McCONNEL
YARDSCRAPERS
Models: M402G & M452G
Operator & Parts Manual

IMPORTANT
VERIFICATION OF WARRANTY REGISTRATION
DEALER WARRANTY INFORMATION & REGISTRATION VERIFICATION
It is imperative that the selling dealer registers this machine with McConnel Limited before
delivery to the end user – failure to do so may affect the validity of the machine warranty.
To register machines go to the McConnel Limited web site at www.mcconnel.com, log
onto ‘Dealer Inside’ and select the ‘Machine Registration button’which can be found in
the Service Section of the site. Confirm to the customer that the machine has been
registered in the section below.
Should you experience any problems registering a machine in this manner please contact
the McConnel Service Department on 01584 875848.
Registration Verification
Dealer Name:
……………………..…………………………………………………………….
Dealer Address:
…….………………………………………………………………………….
Customer Name:
……………………..…………………………………………………………
Date of Warranty Registration:
……/……/...…… Dealer Signature: ………………..……
NOTE TO CUSTOMER / OWNER
Please ensure that the above section above has been completed and signed by the selling
dealer to verify that your machine has been registered with McConnel Limited.
IMPORTANT: During the initial ‘bedding in’ period of a new machine it is the customer’s responsibility
to regularly inspect all nuts, bolts and hose connections for tightness and re-tighten if required. New
hydraulic connections occasionally weep small amounts of oil as the seals and joints settle in – where
this occurs it can be cured by re-tightening the connection – refer to torque settings chart below.The
tasks stated above should be performed on an hourly basis during the first day of work and at least
daily thereafter as part of the machines generalmaintenance procedure.
CAUTION: DO NOT OVER TORQUE HYDRAULIC FITTINGS AND HOSES
TORQUE SETTINGS FOR HYDRAULIC FITTINGS
HYDRAULIC HOSE ENDS PORT ADAPTORS WITH BONDED SEALS
BSP
Setting
Metric
BSP
Setting
Metric
1/4” 18 Nm 19 mm 1/4” 34 Nm 19 mm
3/8” 31 Nm 22 mm 3/8” 47 Nm 22 mm
1/2” 49 Nm 27 mm 1/2” 102 Nm 27 mm
5/8” 60 Nm 30 mm 5/8” 122 Nm 30 mm
3/4” 80 Nm 32 mm 3/4” 149 Nm 32 mm
1” 125 Nm 41 mm 1” 203 Nm 41 mm
1.1/4”
190 Nm
50 mm
1.1/4”
305 Nm
50 mm
1.1/2” 250 Nm 55 mm 1.1/2” 305 Nm 55 mm
2” 420 Nm 70 mm 2” 400 Nm 70 mm

Warranty Policy (page 1 of 3)
WARRANTY POLICY
WARRANTY REGISTRATION
All machines must be registered, by the selling dealer with McConnel Ltd, before delivery to the end user.
On receipt of the goods it is the buyer’s responsibility to check that the Verification of Warranty
Registration in the Operator’s Manual has been completed by the selling dealer.
1. LIMITED WARRANTIES
1.01. All mounted machines supplied by McConnel Ltd are warranted to be free from defects in material
and workmanship from the date of sale to the original purchaser for a period of 12 months, unless a
different period is specified.
All Self Propelled Machines supplied by McConnel Ltd are warranted to be free from defects in
material and workmanship from the date of sale to the original purchaser for a period of 12 months
or 1500 hours. Engine warranty will be specific to the Manufacturer of that unit.
1.02. All spare parts supplied by McConnel Ltd and purchased by the end user are warranted to be free from
defects in material and workmanship from the date of sale to the original purchaser for a period of 6
months. All parts warranty claims must be supported by a copy of the failed part invoice to the end
user. We cannot consider claims for which sales invoices are not available.
1.03. The warranty offered by McConnel Ltd is limited to the making good by repair or replacement for the
purchaser any part or parts found, upon examination at its factory, to be defective under normal use
and service due to defects in material or workmanship. Returned parts must be complete and
unexamined. Pack the component(s) carefully so that any transit damage is avoided. All ports on
hydraulic items should be drained of oil and securely plugged to prevent seepage and foreign body
ingress. Certain other components, electrical items for example, may require particular care when
packing to avoid damage in transit.
1.04. This warranty does not extend to any product from which McConnel Ltd’s serial number plate has
been removed or altered.
1.05. The warranty policy is valid for machines registered in line with the terms and conditions detailed and
on the basis that the machines do not extend a period of 24 months or greater since their original
purchase date, that is the original invoice date from McConnel Limited.
Machines that are held in stock for more than 24 months cannot be registered for warranty.
1.06. This warranty does not apply to any part of the goods, which has been subjected to improper or
abnormal use, negligence, alteration, modification, fitment of non-genuine parts, accident damage,
or damage resulting from contact with overhead power lines, damage caused by foreign objects (e.g.
stones, iron, material other than vegetation), failure due to lack of maintenance, use of incorrect oil or
lubricants, contamination of the oil, or which has served its normal life. This warranty does not apply
to any expendable items such as blades, belts, clutch linings, filter elements, flails, flap kits, skids, soil
engaging parts, shields, guards, wear pads, pneumatic tyres or tracks.
1.07. Temporary repairs and consequential loss - i.e. oil, downtime and associated parts are specifically
excluded from the warranty.
1.08. Warranty on hoses is limited to 12 months and does not include hoses which have suffered external
damage. Only complete hoses may be returned under warranty, any which have been cut or repaired
will be rejected.
1.09. Machines must be repaired immediately a problem arises. Continued use of the machine after a
problem has occurred can result in further component failures, for which McConnel Ltd cannot be held
liable, and may have safety implications.
1.10. If in exceptional circumstances a non McConnel Ltd part is used to effect a repair, warranty
reimbursement will be at no more than McConnel Ltd’s standard dealer cost for the genuine part.

Warranty Policy (page 2 of 3)
1.11. Except as provided herein, no employee, agent, dealer or other person is authorised to give any
warranties of any nature on behalf of McConnel Ltd.
1.12. For machine warranty periods in excess of 12 months the following additional exclusions shall apply:
1.12.1. Hoses, exposed pipes and hydraulic tank breathers.
1.12.2. Filters.
1.12.3. Rubber mountings.
1.12.4. External electric wiring.
1.12.5. Bearings and seals
1.12.6. External Cables, Linkages
1.12.7. Loose/Corroded Connections, Light Units, LED’s
1.12.8. Comfort items such as Operator Seat, Ventilation, Audio Equipment
1.13. All service work, particularly filter changes, must be carried out in accordance with the manufacturer’s
service schedule. Failure to comply will invalidate the warranty. In the event of a claim, proof of the
service work being carried out may be required.
1.14. Repeat or additional repairs resulting from incorrect diagnosis or poor quality previous repair work
are excluded from warranty.
NB Warranty cover will be invalid if any non-genuine parts have been fitted or used. Use of non-genuine
parts may seriously affect the machine’s performance and safety. McConnel Ltd cannot be held
responsible for any failures or safety implications that arise due to the use of non-genuine parts.
2. REMEDIES AND PROCEDURES
2.01. The warranty is not effective unless the Selling Dealer registers the machine, via the McConnel web
site and confirms the registration to the purchaser by completing the confirmation form in the
operator’s manual.
2.02. Any fault must be reported to an authorised McConnel Ltd dealer as soon as it occurs. Continued use
of a machine, after a fault has occurred, can result in further component failure for which McConnel
Ltd cannot be held liable.
2.03. Repairs should be undertaken within two days of the failure. Claims submitted for repairs undertaken
more than 2 weeks after a failure has occurred, or 2 days after the parts were supplied will be
rejected, unless the delay has been authorised by McConnel Ltd. Please note that failure by the
customer to release the machine for repair will not be accepted as a reason for delay in repair or
submitting warranty claims.
2.04. All claims must be submitted, by an authorised McConnel Ltd Service Dealer, within 30 days of the
date of repair.
2.05. Following examination of the claim and parts, McConnel Ltd will pay, at their discretion, for any valid
claim the invoiced cost of any parts supplied by McConnel Ltd and appropriate labour and mileage
allowances if applicable.
2.06. The submission of a claim is not a guarantee of payment.
2.07. Any decision reached by McConnel Ltd. is final.
3. LIMITATION OF LIABILITY
3.01. McConnel Ltd disclaims any express (except as set forth herein) and implied warranties with respect to
the goods including, but not limited to, merchantability and fitness for a particular purpose.
3.02. McConnel Ltd makes no warranty as to the design, capability, capacity or suitability for use of the
goods.
3.03. Except as provided herein, McConnel Ltd shall have no liability or responsibility to the purchaser or
any other person or entity with respect to any liability, loss, or damage caused or alleged to be caused
directly or indirectly by the goods including, but not limited to, any indirect, special, consequential, or
incidental damages resulting from the use or operation of the goods or any breach of this warranty.
Notwithstanding the above limitations and warranties, the manufacturer’s liability hereunder for
damages incurred by the purchaser or others shall not exceed the price of the goods.
3.04. No action arising out of any claimed breach of this warranty or transactions under this warranty may
be brought more than one (1) year after the cause of the action has occurred.

Warranty Policy (page 3 of 3)
4. MISCELLANEOUS
4.01. McConnel Ltd may waive compliance with any of the terms of this limited warranty, but no waiver of
any terms shall be deemed to be a waiver of any other term.
4.02. If any provision of this limited warranty shall violate any applicable law and is held to be
unenforceable, then the invalidity of such provision shall not invalidate any other provisions herein.
4.03. Applicable law may provide rights and benefits to the purchaser in addition to those provided herein.
McConnel Limited

DECLARATION OF CONFORMITY
Conforming to EU Machinery Directive 2006/42/EC
We,
McCONNEL LIMITED, Temeside Works, Ludlow, Shropshire SY8 1JL, UK
Hereby declare that:
The Product; Tractor Mounted Yardscraper
Product Code; M402, M452
Serial No. & Date ………………………………… Type …………………………
Manufactured in; United Kingdom
Complies with the required provisions of the Machinery Directive 2006/42/EC
The machinery directive is supported by the following harmonized standards;
■BS EN ISO 12100 (2010) Safety of machinery –General principles for design –Risk
assessment and risk reduction.
■BS EN 349 (1993) + A1 (2008) Safety of machinery - Minimum distances to avoid the
entrapment with human body parts.
■BS EN ISO 14120 (2015) Safety of machinery - Guards general requirements for the
design and construction of fixed and movable guards.
■BS EN 4413 (2010) Hydraulic fluid power. Safety requirements for systems and their
components.
McCONNEL LIMITED operates an ISO 9001:2008 quality management system,
certificate number: FM25970.
This system is continually assessed by the;
British Standards Institution (BSI), Beech House, Milton Keynes, MK14 6ES, UK
BSI is accredited by UK Accreditation Service, accreditation number: UKAS 003.
The EC declaration only applies if the machine stated above is used in
accordance with the operating instructions.
Signed …………………................ Responsible Person
CHRISTIAN DAVIES on behalf of McCONNEL LIMITED
Status: General Manager Date: January 2018

THIS MANUAL MUST BE HANDED TO THE CUSTOMER
BEFORE THE MACHINE IS USED FOR THE FIRST TIME
McCONNEL LIMITED
TEMESIDE WORKS
LUDLOW
SHROPSHIRE
SY8 1ND
TELEPHONE:
01584 873131
All dimensions and capacities mentioned in this book are approximate. In pursuance of the
Companies policy of constant development, the right is reserved to depart, without notice,
from any detail illustrated or specified in this book, without incurring the obligation to
provide such modifications on machines previously delivered.
No responsibility will be accepted by McConnel Limited for any injury, damage or loss
arising from the improper use or lack of maintenance of any machinery supplied by them
or from any failure of the user to comply with all instructions published by Tractor or
Loader manufacturers, particularly with regard to maximum load capacities, tyre pressures
and stability, or with instructions and regulations pertaining to Tractor Cabs.

LIST OF CONTENTS
Operator Section
General Information
1
Machine Description & Purpose of Use
2
Machine Identification
2
Technical Specifications
2
Safety Information
3
Vehicle / Tractor Preparation
5
General Instructions
6
Handling & Transportation
7
Set Up Instructions
8
Maintenance
9
Parts Section
Yardscraper M402G
11
Yardscraper M452G
13

1
GENERAL INFORMATION
Read this manual before fitting or operating the machine. Whenever any doubt exists
contact your dealer or the McConnel Service Department for assistance.
Use only ‘McConnel Genuine Parts’ on McConnel Equipment and Machinery
DEFINITIONS - The following definitions apply throughout this manual:
WARNING:
An operating procedure, technique etc., which can result in personal injury or loss of life if
not observed carefully.
CAUTION:
An operating procedure, technique etc., which can result in the damage of either machine
or equipment if not observed carefully.
NOTE:
An operating procedure, technique etc., which is considered essential to emphasise.
LEFT AND RIGHT HAND:
This term is applicable to the machine when fitted to the tractor and viewed from the rear.
This also applies to tractor references.
Note: The illustrations in this manual are for instructional purposes only and may on occasion not
show some components in their entirety. In some instances an illustration may appear slightly
different to that of your particular model but the general procedure will be the same. E&OE.
MACHINE & DEALER INFORMATION
Record the Serial Number of your machine on this page and always quote this number when
ordering parts. Whenever information concerning the machine is requested remember also to state
the make and model of tractor to which the machine is fitted.
Machine Serial Number:
Installation Date:
Machine Model details:
Dealer Name:
Dealer Address:
Dealer Telephone No:
Dealer Email Address:

2
Machine Identification Plate
MACHINE DESCRIPTION & PURPOSE OF USE
These machines which are commonly known throughout the agricultural industry as
Yardscrapers are intended for use attached to an agricultural vehicle by means of the
‘three-point linkage’ couple up system; a quick hitch attachment is available as an extra.
The machines, which have robust frames and hardwearing rubber blades, are designed for
the sole purpose of scraping yards and lanes that have a reasonably flat surface.
These machines should only be used to perform tasks for which they were designed –use
of the machine for any other function may be both dangerous to persons and damaging to
components and is therefore not advisable.
MACHINE IDENTIFICATION
Each machine is fitted with an identification plate with the following information:
1. Machine (Part Number)
2. Machine Serial No.
3. Machine Weight
When ordering spares or replacement parts from
your local dealer it is important to quote both Part
Number and Serial Number as stated on the
identification plate so the machine and model can
be quickly and correctly identified.
TECHNICAL SPECIFICATIONS
SPECIFICATION
M402
M452
Attachment
3-point linkage
3-point linkage
Scraping Width (Min.)
1.83m (72”)
1.92m (76”)
Scraping Width (Max.)
2.13m (84”)
2.13m (84”)
Reversible Swing Wings
no
no
Flip-over Profiled Rubber
yes
yes
Load Carrying Facility
no
no
Machine Weight (Approx.)
186kg
210kg

3
SAFETY INFORMATION
General safety rules:
▲Always read and follow the instructions for the use and maintenance of the machine
before carrying out any work operations or servicing tasks.
▲Improper use of the machine is both highly dangerous to persons and damaging to the
machine components –only use the machine for its designated task.
▲Both operators and the maintenance fitters should be familiar with the machine and
fully aware of dangers surrounding improper use or incorrect repairs.
▲Before starting, checks to both tractor and machine must be carried out as regards:
functionality, road safety, accident prevention rules.
▲When using the machine all bystanders and onlookers should be kept at a safe
distance from the tractor and machine. Special attention must be paid when working in
or near buildings.
▲Use tractor’s fitted with safety cabs.
▲The condition of the machine must be checked before use –do not use the machine if
components are missing or damaged.
▲During checks or repairs, make sure nobody could start the machine by mistake.
▲Never wear loose or fluttering clothes when operating machines.
▲Never carry passengers on the tractor.
▲Never carry passengers on the machine.
▲Never connect the power takeoff with the engine running.
▲Never leave the tractor seat whilst the engine or machine is running.
▲Do not enter the working zone of the tractors PTO shaft.
▲Keep the PTO shaft guard in good condition.
▲Before starting, check the surrounding area for the likely presence of children and/or
animals.
▲Do not stand near, or approach, the machine when it is raised or operating.
▲The PTO shaft of a tractor must be assembled and disassembled only with the engine
stopped and the starting key removed.
▲Before connecting the power takeoff, check that the speed and the rotational direction
correspond to those of the machine.
▲Immediately replace missing or damaged safety decals.
Transportation Safety
▲In transport, reduce speed, especially on bumpy roads, the weight of the machine may
render driving difficult and damage the machine itself.
▲Ensure the levers that operate the hydraulic lift are locked, to avoid the lowering of the
machine during transport.
▲When driving on public roads, respect all road rules in force.

4
Operating Safety
▲Pay special attention when working with the machine not to touch fixed objects such as
drains, walls, kerbs, guard rails, tracks etc.
▲Always lower the machine to rest on the ground when not in use.
▲Always ensure the machine is safely supported before attempting to carry out repairs
or maintenance. Never work on a machine that is raised or unsupported.
Although the information given here covers a wide range of safety subjects, it is impossible to
predict every eventuality that can occur under differing circumstances whilst operating this machine.
No advice given here can replace ‘good common sense’ and ‘total awareness’ at all times, but will go
a long way towards the safe use of your McConnel machine.

5
VEHICLE / TRACTOR PREPARATION
We recommend vehicles are fitted with
cabs using ‘safety glass’ windows and
protective guarding when used with our
machines.
Fit Operator Guard (part no. 7313324)
using the hooks provided. Shape the
mesh to cover all vulnerable areas.
Remember the driver must be looking
through mesh and/or polycarbonate
glazing when viewing the machine in all positions - unless the vehicle/ cab manufacturer
can demonstrate that the penetration resistance is equivalent to, or higher than, that
provided by mesh/polycarbonate glazing. If the tractor has a roll bar only, a frame must be
made to carry both mesh and polycarbonate glazing. The operator should also use
personal protective equipment to reduce the risk of serious injury such as; eye protection
(mesh visor to EN1731 or safety glasses to EN166), hearing protection to EN352, safety
helmet to EN297, gloves, filter mask and high visibility clothing.
Vehicle Ballast
It is imperative when attaching ‘third-party’ equipment to a vehicle that the maximum
possible stability of the machine and vehicle combination is achieved –this can be
accomplished by the utilisation of ‘ballast’ in order to counter-balance the additional
equipment added.
Front weights may be required for rear mounted machines to place 15% of total outfit
weight on the front axle for stable transport on the road and to reduce ‘crabbing’ due to the
drag when working.
Where a machine works to the side of the tractor rear weights may be required to maintain
a reasonable amount of rear axle load on the opposing wheel.
All factors must be addressed in order to match the type and nature of the equipment
added to the circumstances under which it will be used - factors that effect stability are:
Centre of gravity of the tractor/machine combination.
Geometric conditions, e.g. position of the cutting head and ballast.
Weight, track width and wheelbase of the tractor.
Acceleration, braking, turning and the relative position of the cutting unit during these
operations.
Ground conditions, e.g. slope, grip, load capability of the soil/surface.
Rigidity of implement mounting.
Suggestions to increase stability:
Increasing rear wheel track - a vehicle with a wider wheel track is more stable.
Ballasting the wheel; it is preferable to use external weights but liquid can be added to
around 75% of the tyre volume –water with anti-freeze or the heavier Calcium Chloride
alternative can be used.
Addition of weights –care should be taken in selecting the location of the weights to
ensure they are added to a position that offers the greatest advantage.
Front axle locking, check with tractor manufacturer.
The advice above is offered as a guide for stability only and is not a guide to vehicle strength. It is
therefore recommended that you consult your vehicle manufacturer or local dealer to obtain specific
advice on this subject, additionally advice should be sought from a tyre specialist with regard to tyre
pressures and ratings suitable for the type and nature of the machine you intend to fit.

6
GENERAL INSTRUCTIONS
1. Attachment of the machine to the tractor should always be performed on a firm level
site.
2. Before and during the maneuvering of the tractor to attach machinery or implements,
make sure that no other persons are in the vicinity. Keep other persons well clear and
make known your intentions, all the while keeping a sharp lookout whilst reversing and
aligning the machines for coupling up.
3. Ensure tractor brakes are applied correctly to prevent the vehicle from moving.
4. Ensure that the lift arms and top link ball ends of the tractor are properly fitted to the
machine or implement using the correct adapter sleeves where necessary, and that
retaining pins of the correct type are used on all three-point linkage points. Secure pins
with the relevant pin and ring assembly.
5. Should it become necessary to make any adjustments or service the machine while
raised on the tractor linkage or front end loader, trestles or suitable supports must be
positioned to support machine to prevent accidental dropping of lift arms or mechanical
failure.
MACHINES MUST ALWAYS BE PROPPED AND CHOCKED.
6. Never attempt to work on, adjust, service or repair machinery of any kind whilst it is still
running or working. Always stop the machine and STOP THE TRACTOR ENGINE
before making adjustments or repairs.
SWITCH OFF THE TRACTOR ENGINE BEFORE LEAVING THE TRACTOR SEAT
7. Always use machines in a sensible and reasonable manner and do not attempt to use
them for work for which they are not intended. Avoid overloading and abusing them as
this can cause damage to machine and tractor and can be very dangerous.
8. When detaching a machine ensure that any stands or legs are securely positioned. The
machine must be parked where it will not be a safety hazard or cause annoyance to
others. Make sure that chosen parking site is firm and level.
9. Carry out regular periodic maintenance, always with safety in mind.
10.Ensure regular maintenance procedures are maintained for the lifetime of the machine.
HEALTH AND SAFETY RULES AND REGULATIONS MUST BE ADHERED TO IN ALL
AGRICULTURAL RESPECTS.

7
HANDLING & TRANSPORTATION OF THE MACHINE
Suitable overhead lifting gear should be used to move or handle this machine safely. The
machine can be attached to the lifting gear using a chain, rope or lifting strap providing it is
of sufficient strength to support a weight in excess of the machines total weight. Lifting
tackle should be securely attached to the correct lifting point on the machine as indicated
in the photo below.
When raising and moving machinery ensure bystanders are kept clear of the machine at
all times. Once the machine has been moved make sure that it comes to rest in a safe
position and location, supports or stay bars may be necessary to ensure stability of the
machinery. Always use supports or stay bars whenever the machine is transported.

8
M402 & M452 YARDSCRAPERS –‘SETTING UP’ INSTRUCTIONS
1. Attachment of the tractor to the machine should be performed on a firm level site.
2. Connect machine to three-point linkage of the tractor and couple up in the conventional
manner using the correct link pins, spacers and linch pins.
3. Adjust ‘top link assembly’ length to a setting that positions the ‘A’ frame vertical to the
ground –see illustration below.
4. Ensure scraper is sitting level on the ground (widthways) by adjusting leveling box on
rear tractor linkage arm to suit.
5. The adjusting screws for setting main lower scraping section in relation to the
headstock should now be checked and set. Adjustment screws are located on both
sides of the headstock assembly.
6. Adjust the pair of rear screws ‘downwards’ to raise the front edge of the rubber until a
dimension of 25mm (1”) is reached at the leading edge of the rubber on both sides
(refer below), lock adjustment screws in position by tightening the locknuts.

9
7. Swing the base scraping section up and over through 180°, this will now put the
machine into rear scraping mode, repeat the previous adjustment procedure to the
same dimensions, but this time using the front pair of adjustment screws (refer below).
Once completed the machine will be set for both forward and reverse scraping, no
further adjustment should be required providing the tractor and top link length remain
constant.
ROUTINE MAINTENANCE & LAYING UP
Weekly Maintenance Tasks
Grease pivot points and catch plunger.
(Do not over grease plunger as this will impair it’s movement).
Check all nuts and bolts for tightness.
Pre-storage Maintenance Tasks
Clean machine thoroughly and note any damage or repairs
needed, arrange for spares or repairs as required so the
machine is fully prepared for the next seasons work.
Lubricate the machine fully.
Store the machine in a safe, dry location protected from the
elements.

10
YARDSCRAPERS
Models: M402G & M452G
Parts Manual
