help to ensure the enclosure joints
are secure.
Bracing
Internal bracing is also recommended to prevent flexing and to
strengthen the enclosure.
Note: The volume taken up by the bracing should be added to the
total enclosure interior volume.
There are two common bracing methods.
1. Corner Bracing: These help prevent the connection joints
from separating under heavy vibration and air pressure.
Use 1’ x 1” MDF at all interior joints
2. Diagonal Bracing: These internal braces connect the top side
to the bottom side as well front side to back side. This prevents
the wood from bowing or pushing outwards.
Use 1” x 2” with 1” surface contact that is glued and screwed.
Wiring
Wiring Parallel, Series or Parallel/Series will affect the final
impedance at the amp and great care must taken to ensure the
amp is not driven below it’s intended impedance capabilities.

3
4+4

4

5
Q The energy losses of relative damping (ratio of stored to dissipated
energy or ratio of reactive to resistive energy).
Fs Free air resonance of driver in Hz.
Qms Mechanical Q.
Vas Volume of air equivalent to driver from the rest position.
Cms Mechanical compliance of a loud speaker piston.
Mms Moving mass of total loud speaker piston assembly.
Xmax The maximum linear excursion of a loud speaker.
Sd Surface area of the cone.
Dia The piston diameter of a loud speaker.
Qes Electrical Q of a system.
Re DC resistance.
Le VC inductance.
Pe Maximum input power.
Qts Total Q of the system.
Sens Sensitivity. An efficiency measurement in dB’s.
Vc Volume of a closed or sealed enclosure
Vb Volume of a vented enclosure.
Fc The resonant frequency of a closed or sealed system
Fb The resonant frequency of a vented system
F3 The half-power (-3dB) frequency of a loud speaker enclosure
Qtc The Q of a loud speaker at Fc in a closed box, considering both
it’s electrical and mechanical resistance.
QL The Q of a vented box, resulting from all box losses.
DV Diameter of vent.
LV Length of vent.
H Height.
W Width.
D Depth
Glossary of Terms

6
MW10D4 / MW12D4 / MW12SQD4
DVC 4-Ohms
PARALLEL COILS / PARALLEL SUBS
1-Ohm
utotek
a
utotek
a
utotek
a
utotek
a
+
+
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
8-Ohms
SERIES
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
2-Ohms
PARALLEL
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
SERIES COILS / PARALLEL SUBS
4-Ohms
utotek
a
utotek
a
utotek
a
utotek
a
+
+
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-

7
MW10D2 / MW12D2 / MW15D2
DVC 2-Ohms
PARALLEL COILS / PARALLEL SUBS
0.5-Ohms
utotek
a
utotek
a
utotek
a
utotek
a
+
+
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
4-Ohms
SERIES
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
1-Ohms
PARALLEL
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-
SERIES COILS / PARALLEL SUBS
2-Ohms
utotek
a
utotek
a
utotek
a
utotek
a
+
+
utotek
a
utotek
a
utotek
a
utotek
a
+
+
+
-

MW10 9.1” / 230mm 6.2” / 157.48mm
Model A - Cut Out Diameter B - Mounting Depth
11” / 280mm 6.9” / 175.26mm
MW12
13.8” / 350mm 8” / 203.2mm
MW15
7.3” / 185.42mm
11.1” x 11.1”
282 x 282mm
MW12SQ
Subwoofer Dimensions
A
B

9
